Acura TSX 2009 Owner's Manual

ÛÝ ÛÝ
If you want to set the def ault settings,
press the INFO ( / ) button to
select DEFAULT ALL, then press
the SEL/RESET button.
If the setting is not successfully
completed, ‘‘FAILED’’ is shown f or
several seconds, and then the screen
goes back to the normal message
mode. Repeat the same procedure to
select DEFAULT ALL.
If you want to cancel DEFAULT
ALL, select CANCEL, then press the
SEL/RESET button. The screen
goes back to the previous display.
To set the def ault settings, press the
INFO ( / ) button to select SET
then press the SEL/RESET button.
When DEFAULT ALL is set, you will
see the above display for several
seconds, then the screen returns to
the default all setting display.
DEFAUL T AL L
Multi-Inf ormation Display
108
\f—\f—\fy\f

y
)!
\f\fy\f

y
2009 TSX

Î
Î Î
Î Î
Î
Î
Î
Î
To use the horn, press the center pad of the steering wheel.
Only on vehicles equipped with navigation system. Ref er to the navigation system manual.
If equipped
1:
2:
3:
Controls Near the Steering Wheel
Inst rument s and Cont rols
109
REMOTE AUDIO
CONTROL BUTTONS WINDSHIELD WIPERS/
WASHERS
HAZARD WARNING
BUTTON
VEHICLE STABILITY
ASSIST (VSA) SYSTEM
OFF SWITCH
Vehicle without navigation system is shown. SEAT HEATER SWITCHESCENTER DISPLAY
INTERFACE DIAL
REAR WINDOW DEFOGGER/
HEATED MIRROR BUTTON MULTI-INFORMATION
BUTTONS
CRUISE CONTROL BUTTONS
INSTRUMENT PANEL
BRIGHTNESS
(P.115) (P.110)PASSENGER AIRBAG OFF
INDICATOR
(P.33)
(P.222) (P.175)
(P.117)
(P.117,146)
(P.299)
(P.71)
(P.287)
(P.399)
(P.118)(P.141)
STEERING WHEEL ADJUSTMENTS
HEADLIGHTS/TURN SIGNALS
SELECTOR KNOB
(P.111)/
NAVIGATION SYSTEM VOICE
CONTROL BUTTONS HORN
FRONT FOG LIGHTS (P.115)
(P.308)
BLUETOOTH
HANDSFREELINKSYSTEM
VOICE CONTROL BUTTONS
2
2 3
2 1
3
\f—\f—\fy\fy
)!
\f\fy\f

y
2009 TSX

µ
µ µ
µ µ
µ
µ
µ µ
Push the right lever up or down to
select a position.
The wipers run at high
speed until you release the lever.
The wipers are not activated. The wipers run at low speed.
The wipers run at high speed. Pull the
wiper control lever toward you, and
hold it. The washers spray until you
release the lever. The wipers run at
low speed, then complete one more
sweep after you release the lever.
MIST
OFF
INT Intermittent
LO Low speed
HI High speed
Windshield washers Vary the delay by turning the
adjustment ring. If you turn it to the
shortest delay ( position), the
wipers change to low speed
operation when the vehicle speed
exceeds 12 mph (20 km/h).The length of the wipe
interval is varied automatically
according to vehicle’s speed.
1.
2.
3.
4.
5.
6. MIST
OFF
LO
HI
Windshield Washer
INT
Windshield Wipers and Washers
110
ADJUSTMENT RING
\f—\f—\fy\fy
)!
\f\fy\f

y
2009 TSX

µ
µ µ
Î
Î Î
Î
Push down on the
lef t lever to signal a lef t turn and up
to signal a right turn. To signal a lane
change, push lightly on the lever and
hold it. The lever will return to the
center when you release it or
complete a turn.
Turning the switch to
the ‘‘ ’’ position turns on the
parking lights, taillights, instrument
panel lights, side-marker lights, and
rear license plate lights.
Turning the switch to the ‘‘ ’’
position turns on the headlights.
When the light switch is in the
‘‘ ’’ or ‘‘ ’’ position, the
lights on indicator comes on as a
reminder.
This indicator stays on if you leave
the lights on and turn the ignition
switch to the ACCESSORY (I) or
LOCK (0) position. If you leave the lights on with the
key removed f rom the ignition
switch, you will hear a reminder
chime when you open the driver’s
door.
Push the lef t lever
f orward until you hear a click. The
blue high beam indicator will come
on (see page ). Pull the lever back
to return to the low beams.
To f lash the high beams, pull the
lever back lightly, then release it.
The high beams will stay on as long
as you hold the lever back.
Turn signal
Of f
Parking and instrument panel
lights
AUTO
Headlights on
High beams
Flashhighbeams
Fog lights of f
Fog lights on
If equipped
:
1.
2.
3.
4.
5.
6.
7.
8.
9. 66
Turn Signals and Headlights
Turn Signal
Headlights
High Beams
Inst rument s and Cont rols
111
\f—\f—\fy\fy
)!
\f\fy\f

