Your vehicle’s tires have wear
indicators molded into the tread.
When the tread wears down to that
point, you will see a 1/2 inch (12.7
mm) wide band running across the
tread. This shows there is less than
1/16 inch (1.6 mm) of tread lef t on
the tire. A tire that is this worn gives
very little traction on wet roads. You
should replace the tire if you can see
the tread wear indicator in three or
more places around the tire.In addition to proper inf lation,
correct wheel alignment helps to
decrease tire wear. If you f ind a tire
is worn unevenly, have your dealer
check the wheel alignment.
Have your dealer check the tires if
you f eel a consistent vibration while
driving. A tire should always be
rebalanced if it is removed f rom the
wheel. When you have new tires
installed, make sure they are
balanced. This increases riding
comf ort and tire lif e. For best results,
have the installer perform a dynamic
balance.
To help increase tire lif e and
distribute wear more evenly, rotate
the tires according to the
maintenance messages displayed on
the multi-information display. Move
the tires to the positions shown in
the illustration each time they are
rotated. If you purchase directional
tires, rotate only front-to-back.
T ire Maintenance
T ire Rotation
Tires
Maint enance
305
INDICATOR LOCATION MARKS
TREAD WEAR INDICATOR Front
Front
(For Non-directional
Tires and Wheels) (For Directional
Tires and Wheels)
Improper wheel weights can damage
your vehicle’s aluminum wheels. Use
only Acura wheel weights f or balancing.
——
y
y
(%y
y

If the indicator comes on repeatedly,
even though it may go off as you
continue driving, have the vehicle
checked by your dealer as soon as
possible.
If
this indicator comes on
while driving, it means one
of the engine’s emissions control
systems may have a problem. Even
though you may feel no difference in
your vehicle’s performance, it can
reduce your fuel economy and cause
increased emissions. Continued
operation may cause serious damage.
Your vehicle has certain ‘‘readiness
codes’’ that are part of the on-board
diagnostics for the emissions
systems. In some states, part of the
emissions testing is to make sure
these codes are set. If they are not
set, the test cannot be completed. To
check if they are set, turn the
ignition switch to the ON (II)
position, without starting the engine.
The malfunction indicator lamp will
come on for 20 seconds. If it then
goes off, the readiness codes are set.
If it blinks five times, the readiness
codes are not set. If possible, do not
take your vehicle for a state
emissions test until the readiness
codes are set. Refer to
for more
info rmation (see page ).
If
you have recently refueled your
vehicle, the indicator coming on
could be due to a loose or missing
fu el fill cap. You will also see a
‘‘TIGHTEN FUEL CAP’’ message on
the multi-information display.
Tighten the cap until it clicks at least
once (see page ). Tightening the
cap will not turn the indicator of f
immediately; it can take several days
of normal driving. If your vehicle’s battery has been
disconnected or gone dead, these
codes are erased. It can take several
days of driving under various
conditions to set the codes again.
348
236
Malf unction Indicator L amp
Readiness Code
State
Emissions T estingT aking Care of t he Unexpect ed
325
If you keep driving with the
malf unction indicator lamp on, you can
damage your vehicle’s emissions
controls and engine. Those repairs may
not be covered by your vehicle’s
warranties.
——
y

y
(%yy

Check the smaller fuses in the
under-hood fuse box and all the
fuses in the interior fuse box by
pulling out each one with the fuse
puller pro vided in the under-hood
fuse box. If
the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem with your
vehicle. Leave the blown fuse in
that circuit, and have your vehicle
checked by a qualified technician.
If the radio fuse is removed, the
audio system will disable itself. The
nexttimeyouturnontheradioyou
will see ‘‘CODE’’ in the frequency
display. Use the preset buttons to
enter the f ive-digit code (see page ).
If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket or radio).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.
Look f or a blown wire inside the
f use. If it is blown, replace it with
oneof thesparefusesof thesame
rating or lower.
5. 6.
4. 182
Fuses
328
BLOWN
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper rating
f or the circuit, install one with a lower
rating.
——
y

y
(%yy

µ
Your vehicle has also been equipped
with a TPMS malf unction indicator
to indicate when the system is not
operating properly. The TPMS
malf unction indicator is provided by
a separate telltale, which displays the
symbol ‘‘TPMS’’ when illuminated.
When the malf unction indicator is
illuminated,
the system may not be able to detect
or signal low tire pressure as
intended.
TPMS malf unctions may occur f or a
variety of reasons, including the
installation of replacement or
alternate tires or wheels on the
vehicle that prevent the TPMS f rom
f unctioning properly.Always check the TPMS malf unction
telltale af ter replacing one or more
tires or wheels on your vehicle to
ensure that the replacement or
alternate tires and wheels allow the
TPMS to continue to f unction
properly.
Tire Pressure Monitoring System (TPMS) Required Federal Explanation
344
——
y
y
(%yy

CONT INUED
..................................................
Keys .92
...............
Keyless Memory Setting . 76
.......................
Label, Certif ication .336
.................
Lane Change, Signaling . 86
........................
Lap/Shoulder Belts .19
Lights ....................
Bulb Replacement .293
.......................................
Indicator .58
.........................................
Parking .86
..................................
Turn Signal .86
.....................................
Load Limit .243
......
LOCK (Ignition Key Position) . 95
........................
Lockout Prevention .96
Locks .......
Anti-thef t Steering Column . 95
..................................
Glove Box .121
.................................
Power Door .96
...........................................
Trunk .97
........................
Low Coolant Level .239
...
Low Oil Pressure Indicator . 59, 324
...
Lubricant Specif ications Chart . 338...........
Luggage, Storing (Cargo) . 243
..................................
Maintenance .271
........................................
Minder .273
...
Owner Maintenance Checks . 277
........................................
Record .279
..........................................
Saf ety .272
Malf unction Indicator ....................................
Lamp . 59, 325
...................
Manual Transmission . 250
........
Manual Transmission Fluid . 290
...........
Memory, Driving Position . 108
...............................
Meters, Gauges .65
........................
Mirrors, Adjusting .106
...............
Modif ying Your Vehicle . 241
.......................................
Moonroof .116
.............
Multi-Inf ormation Display . 66
............................
Engine Oil Lif e .72
...........................
HandsFreeLink .73
.........
Keyless Memory Settings . 76
................
Maintenance Minder . 273
.....................................
Odometer .70
.................
Outside Temperature . 71
............................
Trip Computer .73 ...................................
Trip Meter .70
...................
Neutral Gear Position . 254
..................
New Vehicle Break-in . 234
...................
NOTICE, Explanation of . i
...............
Numbers, Identif ication . 336
...
Octane Requirement, Gasoline . 234
.........................................
Odometer .70
...............................
Odometer, Trip .70
Oil ........................
Change, How to .284
......................
Change, When to .273
......................
Checking Engine .238
..............
Pressure Indicator . 51, 324
Selecting Proper Viscosity ......................................
Chart .283
...........
ON (Ignition Key Position) . 95
Onboard Ref ueling Vapor ....................................
Recovery .345
