The ignition switch must be in the
ACCESSORY (I) or the ON (II)
position. Make sure the open side of
thetapeisfacingright,theninsert
thetapemostof thewayintotheslot.
Thesystemwillpullthetapeinthe
rest of the way and begin to play it.
Thetapedirectionindicatorinthe
display comes on to show you which
side of the tape is playing. The
indicates the side you inserted
upward is now playing. If you want to
play the other side, press the PLAY/
PROG (preset 2) button. When the
player reaches the end of the tape, it
will automatically reverse direction
and play the other side.
Audio System (Models without Navigation System)
Playing a T ape
152
EJECT BUTTON
SEEK BUTTONS
REWIND BUTTON DOLBY BUTTON
PLAY/PROGRAM BUTTON
DISC/TAPE
BUTTON
AM/FM
BUTTON
PWR/VOL KNOB
REPEAT BUTTON
FAST FORWARD BUTTON
——
y

y
(%y
y

ÃŽ
ÃŽ
µ
µµ ´
µ
Dolby noise reduction turns on
when you insert a tape. The
indicator will come on in the
display. If the tape was not recorded
in Dolby, turn it of f by pressing the (preset 4) button. Dolby
remains of f until you press the
button again. To remove the tape, press the eject
button. If you want to turn the player
of f , press the power/volume knob or
turn off the ignition. The tape will
remain in the drive. When you turn
the system back on, the tape will
begin playing where it lef t of f . To rewind the tape,
push the (preset 1) button. You
will see REW in the display. To f ast
f orward the tape, push the (preset 3) button. You will see
FF displayed. Press the , ,
or PLAY/PROG button to take the
system out of rewind or f ast f orward.
Press the SEEK button
to f ind the beginning of the current
song or passage. Press the SEEK
button to f ind the beginning of the
next song or passage. When the
system reaches the beginning of a
song or passage, it begins to play it.
Press the RPT button
to continuously play a song or
passage. You will see RPT displayed.
The track will repeat until you press
the RPT button again.
To switch to the AM/FM radio, XM
Radio, or disc changer while a tape is
playing, press the AM/FM button,
XM button, or DISC/TAPE button.
To change back to the tape player,
press the DISC/TAPE button.
Dolby noise reduction is manufactured under
license from Dolby Laboratories Licensing
Corporation. ‘‘DOLBY’’ and the double-D symbol are trademarks of Dolby Laboratories
Licensing Corporation.
CONT INUED
T o Stop Playing a T ape T ape Search Functions
FF/REW
SK IP
REPEAT
Audio System (Models without Navigation System)
Features
153
——
y
y
(%y
y

µ
µ ´µ µ
The ignition switch must be in the
ACCESSORY (I) or ON (II) position.
Turn the system on by pushing the
power/volume knob or the AM/FM
button. Adjust the volume by turning
the power/volume knob. You can use any of f ive methods to
f ind radio stations on the selected
band: tune, seek, scan, the preset
buttons, and auto select.
Use the TUNE knob to
tune the radio to a desired f requency.
Turn the knob to the right to tune a
higher f requency, and turn it to the
lef t to tune a lower f requency.
You can also operate the audio
system using the control icons on the
audio screen.
The band and f requency that the
radio was last tuned to are displayed.
To change bands, press the AM/FM
button. On the FM band, STEREO
will be displayed on the audio screen
if the station is broadcasting in
stereo. Stereo reproduction in AM is
not available. The seek f unction
searches up and down from the
current f requency to f ind a station
with a strong signal. To activate it,
press the or SEEK button, then
release it. The scan f unction samples
all stations with strong signals on the
selected band. To activate it, press
the SCAN button, then release it.
You will see SCAN in the display.
The system will scan f or a station
with a strong signal. When it f inds
one, it will stop and play that station
f or about 10 seconds.
If you do nothing, the system will
scan f or the next strong station and
play it f or 10 seconds. When it plays
a station that you want to listen to,
press the SCAN button again.
TUNE
SEEK SCAN
Playing the A M/FM Radio Selecting a Station
Audio System (Models with Navigation System)
156
——
y
y
(%y

