Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
8534310) - 2016 - crc - 2/29/16
Climate Controls 241
6. SYNC (SynchronizedTemperature)
7. AUTO (Automatic Operation)
8. Recirculation
9. A/C (Air Conditioning)
10. Rear Window Defogger
11. Power
Automatic Operation
The system automatically controls
the fan speed, air delivery, air
conditioning, and recirculation in
order to heat or cool the vehicle to
the desired temperature:
When AUTO is lit, all four functions
operate automatically. Each function
can also be manually set and the
selected setting is displayed.
Functions not manually set will
continue to be automatically
controlled, even if the AUTO
indicator is not lit.
For automatic operation:
1. Press AUTO. 2. Set the temperature. Allow the
system time to stabilize. Adjust
the temperature as needed for
best comfort.
To improve fuel efficiency and to
cool the vehicle faster, recirculation
may be automatically selected in
warm weather. The recirculation
light will not come on. Press
@to
select recirculation; press it again to
select outside air.
Q/R: The temperature can be
adjusted separately for the driver
and the passenger. Press to
increase or decrease the
temperature.
SYNC : Press to link the passenger
and rear climate temperature
settings to the driver setting. The
SYNC indicator light will turn on.
When the passenger or rear climate
settings are adjusted, the SYNC
indicator light turns off.
Manual Operation
O: Press to turn the fan off or on.
Q^or^ R:Press to increase or
decrease the fan speed. The fan
speed setting appears on the main display. Pressing either button
cancels automatic fan control and
the fan is controlled manually. Press
AUTO to return to automatic
operation.
Air Delivery Mode Controls :
Press
X,Y, or[to change the
direction of the airflow. The indicator
light in the button will turn on. Any
combination of the three buttons
can be selected. The indicator light
in the button will turn on. The
current mode appears in the display
screen. Pressing any of the three
buttons cancels automatic air
delivery control and the direction of
the airflow is controlled manually.
Press AUTO to return to automatic
operation.
To change the current mode, select
one or more of the following:
X: Clears the windows of fog or
moisture. Air is directed to the
windshield.
Y: Air is directed to the instrument
panel outlets.
[: Air is directed to the floor
outlets.

Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
8534310) - 2016 - crc - 2/29/16
242 Climate Controls
0MAX :Air is directed to the
windshield and the fan runs at a
higher speed. Fog or frost is cleared
from the windshield more quickly.
When the button is pressed again,
the system returns to the previous
mode setting.
For best results, clear all snow and
ice from the windshield before
defrosting.
A/C : Press to turn the air
conditioning system on or off. If the
climate control system is turned off
or the outside temperature falls
below freezing, the air conditioner
will not run.
Pressing this button cancels
automatic air conditioning and turns
off the air conditioner. Press AUTO
to return to automatic operation and
the air conditioner runs
automatically as needed. When the
indicator light is on, the air
conditioner runs automatically to
cool the air inside the vehicle or to
dry the air needed to defog the
windshield faster.@: Press to turn on recirculation.
An indicator light comes on. Air is
recirculated to quickly cool the
inside of the vehicle or to reduce the
entry of outside air and odors.
Auto Defog : The climate control
system may have a sensor to
automatically detect high humidity
inside the vehicle. When high
humidity is detected, the climate
control system may adjust to
outside air supply and turn on the
air conditioner. The fan speed may
slightly increase to help prevent
fogging. If the climate control
system does not detect possible
window fogging, it returns to normal
operation.
To turn Auto Defog off or on, see
“Climate and Air Quality” under
Vehicle Personalization 0146.
Rear Window Defogger
K:Press to turn the rear window
defogger on or off. An indicator light
on the button comes on to show that
the rear window defogger is on. The defogger can be turned off by
turning the ignition to ACC/
ACCESSORY or LOCK/OFF.
The rear window defogger can be
set to automatic operation. See
“Climate and Air Quality”
under
Vehicle Personalization 0146.
