AUDI R8 SPYDER 2014 Owners Manual

-Undeployed airbag modules and preten ­
sioners might be classified as Perchlo­
rate Material -spec ia l hand ling may ap­
ply, see www.dtsc.ca.gov/hazardous­
waste/perch lorate. When the veh icle or
parts of the restraint system includ ing
airbag modules safety belts wit h preten­
s ione rs are scrapped, all applicable laws
and regulations must be observed. Your
a uth o rized Aud i dea le r i s f amiliar w ith
these req uirements and we recommend
that you have your dea le r per fo rm this
service for you.
Additional accessories, modifications and
parts replacement
Additional accessories and parts
replacement
Always consult on authorized Audi dealer be­
fore purchasing accessories .
Your vehicle incorporates the latest safety de­
sign features ensuring a high standard of ac­
tive and passive safety .
This safety could be compromised by non -ap ­
proved changes to the veh icle. For this reason,
if parts have to be replaced, please observe
the following points when installing addition­
al accessories:
Approved Audi accessor ies and genuine Audi
parts are ava ilable from a uthorized Audi deal­
ers.
These dealers also have the necessary faci li­
ties, too ls and trained specialists to insta ll the
parts and accessor ies properly .
A WARNING
Using the wrong spare parts or using non­
approved accessories can cause damage to
the vehicle and se rious personal injury .
- Use only accessor ies expressly approved
by Audi and genuine Aud i spa re parts
Con sumer In formation 229
- These parts and accessories have been
specially designed to be used on yo ur ve­
hicle.
- Never install accessor ies such as tele­
phone crad les or beverage ho lders on air­
bag covers or within the airbag deploy­
men t zones . Do ing so wi ll increase the
ris k of injury if a irbags are triggered in an
accident!
- Before you check anything in the engine compa rtment, always r ead an d heed a ll
WARNI NGS
r:::;> poge 1 72.
(D Note
- If items other than genu ine Audi spare
par ts, add-on equipment and accessory
items are used o r if repair wo rk is not
performed ac cord ing to specified met h­
od s, this c an resu lt in seve re damage to
yo ur vehicle's engine and bo dy (s uch as
co rrosion) and adve rsely affect yo ur vehi ­
cle 's warranty.
- The innovat ive a luminium con cep t of
your Audi means that a ll servicing, re ­
pairs or other work on the vehicle body
must be carr ied out exclusive ly by an
Audi workshop.
- If emergency repa irs must be performe d
elsewhere , have the veh icle examined by
an authorized Audi dealership as soon as
possible.
- The manufacturer cannot be held liable
for damage wh ich occ urs due to failure
to comply with these stipu lations.
Technical Modifications
Our guidelines must be complied with when
technical modifications ore mode .
Always consult an author ized Audi dealer be·
fore start ing work on any modifications.
T his will help ensure t hat veh icle function,
perfo rmance and safety are not impaired
c> _&. .
Attempt ing to work on e lec tronic componen ts
and t he software used with them can ca use
Iii>
•
•

230 Consumer Information
malfunctions. Because of the way electronic
components are interconnected with each
other, such malfunctions can also have an ad­
verse affect on other systems that are not di­
rectly involved. This means that you risk both
a substantial reduction in the operational
safety of your vehicle and an increased wear of
vehicle parts~.&, .
Authorized Audi dealers will perform this
work in a professiona l and competent manner
or, in special cases, refer you to a professional
company that specializes in such mod ifica­
tions.
_& WARNING
Improper repairs and modifications can
change the way vehicle systems work and
cause damage to the vehicle and serious
personal injury .
(D Note
If emergency repairs must be performed
elsewhere, have the vehicle examined by
an authorized Audi dealership as soon as
possible.
-
Declaration of Compliance, Telecommu­
nication or Electronic Systems
Radio Frequency Devices and Radiocommuni­
cation Equipment User Manual Notice.
The manufacturer is not responsible for any
radio or TV interference caused by unauthor­
ized modifications to this equipment.
Devices
The following devices each comp ly with FCC
Part 15.19, FCC Part 15.21 and RSS-Gen Issue
1:
-Cell phone package
- El ectronic immob ilizer
- Homelink® universal remote control
- Remote control key
- Tire pressure monitoring system
FCC Part 15.19
T his device complies with part 15 of the FCC
Rules. Operation is subject to the fo llowing
two conditions :
(1) This device may not cause harmful inter­
ference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation.
FCC Part 15.21
CAUTION:
Changes or modifications not expressly ap­
proved by the party responsible for compli­
ance could vo id the user's authority to operate
the equipment.
RSS-Gen Issue 1
Operation is subject to the following two con­
ditions:
(1) this device may not cause interference,
and
(2) this device must accept any interfe rence ,
i ncl uding interference that may cause unde­
sired operation of the device .
