Acura TSX 2006 Owner's Manual

The back of the rear seat folds down
to give you direct access to the trunk.
Each side f olds down separately.
With only half the seat f olded, you
can still carry a passenger in the
back seat. The seat-back can be
released f rom inside the vehicle or
inside the trunk.To f old down either side of the seat-
back f rom inside the vehicle, insert
the master key in the lock on the
rear shelf . To f old down the driver’s
side, turn the key clockwise, pull
down the top of the seat-back, then
release the key. To f old down the
passenger’s side, turn the key
counterclockwise and perf orm the
same procedure.When storing cargo, you can move
therearcentershoulderbeltoutof
the way by removing the belt from
the guide.
Seats
Folding Rear Seat
140
MASTER KEY
GUIDE
CENTER SHOULDER BELT
——yy
(y
y

To release the seat-back from inside
the trunk, pull the release loop under
the trunk panel.Do not put any heavy items on the
seat-back when it is folded.
Make sure all items in the trunk, or
items extending through the opening
into the back seat, are secured.
Looseitemscanflyforwardand
cause injury if you have to brake
hard. See
on page
.
Never drive with the seat-back
f olded down and the trunk lid open.
See on
page .
Make sure that the folded seat-back
does not interf ere with the f ront
passenger’s seat-back. This will
cause the f ront passenger’s weight
sensors to work improperly (see
page ). Also check the passenger
airbag of f indicator to assure proper
operation of the passenger’s
advanced front airbag.
Make sure all rear shoulder belts are
positioned in f ront of the rear seat-
back, and the center shoulder belt is
re-positioned in the guide whenever
the seat-back is in its upright position.
Be sure there are no twists in the
center shoulder belt.
Push the seat-back down, then let go
of the release.
To lock the seat-back upright, push it
f irmly against the trunk panel. Make
sure it is latched in place by pulling
on the top of the seat. 30
236
56
Seats
Carrying Cargo
Carbon Monoxide Hazard
Inst rument s and Cont rols
141
RELEASE LOOP
——y
y
(y
y

Adjust the seat to a comfortable
position (see page ). Turn the ignition switch to the ON
(II) position. You cannot add a
new driving position in the
memory unless the ignition switch
is in the ON (II) position. You can
recall a memorized position with
the ignition switch in any position.
Store a driving position only when
the vehicle is parked.
Your vehicle has a memory feature
f or the driver’s seat position.
Two seat positions can be stored in
separate memories. You select a
memorized position by pushing the
appropriate button or appropriate
remote transmitter (Driver 1 or
Driver 2).
This setting can be linked or
unlinked with the remote transmitter.
To customize the setting ‘‘MEMORY
POSITION LINK’’, see page .
Press and release the MEMO
button on the driver’s door. You
will hear a beep. Then, both
indicators in the memory buttons
will start to blink. Press and hold
one of the memory buttons (1 or
2) within 5 seconds af ter you press
the MEMO button. When the
system completes to store a new
driving position, you hear two
beeps. The indicator in the stored
memory button will come on.
3.
1.
2.
103
138
Storing a Driving Position in
Memory
Driving Position Memory System
142
MEMO BUTTON
INDICATORS MEMORY BUTTONS
——yy
(y
y

To select a memorized position, do
this:Make sure the parking brake is set
(M/T) or the shif t lever is in Park
(A/T).
Readjusting the seat position. Pressing the MEMO button again
within 5 seconds.
You cannot select a memorized
position if the transmission is in
reverse. Shif t to another gear,
then select.
Doing any of the f ollowing af ter
pressing the MEMO button will
cancel the storing procedure.
All stored driving positions will be
lost if your vehicle’s battery goes
dead or is disconnected. Not pressing a memory button
within 5 seconds.
Each memory button stores only one
driving position. Storing a new
position erases the previous setting
stored in that button’s memory. If
you want to add a new position while
retaining the current one, use the
other memory button. Press the desired memory button
(1 or 2) until you hear a beep.The system will move the driver’s
seat to the memorized position. The
indicator in the selected memory
button will flash during movement.
When the adjustment is complete,
you will hear two beeps, and the
indicator will stay on.
If the parking brake is not set, you
must press and hold the memory
button until the adjustment is
complete.
1.
2.
CONT INUED
Notes f or vehicles with M/T
Selecting a Memorized Position
Driving Position Memory System
Inst rument s and Cont rols
143
MEMORY BUTTONS
——yy
(y
y

To stop the system’s automatic
adjustment, do any of these actions:Push any of the adjustment
switches f or the seat.
Shif t out of Park (A/T), or into
reverse (M/T). Press any button on the driver’s
door: MEMO, memory button 1 or
2. If desired, you can use the
adjustment switches to change the
seat position af ter it is in its
memorized position. If you change
the memorized position, the
indicator in the memory button will
go out. To keep this seat position f or
later use, you must store it in the
driver’s seat position memory.
Driving Position Memory System
144
——yy
(y
y

