WARNING!(Continued)
•If the vehicle carpet has been removed and re-
installed, always properly attach carpet to the
floor and check the floor mat fasteners are secure
to the vehicle carpet. Fully depress each pedal to
check for interference with the accelerator, brake,
or clutch pedals then re-install the floor mats.
• It is recommended to only use mild soap and
water to clean your floor mats. After cleaning,
always check your floor mat has been properly
installed and is secured to your vehicle using the
floor mat fasteners by lightly pulling mat.
Periodic Safety Checks You Should Make
Outside The Vehicle
Tires
Examine tires for excessive tread wear and uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread. Inspect the tread and sidewall for
cuts and cracks. Check the wheel nuts for tightness.
Check the tires for proper pressure.
Lights
Have someone observe the operation of brake lights
and exterior lights while you work the controls. Check
turn signal and high beam indicator lights on the
instrument panel.
Door Latches
Check for positive closing, latching, and locking.
Fluid Leaks
Check area under vehicle after overnight parking for
fuel, engine coolant, oil, or other fluid leaks. Also, if
gasoline fumes are detected or if fuel, power steering
fluid (if equipped), or brake fluid leaks are suspected,
the cause should be located and corrected immediately.
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59
Page 62 of 289
Page 63 of 289
UNDERSTANDING THE FEATURES OF YOUR VEHICLE
CONTENTS
MIRRORS ...........................63
▫ Inside Day/Night Mirror ...............63
▫ Outside Mirrors ......................64
▫ Power Mirrors .......................64
▫ Folding Mirrors .......................65
▫ Heated Mirrors ......................65
SEATS ..............................65
▫ Manual Seats ........................66
▫ Non-Adjustable Head Restraints ..........67
TO OPEN AND CLOSE THE DECKLID ......68
LIGHTS .............................71
▫ Multifunction Lever ....................71
▫ Headlights ..........................71
▫ Daytime Running Lights ................72 ▫
High Beams .........................72
▫ Flash-To-Pass ........................72
▫ Parking Lights .......................72
▫ Turn Signals .........................72
▫ Lane Change Assist ...................72
▫ Follow Me Home/Headlight Delay —
If Equipped .........................73
▫ Dimmer Controls .....................73
▫ Interior Light ........................73
WINDSHIELD WIPERS AND WASHERS .....74
▫ Intermittent Wiper System ..............75
▫ Windshield Wiper Operation .............75
▫ Mist ...............................75
▫ Windshield Washers ...................753
Page 64 of 289
TILT/TELESCOPING STEERING COLUMN . . .76
ELECTRONIC SPEED CONTROL —
IF EQUIPPED .........................77
▫ To Activate ..........................77
▫ To Set A Desired Speed .................78
▫ To Deactivate ........................78
▫ To Resume Speed .....................78
▫ To Vary The Speed Setting ...............78
▫ To Accelerate For Passing ...............79
PARKING SENSORS — IF EQUIPPED .......80
▫ Activation/Deactivation .................80
▫ Acoustic Signal .......................80 ▫
Indications On Display — If Equipped ......81
▫ Fault Indication .......................81
▫ General Warnings .....................82
POWER OUTLETS .....................83
CIGAR LIGHTER AND ASH RECEIVER —
IF EQUIPPED .........................85
CUPHOLDER .........................85
STORAGE ............................86
▫ Seatback Storage ......................86
▫ Console Features ......................86
▫ Rear Compartment Storage ..............87
62 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 65 of 289
MIRRORS
Inside Day/Night Mirror
A single ball joint mirror is provided in the vehicle. It is
a twist on mirror that has a fixed position at the
windshield. The mirror installs on the windshield but-
ton with a counterclockwise rotation and requires no
tools for mounting. The mirror head can be adjusted up,
down, left, and right for various drivers. The mirror
should be adjusted to center on the view through the
rear window.
Headlight glare from vehicles behind you can be re-
duced by moving the small control under the mirror to
the night position (toward the rear of the vehicle). The
mirror should be adjusted while the small control under
the mirror is set in the day position (toward the
windshield).
