TPMS Acura ZDX 2013 User Guide

211
uuWhen DrivinguTire Pressure Monitoring System (TPMS) - Required Federal Explanation
Driving
Please note that the TPMS is not a substitute for proper tire
maintenance, and it is the driver’s responsibility to maintain
correct tire pressure, even if under-inflation has not reached the
level to trigger illumination of the TPMS low tire pressure telltale.
Your vehicle has also been equipped with a TPMS malfunction
indicator to indicate when the system is not operating properly.
The TPMS malfunction indicator is combined with the low tire
pressure telltale. When the system detects a malfunction, the
telltale will flash for approximately one minute and then remain
continuously illuminated. This sequence will continue upon
subsequent vehicle start-ups as long as the malfunction exists.
When the malfunction indicator is illuminated, the system may
not be able to detect or signal low tire pressure as intended.
TPMS malfunctions may occur for a variety of reasons, including
the installation of replacement or alternate tires or wheels on the
vehicle that prevent the TPMS from functioning properly.
Always check the TPMS malfunction telltale after replacing one or
more tires or wheels on your vehicle to ensure that the
replacement or alternate tires and wheels allow the TPMS to
continue to function properly.

264
uuChecking and Maintaining TiresuTire and Wheel Replacement
Maintenance
Tire and Wheel ReplacementReplace your tires with radials of the same size, load range, speed rating, and
maximum cold tire pressure rating (as shown on the tire’s sidewall). Using tires of a
different size or construction can cause the ABS and VSA® (vehicle stability assist)
system to work incorrectly.
It is best to replace all four tires at the same time. If that isn’t possible, replace the
front or rear tires in pairs.
Make sure that the wheel’s specifications match those of the original wheels.
If you replace a wheel, only use TPMS specified wheels approved for your vehicle.
1Tire and Wheel Replacement
3
WARNING
Installing improper tires on your vehicle can
affect handling and stability. This can cause
a crash in which you can be seriously hurt or
killed.
Always use the size and type of tires
recommended in this owner’s manual.

275
Handling the Unexpected
This chapter explains how to handle unexpected troubles.
Tools
Types of Tools .................................. 276
If a Tire Goes Flat
Changing a Flat Tire ......................... 277
Engine Does Not Start
Checking the Engine ........................ 284If the Keyless Access Remote Battery is
Weak ..........................................285Emergency Engine Stop ................... 286
Jump Starting.................................... 287
Shift Lever Does Not Move.............. 289Overheating
How to Handle Overheating............. 290
Indicator, Coming On/Blinking
If the Low Oil Pressure Indicator Comes
On ............................................. 292If the Charging System Indicator Comes
On ................................................. 292
If the Malfunction Indicator Lamp Comes
On or Blinks ................................... 293If the Brake System Indicator (Red)
Comes On .................................. 294
If the Low Tire Pressure/TPMS Indicator
Comes On or Blinks ....................... 294
Fuses
Fuse Locations ................................. 295Circuit Protected and Amps for Each
Fuse............................................ 297Inspecting and Changing Fuses ........ 300
Emergency Towing........................... 301
When You Cannot Unlock the Fuel Fill
Door................................................. 302
When You Cannot Open or Close the
Tailgate............................................ 303

283
uuIf a Tire Goes FlatuChanging a Flat Tire
Handling the Unexpected
1.Remove the center cap and place the flat
tire face up under the hoist.
2.Insert the hoist bracket into the center hole
of the flat tire.
3.Turn the extension bar with the wheel nut
wrench clockwise until the flat tire rests
against the underbody of the vehicle and
you hear the hoist click.
4.Securely put the jack and wheel nut wrench
back in the tool case. Store the case in the
cargo area.
If you replace a flat tire with the spare tire, the low tire pressure/TPMS indicator
comes on while you are driving. After driving for a few miles (kilometers), the
indicator will start blinking for a short time and then stay on. CHECK TPMS
SYSTEM appears on the multi-information display, but this is normal.
If you replace the tire with a specified regular tire, the warning message on the
multi-information display and the TPMS indicator will go off after a few miles
(kilometers).
■Storing the Flat Tire
1Storing the Flat Tire
Always raise the spare tire hoist, even if you are not
stowing a tire. If the hoist is left down, it will be
damaged during driving and need to be replaced.
3
WARNING
Loose items can fly around the interior in a
crash and can seriously injure the
occupants.
Store the wheel, jack, and tools securely
before driving.
Extension Bar
Wheel Nut
Wrench
■TPMS and the Spare Tire
1TPMS and the Spare Tire
The system cannot monitor the pressure of the spare
tire. Manually check the spare tire pressure to be sure
that it is correct.
Use TPMS specific wheels. Each is equipped with a
tire pressure sensor mounted inside the tire behind
the valve stem.

