set clock Acura ZDX 2013 Owner's Manual

267Maintenance
BatteryChecking the BatteryCheck the battery condition monthly. Look at the test indicator window and check
the terminals for corrosion.
If your vehicle’s battery is disconnected or goes dead:
•The audio system is disabled.
2Refer to the Navigation Manual
•The clock resets.
2Refer to the Navigation Manual
•The navigation system is disabled. A PIN code will be required.
2Refer to the Navigation Manual
Charging the BatteryDisconnect both battery cables to prevent damaging your vehicle’s electrical system.
Always disconnect the negative (–) cable first, and reconnect it last.
1BatteryWARNING: Battery post, terminals,
and related accessories contain lead
and lead compounds.
Wash your hands after handling.When you find corrosion, clean the battery terminals
by applying a baking powder and water solution.
Clean terminals with a damp towel. Cloth/towel dry
the battery. Coat the terminals with grease to help
prevent future corrosion.
3
WARNING
The battery gives off explosive hydrogen
gas during normal operation.
A spark or flame can cause the battery to
explode with enough force to kill or
seriously hurt you.
When conducting any battery
maintenance, wear protective clothing and
a face shield, or have a skilled technician do
it.

Continued
281
uuIf a Tire Goes FlatuChanging a Flat Tire
Handling the Unexpected
1.Place the jack under the jacking point
closest to the tire to be changed.
2.Turn the end bracket (as shown in the
image) clockwise until the top of the jack
contacts the jacking point.
uMake sure that the jacking point tab is
resting in the jack notch.
3.Raise the vehicle, using the jack handle bar
and the jack handle, until the tire is off the
ground.
■How to Set Up the Jack
1How to Set Up the Jack
Do not use the jack with people or luggage in the
vehicle.
Use the jack provided in your vehicle.
Other jacks may not support the weight (“load”) or
their shape may not match.
The following instructions must be followed to use
the jack safely.•Do not use while the engine is running.•Use only where the ground is firm and level.•Use only at the jacking points.•Do not get in the vehicle while using the jack.•Do not put anything on top of or underneath the
jack.
3
WARNING
The vehicle can easily roll off the jack,
seriously injuring anyone underneath.
Follow the directions for changing a tire
exactly, and never get under the vehicle
when it is supported only by the jack.
Jack Handle Bar
Wheel Nut
Wrench as Jack Handle

321Index
Replacement
Battery .................................................... 268
Bulbs ...................................................... 249
Fuses ...................................................... 295
Tires........................................................ 264
Wiper Blade Rubber ................................ 256
Reporting Safety Defects......................... 309
Resetting a Trip Meter............................... 89
Reverse Tilt Door Mirror.......................... 143SSafe Driving................................................ 21
Safety Check............................................... 26
Safety Labels.............................................. 64
Safety Message.......................................... 19
Seat Belts.................................................... 27
Adjusting the Shoulder Anchor ................. 31
Automatic Seat Belt Tensioners ................. 29
Checking .................................................. 33
Fastening .................................................. 30
Installing a Child Seat with a Lap/
Shoulder Seat Belt ................................... 57
Pregnant Women...................................... 32
Reminder .................................................. 28
Warning Indicator ............................... 28, 69
Seat Heaters..................................... 161, 162
Seats.......................................................... 144
Adjusting ................................................ 144
Front Seats.............................................. 144
Rear Seats ............................................... 150Seat Heaters .................................... 161, 162
Security System......................................... 122
Immobilizer System Indicator ..................... 74
Security System Alarm Indicator ................. 75
SEL/RESET Button........................................ 87
Select Lever......................................... 12, 189
Operation .......................... 12, 190, 191, 192
Releasing ................................................. 289
Won’t Move ............................................ 289
Selecting a Child Seat................................. 53
Sequential Shift Mode............................. 191
Setting the Clock.......................................... 9
SH-AWD®................................................... 204
Indicator .................................................... 76
Shift Lever........................................... 12, 189
Shift Position Indicator....................... 68, 190
Shifting...................................................... 189
Shoulder Anchor......................................... 31
Side Airbags................................................ 41
Cutoff System ........................................... 43
Off Indicator .............................................. 43
Side Curtain Airbags................................... 44
Side Storage Compartment..................... 156
Snow Tires................................................. 266
Spare Tire.......................................... 277, 306
Spark Plugs................................................ 306
Specifications............................................ 306
Specified Fuel.................................... 221, 306
Speedometer.............................................. 86
SRS Airbags (Airbags)................................. 37Starting the Engine.................................. 185
Does Not Start......................................... 284
Jump Starting .......................................... 287
Steering Wheel......................................... 141
Adjusting ................................................ 141
Stopping................................................... 216
Super Handling-All Wheel Drive
TM (SH-AWD®)
System..................................................... 204
Supplemental Restraint System (SRS)........ 37
Switches (Around the Steering
Wheel)............................................. 2, 3, 129
SYNC Mode............................................... 165
System Message Indicator.......................... 72
TTachometer................................................. 86
Tailgate..................................................... 116
Unable to Open....................................... 303
Temperature
Outside Temperature Display ..................... 89
Temperature Sensor................................. 166
Time (Setting)............................................... 9
Tire Pressure Monitoring System
(TPMS)..................................................... 208
Indicator............................................ 72, 294
