Page 141 of 189

BMW 328Ci COUPE 2000 E46 Owners Manual Overview
Controls and features
Operation, care
and maintenance
Owner service procedures
Technical data
Index Advanced technology
139n
RepairsIndexOverview Controls Car care Technology Data
Replacement

Page 142 of 189

BMW 328Ci COUPE 2000 E46 Owners Manual 140n
The onboard tool kit is located in the
luggage compartment lid.
Loosen the wingnut to open.
460de066
1 Rotate the wiper arm completely out
from the windshield
2 Position the wiper blade at an

Page 143 of 189

BMW 328Ci COUPE 2000 E46 Owners Manual 141n
RepairsIndexOverview Controls Car care Technology Data
Lamps and bulbsThe illustration shows the left-hand side
of the engine compartment.1  Low beams H7, 55 watt bulb2  High beamsH7, 55 watt bu

Page 144 of 189

BMW 328Ci COUPE 2000 E46 Owners Manual 142n
Lamps and bulbsThe illustration shows the left-hand side
of the engine compartment.Parking lamp5 watt bulb
1 Turn the bulb holder to the left (arrow)
and remove
2 Remove and replace the bulb.4

Page 145 of 189

BMW 328Ci COUPE 2000 E46 Owners Manual 143n
RepairsIndexOverview Controls Car care Technology Data
Lamps and bulbsSide turn signals
*
5 watt bulb
1 Use finger pressure against the rear
end of the lens (arrow) to press it for-
ward for rem

Page 146 of 189

BMW 328Ci COUPE 2000 E46 Owners Manual 144n
Lamps and bulbsThe illustration shows the right-hand
luggage compartment opening.
Bulbs in the fender:
All of the bulbs are integrated in a
central bulb holder.
1 Release the bulb holder (arrow

Page 147 of 189

BMW 328Ci COUPE 2000 E46 Owners Manual 145n
RepairsIndexOverview Controls Car care Technology Data
Lamps and bulbsCenter (high-mount) brake lamp

LED light bar on the rear window.
Please contact a BMW center in the
case of a malfunction.

Page 148 of 189

BMW 328Ci COUPE 2000 E46 Owners Manual 146n
Lamps and bulbsRear
Interior lamp (6 watt bulb) with reading
lamp (6 watt bulb)
1 Pry the lamp out using a screwdriver
2 Turn the bulb holder to the left and
remove
3 Remove and replace the bul

Page 149 of 189

BMW 328Ci COUPE 2000 E46 Owners Manual 147n
RepairsIndexOverview Controls Car care Technology Data
Remote controlNew transmitter If you place a new transmitter into ser-
vice (either a replacement or an addi-
tional transmitter), it must b

Page 150 of 189

BMW 328Ci COUPE 2000 E46 Owners Manual 148n
Changing tires
Take these precautionary mea-
sures if you have either a flat tire
or are changing the tire:
Park the vehicle as far from the flow of
traffic as possible and on firm ground.
Sw
