HEADLIGHT CORRECTOR (fig. 121)
If the car is fitted with xenon headlights,
beam aiming is electronic and therefore con-
trol (A) on the mask near the steering col-
umn is not present.
The headlights should be aimed correctly
depending on the vehicle load.
The control (A) on the plate at the side of
the steering column can be moved to four
positions corresponding to the vehicle loads
given below:
position 0: 1 or 2 people occupying front
seats, full fuel tank, on-board equipment pre-
sent;
position 1: 5 people on-board;fig. 121
A0B0240m
HAND BRAKE
(fig. 122)
The hand brake lever is located between
the two front seats.
To operate the brake when the vehicle is
“stationary”, pull the lever (A) upwards un-
til the required braking action is obtained.
When the ignition key is in the MARpo-
sition, the
x
warning light will come on on
the instrument panel.
fig. 122
A0B0288m
position 2: 5 people on-board, luggage
compartment full (50 kg approximately);
position 3: Driver and 300 kg in luggage
compartment.
Check the positioning of
the headlight beams every
time you change the load to be car-
ried.
WARNING

GETTING TO KNOW YOUR CAR
143
SYSTEM ACTIVATIONWARNINGOpening the driver’s door,
the Selespeed starts the hydraulic part of
the system to prepare it for the engine to be
started. This function (noted by the turning
of the electric pump) is deactivated after 10
openings/closings of the door that are not
followed by actual system activation using
the ignition key.
Turning the ignition key to MAR, all the
segments of the display (A-fig. 126), the
gearbox failure warning light (B-fig. 126)
and the word CITYlight up. After about one
second, the display indicates the gear en-
gaged (N, 1, 2, 3, 4, 5, R); from this mo-
ment, the Selespeed system accepts
gearshift commands.
WARNINGIf after 10 seconds the dis-
play segment do not display the gear en-
gaged or the failure warning light stays on,
turn the ignition key to STOPand wait for
the display to go off, then repeat the sys-
tem activation procedure. If the fault per-
sists, contact Alfa Romeo Authorized Ser-
vices
OPERATION WITH THE
ENGINE OFFWARNINGBefore operating the gear-
shift control lever, always check the gear en-
gaged on the display (N, 1, 2, 3, 4, 5, R).
When the engine is off and the vehicle is
stationary, it is possible to engage all the
gears.
With the vehicle stationary and with the
brake pedal pressed, requests to shift gear
are accepted onlyif they are carried out
through the control lever on the central con-
sole.To request gearshifting, in addition to keep-
ing the brake pedal pressed it is necessary to:
– to increase gear (+) (fig. 127) push
the lever “forwards” (if the car is in first gear
this shifts to second, if it is in second gear
it goes to third and so on up to fifth). If the
system is in neutral (N) or reverse (R) the
forward movement on the lever causes en-
gagement of first gear (1).
– to shift down (–) (fig. 127) push the
lever backwards (if the car is in fifth gear
it moves to fourth, if fourth gear is engaged
it shifts to third and so on down to first).
fig. 127
A0B0272m

