Engine Compartment
Fuse Block
To open the fuse block cover, press
the clips at the front and back and
rotate the cover up to the side.
Notice:Spilling liquid on any
electrical component on the
vehicle may damage it. Always
keep the covers on any electrical
component.
Engine Compartment Fuse Block
A fuse puller is located in the engine
compartment fuse block.
The vehicle may not be equipped
with all of the fuses, relays, and
features shown. Mini
Fuses Amps Usage
1 20A Engine Control
Module
2 10A Oxygen Sensor/
Purge Solenoid

Black plate (28,1)Buick Verano Owner Manual - 2012 - CRC - 1/10/12
10-28 Vehicle Care
Mini
Fuses Amps Usage
3 15A Ignition Coils/
Injectors
4 15A Spare
5 –Empty
6a –Empty
6b 7.5A Mirror Defogger
7 5A Powertrain
Cooling
8 7.5A Mass Air Flow
Sensor/Pre
O2 Sensor
9 –Empty
10 5A Battery Potential
Signal
11 7.5A Spare
12 –Empty Mini
Fuses Amps Usage
13 –Empty
14 –Empty
15 10A Engine Control
Module
17 10A Transmission
Control Module
22 10A Left High-Beam
Headlamp
24 –Empty
25 –Empty
26 15A Front Fog Lamps
31 –Empty
32 5A Airbag
33 –Empty
34 7.5A Spare Mini
Fuses Amps Usage
35 5A Door Switch
Supply/Left
Power Window
36 10A Air Conditioning
Compressor
Clutch
37 10A Canister Vent
38 –Empty
39 20A Fuel System
Control Module
40 10A Front Windshield
Washer
41 10A Right High-Beam
Headlamp
46 –Empty
47 15A Horn

Black plate (29,1)Buick Verano Owner Manual - 2012 - CRC - 1/10/12
Vehicle Care 10-29
Mini
Fuses Amps Usage
49 20A Fuel Pump
50 –Empty
51 5A Inside Rear View
Mirror
52 –Empty
53 10A Ignition Engine
Control Module/
Transmission
Control Module
54 7.5A Instrument Panel
Cluster/Fuel
System Control
Module/Heater,
Ventilation, and
Air Conditioning
Run/Crank J-Case
Fuses Amps Usage
16 30A Starter Control
18 30A Rear Window
Defogger
19 30A Front Power
Window
20 30A Rear Power
Window
21 30A Antilock Brake
System Valves
23 –Empty
27 50A Spare
28 –Empty J-Case
Fuses Amps Usage
29 30A Electric Parking
Brake
30 60A Antilock Brake
System Pump
42 40A Engine
Cooling Fan
43 30A Front Wipers
44 –Empty
45 30A Engine
Cooling Fan
48 60A Engine
Cooling Fan

Black plate (30,1)Buick Verano Owner Manual - 2012 - CRC - 1/10/12
10-30 Vehicle Care
RelaysUsage
1 Empty
2 Starter
3 Engine Control
Powertrain
4 Rear Window
Defogger
5 Empty
6 Empty
7 Spare
8 Empty
9 Spare
10 EGR/Coolant Pump/
AIR Solenoid Valve
11 Engine Cooling Fan
12 Engine Cooling Fan
13 Engine Cooling Fan
14 Run/CrankInstrument Panel Fuse
Block
The instrument panel fuse block is
on the driver side of the instrument
panel. To access the fuses:
1. Access the fuse block by opening the storage
compartment.
2. Pull straight down and out to remove the storage
compartment.
3. Remove the cover.
To reinstall the cover, line up the
retainers and push into place.
Instrument Panel Fuse Block
The vehicle may not be equipped
with all of the fuses, relays, and
features shown.

Black plate (31,1)Buick Verano Owner Manual - 2012 - CRC - 1/10/12
Vehicle Care 10-31
Fuses Amps Usage1 2A Body Control
Module
2 20A Body Control
Module
3 20A Body Control
Module
4 20A Infotainment
System
5 10A Information
Display/
Parking
Assist
6 20A Ignition/
Electronic
Key System
7 20A Power Outlet
8 30A Body Control
Module
9 30A Body Control
Module
10 30A Body Control
Module Fuses Amps Usage
11 40A Interior Fan
12 25A Driver
Power Seat
13 –Not Used
14 7.5A Diagnostic
Connector
15 10A Airbag
16 10A Central
Locking
System/
Tailgate
17 10A Air
Conditioning
System
18 30A Infotainment
System
19 30A Body Control
Module
20 5A Passenger
Power Seat Fuses Amps Usage
21 7.5A Instrument
Cluster
22 2A/5A Ignition/
Electronic
Key System
23 20A Body Control
Module
24 20A Body Control
Module
25 –Not Used
26 –Not Used
Relays Usage 1 Trunk Open
2 Door Security
3 Power Outlet

Black plate (32,1)Buick Verano Owner Manual - 2012 - CRC - 1/10/12
10-32 Vehicle Care
Rear Compartment Fuse
Block
The rear compartment fuse block,
if equipped, is located on the left
side of the trunk behind a cover.
The vehicle may not be equipped
with all of the fuses, relays, and
features shown.Mini
Fuses Amps Usage
F02 –Empty
F03 5A Rear Park
Assist Mini
Fuses Amps Usage
F04 –Empty
F06 –Empty
F07 10A Spare
F08 –Empty

