Acura TL 2011 Owner's Manual

Use the compact spare tire as a
temporary replacement only. Get
your regular tire repaired or replaced,
and put it back on your vehicle as
soon as you can.
Check the air pressure of the
compact spare tire every time you
check the other tires. It should be
inf lated to:Replace the tire when you can see
the tread wear indicator bars. The
replacement tire should be the same
sizeanddesign,mountedonthe
same wheel. The spare tire is not
designed to be mounted on a regular
wheel, and the spare wheel is not
designed f or mounting a regular tire.
Follow these precautions:
Never exceed 50 mph (80 km/h).
This tire gives a harsher ride and
less traction on some road
surf aces. Use greater caution
while driving. Do not mount snow chains on the
compact spare tire.
Do not use your compact spare
tire on another vehicle unless it is
thesamemakeandmodel.
After the flat tire is replaced with
the spare tire, the low tire
pressure/TPMS indicator stays on.
Af ter several miles (kilometers)
driving with the spare, this
indicator begins to f lash, then
stays on again. You will also see a
‘‘CHECK TPMS SYSTEM’’
message on the multi-inf ormation
display (see page ).
491
Compact Spare Tire
548
INDICATOR LOCATION MARK
TREAD WEAR INDICATOR BAR
60 psi (420 kPa , 4.2 kgf/cm)
10/07/29 12:52:16 31TK4620_553
2011 TL

Î
Î
CONT INUED
If you have a f lat tire while driving,
pull over saf ely. Drive slowly along
the shoulder until you get to an area
far away from traffic lanes.Park the vehicle on f irm, level, and
non-slippery ground. Put the
transmission in Park (automatic)
or reverse (manual). Apply the
parking brake.
Turn on the hazard warning lights,
and turn the ignition switch to
the LOCK (0) position. Have all
passengers get out of the vehicle
while you change the tire.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. VEHICLE
OFF (LOCK) Mode is the
equivalent of LOCK (0). For
more inf ormation, see pages and . Open the trunk. Pull up the handle
on the trunk f loor lid. Raise the lid
by lif ting it up with the handle,
then hook the handle to the trunk
opening to keep the lid open.
3.
2. 1.
178 181
:
Changing a Flat Tire
T aking Care of t he Unexpect ed
549
HANDLE
The vehicle can easily roll off
the jack, seriously injuring
anyone underneath.
Follow the directions for
changing a tire exactly, and
never get under the vehicle
when it is supported only by the
jack.
10/07/29 12:52:24 31TK4620_554
2011 TL

Loosen each wheel nut 1/2 turn
with the wheel nut wrench.
Take the tool case out of the spare
tire.
Unscrew the wing bolt and take
the spare tire out of its well.
Take the jack out of the tool kit
case. Placethejackunderthejacking
point nearest the tire you need to
change. Turn the end bracket
clockwise until the top of the jack
contacts the jacking point. Make
sure the jacking point tab is
restinginthejacknotch.
7.
8.
6. 4.
5.
Changing a Flat Tire
550
WHEEL NUT WRENCH JACKING POINT
EXTENSION JACK
WHEEL NUT
WRENCH
10/07/29 12:52:32 31TK4620_555
2011 TL

CONT INUED
Bef ore mounting the spare tire,
wipe any dirt of f the mounting
surface of the wheel and hub with
a clean cloth. Wipe the hub
carefully;itmaybehotfrom
driving.
Remove the wheel nuts, then
remove the f lat tire. Handle the
wheel nuts caref ully; they may be
hot from driving. Place the flat tire
on the ground with the outside
surface facing up.
Use the extension and the wheel
nut wrench as shown to raise the
vehicle until the f lat tire is of f the
ground.
9.
10. 11.
Changing a Flat Tire
T aking Care of t he Unexpect ed
551
BRAKE HUB
WHEEL NUT WRENCH EXTENSION
10/07/29 12:52:39 31TK4620_556
2011 TL

Tighten the wheel nuts securely in
the same crisscross pattern. Have
the wheel nut torque checked at
the nearest automotive service
f acility.
Tighten the wheel nuts to:
Remove the center cap before
storing the f lat tire in the trunk
well.
Lower the vehicle to the ground,
and remove the jack.
Put on the spare tire. Put the
wheel nuts back on f inger-tight,
then tighten them in a crisscross
pattern with the wheel nut wrench
until the wheel is f irmly against
the hub. Do not try to tighten the
wheel nuts f ully.
12.
13.
14.
15.
Changing a Flat Tire
552
94 lbf·ft (127 N·m , 13 kgf·m)
10/07/29 12:52:47 31TK4620_557
2011 TL

Store the center cap in the trunk.
Make sure it does not get
scratched or damaged.
Unhookthehandlefromthetrunk
opening and lower the trunk f loor
lid, then close the trunk lid.
Your vehicle’s original tire has a
tire pressure monitoring system
sensor. To replace a tire, ref er to(see
page ). Store the jack and tools in the tool
kit case. Place the tool kit case in
the f lat tire.
To remove the spacer cone,
squeeze the tabs on the wing bolt
to disengage it f rom the center of
the spacer cone, then pull the bolt
downward.
To install the wing bolt to the
spacer cone, reverse this
procedure.
Securetheflattirebyscrewing
the wing bolt back into its hole.
Place the flat tire face down in the
spare tire well.
Remove the spacer cone f rom the
wing bolt, turn it over, and put it
back on the bolt.
18. 19.
20.
21.
17. 16.
492
Changing a Flat Tire
Changing a T ire with T PMS
T aking Care of t he Unexpect ed
553
SPACER CONE
TAB
SPACER CONE For compact
spare tireFor normal
tire
WING BOLT
Loose items can fly around the
interiorinacrashandcould
seriously injure the occupants.
Store the wheel, jack, and tools
securely before driving.
10/07/29 12:52:57 31TK4620_558
2011 TL

