Acura TSX 2014 Owner's Manual

uu Interior Lights/Interior Convenience Items u Interior Convenience Items
130
There are two accessory power sockets; one in
the console compartment and the other at the
front of the center cons ole. They can be used
when the ignition swit ch is in ACCESSORY
(q

or ON
(w
.
Open the cover to use it.
■Accessory Power Sockets1 Accessory Power Sockets
NOTICE
Do not insert an automotive type cigarette lighter
element.
This can overheat the power socket.
The accessory power socket is designed to supply
power for 12 volt DC access ories that are rated 120
watts or less (10 amps).
To prevent battery drain, only use the power socket
with the engine running.
When both sockets are being used, the combined
power rating of the accesso ries should not exceed
120 watts (10 amps).
14 ACURA TSX 4D-31TL16500.book 130 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
ControlsTOC

Continued131
uu Interior Lights/Interior Convenience Items u Interior Convenience Items
There is a coat hook on the rear grab handle
of both sides. Pull it down to use it.
The tie-down anchors in the trunk can be used
to install a net for securing items.
■Coat Hooks1Coat Hooks
The coat hooks are not desi gned for large or heavy
items.
■Tie-down Anchors1 Tie-down Anchors
Distribute cargo evenly on the floor of the trunk,
placing the heaviest item s on the bottom and as far
forward as possible.
2 Maximum Load Limit P. 187
Anchor
14 ACURA TSX 4D-31TL16500.book 131 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
ControlsTOC

uu Interior Lights/Interior Convenience Items u Interior Convenience Items
132
To open the sunglasses holder, push and
release the indent. To clos e, push it again until
it latches.
You can store eyeglasses and other small
items in this holder.
■Sunglasses Holder1 Sunglasses Holder
Keep the holder closed wh ile driving except when
accessing stored items.
Push
14 ACURA TSX 4D-31TL16500.book 132 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
ControlsTOC

133
uu Interior Lights/Interior Convenience Items u Interior Convenience Items
The ignition switch must be in ON (w
to use
the seat heaters. The HI setting heats the seats
faster than the LO setting.
There is no heater in the passenger’s seat-
back due to the side airbag cutoff system.
While in HI , the heater cycles on and off.
u The appropriate indicator will be on
while the seat heater is on. Briefly
press the button on the opposite side
to turn the heater off. The indicator
will be off. When a comfortable
temperature is reached, select LO to
keep the seat warm.
■Seat Heaters1 Seat Heaters
Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.
In the LO setting, the heater runs continuously and
does not automatically turn off.
3 WARNING
Heat induced burns are possible when
using seat heaters.
Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.
14 ACURA TSX 4D-31TL16500.book 133 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
ControlsTOC

134
Climate Control System
Using Automatic Climate Control
The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your pr eference as quickly as possible.
Use the system when the engine is running.
1. Press the AUTO button.
2. Adjust the interior temperature using the driver’s side or passenger’s side
control switch.
3. Press the button to cancel.
■Switching between the recirculation and fresh air modes
Press the (recirculation) button and switch the mode depending on
environmental conditions.
Recirculation mode (indicator on): Recirculat es air from the vehicle’s interior through
the system.
Fresh air mode (indicator off): Maintains ou tside ventilation. Keep the system in
fresh air mode in normal situations.
1 Using Automatic Climate Control
If any buttons are presse d while using the climate
control system in AUTO, the function of the button
that was pressed will take priority.
The AUTO indicator will go off, but functions
unrelated to the button th at was pressed will be
controlled automatically.
To prevent cold air from bl owing in from outside, the
fan may not start i mmediately when the AUTO
button is pressed.
If the interior is very warm, you can cool it down
more rapidly by partial ly opening the windows,
turning the system on AUTO, and setting the
temperature to low. Change the fresh air mode to
recirculation mode until the temperature cools down.
When you set the temperat ure to the lower or upper
limit, Lo or Hi is displayed.
Pressing the button switches the climate
control system between on and off. When turned on,
the system returns to your last selection.
Floor and
defroster
vents
Floor vents
Dashboard and floor
vents, and back of
the center console
*
Dashboard vents
and back of the
center console
*
AUTO Button
Driver’s Side
Temperature
Control Switch (Recirculation) Button
(Fan Control) Bar
A/C (Air Conditioning)
Button
Passenger’s Side
Temperature
Control Switch
* Not available on all models
14 ACURA TSX 4D-31TL16500.book 134 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
ControlsTOC

135
uu Climate Control System u Using Automatic Climate Control
Pressing the button turns the air
conditioner system on and automatically
switches the system to fresh air mode.
Press the button again to turn off, the
system returns to the previous settings.
■To rapidly defrost the windows 1.Press the button.
2. Press the button.
■Defrosting the Windshield and Windows1Defrosting the Windshield and Windows
For your safety, make sure you have a clear view
through all the windows before driving.
Do not set the temperatur e near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.
If the side windows fog up, adjust the vents so that
the air hits th e side windows.
1To rapidly defrost the windows
After defrosting or defogging the windows, switch
over to fresh air mode. If you keep the system in
recirculation mode, the windows may fog up from
humidity. This impedes visibility.
14 ACURA TSX 4D-31TL16500.book 135 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
ControlsTOC

136
uu Climate Control System u Synchronized Mode
Synchronized Mode
You can set the temperature synchronously for the driver side and the passenger
side in synchronized mode.
1. Press the SYNC button.
u The system will switch to synchronized mode.
2. Adjust the temperature using driver’s side temperature control switch.
Press the SYNC button to return to dual mode.
1Synchronized Mode
When you press the button, the system changes
to synchronized mode.
When the system is in dua l mode, the driver side
temperature and the passenger side temperature can
be set separately.
14 ACURA TSX 4D-31TL16500.book 136 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
ControlsTOC

137
uu Climate Control System u Automatic Climate Control Sensors
Automatic Climate Control Sensors
The automatic climate control system is
equipped with sensors. Do not cover or spill
any liquid on them.
Sensor
Sensor
14 ACURA TSX 4D-31TL16500.book 137 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
ControlsTOC

138
14 ACURA TSX 4D-31TL16500.book 138 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index

139
Features
This chapter describes how to operate technology features.
Audio SystemAbout Your Audio System ................ 140
USB Adapter Cable .......................... 141
Auxiliary Input Jack .......................... 142
Audio System Theft Protection ......... 142
Audio System Basic Operation Audio Remote Controls .................... 144
Adjusting the Sound ........................ 145
Playing the AM/FM Radio ................. 146
Playing the XM® Radio
..................... 148
Playing a CD .................................... 150
Playing an iPod® ............................... 153Playing a USB Flash Drive .................
156
Playing Bluetooth ® Audio................. 159
Audio Error Messages CD Player ......................................... 161
iPod ®/USB Flash Dr
ive....................... 162
General Information on the Audio System XM ® Radio Service
........................... 163
Recommended CDs ......................... 164
Compatible iPod® and USB Flash Drives .. . 166
HomeLink® Universal Transceiver
Training HomeLink ........................... 167Bluetooth
® HandsFreeLink®
Using HFL ........................................ 169
HFL Menus ...................................... 171
Compass
*..........................................181
* Not available on all models
14 ACURA TSX 4D-31TL16500.book 139 ページ ２０１３年６月１７日　月曜日　午前９時４０分