When auto rear defog is selected,
the rear window defogger turns on
automatically when the interior
temperature is cold and the outside
temperature is about 7 °C (44 °F)
and below. The auto rear defogger
turns off automatically.
If the vehicle is equipped with
heated outside rearview mirrors,
they turn on when the rear window
defogger button is on and help to
clear fog or frost from the surface of
the mirror. See Heated Mirrors 044.
Caution
Do not try to clear frost or other
material from the inside of the
front windshield and rear window
with a razor blade or anything
else that is sharp. This may
(Continued)

Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
8534310) - 2016 - crc - 2/29/16
Driving and Operating 293
Warning (Continued)
.Detect all vehicles,
especially vehicles with a
trailer, tractors, muddy
vehicles, etc.
. Detect a vehicle when
weather limits visibility, such
as in fog, rain, or snow.
. Detect a vehicle ahead if it
is partially blocked by
pedestrians or other objects.
Complete attention is always
required while driving, and you
should be ready to take action
and apply the brakes and/or steer
the vehicle to avoid crashes.
FAB may slow the vehicle to a
complete stop to try to avoid a
potential crash. If this happens, FAB
may engage the Electric Parking
Brake (EPB) to hold the vehicle at a
stop. Release the EPB or firmly
press the accelerator pedal.
{Warning
FAB may automatically brake the
vehicle suddenly in situations
where it is unexpected and
undesired. It could respond to a
turning vehicle ahead, guardrails,
signs, and other non-moving
objects. To override FAB, firmly
press the accelerator pedal, if it is
safe to do so.
Intelligent Brake Assist (IBA)
IBA may activate when the brake
pedal is applied quickly by providing
a boost to braking based on the
speed of approach and distance to
a vehicle ahead.
Minor brake pedal pulsations or
pedal movement during this time is
normal and the brake pedal should
continue to be applied as needed.
IBA will automatically disengage
only when the brake pedal is
released.
{Warning
IBA may increase vehicle braking
in situations when it may not be
necessary. You could block the
flow of traffic. If this occurs, take
your foot off the brake pedal and
then apply the brakes as needed.
FAB and IBA can be disabled
through vehicle personalization. See
“Auto Collision Preparation” in
“Collision/Detection Systems” under
Vehicle Personalization 0146.
Side Blind Zone
Alert (SBZA)
If equipped, the SBZA system is a
lane-changing aid that assists
drivers with avoiding crashes that
occur with moving vehicles in the
side blind zone (or spot) areas.
When the vehicle is in a forward
gear, the left or right side mirror
display will light up if a moving
vehicle is detected in that blind
zone. If the turn signal is activated
and a vehicle is also detected on

Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
8534310) - 2016 - crc - 2/29/16
336 Vehicle Care
FuseUsage
K01 Start/Stop
K02 A/C clutch
K03 Engine control module
K04 Wiper
K05 Start solenoid
K06 –
K07 –
K08 Transmission oil pump
K09 Wiper speed
K10 Starter K11 Headlamp washers
K12 High-beam headlamps
K13 Daytime running lamps
K14 Run/Crank
K15 Rear window/Mirror defoggerInstrument Panel Fuse
Block
The instrument panel fuse block is
in the glove box. To access the
fuses, open the fuse panel door
from the passenger side by pulling
it out.
To reinstall the door, insert the tabs
on the top of the door into the
console first, then push the door
back into its original location.
The vehicle may not be equipped
with all of the fuses, relays, and
features shown.
Fuses Usage
F1 –
F2 Front HVAC blower
F3 Power seat
F4 Lighter (China only)
F5 –
F6 Front power windows
F7 –
F8 Accessory power outlet
F9 Body control module 8

Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
8534310) - 2016 - crc - 2/29/16
Vehicle Care 377
.Never rub any surface
aggressively or with too much
pressure.
. Do not use laundry detergents or
dishwashing soaps with
degreasers. For liquid cleaners,
use approximately 20 drops per
3.8 L (1 gal) of water.
A concentrated soap solution will
create streaks and attract dirt.
Do not use solutions that contain
strong or caustic soap.
