BMW X5 4.4I 2000 Owners Manual

IndexDataTechnologyRepairsCar careControlsOverview
161n
Changing a wheel Spare wheel 1 Loosen the wing nut 1.
2 Remove the plate 2 to the side.
3 Unscrew the threaded rod 3 com-
pletely. 530us118
Removal aid for the spare wheel By using this device, you do not have to
lift the spare wheel out of the recess by
hand.
Its task is to help you to move the wheel
onto the tailgate, from where you can
easily lift it off.
1 Close the tailgate again.
2 Grasp the handle of the removal aid
behind the spare wheel with both
hands and pull upward over the
tailgate (arrow).530us155
3 Hook both buckles into the latch of
the tailgate (arrow); the tailgate is
released.530us156

162n
Changing a wheel 4 Remove support rod from bracket. 530us080
5 Press the tailgate down and hold it
there. The spare wheel is now pulled
by means of the removal aid onto the
tailgate.
Hold the tailgate in the opened
position and do not allow it to re-
tract sharply upward. If you do so, there
is a risk of personal injury and vehicle
damage.< 530us158
6 Insert support rod in tailgate lock and
press down until it engages (arrow 1);
then lock hook of rod in striker
(arrow 2).
Be sure that the support rod is
locked firmly in place. If you fail to
do so, it could retract sharply upward
and cause personal injury and vehicle
damage.<
7 You can now release the locked tail-
gate and take the spare wheel down
from the tailgate. It is recommended
that you leave the tailgate locked into
place until you have completed the
wheel change and placed the wheel
with the defective tire into the re-
moval aid. 530us082

IndexDataTechnologyRepairsCar careControlsOverview
163n
Changing a wheel >Vehicle jack
Unscrew the wing screw (arrow) and
remove the jack.
When you have completed work,
screw the jack all the way back
down. Fold the handle back and in-
sert it into its holder. 530us116
Procedure 1 Read carefully and comply with the
safety precautions on page 160.
2 Secure the vehicle to prevent it from
rolling:
Place the wedges (chocks) behind
the wheels on the side opposite the
side you are lifting. If the vehicle is
parked on a downward slope, place
the wedges securely in front of the
wheels. If the wheel must be
changed on a surface with a more
severe slope, take additional pre-
cautions to secure the vehicle from
rolling.
3 Loosen the lug bolts 1/2-turn. 4 Position the jack at the jacking point
closest to the flat tire so that the
jack base is vertically below the
jacking point and the entire surface
of the head of the jack will move
into the square recess of the jacking
point (refer to the illustration detail)
when the jack is cranked.
5 Jack the vehicle up until the wheel
you are changing is raised from the
ground.
6 Unscrew the lug bolts and remove
the wheel.
7 Remove accumulations of mud or
dirt from the mounting surfaces of
the wheel and hub. Clean the lug
bolts.
8 Position the spare wheel. Secure
the wheel by turning at least two lug
bolts into opposite bolt holes.
530us119

164n
Changing a wheel 9 Screw in the remaining lug bolts.
Tighten all the bolts securely.
10 Lower the jack and remove it from
beneath the vehicle.
11 Tighten the lug bolts in a diagonal
pattern.
12 Check and correct the tire inflation
pressure at the earliest opportunity.
The vehicle jack is designed for
changing wheels only. Do not at-
tempt to raise another vehicle model
with it or to raise any load of any kind.
To do so could cause accidents and
personal injury.
To ensure continued safety, have the
tightness of the lug bolts checked with
a calibrated lug wrench [torque specifi-
cation: 94 ft-lb (130 Nm)] at the earliest
opportunity.<
Store the wheel and the tools in the or-
der opposite that for removal. Be sure
that the jack is first placed back into its
original position.
Before removing the support rod,
be sure that the tailgate is held
down firmly. If you fail to do so, it could
retract sharply upward and cause per-
sonal injury and vehicle damage.
After you remove the rod, close the tail-
gate carefully. Continue to hold it firmly
until it is completely closed.<
If light-alloy wheels other than original
BMW light-alloy wheels have been
mounted, it may be necessary to use
different lug bolts for those wheels.
Replace the defective tire as soon as
possible and have the new wheel/tire
balanced.
The spare wheel has a size
235/65 R 17 tire. If you have
mounted tires on your vehicle with a
different size, have wheels and tires of
the same size and specification rein-
stalled as soon as possible.
When the spare wheel is mounted, the
maximum speed rating is 130 mph
(210 km/h).<

