Driving and Operating 169
Warning (Continued)
.Detect lane markings under
poor weather or visibility
conditions. This can occur if
the windshield or
headlamps are blocked by
dirt, snow, or ice; if they are
not in proper condition; or if
the sun shines directly into
the camera.
. Detect road edges.
. Detect lanes on winding or
hilly roads.
If LDW only detects lane
markings on one side of the road,
it will only warn you when
departing the lane on the side
where it has detected a lane
marking. Always keep your
attention on the road and
maintain proper vehicle position
within the lane, or vehicle
damage, injury, or death could
occur. Always keep the
windshield, headlamps, and (Continued)
Warning (Continued)
camera sensors clean and in
good repair. Do not use LDW in
bad weather conditions.
How the System Works
The LDW camera sensor is on the
windshield ahead of the rearview
mirror.
To turn LDW on and off, press
@on
the center stack. The control
indicator will light when LDW is on.
When LDW is on,@is green if
LDW is available to warn of a lane
departure. If the vehicle crosses a
detected lane marking without using
the turn signal in that direction,
@
changes to amber and flashes. Additionally, there will be three
beeps on the right or left, depending
on the lane departure direction.
When the System Does Not
Seem To Work Properly
The system may not detect lanes as
well when there are:
.
Close vehicles ahead.
. Sudden lighting changes, such
as when driving through tunnels.
. Banked roads.
If the LDW system is not functioning
properly when lane markings are
clearly visible, cleaning the
windshield may help.
LDW alerts may occur due to tar
marks, shadows, cracks in the road,
temporary or construction lane
markings, or other road
imperfections. This is normal system
operation; the vehicle does not need
service. Turn LDW off if these
conditions continue.

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
174 Driving and Operating
Conversions and
Add-Ons
Add-On Electrical
Equipment
{Warning
The Data Link Connector (DLC) is
used for vehicle service
and Emission Inspection/
Maintenance testing. See
Malfunction Indicator Lamp
(Check Engine Light)0104.
A device connected to the DLC —
such as an aftermarket fleet or
driver-behavior tracking device —
may interfere with vehicle
systems. This could affect vehicle
operation and cause a crash.
Such devices may also access
information stored in the vehicle’s
systems.
Caution
Some electrical equipment can
damage the vehicle or cause
components to not work and
would not be covered by the
vehicle warranty. Always check
with your dealer before adding
electrical equipment.
Add-on equipment can drain the
vehicle's 12-volt battery, even if the
vehicle is not operating.
The vehicle has an airbag system.
Before attempting to add anything
electrical to the vehicle, see
Servicing the Airbag-Equipped
Vehicle 071 and Adding Equipment
to the Airbag-Equipped Vehicle
0 71.

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
Vehicle Care 191
Caution (Continued)
.When using concentrated
washer fluid, follow the
manufacturer instructions for
adding water.
. Fill the washer fluid tank
only three-quarters full when
it is very cold. This allows
for fluid expansion if
freezing occurs, which could
damage the tank if it is
completely full.
Brakes
Disc brake pads have built-in wear
indicators that make a high-pitched
warning sound when the brake pads
are worn and new pads are needed.
The sound can come and go or can
be heard all the time when the
vehicle is moving, except when
applying the brake pedal firmly.
{Warning
The brake wear warning sound
means that soon the brakes will
not work well. That could lead to
a crash. When the brake wear
warning sound is heard, have the
vehicle serviced.
Caution
Continuing to drive with worn-out
brake pads could result in costly
brake repair.
Some driving conditions or climates
can cause a brake squeal when the
brakes are first applied or lightly
applied. This does not mean
something is wrong with the brakes.
Properly torqued wheel nuts are
necessary to help prevent brake
pulsation. When tires are rotated,
inspect brake pads for wear and
evenly tighten wheel nuts in the proper sequence to torque
specifications. See
Capacities and
Specifications 0267.
Brake pads should be replaced as
complete sets.
Brake Pedal Travel
See your dealer if the brake pedal
does not return to normal height,
or if there is a rapid increase in
pedal travel. This could be a sign
that brake service may be required.