y

µµEach preset button can
store one frequency on AM and two
frequencies on FM.
Select the desired band, AM or
FM. FM1 and FM2 let you store
two frequencies with each preset
button.
Usethetune,seek,orscan
function to tune the radio to a
desired station. If
you are
traveling far from home and can no
longer receive your preset stations,
you can use the auto select feature to
find stations in the local area.
Press the A. SEL button. You will see
A. SEL flashing in the display, and
the system goes into scan mode for
several seconds. It stores the
frequencies of six AM, and twelve
FM stations in the preset buttons.
You will see a ‘‘0’’ displayed after
pressing a preset button if auto
select cannot find a strong station for
every preset button. If
you do not like the stations auto
select has stored, you can store
other f requencies on the preset
buttons as previously described.
For inf ormation on AM/FM radio
f requencies and reception, see page . press the
A. SEL button. This restores the
presets you originally set.
Pick a preset button, and hold it
until you hear a beep.
Repeat steps 1 through 3 to store a
total of six stations on AM and
twelve stations on FM.
Each preset button’s f requency is
shown on the bottom of the audio
display. 1.
2.
3.
4. 178
To turn of f auto select,
Preset
A UT O SEL ECT
Audio System (Models with Navigation System)
Features
157
——
y

y
(%y
y

µµ´
µ µ
µ
µ´ µ
µ
ÃŽ
ÃŽ
Bass, treble, lef t/right balance, and
front/rear fader are each adjustable.
In addition, you can adjust the
strength of the sound coming f rom
the center and the subwoofer
speakers.
To adjust them, enter the sound grid
by touching the SOUND icon on the
display or pressing the TUNE/
SOUND knob. To adjust the treble
andbass,touch or icononeach
side of the treble or bass adjustment
bar, or tune the TUNE/SOUND
knob.
Adjusts the side-to-side
strength of the sound.
To adjust the left/right balance,
touch the L or R icon. Adjusts the front-to-back
strength of the sound.
To adjust the front/rear fader, touch
theFRorRRicon.
To adjust the
strength of the sound coming f rom
the center or subwoof er speaker,
touch the or icon on each side
of the center or subwoof er
adjustment bar. The SVC mode
controls the volume based on vehicle
speed. The f aster you go, the louder
the audio volume becomes. As you
slow down, the audio volume
decreases. Touch the appropriate
icon (Low, Mid, Hi, Of f ) to select the
mode. Dolby
PL (ProLogic) II signal processing
creates multi-channel surround
sound f rom the audio signal
recorded with two channel stereo
sources. Dolby ProLogic II can only
activate when using the CD (CD-DA,
MP3/WMA),XMradio,andAUX
audio modes. When it activates,
‘‘DPL2’’ is shown on the upper
display. To turn this feature on or off,
touch the On or Of f icon. Manuf actured under license f rom
Dolby Laboratories. ‘‘Dolby’’,
‘‘ProLogic’’, and the double-D symbol
are trademarks of Dolby
Laboratories.
Adjusting the Sound
Treble/Bass
Balance
Fader
Center/Subwoof erSVC (speed-sensitive volume
compensation)
Dolby PL (ProL ogic) II
Audio System (Models with Navigation System)
158
——
y

y
(%y
y

Your audio system is capable of
receiving XM
Satellite Radio
anywhere in the United States,
except Hawaii and Alaska. XM
Satellite Radio is also available on
Canadian models.
XM radio receives signals f rom two
satellites to produce clear, high-
quality digital reception. It of f ers
many channels in several categories.
Along with a large selection of
dif f erent types of music, XM radio
allows you to view channel and
category selections in the display. XM
is a registered trademark of
XM Satellite Radio, Inc.
Audio System (Models with Navigation System)
Playing the XMSatellite Radio
Features
159
SCAN BUTTON
PWR/VOL KNOB PRESET BUTTONS TUNE KNOB
MODE ICON
AUDIO BUTTONSCAN ICON
CATEGORY
BUTTONS
XM RADIO
BUTTON
DIS/MODE
BUTTON
——
y
y
(%y
y

µµÓÓµ
µ´
To listen to XM radio, turn the
ignition switch to the ACCESSORY
(I) or the ON (II) position. Push the
power/volume knob to turn on the
audio system, and press the ‘‘XM’’
button. Adjust the volume by turning
the knob. The last channel you
listened to will show in the display. To switch between the
channel mode and the category
mode,pressandholdtheDISP/
MODE button until the mode
changes, or touch the MODE icon
on the audio display.
In the channel mode, you can select
all of the available channels. In the
category mode, such as Jazz, Rock,
Classical, etc., you can select all of
the channels within that category.
Each time you press and release the
DISP/MODE button, the display
changes in the f ollowing sequence:
channel name, channel number,
category, artist name, and music title. You may experience periods when
XM Radio does not transmit the
artist’s name and song title
inf ormation. If this happens, there is
nothing wrong with your system.
Turn the TUNE knob lef t
or right to select channels. In the
category mode, you can only select
channels within that category.
In any
mode, press either button to select
another category.
Operating the XM Radio
MODE
TUNE
CATEGORY ( or )
Audio System (Models with Navigation System)
160
——
y
y
(%y
y

