uu Gauges and Multi-Information Display u Multi-Information Display
80
Use the multi-information display to customize certain features.
■How to customize
Press and hold the button for a few seconds while the ignition switch is in
ON
(w
.
■Customized Features1Customized Features
To customize other features, press the
button.
2 List of customizable options P. 82
2 Example for customization settings P. 84
Customization is possible when you see the driver’s
ID ( DRIVER 1 or DRIVER 2) on the CHG setting
screen.
The driver’s ID indicates which remote transmitter
you have used to unlock the driver’s door.
The customized settings are recalled every time you
unlock the driver’s door with that remote.
When you customize settings:
Shift to
(
P

Set the parking brake
Automatic transmission models
Manual transmission models
Button:
Changes the customize
menus and items
Multi-Information
Display:
Goes to customize
settings.
SEL /RESET button:
Enters the selected
item
14 ACURA TSX 4D-31TL16500.book 80 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
Instrument PanelTOC

81
uu Gauges and Multi-Information Display u Multi-Information Display
Continued
■Customization flow
CHG SETTING
Press and hold the button.
DEFAULT ALL
EXIT
METER SETUP
POSITION SETUP
LIGHTING SETUP
DOOR SETUP
ADJUST OUTSIDE TEMP. DISPLAY
LANGUAGE SELECTION
ELAPSED TIME RESET
TRIP A RESET with REFUEL
MEMORY POSITION LINK *
INTERIOR LIGHT DIMMING TIME
AUTO LIGHT SENSITIVITY
HEADLIGHT AUTO OFF TIMER
AUTO DOOR LOCK
SECURITY RELOCK TIMER
AUTO DOOR UNLOCK
DOOR LOCK MODE
KEYLESS LOCK ACKNOWLEDGMENT
SEL/RESET
Press and hold the button.
EXIT
SEL/RESET
SEL/RESET
SEL/RESET
SEL/RESET
SEL/RESET
* Not available on all models
14 ACURA TSX 4D-31TL16500.book 81 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
Instrument PanelTOC

82
uu Gauges and Multi-Information Display u Multi-Information Display
■List of customizable options
*1: Default Setting
Setup Group Customizable Features DescriptionSelectable settings
METER
SETUP
LANGUAGE SELECTIONChanges the displayed language.ENGLISH*1/FRENCH /SPANISH
ADJUST OUTSIDE TEMP.
DISPLAYAdjusts the temperature reading by a few degrees.-5°F ~ ±0°F*1 ~ +5°F (U.S.)
-3°C ~ ±0°C*1 ~ +3°C (Canada)
TRIP A RESET with
REFUELSets Trip A and the average fuel economy to reset
when you refuel.ON/OFF*1
ELAPSED TIME RESETChanges the resetting conditions of the elapsed
time.IGN OFF*1/TRIP A /TRIP B
POSITION
SETUPMEMORY POSITION
LINK *Changes the driver’s seat position to a stored
setting.ON*1/OFF
LIGHTING
SETUP
INTERIOR LIGHT
DIMMING TIMEChanges the length of time the interior lights stay
on after you close the doors.60sec /30sec*1/15sec
HEADLIGHT AUTO OFF
TIMER Changes the length of time the exterior lights stay
on after you close the driver’s door.
60sec
/30sec /15sec
*1/ 0sec
AUTO LIGHT
SENSITIVITY Changes the timing for the headlights to come on.
MAX/HIGH /MID
*1/LOW /MIN
* Not available on all models
14 ACURA TSX 4D-31TL16500.book 82 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
Instrument PanelTOC

83
uu Gauges and Multi-Information Display u Multi-Information Display
Continued
*1: Default Setting
*2: Default Setting for automatic transmission
*3: Default Setting for manual transmission
Setup Group Customizable Features DescriptionSelectable settings
DOOR
SETUP
AUTO DOOR LOCKChanges the setting for the automatic locking
feature.OFF/ WITH VEH SPD*1/SHIFT
FROM P (A/T only)
AUTO DOOR UNLOCKChanges the setting for when the doors unlock
automatically.
OFF/DRIVER DOOR With
SHIFT to P*2 (A/T only)/ ALL
DOORS With SHIFT to P (A/T
only)/ DRIVER DOOR With IGN
OFF
*3/ ALL DOORS With IGN
OFF
DOOR LOCK MODESets up either the driver’s door or all doors to unlock
on the first push of the remote.DRIVER DOOR*1/ ALL DOORS
KEYLESS LOCK
ACKNOWLEDGMENTLOCK/UNLOCK - The exterior lights flash LOCK (2nd
push) - The beeper soundsON*1/OFF
SECURITY RELOCK
TIMERChanges the time it takes fo r the doors to relock and
the security system to set after you unlock the
vehicle without opening any door.
90sec /60sec /30sec*1
DEFAULT ALLSets/Cancels all the customized settings as default.SET/ CANCEL
14 ACURA TSX 4D-31TL16500.book 83 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
Instrument PanelTOC

84
uu Gauges and Multi-Information Display u Multi-Information Display
■Example for customization settings
The steps for changing the TRIP A RESET with REFUEL setting to ON are shown
below. The default setting for TRIP A RESET with REFUEL is OFF.
1. Press and hold the button until
CHG SETTING appears on the display.
2. Press the SEL /RESET button to go into the
METER SETUP group.
3. Press the SEL /RESET button again.
u LANGUAGE SELECTION appears first in
the display.
14 ACURA TSX 4D-31TL16500.book 84 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
Instrument PanelTOC