294
uuIndicator, Coming On/BlinkinguIf the Brake System Indicator (Red) Comes On
Handling the Unexpected
If the Brake System Indicator (Red) Comes On
■Reasons for the indicator to come on
•The brake fluid is low.
•There is a malfunction in the brake system.■What to do when the indicator comes on while driving
Press the brake pedal lightly to check pedal pressure.
•If normal, check the brake fluid level the next time you stop.
•If abnormal, take immediate action. If necessary, downshift the
transmission to slow the vehicle using engine braking.
If the Low Tire Pressure/TPMS Indicator Comes On or Blinks
■Reasons for the indicator to come on or blink
A tire pressure is significantly low. If there is a problem with the TPMS or
the compact spare tire is installed, the indicator blinks for about one
minute, and then stays on.■What to do when the indicator comes on
Stop your vehicle in a safe place. Check the tire pressure and adjust the
pressure to the specified level. The specified tire pressure is on a label on
the driver side doorjamb.■What to do when the indicator blinks
Have the tire inspected by a dealer as soon as possible. If the compact
spare tire causes the indicator to blink, change the tire to a full-size tire.
The indicator goes off after driving for a few miles (kilometers).
1If the Brake System Indicator (Red) Comes On
Have your vehicle repaired immediately.
It is dangerous to drive with low brake fluid. If there
is no resistance from the brake pedal, stop
immediately in a safe place. If necessary downshift
the gears.
If the brake system indicator and ABS indicator come
on simultaneously, the electronic brake distribution
system is not working. This can result in vehicle
instability under sudden braking.
Have your vehicle inspected by a dealer immediately.
U.S.
Canada
1If the Low Tire Pressure/TPMS Indicator Comes On or BlinksNOTICEDriving on an extremely underinflated tire can cause
it to overheat. An overheated tire can fail. Always
inflate your tires to the prescribed level.

298
uuFusesuCircuit Protected and Amps for Each Fuse
Handling the Unexpected
■Secondary Engine
Compartment
Circuits Protected
Amps.
1
VSA Motor
40 A
2
VSA FSR
20 A
3
−
−
4
−
−
5
SH-AWD
30 A
6
Power Tailgate Motor
40 A
7
Tilt Steering Wheel
20 A
8
Telescopic Steering Wheel
20 A
9
Hazard
15 A
10
Headlight Hi/Lo Solenoid
7.5 A
11
Power Management System
7.5 A
12
Keyless Access System
7.5 A
13
Rear Seat Heaters
20 A
14
Sunshade
20 A
15
Power Tailgate Closer
20 A
16
−
−
17
−
−
18
−
−
19
−
−
20
−
−
21
−
−
22
−
−
■Driver Side Interior
Circuits Protected
Amps.
1
Front Seat Heaters and Seat
Ventilation/Blind Spot
Information
(7.5 A)
2
SH-AWD/Headlight
Adjuster
7.5 A
3
Washer
20 A
4
Wiper
7.5 A
5
OPDS
7.5 A
6
VSA
7.5 A
7
−
−
8
STRLD
7.5 A
9
Fuel Pump
20 A
10
VB Solenoid
10 A
11
SRS
10 A
12
Meter
7.5 A
13
ACG
15 A
14
−
−
15
Daytime Running Lights
7.5 A
16
Climate Control System
7.5 A
17
−
(7.5 A)
18
Accessory
7.5 A
19
Left Power Seat Slide
20 A
20
Panoramic Glass Roof
20 A
21
Left Power Seat Reclining
20 A
22
Rear Left Power Window
20 A
23
Accessory Power Socket
(Console Box)
15 A
24
Left Front Power Window
20 A
25
Left Door Lock
15 A
26
Left Front Fog Light
10 A
27
Left Small Light (Exterior)
10 A
28
Left Daytime Running Light
10 A
29
TPMS
7.5 A
30
Left Headlight
15 A
31
−
−
32
STS
*
7.5 A
Circuits Protected
Amps.
* Not available on all models

308Information
Devices that Emit Radio WavesThe following products and systems on your vehicle emit radio waves when in operation.Each of the above complies with the appropriate requirements or the required
standards of FCC (Federal Communications Commission) and Industry Canada
Standard, described below:
As required by the FCC:This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Industry Canada Standard RSS-Gen/210/310. Operation is
subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.U.S. AcuraLinkBlind Spot InformationBluetooth® HandsFreeLink®HomeLink® Universal TransceiverImmobilizer SystemKeyless Access SystemRemote TransmitterTire Pressure Monitoring System (TPMS)

