294Handling the Unexpected
FusesFuse LocationsIf any electrical devices are not working, turn the ignition switch to LOCK
(0
and
check to see if any applicable fuse is blown.
Located near the brake fluid reservoir. Push
the tabs to open the box.
Located under the dashboard.
■
Engine Compartment Fuse Box
1Engine Compartment Fuse Box
Fuse locations are shown on the fuse box cover.
Locate the fuse in question by the fuse number and
box cover number.
■
Driver Side Fuse Box
1Driver Side Fuse Box
Fuse locations are shown on the label on the side
panel.
Locate the fuse in question by the fuse number and
label number.
Fuse Label

296
uuFuses uCircuit Protected and Amps for Each Fuse
Handling the Unexpected
Circuit Protected and Amps for Each FuseThe current rating in brackets indicate that
you may find a fuse in the location even if
your particular model is not equipped with
the device the fuse is used for.■
Engine Compartment
Circuit Protected
Amps
1
Battery
100 A
*1
120 A
*2
Passenger’s Side Fuse Box
40 A
2
EPS
70 A
Passenger’s Side Fuse Box (40 A)
ABS/VSA FSR
30 A
−−
ABS/VSA Motor
30 A
−−
3
IG
50 A
Driver’s Side Fuse Box
(40 A)
Passenger’s Side Light Main
30 A
Driver’s Side Fuse Box
(60 A)
Driver’s Side Light Main
30 A
Main Fan Motor
30 A
−*1
−
Wiper Motor
*2
30 A
Wiper Motor
*1
30 A
Sub Fan Motor
*2
*1:4-cylinder models
*2:6-cylinder models 4 Rear Defogger 40 A5
Sub Fan Motor
*1
20 A
−*2
−
6− −
7
−
−
8 Heater Motor 40 A
9
Hazard
15 A
10 Horn 10 A
11
−
−
12 Stop 15 A
13
IG Coil
15 A
14 FI Sub 15 A
15
Backup
10 A
16 Interior Lights 7.5 A
17
FI Main
15 A
18 DBW 15 A
19
−*1
−
Back Up FI ECU
*2
7.5A
20 MG Clutch 7.5 A
21
Engine Oil Level
*1
7.5 A
Fan RLY
*2
Circuit Protected
Amps
■
Driver Side
Circuit Protected
Amps
1
−
−
2
Seat Memory
(7.5 A)
3
Washer
15 A
4
Wiper
10 A
5
Meter
7.5 A
6
ABS/VSA
7.5 A
7
ACG
15 A
8
STS
*1
(7.5 A)
Starter DIAG
*2
9
Fuel Pump
20 A
10
VB SOL
*
(10 A)
11
SRS
10 A
12
ODS
7.5 A
13
−*1
(7.5 A)
STS
*2
14
−
−
15
Daytime Running Lights
7.5 A
16
A/C
7.5 A
17
Accessory, Key, Lock
7.5 A
* Not available on all models

297
uuFuses uCircuit Protected and Amps for Each Fuse
Handling the Unexpected
*1:4-cylinder models
*2:6-cylinder models18
Accessory
7.5 A
19
Driver’s Power Seat Sliding
(20 A)
20
Moonroof
(20 A)
21
Driver’s Power Seat
Reclining
(20 A)
22
Rear Driver’s Side Power Window
20 A
23
Front Accessory Power Socket
20 A
24
Driver’s Power Window
20 A
25
Driver’s Side Door Lock
15 A
26
Left Front Fog Light
(10 A)
27
Left Side Small Lights
(Exterior)
10 A
28
Left Headlight High Beam
10 A
29
TPMS
10 A
30
Left Headlight Low Beam
15 A
31
−
−
32 Engine Oil Level
*
(7.5 A)
Circuit Protected
Amps
■
Passenger Side
Circuit Protected
Amps
1
Right Headlight High Beam
10 A
2
Right Side Small Lights (Exterior)
10 A
3
Right Front Fog Light
(10 A)
4
Right Headlight Low Beam
15 A
5
−
−
6
Interior Lights
7.5 A
7
−
−
8
Passenger’s Side Power Seat
Reclining
20 A
9
Passenger’s Side Power Seat
Sliding
20 A
10
Right Side Door Lock
10 A
11
Rear Passenger’s Side Power Window
20 A
12
Console Accessory Power
Socket
20 A
13
Front Passenger’s Power Window
20 A
14
−
−
15
Premium AMP
(20 A)
16
−
−
17
−
−
18
−
−
19
Seat Heater
20 A
20
−
−
21
−
−
22
−
−
Circuit Protected
Amps
* Not available on all models