Replacing Brake System Parts
Always replace brake system parts
with new, approved replacement
parts. If this is not done, the brakes
may not work properly. The braking
performance expected can change
in many other ways if the wrong
replacement brake parts are
installed or if parts are improperly
installed.

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
262 Service and Maintenance
Shocks and Struts
Shocks and struts help aid in control
for a smoother ride.
.Signs of wear may include
steering wheel vibration, bounce/
sway while braking, longer
stopping distance, or uneven
tire wear.
. As part of the multi-point
inspection, trained dealer
technicians can visually inspect
the shocks and struts for signs
of leaking, blown seals,
or damage, and can advise
when service is needed.
Tires
Tires need to be properly inflated,
rotated, and balanced. Maintaining
the tires can save money and fuel,
and can reduce the risk of tire
failure.
. Signs that the tires need to be
replaced include three or more
visible treadwear indicators; cord
or fabric showing through the rubber; cracks or cuts in the
tread or sidewall; or a bulge or
split in the tire.
. Trained dealer technicians can
inspect and recommend the right
tires. Your dealer can also
provide tire/wheel balancing
services to ensure smooth
vehicle operation at all speeds.
Your dealer sells and services
name brand tires.
Vehicle Care
To help keep the vehicle looking like
new, vehicle care products are
available from your dealer. For
information on how to clean and
protect the vehicle’s interior and
exterior, see Interior Care 0248 and
Exterior Care 0244.
Wheel Alignment
Wheel alignment is critical for
ensuring that the tires deliver
optimal wear and performance.
. Signs that the alignment may
need to be adjusted include
pulling, improper vehicle
handling, or unusual tire wear. .
Your dealer has the required
equipment to ensure proper
wheel alignment.
Windshield
For safety, appearance, and the
best viewing, keep the windshield
clean and clear.
. Signs of damage include
scratches, cracks, and chips.
. Trained dealer technicians can
inspect the windshield and
recommend proper replacement
if needed.
Wiper Blades
Wiper blades need to be cleaned
and kept in good condition to
provide a clear view.
. Signs of wear include streaking,
skipping across the windshield,
and worn or split rubber.
. Trained dealer technicians can
check the wiper blades and
replace them when needed.

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
Index 299
Gauges (cont'd)Odometer . . . . . . . . . . . . . . . . . . . . . 101
Speedometer . . . . . . . . . . . . . . . . . 101
Tachometer . . . . . . . . . . . . . . . . . . . 101
Trip Odometer . . . . . . . . . . . . . . . . 101
Warning Lights and
Indicators . . . . . . . . . . . . . . . . . . . . . 99
General Information Service and Maintenance . . . . . 253
Towing . . . . . . . . . . . . . . . . . . . . . . . . 173
Vehicle Care . . . . . . . . . . . . . . . . . . 176
Glove Box . . . . . . . . . . . . . . . . . . . . . . . 92
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 273
H
Hazard Warning Flashers . . . . . . . 124
Head Restraints . . . . . . . . . . . . . . . . . 47
Headlamp Leveling Control . . . . . 124
Headlamps
Adaptive ForwardLighting (AFL) . . . . . . . . . . . . . . . 123
Aiming . . . . . . . . . . . . . . . . . . . . . . . . 197
Automatic . . . . . . . . . . . . . . . . . . . . . 123
Bulb Replacement . . . . . . . . . . . . 197
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . 122
Flash-to-Pass . . . . . . . . . . . . . . . . . 122 Headlamps (cont'd)
High Intensity Discharge
(HID) Lighting . . . . . . . . . . . . . . . 197
High-Beam On Light . . . . . . . . . . . 111
High/Low Beam Changer . . . . . 122
Lamps On Reminder . . . . . . . . . . 111
Heated Steering Wheel . . . . . . . . . . . . . . . . . 96
Heated Front Seats . . . . . . . . . . . . . . 51
Heated Mirrors . . . . . . . . . . . . . . . . . . . 34