Adjusting Rearview Mirror
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 63
Page 66 of 289
Outside Mirrors
To receive maximum benefit, adjust the outside mirrors
to center on the adjacent lane of traffic and a slight
overlap of the view obtained from the inside mirror.
NOTE:The passenger side convex outside mirror will
give a much wider view to the rear, and especially of the
lane next to your vehicle.
WARNING!
Vehicles and other objects seen in the passenger
side convex mirror will look smaller and farther
away than they really are. Relying too much on your
passenger side mirror could cause you to collide
with another vehicle or other object. Use your
inside mirror when judging the size or distance of a
vehicle seen in the passenger side mirror.
Power Mirrors
The power mirror controls are located on the center
console.
The power mirror controls consist of mirror select knob
and a four-way mirror control switch. To adjust a
mirror, turn the power mirror control knob to the left or
right to select the mirror that you want to adjust.
Using the mirror control switch, push on any of the four
arrows for the direction that you want the mirror to
move.
Power Mirror Control
64 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 67 of 289
Folding Mirrors
The exterior mirrors are hinged to allow the mirror to
pivot forward or rearward to help avoid damage. The
mirror has three detent positions: full forward, full
rearward and normal.
Heated Mirrors
These mirrors are heated to melt frost or ice.
This feature can be activated whenever you
turn on the mirror defroster. The Door
Demist/Defrost button is located in the
switch bank above the Climate Controls.
SEATS
Seats are a part of the Occupant Restraint System of the
vehicle.
WARNING!
• It is dangerous to ride in a cargo area, inside or
outside of a vehicle. In a collision, people riding
in these areas are more likely to be seriously
injured or killed.
• Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat
belts. In a collision, people riding in these areas
are more likely to be seriously injured or killed.
• Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
Folding Mirrors
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 65
Page 68 of 289
Manual Seats
Forward And Rearward Adjustment
The adjusting bar is at the front of the driver seat, near
the floor. Pull the bar upward to move the seat forward
or rearward. Release the bar once the seat is in the
desired position. Then, using body pressure, move
forward and rearward on the seat to be sure that the
seat adjusters have latched.
Seat Height Adjustment
In order to achieve the ideal driving position, the height
of the seats can also be adjusted. Tools are required to
make this height adjustment. Contact your authorized
dealership.
Recliner Adjustment
The recliner lever is located on the outboard side of the
seat. To recline the seat, lean forward slightly, pull the
recliner lever upward, lean backward until the seat is in
the desired position, and release the lever. To return the
seat to its full upright position, lean forward, pull the
recliner lever upward and hold it until the seat returns
to its full upright position.
Seat Adjustment Bar
66 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 69 of 289
WARNING!
•Adjusting a seat while driving may be dangerous.
Moving a seat while driving could result in loss of
control which could cause a collision and serious
injury or death.
•Seats should be adjusted before fastening the seat
belts and while the vehicle is parked. Serious
injury or death could result from a poorly adjusted
seat belt.
(Continued)
WARNING! (Continued)
•Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your chest.
In a collision you could slide under the seat belt,
which could result in serious injury or death.
Non-Adjustable Head Restraints
The non-adjustable head restraints are form fitted into
the upper structure of the seatback and are designed to
reduce the risk of injury by restricting head movement
in the event of a rear impact. The seatback should be
properly adjusted to an upright position where the head
restraint is positioned as close as possible to the back of
your head.
WARNING!
Be certain that the seatback is locked securely into
position. Otherwise, the seat will not provide the
proper stability for passengers. An improperly
latched seatback could cause serious injury.
Recline Lever
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 67
Page 70 of 289
TO OPEN AND CLOSE THE DECKLID
CAUTION!
•To prevent possible damage, do not slam the
decklid to close it. Use a firm downward push at
the center of the decklid to ensure the decklid
latch is fully engaged.
• During normal vehicle operation, the luggage
compartment (located rear of the engine) can
reach temperatures above 149 °F (65 °C). Do not
transport objects in the luggage compartment that
may be damaged at such temperatures. Do not
place aerosol cans in the luggage compartment.
To open the decklid:
1. Open the drivers side door. 2. Pull the decklid release lever located on the rear of
the drivers door sill.
Decklid Release Lever
68 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
