Acura TL 2011 Owner's Manual

If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem with your
vehicle. Leave the blown fuse in
that circuit, and have your vehicle
checked by a qualif ied technician.
If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate that anything is wrong.
Replace the f use with one of the
correct rating as soon as you can.
Your vehicle has spare fuses on the
back of the under-hood f use box
cover. 6.
Fuses
568
FUSE PULLER SPARE FUSES
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper
rating f or the circuit, install one with
a lower rating.
10/07/29 12:54:50 31TK4620_573
2011 TL

µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ µ
µ
µ
µ
µ
µ
µ
µ
Î
Î
Î
Î
Î
Î
Î
Î
Î Î
No. Amps.
No.
CONT INUED
Circuits Protected
No.
Amps. Amps.
Circuits Protected Circuits Protected
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21 40 A
40 A
15 A
20 A
7.5 A
15 A
15 A
10 A
7.5 A 15 A
15 A
7.5 A
7.5 A
7.5 A
11
12
21
22
23
24
25
26 IG Main
Sub Fan Motor
Sub Fan Motor
Driver’s Side Fuse Box
Main Fan Motor
Driver’s Side Light Main
Wiper Motor
Passenger’s Side Light Main
31
32
33
34
35
36
37
38
120 A
40 A
70 A
40 A
30 A
40 A
30 A
30 A 50 A
40 A
30 A
60 A
40 A
30 A
30 A
30 A
30 A
Battery
Passenger’s Side Fuse Box
EPS
ABS/VSA MTR
ABS/VSA
Passenger’s Side Fuse Box
Option
Headlight Washer
SH-AWD Rear Defroster
Not Used
Not Used
Not Used
Heater Motor
Hazard
Horn and Stop
Keyless Access System
Not Used
IG Coil
FI Sub
Back Up
Interior Lights
FI Main
DBW
Back Up FI ECU
MG, Clutch
Radiator Fan Timer
If equipped Used on SH-AWD models
1:
2:
3: Used on 2WD models
1
2
1
2
3
1 1
Fuse Locations
T aking Care of t he Unexpect ed
569
UNDER-HOOD FUSE BOX
10/07/29 12:54:59 31TK4620_574
2011 TL

µ
µ
µ
µ
Î
Î
Î
Î
No. Amps.
Amps. Circuits Protected
Circuits Protected
No.
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32 10 A
7.5 A 15 A
7.5 A
7.5 A
7.5 A
7.5 A 20 A
20 A
20 A
20 A
15 A
20 A
15 A
10 A
10 A
10 A
7.5 A 15 A
7.5 A
7.5 A
20 A
7.5 A
7.5 A
7.5 A
7.5 A 20 A
10 A SRS
Meter
ACG
Not Used
Daytime Running Light
A/C
Accessory, Key, Lock
Accessory
Driver’s Power Seat Sliding
Moonroof
Driver’s Power Seat Reclining
Rear Left Power Window
Front ACC Socket
Driver’s Power Window
Driver’s Side Door Lock
FrontLeftFogLight
Lef t Side Small Lights
(Exterior)
Left Headlight High Beam
TPMS
Left Headlight Low Beam
Not Used
STS
Not Used
SH-AWD
Washer
Wiper
ODS
ABS/VSA
Not Used
Starter Relay
Fuel Pump
VB SOL
1
2
3
4
5
6
7
8
9
10 : If equipped
Fuse Locations
570
INTERIOR FUSE BOX
Driver’s side
10/07/29 12:55:05 31TK4620_575
2011 TL

µµ
µ
µ
µ
µ
µ
Î
Î
No. Amps. Circuits Protected Amps.
No. Circuits Protected
1
2
3
4
5
610 A
10 A
10 A
15 A
7.5 A Right Headlight High Beam
Right Side Small Lights
(Exterior)
Right Front Fog Light
Right Headlight Low Beam
Not Used
Interior Lights 20 A
20 A
10 A
20 A
10 A
20 A
20 A
15 A
7.5 A 20 A
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22 Not Used
Passenger’s Power Seat
Reclining
Passenger’s Power Seat
Sliding
Right Side Door Lock
Rear Passenger’s Side
Power Window
Keyless Access System
Front Passenger’s Power
Window
Not Used
Premium amplifier
Console ACC Socket
Not Used
Lumbar Support
Seat Heater
Not Used
Not Used
Not Used
: If equipped
Fuse Locations
T aking Care of t he Unexpect ed
571
INTERIOR FUSE BOX
Passenger’s side
10/07/29 12:55:12 31TK4620_576
2011 TL