IndexDataTechnologyRepairsCar careControlsOverview
165n
Battery Battery location The battery is located in the floor of the
vehicle below the spare wheel. Battery care The battery is maintenance-free, that is,
the original electrolyte will normally last
for the service life of the battery under
moderate climatic conditions.
For all questions that regard the
battery, please consult your BMW
center. Since the battery is mainte-
nance-free, the following is for your in-
formation only.<
Symbols You will find the following symbols on
your vehicle battery. To avoid injury,
please comply with the corresponding
precautions whenever you work with or
near the battery.
Before handling the battery,
please read the following infor-
mation:
Wear eye protection. Do not al-
low particles containing battery
acid or lead to come into con-
tact with your eyes, your skin, or your
clothing.
Battery acid is extremely corro-
sive. Wear eye protection and
protective gloves. Do not tip the
battery. Battery acid can leak from the
ventilation openings.
Do not allow children to have
access to batteries and battery
acid.
Never allow sparks or open
flame near the battery. Do not
smoke in the vicinity of the bat-
tery. Avoid sparks from electrical cables
or electrical equipment. Turn the key to
position 0 in the steering lock when you
are disconnecting or connecting the
battery. Never short-circuit the battery
terminals. This creates a risk of injury
from high-energy sparks.
A highly-explosive gas is
generated when the battery is
charged.
If you happen to get acid in your
eyes, rinse thoroughly for
15 minutes with clear water.
Following that, consult a physician im-
mediately. If you get acid spray on your
skin or clothing, rinse with plenty of wa-
ter. If electrolyte is accidentally swal-
lowed, consult a physician immediately.
In order to protect the battery
case from ultraviolet radiation,
do not place it in direct sunlight.
A discharged battery can freeze. Store
the battery in areas where temperature
remains above freezing.

166n
Battery Charging the battery Charge the battery in the vehicle only
when the engine is not running. Use the
connections provided in the engine
compartment (for correct connections,
refer to "Jump-starting" on page 170).
The service life specified for the
battery can be achieved only if it
is always kept adequately charged.
Have the charge condition of the bat-
tery checked frequently if the vehicle
is used primarily for driving short
distances.<
Before performing any work on
the electrical system, disconnect
the cable from the negative terminal. If
you do not, short circuits can create the
risk of fire or personal injury.<
If you plan to park the vehicle longer
than 4 weeks, have the battery discon-
nected from the vehicle's electrical
system by disconnecting the cable from
the negative terminal. Then have the
battery charged with an appropriate
battery charger.
If the vehicle will not be driven for a
period longer than 12 weeks, have the
battery removed, charged and store it
in a clean and cool (frost-free) area.
Recharge the battery at least every
three months during storage. Also,
recharge the battery before it is in-
stalled. If you fail to do so, it will not be
serviceable. Every time the battery is
discharged, especially over extended
periods, its service life is reduced. Do not disconnect the battery
when the engine is running. If
you do so, the ensuing voltage surge
will damage the vehicle's onboard elec-
tronics.
Do not make any modifications in the
wires to the positive terminal. If you do
so, the protective function of the safety
battery terminal is no longer ensured.
Repair and disposal must be performed
by trained technicians only.<
Return used batteries to a recy-
cling point or your authorized
BMW center. Maintain the battery in an
upright position for transport and stor-
age. Secure the battery against tilting in
transit.<