319Index
ABS (Anti-lock Brake System) .................... 70
BSI (Blind Spot Information) ...................... 76
Charging System............................... 67, 292
CRUISE CONTROL ............................. 75, 194
CRUISE MAIN.................................... 75, 193
Door and Tailgate Open ...................... 26, 71
Fog Light .................................................. 73
Forward Collision Warning (FCW) ............. 77
High-Beam................................................ 73
Immobilizer System ................................... 74
Keyless Access System............................... 75
Lane Departure Warning (LDW) ................ 78
Lights On .................................................. 73
Low Fuel ................................................... 69
Low Oil Pressure ............................... 66, 292
Low Tire Pressure/TPMS ............ 72, 208, 210
Malfunction Indicator Lamp .............. 67, 293
Parking Brake and Brake System ....... 66, 294
Seat Belt Reminder.............................. 28, 69
Security System Alarm............................... 75
SH-AWD®......................................... 76, 204
Shift Position............................................. 68
Side Airbag Off ................................... 47, 74
Supplemental Restraint System ........... 45, 70
System Message ....................................... 72
Transmission ............................................. 68
Turn Signal ............................................... 73
VSA® (Vehicle Stability Assist)
System ............................................ 71, 202
VSA® OFF.......................................... 71, 203
Information.............................................. 305Information Buttons................................... 87
Instant Fuel Economy................................. 90
Instrument Panel........................................ 65
Brightness Control ................................... 137
Interior Lights........................................... 152
Interior Rearview Mirror.......................... 142
JJack (Wheel Nut Wrench)........................ 281
Jump Starting........................................... 287KKey Number Tag....................................... 107
Keyless Access System............................... 109
Keyless Lockout Prevention..................... 111
Keys........................................................... 106
Lockout Prevention .................................. 111
Number Tag ............................................ 107
Rear Door Won’t Open ............................ 114
Remote Transmitter ................................. 108
Types and Functions ................................ 106
Kickdown.................................................. 188
LLane Departure Warning (LDW)............. 199
LATCH (Child Seats).................................... 54
Lights................................................. 132, 249
Automatic ............................................... 133
Bulb Replacement ................................... 249
Daytime Running Lights........................... 134
Fog Lights ............................................... 134
High-Beam Indicator.................................. 73
Interior .................................................... 152
Light Switches ......................................... 132
Lights On Indicator .................................... 73
Turn Signals ............................................ 132
Load Limits................................................ 175
Locking/Unlocking.................................... 106
Auto Door Locking/Unlocking.................. 115
Childproof Door Locks............................. 114
From Inside ............................................. 113
From Outside .......................................... 108
Keys ........................................................ 106
Using a Key ..................................... 109, 111
Lockout Prevention System..................... 111
Low Battery Charge................................. 292
Low Fuel Indicator...................................... 69
Low Oil Pressure Indicator................. 66, 292
Lower Anchors............................................ 54
Luggage (Maximum Load Limit)............. 175