Heating . . . . . . . . . . . . . . . . . . . . . . . . . 130
High-Beam On Light . . . . . . . . . . . . 111
Hill and Mountain Roads . . . . . . . . 140
Hill Start Assist (HSA) . . . . . . . . . . 158
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
How to Wear Seat Belts Properly . . . . . . . . . . . . . . . . . . . . . . . . 54
HVAC . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
I
Ignition Positions . . . . . . . . . . . . . . . 146
Ignition Transmission Lock Check . . . . . . . . . . . . . . . . . . . . . . . . . 194
Immobilizer . . . . . . . . . . . . . . . . . . . . . . 32
Indicator Vehicle Ahead . . . . . . . . . . . . . . . . 108 Infants and Young Children,
Restraints . . . . . . . . . . . . . . . . . . . . . . 74
Information Publication Ordering . . . . . . . . . . 278
Infotainment . . . . . . . . . . . . . . . . . . . . 129
Infotainment System . . . . . . . . . . . . 282
Instrument Cluster . . . . . . . . . . . . . . 100
Instrument Panel Storage Area . . . . . . . . . . . . . . . . . . . 92
Instrument Panel Overview . . . . . . . 6
Interior Rearview Mirrors . . . . . . . . . 34
Introduction . . . . . . . . . . . . . . . . . . . . . . . 2
J
Jump Starting - North America . . . . . . . . . . . . . . . . . . . . . . . 238
K
Keyless EntryRemote (RKE) System . . . . . . . . . 23
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
L
Labeling, Tire Sidewall . . . . . . . . . . 213
Lamps Adaptive Forward Lighting . . . . 197
Courtesy . . . . . . . . . . . . . . . . . . . . . . 126
Daytime Running (DRL) . . . . . . 122
Dome . . . . . . . . . . . . . . . . . . . . . . . . . 126

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
300 Index
Lamps (cont'd)Exterior Controls . . . . . . . . . . . . . . 121
Exterior Lighting Battery
Saver . . . . . . . . . . . . . . . . . . . . . . . 127
Front Turn Signal . . . . . . . . . . . . . 199
License Plate . . . . . . . . . . . . . . . . . 203
Malfunction Indicator (Check Engine) . . . . . . . . . . . . . 104
On Reminder . . . . . . . . . . . . . . . . . . 111
Reading . . . . . . . . . . . . . . . . . . . . . . 126
Side Turn Signal . . . . . . . . . . . . . . 200
Sidemarker . . . . . . . . . . . . . . . . . . . 199
Lane Departure Warning (LDW) . . . . . . . . . . . . . . . . 168
Lane Departure Warning Light . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Lap-Shoulder Belt . . . . . . . . . . . . . . . 56
LATCH System Replacing Parts after aCrash . . . . . . . . . . . . . . . . . . . . . . . . . 86
LATCH, Lower Anchors and Tethers for Children . . . . . . . . . . . . 79
Latches, Seatback . . . . . . . . . . . . . . . 50
LED Lighting . . . . . . . . . . . . . . . . . . . . 197
Leveling Control
Headlamp . . . . . . . . . . . . . . . . . . . . 124 Lighting
Adaptive Forward . . . . . . . . . . . . . 123
Entry . . . . . . . . . . . . . . . . . . . . . . . . . 126
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Illumination Control . . . . . . . . . . . 125
LED . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Lights
Adaptive Forward Lighting(AFL) Light . . . . . . . . . . . . . . . . . . . 111
Airbag Readiness . . . . . . . . . . . . . 103
Antilock Brake System (ABS) Warning . . . . . . . . . . . . . . 107
Brake System Warning . . . . . . . 106
Charging System . . . . . . . . . . . . . 104
Check Engine (Malfunction Indicator) . . . . . . . . . . . . . . . . . . . . 104
Cruise Control . . . . . . . . . . . . . . . . . 111
Door Ajar . . . . . . . . . . . . . . . . . . . . . .112
Electric Parking Brake . . . . . . . . 106
Engine Oil Pressure . . . . . . . . . . .110
Flash-to-Pass . . . . . . . . . . . . . . . . . 122
Front Fog Lamp . . . . . . . . . . . . . . . 111
High-Beam On . . . . . . . . . . . . . . . . . 111
High/Low Beam Changer . . . . . 122
Lane Departure Warning . . . . . . 108
Low Fuel Warning . . . . . . . . . . . . .110 Lights (cont'd)
Operate Pedal . . . . . . . . . . . . . . . . 107
Seat Belt Reminders . . . . . . . . . . 102
