display Acura TL 2014 Owner's Manual

Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.If you think you can saf ely drive a
short distance to a service station,
proceed slowly to the station, then
inflate the tire to the recommended
pressure shown on the driver’s
doorjamb.
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (see page ).
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure/TPMS
indicator may come on unexpectedly.
When the low tire pressure/TPMS
indicator is on, one or more of your
tires is signif icantly underinf lated.
Youshouldstopandcheckyourtires
as soon as possible, and inflate them
to the proper pressure as indicated
on the vehicle’s tire inf ormation
placard.
Each tire has its own pressure
sensor (not including the spare tire).
If the air pressure of a tire becomes
signif icantly low, the sensor in that
tire immediately sends a signal that
causes the low tire pressure/TPMS
indicator in the instrument panel to
come on. If this happens, you will see
which tire is losing pressure on the
multi-inf ormation display along with
a ‘‘CHECK TIRE PRESSURE’’
message. It is possible that the pressures
shown on the multi-inf ormation
display and the pressures you
manually measure are slightly
dif f erent.
If the dif f erence is signif icant or you
cannot make the low tire pressure/
TPMS indicator and message on the
multi-inf ormation display go out af ter
inf lating the tires to the specif ied
values, have your dealer check the
system as soon as possible. 583
Low Tire Pressure/
TPMS Indicator
Tire Pressure Monitoring System (TPMS)
514
12/07/20 11:36:41 31TK4640_519

Î
Although your tire pressure is
monitored, you must manually check
thetirepressuresmonthly.
Each tire, including the spare, should
be checked monthly when the
vehicle is cold, and set to the
recommended inf lation pressure as
specif ied on the vehicle placard and
intheowner’smanual(seepage).
For example, if you check and f ill
your tires in a warm area, then drive
in extremely cold weather, the tire
pressure will be lower than
measured and could be underinf lated
and cause the low tire pressure/
TPMS indicator to come on. Or, if
youcheckandadjustyourtire
pressure in cooler conditions, and
drive into extremely hot conditions,
the tire may become overinf lated.
However, the low tire pressure/
TPMS indicator will not come on if
thetiresareoverinflated.
Refer to page for tire inflation
guidelines.
If there is a problem with the TPMS,
this indicator begins to f lash. It stops
flashing after approximately 1
minute, then stays on. You will also
see a ‘‘CHECK TPMS SYSTEM’’
message on the multi-inf ormation
display (see page ). Toselectthetirepressuremonitor,
press the INFO button several times
with the ignition switch in the ON
(II) position or with the power mode
ON.
You will see the above display on the
multi-inf ormation display when each
tire pressure is normal.
517 570
568
CONT INUED
Tire Pressure Monitor
Tire Pressure Monitoring System (TPMS)
Driving
515
U.S.
Example: Technology Package is shown.
12/07/20 11:36:50 31TK4640_520

Î Each tire pressure is shown in PSI
(U.S. models) or in kPa (Canadian
models).If any of the tires has low pressure,
thetirepressuremonitoralsoshows
the above message and each tire
pressure to warn you about the low
tire pressure when you select the
displaybypressingtheINFObutton
several times.
Each tire has its own pressure
sensor (not including the spare tire).
If the air pressure of a tire becomes
signif icantly low, the sensor in that
tire immediately sends a signal that
causes the low tire pressure/TPMS
indicator in the instrument panel to
come on. If this happens, you will see
which tire is losing pressure on the
multi-inf ormation display along with
a ‘‘CHECK TIRE PRESSURE’’
message.
Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
:
184 187
Tire Pressure Monitoring System (TPMS)
516
Canadian model
Canada
This shows that the front left tire is
losing pressure. U.S. model
Example: Technology Package is
shown.
12/07/20 11:36:57 31TK4640_521