GETTING TO KNOW YOUR CAR
145
STARTING THE ENGINEThe engine can be started with the gear
engaged or in neutral (N), provided that the
brake pedal is pressed down.
WARNINGKeep the brake pedal
pressed during the starting operation. As the
brake pedal stiffens if it is pressed repeat-
edly with the engine off, in this situation, to
allow the engine to be started, it is neces-
sary to increase the pressure exerted on the
pedal itself.
After starting, the gearbox automatically
sets to neutral, the display shows the let-
ter (N) and the system selects the operat-
ing mode stored before switching off.
TURNING THE ENGINE OFF
AND SYSTEM DEACTIVATIONTurning the ignition key to STOPthe en-
gine switches off but the Selespeed system
still remains active, waiting for the vehicle
to stop completely. After about 2 - 4 seconds
from when the key has been turned to the
STOPposition, the hydraulic part is deac-
tivated and immediately afterwards the dis-
play on the rev counteralso goes out ; the
Selespeed system is only deactivated at this
point.
The gear selected before turning the en-
gine off remains engaged.
If the engine stops with the gearbox in
neutral (N), the buzzer draws the attention
of the driver so that the vehicle can be put
in safety conditions engaging the first gear
(1) or reverse (R). In this case, it is nec-
essary to turn the ignition key to MARand
with the brake pedal pressed, engage first
gear (1) or reverse (R).
If the engine fails to start
with the gear engaged, the
driver is alerted of the potentially
dangerous situation due to the fact
that the gearbox has automatically
set to neutral by the buzzer and
the display on the rev counter.
WARNING
NEVER leave the car with
the gearbox in neutral (N).
WARNING
Never remove the key
when the car is on the
move, because in addition to the
fact that the Selespeed system
would not work properly until
stopping the car, the steering
wheel would automatically lock at
the first turn.
WARNING
It is absolutely necessary
to turn off the engine con-
sequently deactivating the Sele-
speed system keeping the brake
pedal pressed: release the pedal
ONLY when the display on the rev
counter goes off.
WARNING

GETTING TO KNOW YOUR CAR
150
AUTOMATIC OPERATION (CITY)The CITYautomatic operating mode is se-
lected pressing the button (A-fig. 132),
at the base of the gearshift lever.
In addition to the gear, the display on the
rev counter will show the word CITY.
The system decides directly when gearshift-
ing according to the engine running speed
and the driving style.
Quickly releasing the accelerator pedal, the
system does not engage a higher gear in or-
der to maintain an adequate level of engine
brake.
FAILURE SIGNALLINGFailures to the Selespeed gearbox are in-
dicated by the
t
(A-fig. 133) warn-
ing light on the instrument cluster.
When the system is turned on (turning the
ignition key to MAR), the warning light
should turn on glowing steadily for about
4 seconds and then turn off.
If the warning light stays on it means that
a fault to the gearbox has been detected; at
the same time a buzzer sounds intermit-
tently for 4 seconds to attract the driver's
attention.In the case of a fault to the gearshift lever,
the system automatically activates the au-
tomatic CITYmode to allow the car to
reach the nearest Authorized Alfa Romeo
Services to have the fault detected elimi-
nated.
In the event of faults to other components
of the gearbox, the system only allows the
engagement of certain ratios: first gear (1),
second (2) and reverse (R).
fig. 132
A0B0269m
fig. 133
A0B0383m
If the warning light
t
comes on, contact the Alfa
Romeo Authorized Services
as soon as possible to remove the
fault.In case of transmission
fault, contact the Alfa
Romeo Authorized Services as
soon as possible to check the sys-
tem.
WARNING

GETTING TO KNOW YOUR CAR
151
SIGNALLING WITH THE BUZZERThe buzzer is activated when:
– reverse gear (R) is engaged;
– the vehicle is parked with the gearbox
at neutral (N); this can be seen turning the
ignition key to STOP;
– clutch overheating takes place during
pick-up;
– the car moves in the opposite direction
to the gear engaged (e.g.: the car tends to
do downhill with reverse gear engaged);
– in the event of gearbox failure;
– the system has automatically engaged
neutral (N) after:•
there is no action on the accelerator
and/or brake pedal for at least 3 min-
utes;
•
the brake pedal is pressed for over 10
minutes;
•
the driver’s door is opened and the ac-
celerator and brake pedal are not
pressed for at least 1 second;
•
detection of a gearbox fault.
PARKING THE VEHICLETo park the car safely it is absolutely
necessaryto engage first gear (1) or re-
verse (R) and, when on a sloping road, also
engage the hand-brake.
Turning the engine off with the car facing
uphill and a gear engaged, it is absolutely
necessaryto wait for the display on the
rev counter to go off before releasing the
brake pedal, so that the clutch has innested
completely.
If the gearbox is in neutral (N) and you
want to engage a parking gear, it is neces-
sary to activate the system and engage the
gear (1) or reverse (R) with your foot on
the brake pedal.
TOWING THE VEHICLEWARNINGFor towing the vehicle, ad-
here to local regulations. Make sure that the
gearbox is in neutral (N) (checking that the
car moves when pushed) and proceed as for
towing a normal car with mechanical gear-
box following the instructions given in the
chapter “In an emergency”.
Should it be impossible to set to neutral,
do not tow the vehicle; contact Alfa Romeo
Authorised Services.
Do not start the engine
when towing the vehicle.
WARNING