. Do not heavily saturate the
upholstery when cleaning.
. Do not use solvents or cleaners
containing solvents.
Interior Glass
To clean, use a terry cloth fabric
dampened with water. Wipe droplets
left behind with a clean dry cloth.
If necessary, use a commercial
glass cleaner after cleaning with
plain water.
Caution
To prevent scratching, never use
abrasive cleaners on automotive
glass. Abrasive cleaners or
aggressive cleaning may damage
the rear window defogger.
Cleaning the windshield with water
during the first three to six months
of ownership will reduce tendency
to fog.
Speaker Covers
Vacuum around a speaker cover
gently, so that the speaker will not
be damaged. Clean spots with water
and mild soap.
Coated Moldings
Coated moldings should be cleaned.
. When lightly soiled, wipe with a
sponge or soft, lint-free cloth
dampened with water.
. When heavily soiled, use warm
soapy water.
Fabric/Carpet/Suede
Start by vacuuming the surface
using a soft brush attachment. If a
rotating vacuum brush attachment is
being used, only use it on the floor
carpet. Before cleaning, gently
remove as much of the soil as
possible:
.Gently blot liquids with a paper
towel. Continue blotting until no
more soil can be removed.
. For solid soils, remove as much
as possible prior to vacuuming.
To clean: 1. Saturate a clean, lint-free colorfast cloth with water.
Microfiber cloth is
recommended to prevent lint
transfer to the fabric or carpet.
2. Remove excess moisture by gently wringing until water does
not drip from the cleaning cloth.
3. Start on the outside edge of the soil and gently rub toward the
center. Fold the cleaning cloth

Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
8534310) - 2016 - crc - 2/29/16
424 Index
Flat Tire (cont'd)Changing . . . . . . . . . . . . . . . . . . . . . 359
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 379
Fluid Automatic Transmission . . . . . . 317
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 325
Washer . . . . . . . . . . . . . . . . . . . . . . . 324
Fog Lamps . . . . . . . . . . . . . . . . . . . . . 160
Folding Mirrors . . . . . . . . . . . . . . . . . . 44
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . 290
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 406
Front Automatic Braking
(FAB) System . . . . . . . . . . . . . . . . . 292
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Front Seats
Heated and Cooled . . . . . . . . . . . . . 55
Front Storage . . . . . . . . . . . . . . . . . . . . 97
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 298 Additives . . . . . . . . . . . . . . . . . . . . . 299
Economy Driving . . . . . . . . . . . . . . . 24
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 301
Filling the Tank . . . . . . . . . . . . . . . 299
Foreign Countries . . . . . . . . . . . . 299
Gauge . . . . . . . . . . . . . . . . . . . . . . . . .115 Fuel (cont'd)
Low Fuel Warning Light . . . . . . . 126
Requirements, California . . . . . 299
System Messages . . . . . . . . . . . . 140
Fuses Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 334
Fuses and Circuit Breakers . . . 333
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 336
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 337
G
Garage Door Opener . . . . . . . . . . . 151Programming . . . . . . . . . . . . . . . . . 151
Gauges Engine CoolantTemperature . . . . . . . . . . . . . . . . .116
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . .115
Odometer . . . . . . . . . . . . . . . . . . . . . .114
Speedometer . . . . . . . . . . . . . . . . . .114
Tachometer . . . . . . . . . . . . . . . . . . . .114
Trip Odometer . . . . . . . . . . . . . . . . .114
Warning Lights and Indicators . . . . . . . . . . . . . . . . . . . .110
General Information Service and Maintenance . . . . . 381
Towing . . . . . . . . . . . . . . . . . . . . . . . . 301 General Information (cont'd)