If there is a problem with the TPMS,
thetirepressuremonitorshowsa
‘‘TPMS ERROR’’ message and the
tire pressure readings are not
displayed. If this happens, you will
f irst see a system warning message
‘‘CHECK TPMS SYSTEM’’ on the
multi-inf ormation display.If there is a problem with the TPMS,
youwillseetheabovemessageon
the multi-information display.If the low tire pressure/TPMS
indicator comes on, or the multi-
inf ormation display shows a
‘‘CHECK TPMS SYSTEM’’ message,
the VSA system automatically turns
on even when the VSA system is
turned of f by pressing the VSA OFF
switch (see page ). If this
happens, you cannot turn the VSA
system of f by pressing the VSA OFF
switch again.
When you restart the vehicle with
thecompactsparetire,theTPMS
system message will also be
displayed on the multi-information
display af ter several miles
(kilometers) driving.
If you see this message, the system
is of f and is not monitoring the tire
pressures. Have the system checked
by your dealer as soon as possible.
Also, the low tire pressure/TPMS
indicator begins to f lash, then stays
on (see page ). 511
515
TPMS System Failure
Tire Pressure Monitoring System (TPMS)
Driving
517
U.S. model Canadian model
12/07/20 11:37:05 31TK4640_522

If you have a f lat tire, the low tire
pressure/TPMS indicator and tire
monitor indicator will come on.
Replace the indicated f lat tire with
thecompactsparetire(seepage).
After the flat tire is replaced with the
spare tire, the low tire pressure/
TPMS indicator stays on while
driving. Af ter several miles
(kilometers) driving, this indicator
begins to f lash, then stays on again.
You will also see a ‘‘CHECK TPMS
SYSTEM’’ message on the multi-
inf ormation display. This is normal;
the system cannot monitor the spare
tire pressure. Manually check the
spare tire pressure to be sure it is
correct.
This indicator and the warning
message on the multi-inf ormation
display will go of f , af ter several miles
(kilometers) driving, when the spare tire is replaced with the specified
regular tire equipped with the tire
pressure monitor sensor.
Never use a puncture-repairing agent
in a f lat tire. If used, you will have to
replace the tire pressure sensor.
Havetheflattirerepairedbyyour
dealer as soon as possible.
If the low tire pressure/TPMS
indicator and the low tire position on
the low tire pressure monitor do not
go out af ter inf lating the tires to the
specified values, have your dealer
check the system as soon as possible. Each wheel (except the compact
sparetirewheel)isequippedwitha
tire pressure sensor. You must use
TPMS specif ic wheels. It is
recommended that you always have
your tires serviced by your dealer or
qualif ied technician.
This device complies with the
appropriate requirements or the
required standards. See page f or
more inf ormation.
583 628
Changing a T ire with T PMS
Tire Pressure Monitoring System (TPMS)
518
12/07/20 11:37:12 31TK4640_523

CONT INUED
Blind Spot Inf ormation System (BSI)
Driving
521
BSI INDICATOR
BSI OFF BUTTONMULTI-INFORMATION DISPLAY
BSI ALERT INDICATOR
LEFT SIDE RIGHT SIDE
U.S. model is shown.
12/07/20 11:37:30 31TK4640_526

ÎÎ
Î
To turn the system off, press and
hold the BSI OFF button when the
ignition switch is in the ON (II)
position. The BSI indicator on the
instrument panel glows amber,
indicating that the system is turned
of f . The multi-inf ormation display
indicates that the system is of f . To turn the system on again, press
and hold the same button. The BSI
indicator on the instrument panel
turns off. The multi-information
display indicates that the system is
on.
When the ignition switch is turned
to the ON (II) position, the system
will be in the previously selected ON
or OFF setting. Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
:
184 187
Blind Spot Inf ormation System (BSI)
BSI OFF Button
Driving
525
U.S. model is shown. Canadian model is shown.
12/07/20 11:37:59 31TK4640_530