y
2009 TSX

µThe automatic lighting
f eature turns on the headlights and
all other exterior lights, when it
senses low ambient light.
To turn on automatic lighting, turn
the light switch to AUTO at any time.
The lights will come on automatically
when the outside light level becomes
low (at dusk, f or example). The
lights on indicator comes on as a
reminder. The lights and indicator
will turn of f automatically when the
system senses high ambient light.
The lights will remain on when you
turn of f the ignition switch. They will
turn of f automatically when you
remove the key and open the driver’s
door. To turn them on again, either
turn the ignition switch to the ON
(II) position or turn the light switch
to the position. Even with the automatic lighting
f eature turned on, we recommend
thatyouturnonthelightsmanually
when driving at night or in a dense
f og, or when you enter dark areas
such as long tunnels or parking
f acilities.
The automatic lighting f eature is
controlledbyasensorlocatedontop
of the dashboard. Do not cover this
sensor or spill liquids on it.
To change the ‘‘AUTO LIGHT
SENSITIVITY’’ setting, see page
.
Do not leave the light switch in
AUTO if you will not be driving the
vehicle f or an extended period (a
weekormore).Youshouldalsoturn
of f the lights if you plan to leave the
engine idling or of f f or a long time. 97
U.S. TSX and Canadian TSX Premium
AUTO
Headlights
112
LIGHT SENSOR
\f—\f—\fy

y
)!
\f\fy\f

y
2009 TSX

The lights will turn on again when
you unlock or open the driver’s door.
If you unlock the door, but do not
open it within 15 seconds, the lights
will go off. With the driver’s door
open, you will hear a lights on
reminder chime.
This f eature turns of f the headlights,
all other exterior lights, and the
instrument panel lights within 15
seconds after you remove the key
and close the driver’s door.
You can change this 15 second timer
to 0, 30, or 60 seconds (see page
). The automatic lighting of f f eature
activates if you leave the headlight
switch in the ‘‘ ’’ or ‘‘ ’’
position or if the lights are turned on
by setting the switch in the ‘‘AUTO’’
position (if equipped), and you
remove the key, then open and close
the driver’s door.
If you turn the ignition switch to the
LOCK (0) position with the
headlight switch on, but do not open
the door and get out, the lights turn
of f af ter 10 minutes (3 minutes, if
the switch is in the ‘‘AUTO’’
position).
96
Headlights
Automatic Lighting Of f Feature
Inst rument s and Cont rols
113
\f—\f—\fy\f\f\fy
)!
\f\fy\f

y
2009 TSX

With the headlight switch of f or in
the position, the high beam
headlights and the high beam
indicator come on with reduced
brightness when you turn the
ignition switch to the ON (II)
position and release the parking
brake. They remain on until you turn
the ignition switch of f , even if you
set the parking brake.
The headlights revert to normal
operation when you turn them on
with the switch.If you see a ‘‘CHECK DRL
SYSTEM’’ message on the multi-
inf ormation display, there is a
problem with the daytime running
light system. Take your vehicle to a
dealer to have it checked.
Headlights
Daytime Running L ights
114
\f—\f—\fy\f\fy
)!
\f\fy\f

y
2009 TSX

You can use the f og lights only when
the headlights are on low beam.
Turn the f og lights on and of f by
turning the switch next to the
headlight switch. With the light switch in the AUTO
position, you can also use the f og
lights when the headlights turn on
automatically. They will go of f when
the headlights turn of f , or the
daytime running lights are on.
Theknobontheinstrumentpanel
controls the brightness of the
instrument panel lights. Turn the
knob to adjust the brightness with
the ignition switch in the ON (II)
position and the parking lights on.
CONT INUED
U.S. TSX and Canadian TSX Premium
Fog L ights Instrument Panel Brightness
Fog L ights, Instrument Panel Brightness
Inst rument s and Cont rols
115
INSTRUMENT PANEL BRIGHTNESS
CONTROL KNOB
\f—\f—\fy\f
y
)!
\f\fy\f
\fy
2009 TSX

When you turn the knob, the multi-
inf ormation display changes to
vertical bars that show you the
current level.
You will hear a tone when you reach
the maximum or minimum
brightness. The brightness level
goes out about 5 seconds af ter you
stop adjusting.To reduce glare at night, the
instrument panel illumination dims
when you turn the light switch to
or position. Turning the
knob to the right until you hear a
tone will cancel the reduced
brightness.
The instrument panel will illuminate
with reduced brightness when you
unlock and open the driver’s door.
The brightness will increase slightly
when you insert the key in the
ignitionswitch,thengotonormal
brightness when you turn the
ignition switch to the ON (II)
position. If you do not insert the key in the
ignition switch af ter opening the
driver’s door, the illumination turns
of f about 30 seconds af ter you close
the door.
If you insert the key but do not turn
the ignition switch to the ON (II)
position, the illumination turns of f in
about 10 seconds.
Instrument Panel Brightness
116
BRIGHTNESS LEVEL
\f—\f—\fy\fy
)!
\f\fy\f

y
2009 TSX

Push the button under the audio
controls to turn on the hazard
warning lights (f our-way f lashers).
This causes all f our outside turn
signal lights and both turn signal
indicators in the instrument panel to
f lash. Use the hazard warning lights
if you need to park in a dangerous
area near heavy traffic, or if your
vehicle is disabled.The rear window def ogger will clear
fog, frost, and thin ice from the
window. Push the def ogger button to
turn it on and of f . The indicator in
the button comes on to show the
def ogger is on. It also shuts of f when
you turn of f the ignition switch. You
have to turn the defogger on again
when you restart the vehicle.The def ogger will shut itself of f
withinabout10to30minutes
according to the outside temperature
(over 32°F, 0°C).
Make sure the rear window is clear
and you have good visibility bef ore
starting to drive.
The def ogger and antenna wires on
the inside of the rear window can be
accidentally damaged. When
cleaning the glass, always wipe side-
to-side.
Pushing this button also turns the
mirror heaters on or of f . For more
inf ormation, see page .
146
Rear Window Def ogger
Hazard Warning Button
Hazard Warning Button, Rear Window Def ogger
Inst rument s and Cont rols
117
HAZARD WARNING BUTTON
\f—\f—\fy\fy
)!
\f\fy\f
y
2009 TSX