µµ
Î
Î
If your vehicle needs to be towed,
call a prof essional towing service or
organization. Never tow your vehicle
with just a rope or chain. It is very
dangerous. Therearetwowaystotowyour
vehicle:
The operator
loads your vehicle on the back of a
truck.
The operator will load
your vehicle on the back of a truck.
Any other method of towing will
damage the drive system. When you
contact the towing agency, inf orm
them a f lat-bed is required. If , due to damage, your vehicle must
be towed with the f ront wheels on
the ground, do this:
The tow
truck uses two pivoting arms that go
under the f ront tires and lif t them of f
the ground. The rear tires remain on
the ground. Start the engine.
Shif t to the D position and hold f or
5 seconds, then to N.
Turn of f the engine.
Release the parking brake. Leave the ignition switch in the
ACCESSORY (I) position so the
steering wheel does not lock.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch.
ACCESSORY Mode is the
equivalent of ACCESSORY (I).
For more inf ormation, see pages and .
178 181
:
On SH-AWD models
Except SH-AWD models
Emergency Towing
Flat -bed Equipment
Wheel-lif t Equipment
T his is the best way to
transport your vehicle.
The only way you can saf ely tow
your vehicle is with f lat-bed
equipment.
This is an acceptable
way to tow your vehicle.
572
Towing with only two tires on the
ground will damage parts of the
all-wheel-drive system. Your vehicle
should be transported on a f lat-bed
truck or trailer.
10/07/29 12:55:22 31TK4620_577
2011 TL

Î
Î
With the f ront wheels on the ground,
it is best to tow the vehicle no farther
than 50 miles (80 km), and keep the
speedbelow35mph(55km/h).
If your vehicle is equipped with a
f ront spoiler, remove it bef ore
towing so it is not damaged. Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch.
ACCESSORY Mode is the
equivalent of ACCESSORY (I).
For more inf ormation, see pages
and .
178 181
:
CONT INUED
Emergency Towing
T aking Care of t he Unexpect ed
573
Trying to lif t or tow your vehicle by the
bumpers will cause serious damage.
The bumpers are not designed to
support the vehicle’s weight. Improper towing preparation will
damage the transmission. Follow the
above procedure exactly. If you cannot
shif t the transmission or start the
engine (automatic transmission), your
vehicle must be transported with the
f ront wheels of f the ground.
The steering system can be damaged if
the steering wheel is locked. Leave the
ignition switch in the ACCESSORY (I)
position, and make sure the steering
wheel turns f reely bef ore you begin
towing.
On models with the Keyless Access
system, the ENGINE START/STOP
BUTTON indicator will conf irm that
the power mode is in the ACCESSORY
mode and that the steering lock is
released. If the steering wheel does not
turn f reely, rotate the wheel right and
lef t while pressing the ENGINE
START/STOP BUTTON. This
inf ormation also appears on the multi-
inf ormation display (see page ).
183
10/07/29 12:55:29 31TK4620_578
2011 TL

To use the towing hook:Remove the cover f rom the f ront
bumper using your f ingers, or pry
it of f using a cloth and a f lat-tip
screwdriver to prevent scratches.
If your vehicle gets stuck in sand,
mud, or snow, call a towing service
to pull it out (see page ).
For very short distances, such as
f reeing the vehicle, you can use the
detachable towing hook that mounts
on the anchor in the f ront bumper.
When you need to release the
steering lock while your vehicle’s
battery is dead, do this:
Follow the proper jump starting
procedures, Step 1 through Step 5,
to apply the power to your vehicle
(see pages and ).
Follow the jump starting
procedures, Step 8 and Step 9, and
the instructions to disconnect the
jumpercable(seepage ).The
steering will remain unlocked even
if the battery is dead.
Failure to comply means the steering
lockmaybedamaged. Press the ENGINE START/STOP
button to set the power mode to
ACCESSORY (see page ) and
verif y the steering lock is released.
Remove the towing hook and
wheel nut wrench f rom the tool
case in the spare tire (see).
1.
2.
1.
2.
3.
178
557 558
558 572
On models with keyless access systemIf Your Vehicle Gets Stuck
Emergency Towing, If Your Vehicle Gets Stuck
574
10/07/29 12:55:38 31TK4620_579
page
550
2011 TL

Screw the towing hook into the
hole, and tighten it with the wheel
nut wrench.
3.
If Your Vehicle Gets Stuck
T aking Care of t he Unexpect ed
575
To avoid damage to your vehicle, use
the towing hook f or straight, f lat
ground towing only. Do not tow at an
angle. The tow hook should not be used
to tow the vehicle onto a f lat bed. Do
not use it as a tie down.
10/07/29 12:55:43 31TK4620_580
2011 TL

576
10/07/29 12:55:46 31TK4620_581
2011 TL

µ
Thediagramsinthissectiongive
you the dimensions and capacities of
your vehicle and the locations of the
identif ication numbers. It also
includes inf ormation you should
know about your vehicle’s tires and
emissions control systems. ................
Identif ication Numbers . 578
................................
Specif ications .580
DOT Tire Quality Grading ..........................
(U.S. Vehicles) .583
.................................
Tire Labeling .585
Tire Pressure Monitoring System (TPMS) Required Federal ............................
Explanation .587
.......................
Emissions Controls .589
Three Way Catalytic .................................
Converters .591
........................
Emissions Testing .592
T echnical Inf ormation
Technical Inf ormation
577