µ
Î
Î
Î
Î
Multi-Inf ormationDisplay Message BSI Indicator
System
Status
ON
OFF
ON/OFF OFF Description
2
When you press and hold the BSI OFF button with the ignition switch in the ON (II) position, a
BSI ON or OFF message is displayed on the multi-information display for about 5 seconds.
The BSI indicator will remain on while the system is off.
The BSI alert indicator illuminates or flashes according to the system status.
A chime sounds to indicate that the system has been turned ON or OFF.
1: ON mode on models with keyless access system (see pages 184 and 187).
If while driving, mud, snow, or ice accumulates in the vicinity of sensor: The system may shut down
The BSI indicator illuminates, a message is displayed on the multi-information display, and a
chime sounds.
The BSI indicator will turn off and the system will return to normal once the obstacle is removed,
and you begin to drive.
Always keep the area around the radar sensors clean. BSI may not operate properly if the sensors
are obstructed.
The BSI alert indicator: May come on when a vehicle enters one of the alert zones, even if this message is displayed.
May not come on due to obstruction (splashes, etc.) even if this message is not displayed.
2: System status may remain on even when the BLIND SPOT NOT AVAILABLE message is displayed.
If the system is faulty, the BSI indicator illuminates and a message is displayed on the multi-
information display.
Have your vehicle inspected by your Acura dealer.1
Blind Spot Inf ormation System (BSI)
BSI Status Displays
526
12/07/20 11:38:08 31TK4640_531

This section explains why it is
important to keep your vehicle well
maintained and how to f ollow basic
maintenance saf ety precautions.
This section also includes
instructions on how to read the
Maintenance Minder messages on
the multi-information display, and
instructions f or simple maintenance
tasks you may want to take care of
yourself .
If you have the skills and tools to
perf orm more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer.U.S. Vehicles: ......................
Maintenance Saf ety . 530
.................
Maintenance Minder . 531
..............................
Fluid Locations . 541
......
Engine Compartment Covers . 542
........................
Adding Engine Oil . 543
Changing the Engine Oil and
...........................................
Filter . 544
..............................
Engine Coolant . 546
....................
Windshield Washers . 548
.......................
Transmission Fluid . 549
..........
Automatic Transmission . 549
..............
Manual Transmission . 551
................
Brake and Clutch Fluid . 553
....................................
Timing Belt . 554
.............................................
Lights . 555
................
Cleaning the Seat Belts . 564
.....................................
Floor Mats . 565
..................
Dust and Pollen Filter . 566
.................................
Exterior Care . 566
.................................
Wiper Blades . 566
...............................................
Tires . 568
...................
Checking the Battery . 577
.............................
Vehicle Storage . 578
..................................
Interior Care . 579
633
Maintenance
Maintenance, replacement, or
repair of emissions control
devices and systems may be done
by any automotive repair
establishment or individual using
parts that are ‘‘certif ied’’ to EPA
standards.
Maint enance
529
TM
12/07/20 11:38:22 31TK4640_534

Î
Î
CONT INUED
Your vehicle displays engine oil lif e
and maintenance service items on
the multi-information display to show
youwhenyoushouldhaveyour
dealer perf orm engine oil
replacement and indicated
maintenance service.To see the current engine oil lif e
displayed on the multi-inf ormation
display, turn the ignition switch to
the ON (II) position, and press the
SEL/RESET button on the steering
wheel repeatedly until the engine oil
lif e is displayed. Models equipped with the
keyless access system have an
engine start/stop button instead
of an ignition switch. ON Mode
is the equivalent of ON (II). For
more inf ormation, see pages
and .
Based on the engine operating
conditions, the onboard computer in
your vehicle calculates the remaining
engine oil lif e and displays it as a
percentage. :
184 187
Maintenance Minder
Engine Oil L if e Display
Maint enance
531
REMAINING ENGINE OIL LIFE
U.S. model is shown.
TM
12/07/20 11:38:38 31TK4640_536
