Track Brake Package Parts

PART
DESCRIPTION BRAMMO PART
# MANUFACTURER AND
MFR. PART # QTY.
Mr. Parker parking brake
caliper AA-BK-019 Revolution Brake
Mr. Parker 2 Mr. Parker parking brake
pads (4 pads) AA-BK-035 Wilwood
150-8937K/6823K 1
Aluminum Rotor Hat
Front and Rear AA-UP-044-1 4 Wilwood 4x 35.1mm
Dynalite caliper (L & R) AA-BK-010 Wilwood
120-6806-R/L 4 Wilwood two-piece vented & slotted rotor (right) 279.4x20.6mm
AA-BK-054
Wilwood 160-5840-SR
2
Wilwood two-piece
vented & slotted rotor, left (279.4 x 20.6mm) AA-BK-057
Wilwood
160-5840-SL 2
Pads, Type 7112 BP-20
(medium-high
compound-4 pads) AA-BK-056
Wilwood
150-9413K 2

66



Race Brake Package Parts

PART
DESCRIPTION BRAMMO PART
# MANUFACTURER AND
MFR. PART # QTY.
Alcon 4x34.9 mm fixed
racing caliper (left) AA-BK-036 Alcon
CAR3653D01ASLL 2 Alcon 4x34.9 fixed
racing caliper (right) AA-BK-026 Alcon
CAR3653D01ASRL 2
Mr. Parker parking brake
caliper AA-BK-019 Revolution Brake
Mr. Parker 2 Front pads set (4 pads)
AA-BK-033
Alcon PNP4436X502.4
2
Mr. Parker brake pads (4
pads) AA-BK-035 Wilwood
150-8937K
1 Front Aluminum Rotor
Hat AA-UP-044-1 2 Rear Aluminum Rotor
Hat AA-UP-060 2 Wilwood two-piece
vented & slotted rotor,
right (279.4 x 20.6mm) AA-BK-054
Wilwood
160-5840-SR 2 Wilwood two-piece
vented & slotted rotor, left (279.4 x 20.6mm) AA-BK-057
Wilwood
160-5840-SL 2

67


Ariel Atom Standard Paint Codes

COLOR
DESCRIPTION MFG PART NUMBER
Brammo Silver Chassis
(Touch Up Paint Color) Valspar 3335324 GM 12/9301 1984-1986 Flat Black found on
Suspension Components Duplicolor DA1603 Semi-Gloss Black Brammo Black Body
Panels BASF Diamont Black D403 Brammo Blue Body
Panels
Valspar
Universal Intermix, Color Base 33-L1807 converted from No. 840
Brammo Green Body
Panels TBD Brammo Orange Body
Panels Valspar 333A4632 Brammo Red Body Panels Glasurit 55 SRO40-50 Stock N
o. 577980
Brammo Yellow Body
Panels Valspar 333Y1129L Custom Chassis Color Custom Body Panel Color
