Retrofit kit No. 84 64 0 152 501
Installation Instructions No. 01 29 0 152 511 Issue date: 07.2002
Universal BMW Bluetooth Hands-Free Kit Upgrade
BMW 3 Series Coupé and Saloon (E
46/2/4) from 03/02
These installation instructions are only valid for cars with SA 640 (telephone preparation).
Important information
This upgrade kit is for use within the BMW dealership organisation only.
Subject to technical modifications.
Target group
The target group for these installation instructions is specialist personnel trained on BMW cars with the
appropriate specialist knowledge.
All work must be completed using the latest BMW repair manuals, circuit diagrams, servicing manuals and
work instructions in a rational order using the prescribed tools (special tools) and observing current health and
safety regulations.
Installation information
Ensure that the cables/lines are not kinked or damaged as you install them in the car.
The installed cables are to be secured with cable ties.
If the specified PIN chambers are occupied, bridges, double crimps or twin-lead terminals must be used.
Ordering instructions
Telephone console insert
The black telephone console insert is supplied in the upgrade kit.
An insert for the centre console in other colours for cars with different interior colours can be ordered if
required. See the EPC for all further ordering information.
The snap-in adapter is not supplied with the upgrade kit and must be ordered separately for the various
telephones.
List of special equipment
The following special equipment must be taken into consideration when installing the upgrade kit.
The various sections contain corresponding information.
SA 401
Tilt and slide sunroof
SA 602
On-board monitor
SA 606
Radio navigation system
SA 609
Navigation system
SA 660
BMW Reverse radio
SA 661
BMW Business radio
SA 662
BMW Business CD radio
Parts and Accessories
Installation Instructions
Page 2 of 14
EN/2
Retrofit kit No. 84 64 0 152 501
Installation Instructions No. 01 29 0 152 511 Issue date: 07.2002
Installation time
Approx. 2 hours, but this may vary depending on the condition of the car and the equipment in it.
Pictograms
denotes instructions that draw your attention to special features
.
denotes the end of the instruction or caution text.
Retrofit kit No.
84 64 0 152 501
Special tools required
None
Page 3 of 14
EN/3
Retrofit kit No. 84 64 0 152 501
Installation Instructions No. 01 29 0 152 511 Issue date: 07.2002
Contents
SectionPage
1. Preparations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. Parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3. Installation and cabling diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4. To install and connect the universal charger/hands-free electronic control unit
(cars with SA 660/661/662 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5. To install and connect the universal charger/hands-free electronic control unit
(cars with SA 602/606/609 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6. To install and connect the eject box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7. To install the hands-free microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
8. Concluding work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Page 4 of 14
EN/4
Retrofit kit No. 84 64 0 152 501
Installation Instructions No. 01 29 0 152 511 Issue date: 07.2002
1. Preparations
0
TIS instruction No.
Conduct a brief test---
Disconnect the negative pole of the battery 12 00 ...
The following components must be removed first of all:
Left boot – wheel arch trim 51 47 151
Oddments box51 16 200
Ceiling light63 31 000
Page 5 of 14
EN/5
Retrofit kit No. 84 64 0 152 501
Installation Instructions No. 01 29 0 152 511 Issue date: 07.2002
2. Parts list
0
Legend
0
A Eject box
B Telephone console insert
C Holder for WDCT aerial
D WDCT aerial
E Hands-free microphone
F ULF (universal charger/hands-free electronic control unit)
G ULF holder (cars with SA 660/661/662 only)
H ULF holder (cars with SA 602/606/609 only)
I Speed nut St 4.2 (2x)
J Hexagonal nut M5 (5x)
K Hexagonal screw M5 x 14 (6x)
L Speed nut M5 (6x)
ACBD
FE
IJKL
GH
046 0979 Z
Page 6 of 14
EN/6
Retrofit kit No. 84 64 0 152 501
Installation Instructions No. 01 29 0 152 511 Issue date: 07.2002
3. Installation and cabling diagram
0
Legend
A Eject box
D WDCT aerial
E Hands-free microphone
F ULF (universal charger/hands-free electronic control unit)
AE
F
D
046 0961 Z
Page 7 of 14
EN/7
Retrofit kit No. 84 64 0 152 501
Installation Instructions No. 01 29 0 152 511 Issue date: 07.2002
4. To install and connect the universal charger/hands-free electronic control unit
(cars with SA 660/661/662 only)
0
0
00
Push the speed nuts
L
onto the holder
G
.
0
Use the hexagonal screws
K
to screw the universal
charger/hands-free electronic control unit
F
onto the
holder
G
.
0
Push the speed nuts
L
on in the boot at the rear left.
G
L
046 0977 Z
GF
K
046 0974 Z
L
046 0963 Z
Page 8 of 14
EN/8
Retrofit kit No. 84 64 0 152 501
Installation Instructions No. 01 29 0 152 511 Issue date: 07.2002
0
0
Use the hexagonal screws
K
to screw on the holder
G
in
the boot at the rear left.
G
K
046 0964 Z
Page 9 of 14
EN/9
Retrofit kit No. 84 64 0 152 501
Installation Instructions No. 01 29 0 152 511 Issue date: 07.2002
4. To install and connect the universal charger/hands-free electronic control unit (cars with SA 660/661/
662 only)
0
0
Connect the white FAKRA plug (1) of the WDCT aerial to
the tied back, black 54-pin plug
X4038
on the universal
charger/hands-free electronic control unit
F
.
Make sure that the standard aerial cable (2) is
plugged onto the standard wiring harness.
F
1
2
X4038
046 0965 Z
Page 10 of 14
EN/10
Retrofit kit No. 84 64 0 152 501
Installation Instructions No. 01 29 0 152 511 Issue date: 07.2002
5. To install and connect the universal charger/hands-free electronic control unit
(cars with SA 602/606/609 only)
0
0
00
Use the hexagonal nuts
J
to screw the universal charger/
hands-free electronic control unit
F
onto the holder
H
.
0
Connect the white FAKRA plug (1) of the WDCT aerial to
the tied back, black 54-pin plug
X4038
on the universal
charger/hands-free electronic control unit
F
.
0
Use the hexagonal screws
K
to screw the holder
H
onto
the module holder.
Make sure that the standard aerial cable (1) is
plugged onto the standard wiring harness.
J
F
H
046 0973 Z
1
F
X4038
046 0978 Z
K
H
1
046 0975 Z