µ
µ Youcanstoreupto12
preset channels using the six preset
buttons or preset icons. Each button
stores one channel f rom the XM1
band and one channel f rom the XM2
band.
In category mode, only channels
within that category can be selected.
In channel mode, all channels can be
selected. Use the TUNE knob, or the
CATEGORY or SCAN buttons to
tune to a desired channel.
To store a channel: Pick the preset button (icon) you
want f or that channel. Press and
hold the button (icon) until you
hear a beep.
Repeat steps 2 and 3 to store the
f irst six channels.
Press the XM button again. The
other XM band will show. Store
the next six channels using steps 2
and 3.
Once a channel is stored, simply
press and release the proper preset
button (icon) to tune to it.
Press the XM button. Either XM1
or XM2 will show in the display.
The scan f unction gives
you a sampling of all channels while
in the channel mode. In the category
mode, only the stations within that
category are scanned. To activate
scan, press the SCAN button or
touch the SCAN icon on the audio
display. The system plays each
channel in numerical order f or 10
seconds. When you hear a channel
you want to continue listening to,
press the SCAN button or touch the
icon again. 3.
4.
1.
2. 5.
Preset
SCAN
Audio System (Models with Navigation System)
Features
161
——
y
y
(%y
y

µ
µ
µ µ
µ
µ
µ
XM is loading the
audio or program inf ormation.
The channel
currently selected is no longer
broadcasting.
The encryption
code is being updated. Wait until the
encryption code is f ully updated.
Channels 0 and 1 should still work
normally. The signal is
currently too weak. Move the vehicle
to an area away from tall buildings,
and with an unobstructed view of the
southern horizon.
The selected channel
number does not exist or is not part
of your subscription.
There is a problem
with the XM antenna. Please consult
your dealer. The selected
channel has no artist or title
inf ormation at this time.
XM Radio Display Messages
‘‘L OA DING’’
‘‘OFF A IR’’
‘‘UPDA T ING’’
‘‘NO SIGNA L ’’
‘‘----’’
‘‘A NT ENNA ’’ ‘‘NO INFO’’
Audio System (Models with Navigation System)
162
——
y

y
(%y
y

Depending on where you drive, you
may experience reception problems.
Interf erence can be caused by any of
these conditions:Driving on the north side of a
large commercial truck on an
east/west road.
Driving in tunnels.
Driving on a road beside a vertical
wall, steep clif f , or hill to the south
of you.
Driving on the lower level of a
multi-tiered road.
Driving on a single lane road
alongside dense trees taller than
50 ft. (15 m) to the south of you. If you decide to purchase XM
satellite radio service, contact XM
Radio at, or at
1-800-852-9696. You will need to give
them your radio I.D. number and
your credit card number. To get your
radio I.D. number, turn the TUNE knob until ‘‘0’’ appears in the display.
Your I.D. will appear in the display.
There may be other geographic
situations that could af f ect XM radio
reception. Driving on the north side of an
east/west mountain road.
While waiting f or activation, make
sure your vehicle remains in an open
area with good reception. Once your
audio system is activated, you should
be able to listen to XM radio
broadcasts. XM Radio will continue
to send an activation signal to your
vehicle for at least 12 hours from the
activation request. If the service has
not been activated after 36 hours,
contact XM Radio.
If your XM Radio service has expired
or you purchased your vehicle f rom
a previous owner, you can listen to a
sampling of the broadcasts available
on XM Satellite Radio. With the
ignition switch in the ACCESSORY
(I) or ON (II) position, push the
power/volume knob to turn on the
audio system and press the XM
RADIO button. A variety of music
types and styles will play. After you’ve registered with XM
Radio, keep your audio system in the
Satellite Radio mode while you wait
f or activation. This should take about
30 minutes.As required by the FCC:
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
www.xmradio.com
Receiving Satellite Radio Service
Audio System (Models with Navigation System)
164
——
y

y
(%y
y