Black plate (33,1)Buick Verano Owner Manual - 2012 - CRC - 1/10/12
Vehicle Care 10-33
Mini
Fuses Amps Usage
F09 –Empty
F10 –Empty
F11 –Empty
F13 –Empty
F14 –Empty
F15 –Empty
F16 –Empty
F17 –Empty
F18 –Empty
F19 7.5A Heated
Steering
Wheel Mini
Fuses Amps Usage
F20 25A Sunroof
F21 25A Heated Seats
F22 –Empty
F24 –Empty
F25 5A Spare
F26 30A Spare
F28 –Empty
F30 –Empty
F31 30A Amplifier J-Case
Fuses Amps Usage
F1 –Empty
F5 –Empty
F12 –Empty
F23 –Empty
F27 30A Passive Entry
F29 –Empty
Relays Usage R01 Empty
R02 Run
R03 Empty
R04 Empty
R05 Empty

Black plate (34,1)Buick Verano Owner Manual - 2012 - CRC - 1/10/12
10-34 Vehicle Care
Wheels and Tires
Tires
Every new GM vehicle has
high-quality tires made by a
leading tire manufacturer.
See the warranty manual for
information regarding the tire
warranty and where to get
service. For additional
information refer to the tire
manufacturer.
{WARNING
.Poorly maintained and
improperly used tires are
dangerous.
.Overloading the tires can
cause overheating as a result
of too much flexing. There
could be a blowout and a
serious crash. SeeVehicle
Load Limits on page 9‑10.
(Continued)
WARNING (Continued)
.Underinflated tires pose the
same danger as overloaded
tires. The resulting crash
could cause serious injury.
Check all tires frequently to
maintain the recommended
pressure. Tire pressure
should be checked when the
tires are cold.
.Overinflated tires are more
likely to be cut, punctured,
or broken by a sudden
impact—such as when
hitting a pothole. Keep tires at
the recommended pressure.
.Worn or old tires can cause a
crash. If the tread is badly
worn, replace them.
(Continued)
WARNING (Continued)
.Replace any tires that have
been damaged by impacts
with potholes, curbs, etc.
.Improperly repaired tires can
cause a crash. Only the
dealer or an authorized tire
service center should repair,
replace, dismount, and mount
the tires.
.Do not spin the tires in
excess of 56 km/h (35 mph)
on slippery surfaces such
as snow, mud, ice, etc.
Excessive spinning may
cause the tires to explode.

Black plate (35,1)Buick Verano Owner Manual - 2012 - CRC - 1/10/12
Vehicle Care 10-35
Winter Tires
Consider installing winter tires on
the vehicle if frequent driving on
snow or ice covered roads is
expected. All season tires provide
good overall performance on most
surfaces, but they may not offer
the traction or the same level of
performance as winter tires on snow
or ice covered roads.
Winter tires, in general, are
designed for increased traction on
snow and ice covered roads. With
winter tires, there may be decreased
dry road traction, increased road
noise, and shorter tread life. After
changing to winter tires, be alert for
changes in vehicle handling and
braking.
See your dealer for details
regarding winter tire availability and
proper tire selection. Also, see
Buying New Tires on page 10‑49.If using snow tires:.Use tires of the same brand and
tread type on all four wheel
positions.
.Use only radial ply tires of the
same size, load range, and
speed rating as the original
equipment tires.
Winter tires with the same speed
rating as the original equipment tires
may not be available for H, V, W, Y,
and ZR speed rated tires. If winter
tires with a lower speed rating are
chosen, never exceed the tire's
maximum speed capability.
Low-Profile Tires
If the vehicle has P235/45R18
size tires, they are classified as
low‐profile tires. Notice:
Low‐profile tires are
more susceptible to damage
from road hazards or curb
impact than standard profile
tires. Tire and/or wheel
assembly damage can occur
when coming into contact
with road hazards like,
potholes, or sharp edged
objects, or when sliding into a
curb. The warranty does not
cover this type of damage.
Keep tires set to the correct
inflation pressure and, when
possible, avoid contact with
curbs, potholes, and other
road hazards.

Black plate (36,1)Buick Verano Owner Manual - 2012 - CRC - 1/10/12
10-36 Vehicle Care
Tire Sidewall Labeling
Useful information about a tire is
molded into its sidewall. The
examples show a typical
passenger vehicle tire and a
compact spare tire sidewall.
Passenger (P‐Metric) Tire Example
(A) Tire Size:The tire size is
a combination of letters and
numbers used to define a
particular tire's width, height,
aspect ratio, construction type, and service description. See the
“Tire Size”
illustration later in this
section for more detail.
(B) TPC Spec (Tire
Performance Criteria
Specification)
:Original
equipment tires designed to
GM's specific tire performance
criteria have a TPC specification
code molded onto the sidewall.
GM's TPC specifications meet
or exceed all federal safety
guidelines.
(C) DOT (Department of
Transportation)
:The
Department of Transportation
(DOT) code indicates that the
tire is in compliance with
the U.S. Department of
Transportation Motor Vehicle
Safety Standards. (D) Tire Identification Number
(TIN)
:The letters and numbers
following the DOT (Department
of Transportation) code are
the Tire Identification Number
(TIN). The TIN shows the
manufacturer and plant code,
tire size, and date the tire was
manufactured. The TIN is
molded onto both sides of the
tire, although only one side may
have the date of manufacture.
(E) Tire Ply Material
:The type
of cord and number of plies in
the sidewall and under the tread.
(F) Uniform Tire Quality
Grading (UTQG)
:Tire
manufacturers are required to
grade tires based on three
performance factors: treadwear,
traction, and temperature
resistance. For more information
see Uniform Tire Quality
Grading on page 10‑51.