298
uuFuses uInspecting and Changing Fuses
Handling the Unexpected
Inspecting and Changing Fuses
1. Turn the ignition switch to LOCK
(0
. Turn
headlights and all accessories off.
2. Remove the fuse box cover.
3. Check the large fuse in the engine
compartment.
u If the fuse is blown, use a Phillips-head
screwdriver to remove the screw and
replace it with a new one.
4. Inspect the small fuses in the engine
compartment and the vehicle interior.
u If there is a burned out fuse, remove it
with the fuse puller and replace it with a
new one.
1Inspecting and Changing Fuses
NOTICEReplacing a fuse with one that has a higher rating
greatly increases the chances of damaging the
electrical system. If you do not have a replacement
fuse with the proper rating fo r the circuit, install one
with a lower rating.
Replace fuse with a spare fuse of the same specified
amperage.
Confirm the specified amperage using the charts on
P. 296 and P. 297.
There is a fuse puller on the back of the engine
compartment fuse box.
Fuse Blown FuseCombined Fuse
Blown FuseFuse Puller

303
Information
This chapter includes your vehicle’s specifications, locations of identification numbers, and other
information required by regulation.
Specifications .................................... 304
Identification Numbers Vehicle Identification Number (VIN).. 308
Engine Number and Transmission Number ...................................... 308
Devices that Emit Radio Waves ....... 309
Reporting Safety Defects ................. 310
Emissions Testing Testing of Readiness Codes.............. 311
Warranty Coverages ........................ 313
Authorized Manuals ......................... 315
Client Service Information ............... 316

304Information
Specifications■Vehicle Specifications*1: Automatic transmission models
*2: Manual transmission modelsModel
Acura TSX
No. of Passengers:
Front 2
Rear 3
Total 5
Weights:Gross Vehicle Weight
Rating
U.S.: 4,475 lbs (2,030 kg)
*1
Canada: 2,030 kg
*1
U.S.: 4,395 lbs (1,995 kg)
*2
Canada: 1,995 kg
*2
Gross Axle Weight
Rating (Front)
U.S.: 2,410 lbs (1,095 kg)
*1
Canada: 1,095 kg
*1
U.S.: 2,325 lbs (1,055 kg)
*2
Canada: 1,055 kg
*2
Gross Axle Weight
Rating (Rear)
U.S.: 2,090 lbs (950 kg)
Canada: 950 kg
Air Conditioning:
Refrigerant Type HFC-134a (R-134a)
Charge Quantity 15.8 – 17.6 oz (450 – 500 g)
Lubricant Type SP-10
4-cylinder models
■ Engine Specifications
■ Fuel
■ Battery
■ Washer FluidDisplacement
144 cu-in (2,354 cm
3)
Spark Plugs NGK ILZKR7B-11S
DENSO SXU22HCR11S
Fuel:
Type
Unleaded gasoline, Pump octane number
of 91 or higher
Fuel Tank Capacity 18.5 US gal (70 ℓ)
Capacity/Type
36AH(5)/45AH(20)
36AH(5)/47AH(20)
Tank Capacity
U.S.: 2.6 US qt (2.5 ℓ)
Canada: 4.8 US qt (4.5 ℓ)
■ Light Bulbs*3: Vehicle with discharge headlights
*4: Vehicle with halogen bulb low beam headlightsHeadlights (Low Beam)
35W (D2S)
*3
55W (H1)
*4
Headlights (High Beam) 60W (HB3)Fog Lights
55W (H11)
Front Turn Signal/Parking/Side
Marker Lights 21/5W
Side Turn Signal Lights
(on Door Mirrors)
LED
Brake/Taillights 21/5W
Rear Turn Signal Lights
21W
Back-Up Lights 21W
Rear Side Marker Lights
3CP
High-Mount Brake Light 21W
License Plate Lights
5W
Trunk Light 5W
Interior Lights
Spotlight
8W
Ceiling Light
8W
Vanity Mirror Lights 2W
Courtesy Lights
3.8W

