MAINTENANCE SCHEDULE FOR THE ARIEL ATOM 2
SCHEDULE II: BEFORE EVERY TRACK EVENT
Component Service/Operation
Engine Oil
Check before every track event. Change as necessar y. Engine Oil Filter
Replace during every oil change. Engine Coolant
Check before every track event. Supercharger
Aftercooler Coolant Check before every track event.
Air Filter
Check before every track event. Spark Plugs
Inspect before every track event and change if nece ssary. Transmission Fluid
Inspect for leaks before every track event. Brake Fluid
Inspect levels, condition, and any leakage before e very track event. Brake Rotors Refer to the Brake Bedding Procedures on page12. I
nspect and replace when thickness decreases
to 19mm, when pulsation is noted, or if cracking or other physical damage is found during inspection.
Brake Pads Inspect for pad damage, thickness issues or deterio
ration. Replace brake pads when brake rotors
are replaced. Refer to the brake bedding procedure s on page12. Brake Hoses &
Lines Inspect brake lines for rubbing, scraping, or any d
amage. Fuel Lines &
Connections Inspect lines for rubbing or scraping before every
track event. Exhaust System
Visually inspect exhaust flange bolts for tightness and/or damage. Tires
Inspect tires for proper pressure and tread wear be fore and after every track event. Wheels
Ensure lug nut torque is 80 ft-lbs. Drive Belt
Check for abnormal wear. Rod Ends Inspect rods ends on Push Rods, Steering Rods, and
A-Arms for any signs of fatiguing or wear,
replace if parts appear worn. Verify that all chec k nuts are tight on all rod ends.
Page 62 of 79
56
MAINTENANCE SCHEDULE FOR THE ARIEL ATOM 2
SCHEDULE III: INITIAL 50 MILES (80 KM)
Component Service/Operation
Engine Oil
Check and fill as necessary. Engine Oil Filter
No service required. Engine Coolant
Check and fill as necessary. Supercharger
Aftercooler Coolant Check and fill as necessary.
Air Filter
No service required. Spark Plugs
No service required. Transmission Fluid
No service required. Brake Fluid
Check level. Fill as necessary. Brake Rotors
Refer to the brake bedding procedures on page12. Brake Pads
Refer to the brake bedding procedures on page12. Brake Hoses &
Lines Inspect brake lines for rubbing, scraping, or any d
amage. Fuel Lines &
Connections Inspect for damage.
Exhaust System Visually inspect exhaust flange bolts for tightness
and/or damage, check gaskets visually to ensure
they have not developed a leak. Tires
Inspect for any unusual tread wear. Wheels
Ensure lug nut torque is 80 ft-lbs. Drive Belt
Check for abnormal wear. Rod Ends Inspect rods ends on Push Rods, Steering Rods, and
A-Arms for any signs of fatiguing or wear,
replace if parts appear worn. Verify that all chec k nuts are tight on all rod ends. We recommend
replacement of all suspension rod ends at 3000mi or sooner based upon driving habits.
Page 63 of 79
57
MAINTENANCE SCHEDULE FOR THE ARIEL ATOM 2
SCHEDULE IV: INITIAL 300 MILES (480 KM)
Component Service/Operation
Engine Oil
Check and fill as necessary. Engine Filter
No service required. Engine Coolant
Check and fill as necessary. Supercharger
Aftercooler Coolant Check and fill as necessary.
Air Filter
No service required. Spark Plugs
Inspect before every track event and change if nece ssary. Transmission Fluid
No service required. Brake Fluid
Check level; fill as required. Brake Rotors Inspect and replace when thickness decreases to 19m
m, when pulsation is noted, or if cracking or
other physical damage is found during inspection. Brake Pads Inspect for pad damage, thickness issues or deterio
ration. Replace brake pads when brake rotors
are replaced. Brake Hoses &
Lines Inspect brake lines for rubbing, scraping, or any d
amage. Fuel Lines &
Connections Inspect for damage.
Exhaust System Visually inspect exhaust flange bolts for tightness
and/or damage, check gaskets visually to ensure
they have not developed a leak. Tires
Inspect for any unusual tread wear. Wheels
Ensure lug nut torque is 80 ft-lbs. Drive Belt
Check for abnormal wear. Rod Ends Inspect rods ends on Push Rods, Steering Rods, and
A-Arms for any signs of fatiguing or wear,
replace if parts appear worn. Verify that all chec k nuts are tight on all rod ends. We recommend
replacement of all suspension rod ends at 3000mi or sooner based upon driving habits.