Check these things:
When you turn the ignition switch to
the START (III) position or on
models with keyless access system,
press the engine start/stop button to
set START Mode (see page ),
you do not hear the normal noise of
the engine trying to start. You may
hear a clicking sound, a series of
clicks, or nothing at all.
Diagnosing why the engine won’t
start f alls into two areas, depending
on what you hear when you turn the
ignition switch to the START (III)
position or on models with keyless
access system, press the engine
start/stop button to set START
Mode (see page ):
You can hear the starter motor
operating normally, or the starter
motor sounds like it is spinning
f aster than normal, but the engine
does not start up and run. You hear nothing, or almost
nothing. The engine’s starter
motor does not operate at all, or
operates very slowly. Check the transmission interlock.
If you have a manual transmission,
the clutch pedal must be pushed
all the way to the f loor or the
starter will not operate. With an
automatic transmission, it must be
in Park or neutral.
Turn the ignition switch to the ON
(II) position or on models with
keyless access system, press the
engine start/stop button to set ON
Mode (see page ). Turn on the
headlights, and check their
brightness. If the headlights are
very dim or do not come on at all,
the battery is discharged. See
on page .
178
178
178557
If theEngineWon’tStart
Nothing Happens or the Starter
Motor Operates Very Slowly
Jump Starting
554
10/07/29 12:53:04 31TK4620_559
2011 TL

In this case, the starter motor’s
speed sounds normal, or even f aster
than normal, when you turn the
ignition switch to the START (III)
position or on models with keyless
access system, press the engine
start/stop button to set START
Mode (see page ), but the engine
does not run.
Turn the ignition switch to the
START (III) position or on models
with keyless access system, press
the engine start/stop button to set
STARTMode(seepage ).If
the headlights do not dim, check
the condition of the fuses. If the
f uses are OK, there is probably
something wrong with the
electrical circuit for the ignition
switch or starter motor. You will
need a qualif ied technician to
determine the problem. See
on page .If the headlights dim noticeably or
go out when you try to start the
engine, either the battery is
discharged or the connections are
corroded. Check the condition of
the battery and terminal connec-
tions (see page ). You can
then try jump starting the vehicle
f rom a booster battery (see page
).
Are you using a properly coded
key or keyless access remote (on
models with keyless access
system)? An improperly coded key
or keyless access remote will
cause the immobilizer system
indicator in the instrument panel
to blink rapidly (see page ).65
178
178
542
572 557
CONT INUED
T he Starter Operates Normally
Emergency T owing
If theEngineWon’tStart
T aking Care of t he Unexpect ed
555
10/07/29 12:53:10 31TK4620_560
2011 TL

Do you have your keyless access
system remote with you? The
vehicle will not start without the
remote within operating range and
with the keyless access main
switch in the glove box turned on.
Are you using the proper starting
procedure? Ref er to
on pages and .
If you are unable to stop the
engine normally while in the Park
position, see on page .
You may need to hold the start/
stop button down or hold the key
in the START (III) position until
the engine starts. It can be held
forupto15seconds.
If youfindnothingwrong,youwill
need a qualif ied technician to f ind
the problem. See on page .
There may be an electrical
problem, such as no power to the
f uel pump. Check all the f uses
(see page ). Do you have f uel? Check the f uel
gauge; the warning indicator may
not be working. 461 463
186
565 572
On models with keyless access system
If theEngineWon’tStart
Starting the
Engine
Emergency Engine
Stop
Emergency
Towing
556
NOTE:
10/07/29 12:53:16 31TK4620_561
2011 TL

Although this seems like a simple
procedure, you should take several
precautions.
You cannot start a vehicle with an
automatic transmission by pushing
or pulling it.Open the hood, and check the
physical condition of the battery.
In very cold weather, check the
condition of the electrolyte. If it
seems slushy or like ice, do not try
jump starting until it thaws.
To jump start your vehicle:
Turn of f all the electrical
accessories: climate control, audio
system, lights, etc. Put the
transmission in neutral (manual)
or Park (automatic), and set the
parking brake. Pull up the battery terminal cover
to remove. The battery terminal
cover can be removed without
removing the lef t side engine
compartment cover.
1.
2.
3.
CONT INUED
Jump Starting
T aking Care of t he Unexpect ed
557
BATTERY TERMINAL COVER
A battery can explode if you do
not follow the correct procedure,
seriously injuring anyone
nearby.
Keep all sparks, open flames,
and smoking materials away
from the battery.If a battery sits in extreme cold, the
electrolyte inside can f reeze.
Attempting to jump start with a f rozen
battery can cause it to rupture.
10/07/29 12:53:25 31TK4620_562
2011 TL