Security . . . . . . . . . . . . . . . . . . . . . . .110
Service Electric Parking
Brake . . . . . . . . . . . . . . . . . . . . . . . 107
StabiliTrak OFF . . . . . . . . . . . . . . . 108
Tire Pressure . . . . . . . . . . . . . . . . . 109
Traction Control System (TCS)/StabiliTrak . . . . . . . . . . . . 109
Warning, Power Steering . . . . . 108
Locks Automatic Door . . . . . . . . . . . . . . . . . 29
Delayed Locking . . . . . . . . . . . . . . . . 28
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Lockout Protection . . . . . . . . . . . . . . 29
Power Door . . . . . . . . . . . . . . . . . . . . . 28
Loss of Control . . . . . . . . . . . . . . . . . 138
Low Fuel Warning Light . . . . . . . . . 110
Low-Profile Tires . . . . . . . . . . . . . . . . 213
Lower Anchors and Tethers
for Children (LATCH
System) . . . . . . . . . . . . . . . . . . . . . . . . 79
Lumbar Adjustment . . . . . . . . . . . . . . 49 Front Seats . . . . . . . . . . . . . . . . . . . . . 49

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
Index 301
M
MaintenanceRecords . . . . . . . . . . . . . . . . . . . . . . 265
Maintenance and Care Additional . . . . . . . . . . . . . . . . . . . . . 260
Maintenance Schedule . . . . . . . . . 255 Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . . . 263
Malfunction Indicator Lamp . . . . . 104
Manual Mode . . . . . . . . . . . . . . . . . . . 154
Messages Engine Power . . . . . . . . . . . . . . . . .115
Vehicle . . . . . . . . . . . . . . . . . . . . . . . .115
Vehicle Speed . . . . . . . . . . . . . . . . .116
Mirrors Automatic DimmingRearview . . . . . . . . . . . . . . . . . . . . . . 34
Convex . . . . . . . . . . . . . . . . . . . . . . . . . 33
Folding . . . . . . . . . . . . . . . . . . . . . . . . . 34
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 34
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Mirrors, Interior Rearview . . . . . . . . 34
Monitor System, Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 219
N
Navigation
Connected Services . . . . . . . . . . 291
New Vehicle Break-In . . . . . . . . . . . 146
O
Odometer . . . . . . . . . . . . . . . . . . . . . . . 101 Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . 138
Oil
Engine . . . . . . . . . . . . . . . . . . . . . . . . 181
Engine Oil Life System . . . . . . . 183
Pressure Light . . . . . . . . . . . . . . . . .110
Older Children, Restraints . . . . . . . 73
Online Owner Center . . . . . . . . . . . 272
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . 282
OnStar Additional
Information . . . . . . . . . . . . . . . . . . . . 285
OnStar Emergency . . . . . . . . . . . . . 284
OnStar Overview . . . . . . . . . . . . . . . 283
OnStar Security . . . . . . . . . . . . . . . . 285
Operate Pedal Light . . . . . . . . . . . . 107
Operation
Fog Lamps . . . . . . . . . . . . . . . . . . . 125
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Overheating, Engine . . . . . . . . . . . . 189
P
Park Shifting Into . . . . . . . . . . . . . . . . . . . 150
Shifting Out of . . . . . . . . . . . . . . . . 150
Park Assist . . . . . . . . . . . . . . . . . . . . . 164
Parking
Brake and P (Park)Mechanism Check . . . . . . . . . . 194
Over Things That Burn . . . . . . . 151
Parking or Backing
Assistance Systems . . . . . . . . . . 164
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . 103
Passenger Compartment Air
Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Passenger Sensing System . . . . . 67
Perchlorate Materials Requirements, California . . . . . . 177
Personalization
Vehicle . . . . . . . . . . . . . . . . . . . . . . . .116
Power Door Locks . . . . . . . . . . . . . . . . . . . . . 28
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Outlets . . . . . . . . . . . . . . . . . . . . . . . . . 98
Protection, Battery . . . . . . . . . . . . 127
Retained Accessory (RAP) . . . 149
Seat Adjustment . . . . . . . . . . . . . . . . 48
Windows . . . . . . . . . . . . . . . . . . . . . . . 35