Page 64 of 79
58
MAINTENANCE SCHEDULE FOR THE ARIEL ATOM 2
SCHEDULE V: EVERY 1000 MILES (1600 KM)
Component Service/Operation
Engine Oil
Check before every track event or every 1,000 miles (1,600 km). Change as necessary. Engine Oil Filter
Replace during every oil change. Engine Coolant
Check before every event. Replace every 30,000 mil es (48,000 km). Supercharger
Aftercooler Coolant Check before every event. Replace every 30,000 mil
es (48,000 km). Air Filter
Clean and oil every 5,000 miles (8,000 km) Spark Plugs
Inspect before every track event and change if nece ssary. Transmission Fluid
Change every 10,000 miles (16,000 km). Brake Fluid
Check level. Fill as needed. Brake Rotors Inspect and replace when thickness decreases to 19m
m, when pulsation is noted, or if cracking or
other physical damage is found during inspection. Brake Pads Inspect for pad damage, thickness issues or deterio
ration. Replace brake pads when brake rotors
are replaced. Brake Hoses &
Lines Inspect brake lines for rubbing, scraping, or any d
amage. Fuel Lines &
Connections Inspect for damage.
Exhaust System Visually inspect exhaust flange bolts for tightness
and/or damage. Use a wrench to inspect flange
bolts for tightness every 5,000 miles (8,000 km), c heck gaskets visually to ensure they have not
developed a leak. Tires
Inspect for any unusual tread wear. Wheels
Ensure lug nut torque is 80 ft-lbs. Drive Belt
Check for abnormal wear. Rod Ends Inspect rods ends on Push Rods, Steering Rods, and
A-Arms for any signs of fatiguing or wear,
replace if parts appear worn. Verify that all chec k nuts are tight on all rod ends. We recommend
replacement of all suspension rod ends at 3000mi or sooner based upon driving habits.
Page 65 of 79
59
REPLACEMENT PART INFORMATION FOR
VEHICLES WITH GM ENGINES
PART BRAMMO PART # MFR. PART # TYPE
Battery
All Vehicles AA-PP-036 Braille Auto B20145 Dry Cell - Sealed O2 Sensor
GM AA-GM-069 AC Delco 213-3138
GM 12578576 Air Filter
GM Corrugated
intake AA-PP-136 K&N 33-2282 2004-2007 Suzuki Aerio Air Filter
GM Plastic Intake AA-PP-337 K&N 33-2340 Fuel Filter
GM AA-PP-083 GM 22734980 Oil Filter
GM AA-GM-006 GM 12580254
Spark Plugs
GM None LTR5GP NGK PK16PR-P11 ND
LTR51X-11 NGK
PT16VR13 ND
(or equivalent)
Headlight Bulbs
All Vehicles AA-PP-121 H4 H4
Page 66 of 79
60
REPLACEMENT PART INFORMATION FOR
VEHICLES WITH GM ENGINES (CONTINUED)
PART BRAMMO PART # MFR. PART # TYPE Engine Serpentine Belt
GM
Base & Stage 1 AA-GM-065 NAPA/Gates
25-060512
(20mm x 1315mm)
Engine Serpentine Belt
GM
Stages 2 & 3 AA-GM-066
NAPA/Gates
25-060505
(20mm x 1295mm)
Dampers
Base Front Base Rear
Mid Level Front Mid Level Rear Race Front
Race Rear
AA-PP-153
AA-PP-232
AA-PP-178
AA-PP-233
AA-PP-154
AA-PP-234 KONI
30 BRM1 SP-8
30 SP8 BRM2
3012 BRM1 B16
3012 BRM2
2812 BRM1
2812 BRM2
Rebound Adjustable
Rebound Adjustable
Double Adjustment
Double Adjustment
Double External Adjustment
Double External Adjustment
Small 1/4-turn
fasteners AA-HX-002 Large 1/4-turn