GETTING TO KNOW YOUR CAR
152
Q-SYSTEM
AUTOMATIC GEARBOX(optional for versions/markets
where applicable)
The 2.5 V6 24V engine can be supplied
with an automatic gearbox which in addi-
tion to the normal functions, makes it pos-
sible to shift gear by hand moving the se-
lector lever to the special sector, Q-System
device.
WARNINGTo be able to use the auto-
matic gearbox correctly, the description given
in this chapter should be read thoroughly
in order to learn the correct, allowed oper-
ations also in concerning the Shift-lock and
Key-lock safety devices with which the gear-
box is fitted right from the start.
STARTING THE ENGINEThe engine can only be started with the
gearshift lever (fig. 134) in position P
or N.
For safety reasons, you are advised to start
the engine with the brake pedal pressed.
WARNINGWhen moving off, after hav-
ing started the engine, do not press the ac-
celerator pedal before and while moving the
gearshift lever. This is particularly important
when the engine is cold.
MOVING OFFAfter starting, with the engine idling and
keeping the brake pedal pressed (Shift-lock
safety device), move the gearshift lever
(fig. 134) to position D, or to the man-
ual position. Release the brake pedal and
gradually press the accelerator pedal.
WARNINGMoving the lever from posi-
tion P, with the ignition key at MAR, is
only allowed with the brake pedal pressed
(Shift-lock safety device).
To move the lever, raise the ring (A-
fig. 134) under the gearshift lever knob.
fig. 134
A0B0268m

GETTING TO KNOW YOUR CAR
153
In an emergency (failures, flat battery,
etc.), it is possible to move the lever from
position P, pressing the special mechanical
button under the gearshift lever cover, in the
area (A-fig. 135); at the same time
move the lever from position Pto the re-
quired position. If the engine is being
started, move the lever to position N, which
is the only one that allows this operation
in this case.
WARNINGThe ignition key in the
STOPposition can only be removed from
the ignition switch provided that the
gearshift lever is at P(Key-lock).In an emergency (failures, flat battery,
etc.), it is possible to remove the ignition
key also with the selector lever not posi-
tioned at P.
Press the release device (A-fig. 136),
next to the ignition switch inside the trim,
with your finger removing the key at the
same time.
Do not take the car to peak performance
until the engine has reached normal oper-
ating temperature.fig. 135
A0B0267m
fig. 136
A0B0266m
fig. 137
A0B0385m
SELECTING AUTOMATIC/
MANUAL GEARSHIFTINGThe main feature of this gearbox is the pos-
sibility of using it either automatically or
manually. The choice of the operating mode
is carried out positioning the gearshift lever
in the right sector (automatic gearshifting)
or in the left sector (manual gearshifting).
The gearbox operating mode and the gear
engaged are shown on the display inside the
rev counter (A-fig. 137).