321Index
Replacement
Battery .................................................... 268
Bulbs ...................................................... 249
Fuses ...................................................... 295
Tires........................................................ 264
Wiper Blade Rubber ................................ 256
Reporting Safety Defects......................... 309
Resetting a Trip Meter............................... 89
Reverse Tilt Door Mirror.......................... 143SSafe Driving................................................ 21
Safety Check............................................... 26
Safety Labels.............................................. 64
Safety Message.......................................... 19
Seat Belts.................................................... 27
Adjusting the Shoulder Anchor ................. 31
Automatic Seat Belt Tensioners ................. 29
Checking .................................................. 33
Fastening .................................................. 30
Installing a Child Seat with a Lap/
Shoulder Seat Belt ................................... 57
Pregnant Women...................................... 32
Reminder .................................................. 28
Warning Indicator ............................... 28, 69
Seat Heaters..................................... 161, 162
Seats.......................................................... 144
Adjusting ................................................ 144
Front Seats.............................................. 144
Rear Seats ............................................... 150Seat Heaters .................................... 161, 162
Security System......................................... 122
Immobilizer System Indicator ..................... 74
Security System Alarm Indicator ................. 75
SEL/RESET Button........................................ 87
Select Lever......................................... 12, 189
Operation .......................... 12, 190, 191, 192
Releasing ................................................. 289
Won’t Move ............................................ 289
Selecting a Child Seat................................. 53
Sequential Shift Mode............................. 191
Setting the Clock.......................................... 9
SH-AWD®................................................... 204
Indicator .................................................... 76
Shift Lever........................................... 12, 189
Shift Position Indicator....................... 68, 190
Shifting...................................................... 189
Shoulder Anchor......................................... 31
Side Airbags................................................ 41
Cutoff System ........................................... 43
Off Indicator .............................................. 43
Side Curtain Airbags................................... 44
Side Storage Compartment..................... 156
Snow Tires................................................. 266
Spare Tire.......................................... 277, 306
Spark Plugs................................................ 306
Specifications............................................ 306
Specified Fuel.................................... 221, 306
Speedometer.............................................. 86
SRS Airbags (Airbags)................................. 37Starting the Engine.................................. 185
Does Not Start......................................... 284
Jump Starting .......................................... 287
Steering Wheel......................................... 141
Adjusting ................................................ 141
Stopping................................................... 216
Super Handling-All Wheel Drive
TM (SH-AWD®)
System..................................................... 204
Supplemental Restraint System (SRS)........ 37
Switches (Around the Steering
Wheel)............................................. 2, 3, 129
SYNC Mode............................................... 165
System Message Indicator.......................... 72
TTachometer................................................. 86
Tailgate..................................................... 116
Unable to Open....................................... 303
Temperature
Outside Temperature Display ..................... 89
Temperature Sensor................................. 166
Time (Setting)............................................... 9
Tire Pressure Monitoring System
(TPMS)..................................................... 208
Indicator............................................ 72, 294

322Index
Tires........................................................... 258
Air Pressure ..................................... 259, 306
Checking and Maintaining ....................... 258
Compact Spare Tire ................................. 277
Inspection ................................................ 258
Labeling................................................... 259
Puncture (Flat Tire) ................................... 277
Regulations.............................................. 261
Rotation .................................................. 265
Tire Chains .............................................. 266
Wear Indicators ....................................... 263
Winter ..................................................... 266
Tools.......................................................... 276
Towing a Trailer........................................ 177
Equipment and Accessories...................... 178
Load Limits .............................................. 177
Towing Your Vehicle................................ 181
Emergency............................................... 301
TPMS (Tire Pressure Monitoring
System).................................................... 208
Indicator ............................................ 72, 294
Transmission.............................................. 189
Automatic ............................................... 189
Fluid ........................................................ 245
Number ................................................... 307
Sequential Shift Mode ............................. 191
Shift Position Indicator ....................... 68, 190
Trip Meter................................................... 89Troubleshooting....................................... 275
Blown Fuse.............................................. 295
Brake Pedal Vibrates .................................. 16
Buzzer Sounds When Opening Door.......... 17
Emergency Towing .................................. 301
Engine Won’t Start .................................. 284
Noise When Braking .................................. 17
Overheating ............................................ 290
Premium Gasoline ........................... 221, 306
Puncture/Flat Tire .................................... 277
Rear Door Won’t Open...................... 16, 114
Select Lever Won’t Move ......................... 289
Warning Indicators .................................... 66
Turn Signals.............................................. 132
Indicators (Instrument Panel) ..................... 73
UUnder-floor Storage Area........................ 156
Unlocking the Doors................................ 108VVanity Mirrors............................................... 5
Vehicle Identification Number................ 307
Vehicle Stability Assist (VSA®).................. 202
Off Button............................................... 203
Off Indicator.............................................. 71
System Indicator ........................................ 71
Viscosity (Oil).................................... 238, 306
VSA® (Vehicle Stability Assist).................. 202
WWarning and Information Messages........ 79
Warning Indicator On/Blinking............... 292
Warning Labels.......................................... 64
Warranties (Warranty Manual provided
separately).............................................. 312
Watts........................................................ 306
Wear Indicators (Tire).............................. 263
Wheel Nut Wrench (Jack Handle)........... 281
Window Washers..................................... 135
Adding/Refilling Fluid .............................. 248
Switch .................................................... 135
Windows (Opening and Closing)............ 125
Windshield............................................... 135
Cleaning ................................................. 273
Washer Fluid ........................................... 248
Wiper Blades........................................... 256
Wipers and Washers ............................... 135
Winter Tires.............................................. 266
Snow Tires .............................................. 266
Tire Chains.............................................. 266
Wipers and Washers................................ 135
Checking and Replacing Wiper Blades..... 256
Worn Tires................................................ 258