fasteners AA-HX-003 Exhaust Gasket
All Vehicles AA-PP-081 NAPA F7135
Rod Ends
All Vehicles AA-PP-316
AA-PP-317
AA-PP-318 Aurora Bearing AM-6T
Aurora Bearing AB-6T
Aurora Bearing AB-10T 3/8-24 Rod End, Right Hand
3/8-24 Rod End, Left Hand
5/8-18 Rod End, Left Hand
Page 67 of 79
61
REPLACEMENT PART INFORMATION FOR
VEHICLES WITH HONDA ENGINES
NOTE: Honda and Acura parts are both made by the American Honda Motor Company. Honda parts end with a number ; Acura part
numbers end with a letter. The products are interchangeable
PART BRAMMO PART # MFR. PART # TYPE
Battery
All Vehicles AA-PP-036 Braille Auto B20145 Dry Cell - Sealed 02 Sensor
Honda AA-HN-014 36531-PRB-A01 Air Filter
Honda AA-PP-136 K&N 33-2282 Fuel Filter
Honda AA-PP-083 GM 22734980 Oil Filter Honda
None
15400-PLMA02
Spark Plugs
Honda
None
IK 20
Denso Iridium
Headlight Bulbs
All Vehicles AA-PP-121 BP 1260 / H4 H4
Engine Serpentine Belt
Honda
Non-Supercharged AA-HN-016 60495 Gates
Engine Serpentine Belt
Honda
Supercharged AA-HN-018 60478 Gates
Page 68 of 79
62
REPLACEMENT PART INFORMATION FOR
VEHICLES WITH HONDA ENGINES (CONTINUED)
PART BRAMMO PART # MFR. PART # TYPE
Dampers
Base Front
Base Rear
Mid Lvl Front Mid Lvl Rear Race Front Race Rear
AA-PP-153
AA-PP-232
AA-PP-178
AA-PP-233
AA-PP-154
AA-PP-234 KONI
30 BRM1 SP-8
30 SP8 BRM2
3012 BRM1 B16
3012 BRM2
2812 BRM1
2812 BRM2
Rebound Adjustable
Rebound Adjustable
Double Adjustment
Double Adjustment
Double External Adjustment
Double External Adjustment
Small 1/4-turn
fasteners
AA-HX-002
Large 1/4-turn
fasteners AA-HX-003 Exhaust Gasket
All Vehicles AA-PP-081 NAPA F7135
Rod Ends
All Vehicles AA-PP-316
AA-PP-317
AA-PP-318 Aurora Bearing AM-6T
Aurora Bearing AB-6T
Aurora Bearing AB-10T 3/8-24 Rod End, Right Hand
3/8-24 Rod End, Left Hand
5/8-18 Rod End, Left Hand
Page 69 of 79
63
BRAKE PAD OPTIONS
Base Brake Package Parts
PART
DESCRIPTION BRAMMO PART
# MANUFACTURER AND
MFR. PART # QTY.
PBR 54mm floating front
caliper (left) AA-BK-002 PBR
BCB843199PL
1 PBR 54mm floating front
caliper (right) AA-BK-003 PBR
BCB843200PL 1 PBR 40.5mm floating
rear caliper w/ e-brake (left) AA-BK-004
PBR
BCB821020PL 1 PBR 40.5mm floating
rear caliper w/ e-brake (right) AA-BK-005
PBR
BCB821019PL 1 Single piece ventilated 10.3 rotor (262 x 21mm)
AA-BK-006
Galfer SKU#A24255VF
4
Front pads AA-BK-008 PBR
SS-7662X 1
Organic rear brake pads
for 1993-1997 Chevrolet
Camaro AA-BK-055
NAPA
SS-7301-M 1
Page 70 of 79
64
Sport Brake Package Parts
PART
DESCRIPTION BRAMMO PART
# MANUFACTURER AND
MFR. PART # QTY.
Wilwood 4 x 35.1mm
Dynalite caliper (L & R) AA-BK-010 Wilwood
120-6806-R/L 2 PBR 40.5mm floating
rear caliper/parking brake (left) AA-BK-004
PBR
BCB821020PL 1 PBR 40.5mm floating
rear caliper/parking brake (right) AA-BK-005
PBR
BCB821019PL 1 Single piece ventilated
10.3 front rotor (262 x 21mm) AA-BK-006
Galfer
SKU#A24255VF 4 Front pads-Type 7112 Q
(street compound-4
pads)
AA-BK-015
Wilwood 15Q-6824K
1
Organic rear brake pads
for 1993-1997 Chevrolet
Camaro AA-BK-055
NAPA
SS-7301-M 1
