The primary under-hood fuse box is
on the passenger's side. The
secondary fuse box is located next to
the battery.
To open it, push the tabs as shown.Checking and Replacing Fuses
If something electrical in your
vehicle stops working, the first thing
you should check for is a blown fuse.
Determine from the chart on pages
599, 600, and 601, or the diagram on
the fuse box lid, which fuse or fuses
control that device. Check those
fuses first, but check all the fuses
before deciding that a blown fuse is
the cause. Replace any blown fuses,
and check if the device works.
1. Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are off.
Models equipped with the keyless
access system have an engine
start/stop button instead of an
ignition switch. VEHICLE OFF
(LOCK) mode is the equivalent of
LOCK (0). See page 196 for
ignition switch and power mode
comparison.
2. Remove the cover from the fusebox.
3. Check each of the large fuses in the under-hood fuse boxes by
looking through the top at the wire
inside. Removing these fuses
requires a Phillips-head
screwdriver.FUSE BLOWN
Fuses59609/10/28 17:15:37 10 ACURA ZDX KA KC New North America Own 50 31SZN600 enu
ProCarManuals.com

13 20 A Rear Seat Heaters
14 20 A Sunshade
15 20 A Power Tailgate Closer
16－ Not Used
17 － Not Used
18 － Not Used
19 － Not Used
20 － Not Used
21 － Not Used
22 － Not Used
INTERIOR FUSE BOX (Driver's Side)No. Amps. Circuits Protected
1 7.5 A Front Seat Heaters and Seat Ventilation/Blind Spot
Information
ꭧ1
2 7.5 A SH-AWD/Headlight Adjuster
3 20 A Washer
4 7.5 A Wiper
5 7.5 A OPDS
6 7.5 A VSA
7 － Not Used
8 7.5 A STRLD
9 20 A Fuel Pump
10 10 A VB Solenoid 11 10 A SRS
12 7.5 A Meter
13 15 A ACG
14
－ Not Used
15 7.5 A Daytime Running Lights
16 7.5 A Climate Control System
17 7.5 A Accessory Key Lock
ꭧ 2
18 7.5 A Accessory
19 20 A Left Power Seat Slide
20 20 A Panoramic Glass Roof
21 20 A Left Power Seat Reclining
22 20 A Rear Left Power Window
23 15 A Accessory Power Socket
(Console Box)
24 20 A Left Front Power Window
25 15 A Left Door Lock
26 10 A Left Front Fog Light
27 10 A Left Small Light (Exterior)
28 10 A Left Daytime Running Light
29 7.5 A TPMS
30 15 A Left Headlight
31 － Not Used
32 7.5 A STS
ꭧ 2
ꭧ1: On U.S. ADVANCE and Canadian ELITE
models
ꭧ 2: On BASE model
Fuse Locations60009/10/28 17:15:37 10 ACURA ZDX KA KC New North America Own 50 31SZN600 enu