GETTING TO KNOW YOUR CAR
156
SPORT(button (A-fig. 139)
pressed):
This is selected when wanting to avail of
the vehicle’s peak performance for sporty
driving or on demanding routes.
Driving in the SPORTmode increases fuel
consumption.
WARNINGThe CITYor SPORTdri-
ving modes can be selected under any con-
dition (vehicle stationary or on the move).
WARNINGWhen the car is started with
a cold engine, the system selects the
SPORTdriving mode, even if the CITY
mode has been selected, until the engine
reaches normal operating temperature.
C/S
ICE( button (B-fig. 133) pressed):
This driving mode is recommended when
the road surface offers poor grip (snow, ice,
etc.). Moving off takes place in 2
ndgear.
The ICEdriving mode is available only with
the selector lever at D.
Moving the lever from D, the ICEmode
is automatically cut off.
WARNINGThe ICEdriving mode can
be engaged pressing the corresponding but-
ton also with the car on the move, provided
that the speed is below 45 km/h.
ICE
SELECTING THE DRIVING
MODESThe automatic gearbox for this car is con-
trolled electronically and includes the selec-
tion of three different driving modes, thereby
giving the best response in terms of driving
comfort, consumption levels, sporty perfor-
mance and travelling safety.
The three driving modes CITY, SPORT
and are selected by 2 buttons on the
centre console (fig. 139).
The button (A-fig. 139) selects the
CITYor SPORTfunctions, the button
(B-fig. 139) selects the mode.
With the ignition key at MAR, the driving
mode selected is indicated by the lighting
up of the corresponding word on the display
on the instrument cluster (rev counter):
CITY( button (A-fig. 139)
pressed):
This is used under normal operating con-
ditions; it gives preference to comfortable
driving and balanced consumption control
engaging gears at relatively low engine
speed.
C/S
ICE
ICE
C/SICE
fig. 139
A0B0264m

GETTING TO KNOW YOUR CAR
158
1st2nd3rd4th
2nd2nd4th4th
Gear engaged Gear ratiomanually available
FAULT SIGNALLINGAutomatic gearbox faults are indicated by
the t
warning light (A-fig. 141) on
the instrument cluster as follows:
–warning light glowing steadily
= maximum automatic gearbox oil temper-
ature;
–warning light flashing= automatic
gearbox fault.
Turning the ignition key to MARthe warn-
ing light should turn on and go out after
approx. 4 seconds.
If the warning light stays on or turns on
during travelling, it indicates a gearbox fault
(flashing) or overheated gearbox oil (glow-
ing steadily).Warning light glowing steadily
If the warning light turns on and glows
steadily when the car is travelling, it indi-
cates that the gearbox oil has reached the
maximum established temperature.
The automatic control system provides an
emergency programme.
It is however advisable to stop the car,
move the lever to Por Nand let the engine
idle until the warning light goes out. Resume
driving without demanding high perfor-
mance from the engine.
If the warning light comes on again, it is
necessary to stop again with the engine
idling until it goes out again.
If the interval between one lighting up of
the warning light and the next is below 15
minutes, you are advised to stop the car,
turn off the engine and wait for the engine-
gearbox unit to cool down completely.
fig. 141
A0B0386m
Warning light flashing
The flashing of the warning light when trav-
elling indicates a fault in the automatic gear-
box.
The automatic control system provides an
emergency programme. Under these cir-
cumstances, you are advised to stop the car
and turn off the engine; in fact, the next
time the engine is started, the self-diag-
nostics system could cut off the fault which
will, however, be memorised by the elec-
tronic control device.
Conversely, if the fault remains (warning
light (A- fig. 141) flashing), it is neces-
sary to select the gears manually as if dri-
ving a car with mechanical gearbox, bear-
ing in mind that the only two speeds
available are the 2
ndand 4
thgear, as shown
in the table below:

GETTING TO KNOW YOUR CAR
161
INTERNAL FITTINGSGLOVEBOX On the dashboard there is a key glovebox
with light.The compartment is lit by a courtesy light
when it is open (when the ignition key is
at MAR(B-fig. 143).
There is a recess on the lid (C-fig. 143)
for inserting a pen or pencil. For the versions
/ markets where provided, the closure flap
is fitted with a lock. The lock can be
opened/closed using the ignition key.
GRAB HANDLES
(fig. 144)
Grab handles are set above the front doors.
Two grab handles (A) fitted with a coat
hook (B) are located above the rear doors.
fig. 142
A0B0587m
fig. 144
A0B0124m
fig. 143
A0B0261m
To open the glovebox use lever (A-
fig. 142).
Do not travel with the
glovebox open; it could
harm the passenger in the event of
an accident.
WARNING