85
uu Gauges and Multi-Information Display u Multi-Information Display
4. Press the button until TRIP A
RESET with REFUEL appears on the
display, then press the SEL/RESET button.
u The display swit ches to the
Customization setup screen, where you
can select ON, OFF , or EXIT .
5. Press the button and select ON,
then press the SEL/RESET button.
u The ON setup screen appears, then the
display returns to the Customization
menu screen.
6. Press the button until EXIT
appears in the display, then press the SEL/
RESET button.
7. Repeat step 6 until you retu rn to the
normal screen.
14 ACURA TSX 4D-31TL16500.book 85 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
Instrument PanelTOC

86
14 ACURA TSX 4D-31TL16500.book 86 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index

87
Controls
This chapter explains how to operate the various controls necessary for driving.
Setting the Clock................................ 88
Locking and Unlocking the Doors
Key Types and Functions .................... 89
Locking/Unlocking the Doors from the Outside ............................................ 91
Locking/Unlocking the Doors from the Inside ............................................... 93
Childproof Door Locks ....................... 95
Auto Door Lock/Unlock ...................... 95
Opening and Closing the Trunk ......... 96
Security System .................................. 99
Immobilizer System ............................ 99
Security System Alarm ........................ 99
Opening and Closing the Windows ... 101 Opening and Closing the Moonroof
.. 104
Operating the Switches Around the
Steering Wheel Ignition Switch ................................. 105
Turn Signals ..................................... 106
Light Switches.................................. 106
Fog Lights ........................................ 108
Daytime Running Lights (DRL) .......... 108
Wipers and Washers ........................ 109
Brightness Control ........................... 110
Rear Defogger/Heated Door Mirror
Button........................................ 111
Driving Position Memory System *....112
Adjusting the Steering Wheel........... 114 Adjusting the Mirrors
....................... 115
Interior Rearview Mirror ................... 115
Power Door Mirrors ......................... 115
Adjusting the Seats .......................... 117
Adjusting the Seat Positions ............. 117
Interior Lights/Interior Convenience Items .............. .................................. 126
Interior Lights .................................. 126
Interior Convenience Items .............. 127
Climate Control System ................... 134
Using Automatic Climate Control .... 134
Automatic Climate Control Sensors ... 137
* Not available on all models
14 ACURA TSX 4D-31TL16500.book 87 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index 2014 TSX

88
Controls
Setting the Clock
Clock
You can adjust the time in the clock display, using the CLOCK button.
1. Press the MENU button.
2. Rotate to select CLOCK ADJUST in
the display.
3. Press . CLOCK ADJUST appears.
4. Rotate to select the item you want to
adjust (12/24 hour mode, hour, minute).
Then press .
5. Rotate to make the adjustment.
6. Press to enter your selection. The display
returns to CLOCK ADJUST . Repeat steps 4
to 6 to adjust other items.
7. To enter the selection, Rotate and select
SET , then press .
8. Press the MENU button to go back to the
normal display.
■Adjusting the Time
1 Clock
You can switch the clock display between 24 hours
and 12 hours when in the menu mode.
Selector Knob Icon details
Rotate to select.
Press to enter.
To set the time to the nearest hour:
Press and hold the CLOCK button until the clock
display begins to blink, then press the
(
3
(Reset)
button.
Depending on the displayed time, the clock sets
forward or backward.
Example:
1:06 will reset to 1:00
1:53 will reset to 2:00
The clock is automatica lly updated through the
navigation system, so the ti me does not need to be
adjusted.
Models with navigation system
Models without navigation system
Menu Button
12/24 Hour Mode
Hour Setting Minute Setting
14 ACURA TSX 4D-31TL16500.book 88 ページ ２０１３年６月１７日　月曜日　午前９時４０分
QRG
Index
TOC

89Continued
Locking and Unlocking the Doors
Key Types and Functions
This vehicle comes with the following keys:
Use the key to start and stop the engine, and
to lock and unlock all the doors, trunk, and
fuel fill door. You can also use the remote
transmitter to lock and unlock the doors,
trunk, and fuel fill door.
The master key folds up inside the
remote transmitter.
1.Press the release button to release the key
out from the transmitter.
u Make sure to fully extend the key.
2. To close the key, press the release button
then push the key inside the transmitter
until you hear a click.
■Retractable Master Keys
1Key Types and Functions
All the keys have an immobilizer system. The
immobilizer system helps to protect against vehicle
theft. 2 Immobilizer System P. 99
The keys contain precision electronics.
Adhere to the following advi ce to prevent damage to
the electronics:
•Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.
•Do not drop the keys or set heavy objects on them.
•Keep the keys away from liquids.
•Do not take the keys apart except for replacing the
battery.
If the circuits in the keys are damaged, the engine
may not start, and the remote transmitter may not
work.
If the keys do not work properly, have them
inspected by a dealer.
If the key is not fully extended, the immobilizer
system may not work prope rly, and the engine may
not start.
Avoid contact with the key whenever it extends or
retracts.
Panic Button Trunk Button
Lock
Button
Release Button Unlock
Button
Release Button
Press