The inside mirror can automatically
darken to reduce glare. To turn on
this feature, press the AUTO button
on the bottom of the mirror. The
indicator comes on as a reminder.
When it is on, the mirror darkens
when it senses the headlights of a
vehicle behind you, then returns to
normal visibility when the lights are
gone. Press the OFF button to turn
of f this f eature.
Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving.
Mirrors
Inst rument s and Cont rols
145
OFF BUTTON
AUTO BUTTON INDICATOR
——yy
(y
y

Turn the ignition switch to the ON
(II) position.Push or pull the adjustment knob
right, left, up, or down to move the
mirror.
When you f inish, turn the
adjustment knob to the center
(of f ) position. This turns of f the
adjustment knob to keep your
settings.
The outside mirrors are heated to
remove fog and frost. With the
ignition switch in the ON (II)
position, turn on the heaters by
pressing the button. The indicator in
the button comes on as a reminder.
Press the button again to turn the
heaters off.
Turn the adjustment knob to L
(driver’s side) or R (passenger’s
side).
1. 3.
2. 4.
PowerMirrorHeaters
Adjusting the Power Mirrors
Mirrors
146
ADJUSTMENT KNOB HEATED MIRROR BUTTON
——yy
(y
y

µTo open the driver’s
window, push the window switch
f irmly down, then release it. To stop
the window f rom going all the way
down, pull back on the window
switch brief ly.
To close the driver’s window f ully,
pull back the window switch f irmly,
then release it. To stop the window
f rom going all the way up, push
down on the window switch brief ly.
If the MAIN switch is pushed down
(OFF), the passenger windows
cannot be raised or lowered. Keep
the MAIN switch off when you have
children in the vehicle so they do not
injure themselves by operating the
windows unintentionally. To open or close the driver’s window
partially, push down or pull back on
the window switch lightly and hold it.
The window will stop when you
release the switch.
Turn the ignition switch to the ON
(II) position bef ore operating any of
the window switches. To open a
window, push the switch down and
hold it. To close the window, pull the
switchupandholdit.Releasethe
switch to stop the window.
CONT INUED
AUTO
Power Windows
Inst rument s and Cont rols
147
MAIN SWITCH
DRIVER’S WINDOW SWITCH
Closing a power window on
someone’s hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.
——yy
(y
y

µIf the driver’s
window senses any obstacle while it
is closing automatically, it will
reverse direction, and then stop. To
close the window, remove the
obstacle, then use the window switch
again.
Auto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it. If your vehicle’s battery is
disconnected or goes dead, or the
driver’s window f use is removed, the
AUTO f unction will be disabled. The
power window system needs to be
reset af ter reconnecting the battery
or installing the f use.
Start the engine. Push down and
hold the driver’s window switch
until the window is f ully open.
Pull and hold the driver’s window
switch to close the window
completely, then hold the switch
f or about 2 seconds.
If the power windows do not operate
properly af ter resetting, have your
vehicle checked by your dealer. The power window system has a key-
of f delay f unction. The windows will
still operate f or up to 10 minutes
after you turn off the ignition switch.
Opening either f ront door cancels
the delay function. You must turn
the ignition switch to the ON (II)
position again bef ore you can raise
or lower the windows.
1.
2.
AUTO REVERSE
Power Windows
148
——yy
(y

y

To open: You can open and close the windows
with the key in the driver’s door lock.Insert the key in the driver’s door
lock.
Turn the key clockwise, then
release it.
You can open all of the windows
from the outside with the remote
transmitter.
Press the UNLOCK button once
to unlock the driver’s door
(depending on the ‘‘DOOR LOCK
MODE’’ setting).
Press the UNLOCK button a
second time, and hold it. The
passenger’s doors unlock, and all
f our windows start to open. To
stop the windows, release the
button.
To open the windows further,
press the button again (within 10
seconds).
You cannot close the windows with
the remote transmitter. Turnthekeyclockwiseagain,and
hold it. All f our windows start to
open. To stop the windows,
release the key.
To open the windows f urther, turn
andholdthekeyagain(within
10 seconds).
To close: Insert the key in the driver’s door
lock.
Turn the key counterclockwise,
then release it.
Turn the key counterclockwise
again, and hold it. All four
windowsstarttoclose.Tostopthe
windows, release the key.
To close the windows f urther, turn
andholdthekeyagain(within
10 seconds).
1.
2.
3.
1.
2.1.
2.
3. 3.
4.
4.
Power Windows
Opening t he Windows wit h t he
Remote Transmitter
Opening/Closing t he Windows wit hthe Key
Inst rument s and Cont rols
149
Open
Close UNLOCK BUTTON
——y
y
(y
y