IndexDataTechnologyRepairsCar careControlsOverview
167n
Fuses When an electrical accessory fails to
operate, switch it off and inspect the
fuse. In the glove compartment 1 Open the glove compartment and
turn the two quick-release knobs to
the left. Spare fuses and plastic
tweezers are located on the fuse
holder.
2 Use the plastic tweezers to remove
the fuse for the accessory or equip-
ment that has stopped working.
3 If the fuse is burned through (the
metal strip will have melted and sep-
arated), replace it with a new fuse of
the same ampere rating (color code). 530us121
A list of the fuses, their respective
ampere ratings and the equipment in
their circuits is provided below the fuse
holder.
Close the fuse holder by holding the top
of the cover in place and screwing the
two quick-release knobs to the right.
Additional fuses are provided in the
cargo area.
The fuse for continuous positive current
is located in a separate fuse box in front
of the spare wheel. If this fuse is defec-
tive, refer the problem to your BMW
center for repair.
Do not attempt to repair a burned
fuse or replace it with a fuse hav-
ing a different color or amperage rating.
To do this could cause a fire in the vehi-
cle resulting from a circuit overload.<
If the fuse continues to burn through,
have the problem corrected by a BMW
center.
In the cargo area Open the right cover by pulling the han-
dle.
A list of the fuses, their respective am-
pere ratings and the equipment in their
circuits is provided on the rear of the
cover. 530us122

168n
Manual release In the event of an electrical malfunction,
you can release the fuel filler door man-
ually:
1 Open the cover on the right in the
cargo area: lift the handle on the
cover.
2 Pull the button with the fuel pump
symbol (arrow). 530us123
Manual operation In the event of an electrical system mal-
function, you can operate the sliding/tilt
sunroof manually:
1 Open the glasses compartment (re-
fer to page 102).
2 Insert the Allen wrench from the vehi-
cle tool kit (refer to page 154) in the
opening provided and turn the slid-
ing/tilt sunroof in the desired direc-
tion .530us124
Manual release In the event of an electrical malfunction,
you can release the liftgate manually:
1 Remove the plastic plug from inside
the cargo area and pull toward the
interior (arrow). The liftgate will be
released.
2 Reinstall the plug. 530us125
Fuel filler door Sliding/Tilt sunroof Liftgate

IndexDataTechnologyRepairsCar careControlsOverview
169n
Tailgate Manual release In the event of an electrical malfunction,
you can release the tailgate manually.
1 Unfasten the trim panel clip with the
vehicle key or with a screwdriver
(arrow 1) and remove it toward the
top (arrow 2). 530us091
2 Using the same tool, press the latch
in the direction of the arrow; the
tailgate is released.
3 Reinstall the trim panel. 530us092

170n
Do not use spray starter fluids to start
the engine.
If the battery is discharged, the engine
can be started with the use of two
jumper cables and the battery of an-
other vehicle. Always use jumper ca-
bles with fully insulated handles on the
terminal clamps.
Do not touch the parts conducting
current while the engine is run-
ning. Failure to comply with this creates
a risk of fatal injury.<
Carefully comply with the following in-
structions to avoid personal injury and
damage to one or both vehicles:
1 Be sure that the battery on the sup-
port vehicle is also rated at 12 volts,
and that the capacities of the two
batteries (Ah) are roughly comparable
(printed on casing).
2 Leave your battery connected to the
vehicle's electrical system.
3 Make sure that there is no contact
between the bodywork of the two
vehicles Ð this creates a risk of short
circuits.
4 Start by connecting the jumper cable
from the positive terminal of the sup-
port vehicle to the positive terminal
connector located in your BMW's en-
gine compartment The cover of the
auxiliary terminal for jump starting is
marked with a "+" sign (refer to the il-
lustration). To remove the cover, tip
up the cap (arrow). 530us126
5 Then connect the negative terminals.
Attach the cable to either the support
vehicle's negative battery terminal (-),
or to a suitable ground on its engine
or bodywork. Then connect the other
end of the cable to a ground on the
engine or on the bodywork of the ve-
hicle that is to be started. There is a
special nut for this on the left side
panel of your BMW. Refer to the ar-
row in the illustration.
Follow the same sequence for
connecting the jumper cables
when helping other vehicles. If you do
not, there is the risk of injury if sparks
generate at the battery.< 530us127
Jump-starting