305
uuSpecifications u
Continued
Information
■Brake/Clutch Fluid
■ Transmission Fluid*1: Automatic transmission models
*2: Manual transmission modelsSpecified
Honda Heavy Duty Brake Fluid DOT 3
Specified
*1
Acura ATF DW-1
(automatic
transmission fluid)
2.6 US qt (2.5 ℓ)
(Change)
Specified
*2
Acura Manual
Transmission Fluid 2.0 US qt (1.9 ℓ)
(Change)
■
Engine Oil
■ Engine Coolant*1: Automatic transmission models
*2: Manual transmission modelsRecommended
·Acura Genuine Motor Oil 0W-20
·API Premium-grade 0W-20 detergent oil
Capacity Change 4.0 US qt (3.8 ℓ)
Change
including
filter
4.2 US qt (4.0 ℓ)
Specified
Honda Long-Life Antifreeze/Coolant Type2
Ratio 50/50 with distilled water
Capacity
*1
1.64 US gal (6.2 ℓ)
(change including the remaining
0.196 US gal (0.74 ℓ) in the reserve tank)
Capacity
*2
1.66 US gal (6.3 ℓ)
(change including the remaining
0.196 US gal (0.74 ℓ) in the reserve tank)
■ TireRegular
Size
P225/50R17 93V
Pressure
psi (kPa [kgf/cm
2])
33 (230 [2.3])
Compact
Spare Size
T135/80D16 101M
Pressure
psi (kPa [kgf/cm
2]) 60 (420 [4.2])
Wheel Size
Regular
17 x 7.5J
Compact Spare
16 x 4T

306
uuSpecifications u
Information
■Vehicle SpecificationsModel
Acura TSX
No. of Passengers:
Front 2
Rear 3
Total 5
Weights:Gross Vehicle Weight
Rating
U.S.: 4,630 lbs (2,100 kg)
Canada: 2,100 kg
Gross Axle Weight
Rating (Front)
U.S.: 2,557 lbs (1,160 kg)
Canada: 1,160 kg
Gross Axle Weight
Rating (Rear)
U.S.: 2,083 lbs (945 kg)
Canada: 945 kg
Air Conditioning:
Refrigerant Type HFC-134a (R-134a)
Charge Quantity 15.8 – 17.6 oz (450 – 500 g)
Lubricant Type SP-10
6-cylinder models
■ Engine Specifications
■ Fuel
■ Battery
■ Washer FluidDisplacement
212 cu-in (3,471 cm
3)
Spark Plugs NGK ILZKR7B11
DENSO SXU22HCR11
Fuel:
Type
Unleaded gasoline, Pump octane number
of 91 or higher
Fuel Tank Capacity 18.5 US gal (70 ℓ)
Capacity/Type
55AH(5)/72AH(20)
Tank Capacity
U.S.: 2.6 US qt (2.5 ℓ)
Canada: 4.8 US qt (4.5 ℓ)
■ Light BulbsHeadlights (Low Beam)
35W (D2S)
Headlights (High Beam) 60W (HB3)
Fog Lights
55W (H11)
Front Turn Signal/Parking/Side
Marker Lights 21/5W
Side Turn Signal Lights
(on Door Mirrors)
LED
Brake/Taillights 21/5W
Rear Turn Signal Lights
21W
Back-Up Lights 21W
Rear Side Marker Lights
3CP
High-Mount Brake Light 21W
License Plate Lights
5W
Trunk Light 5W
Interior Lights
Spotlight
8W
Ceiling Light
8W
Vanity Mirror Lights 2W
Courtesy Lights
3.8W

307
uuSpecifications u
Information
■Brake/Clutch Fluid
■ Transmission FluidSpecified
Honda Heavy Duty Brake Fluid DOT 3
Specified
Acura ATF DW-1
(automatic
transmission fluid)
3.5 US qt (3.3 ℓ)
(Change)
■ Engine Oil
■ Engine CoolantRecommended
·Acura Genuine Motor Oil 0W-20
·API Premium-grade 0W-20 detergent oil
Capacity Change 4.2 US qt (4.0 ℓ)
Change
including
filter
4.5 US qt (4.3 ℓ)
Specified
Honda Long-Life Antifreeze/Coolant Type2
Ratio 50/50 with distilled water
Capacity
1.77 US gal (6.7 ℓ)
(change including the remaining
0.196 US gal (0.74 ℓ) in the reserve tank)
■ TireRegular
Size
P235/45R18 94V
Pressure
psi (kPa [kgf/cm
2])
33 (230 [2.3])
Compact
Spare Size
T135/80D16 101M
Pressure
psi (kPa [kgf/cm
2]) 60 (420 [4.2])
Wheel Size
Regular
18 x 8J
Compact Spare
16 x 4T

308Information
Identification NumbersVehicle Identification Number (VIN)Your vehicle has a 17-digit vehicle identification number (VIN) used to register your
vehicle for warranty purposes, and for licensing and insuring your vehicle. See the
image below for the VIN locations.Engine Number and Transmission NumberSee the image below for the locations of your vehicle’s engine number and
transmission number.
Vehicle Identification Number
Engine Number
Certification Label/
Vehicle Identification
Number
Manual Transmission
Number Automatic Transmission
Number
6-cylinder models4-cylinder modelsEngine Number
Automatic Transmission
Number