Vehicle Care . . . . . . . . . . . . . . . . . . 310
Global Positioning System (GPS) . . . . . . . . . . . . . . . . . 211
Glove Box . . . . . . . . . . . . . . . . . . . . . . . 97
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 399
Guidance Problems with the Route . . . . . . 212
H
Halogen Bulbs . . . . . . . . . . . . . . . . . . 331
Hazard Warning Flashers . . . . . . . 159
HD Radio Technology . . . . . . . . . . 173
Head Restraints . . . . . . . . . . . . . . . . . 50
Head-up Display . . . . . . . . . . . . . . . . 133
Headlamp Leveling Control . . . . . 158
HeadlampsAdaptive Forward
Lighting (AFL) . . . . . . . . . . . . . . . 158
Aiming . . . . . . . . . . . . . . . . . . . . . . . . 331
Automatic . . . . . . . . . . . . . . . . . . . . . 157
Bulb Replacement . . . . . . . . . . . . 331
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . 157
Flash-to-Pass . . . . . . . . . . . . . . . . . 157
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . 331
High-Beam On Light . . . . . . . . . . 126

Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
8534310) - 2016 - crc - 2/29/16
426 Index
Lights (cont'd)Airbag Readiness . . . . . . . . . . . . . .118
Antilock Brake System
(ABS) Warning . . . . . . . . . . . . . . 122
Brake System Warning . . . . . . . 121
Charging System . . . . . . . . . . . . . .119
Cruise Control . . . . . . . . . . . . . . . . 127
Door Ajar . . . . . . . . . . . . . . . . . . . . . 128
Electric Parking Brake . . . . . . . . 122
Engine Coolant Temperature Warning . . . . . . . 124
Engine Oil Pressure . . . . . . . . . . 125
Flash-to-Pass . . . . . . . . . . . . . . . . . 157
Front Fog Lamp . . . . . . . . . . . . . . 127
High-Beam On . . . . . . . . . . . . . . . . 126
High/Low Beam Changer . . . . . 157
Low Fuel Warning . . . . . . . . . . . . 126
Safety Belt Reminders . . . . . . . . .117
Security . . . . . . . . . . . . . . . . . . . . . . 126
Service Electric Parking Brake . . . . . . . . . . . . . . . . . . . . . . . 122
StabiliTrak
®OFF . . . . . . . . . . . . . 124
Tire Pressure . . . . . . . . . . . . . . . . . 125
Traction Control System
(TCS)/StabiliTrak
®. . . . . . . . . . 124
Traction Off . . . . . . . . . . . . . . . . . . . 123
Locks Automatic Door . . . . . . . . . . . . . . . . . 35 Locks (cont'd)
Delayed Locking . . . . . . . . . . . . . . . . 34
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Lockout Protection . . . . . . . . . . . . . . 35
Power Door . . . . . . . . . . . . . . . . . . . . . 34
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Loss of Control . . . . . . . . . . . . . . . . . 251
Low Fuel Warning Light . . . . . . . . . 126
Lower Anchors and Tethers for Children (LATCH
System) . . . . . . . . . . . . . . . . . . . . . . . . 85
Lumbar Adjustment . . . . . . . . . . . . . . 52 Front Seats . . . . . . . . . . . . . . . . . . . . . 52
M
MaintenanceRecords . . . . . . . . . . . . . . . . . . . . . . 392
Maintenance and Care Additional . . . . . . . . . . . . . . . . . . . . . 387
Maintenance Schedule . . . . . . . . . 382 Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . . . 390
Malfunction Indicator Lamp . . . . . 119
Manual Mode . . . . . . . . . . . . . . . . . . . 269
Map Data Updates . . . . . . . . . . . . . . 212
Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Media Avoiding Untrusted Devices . . 179
Memory Features . . . . . . . . . . . . . . . . 11 Memory Seats . . . . . . . . . . . . . . . . . . . 53
Messages
Airbag System . . . . . . . . . . . . . . . . 143
Battery Voltage andCharging . . . . . . . . . . . . . . . . . . . . 137
Brake System . . . . . . . . . . . . . . . . 137
Door Ajar . . . . . . . . . . . . . . . . . . . . . 138
Engine Cooling System . . . . . . . 139
Engine Oil . . . . . . . . . . . . . . . . . . . . 139
Engine Power . . . . . . . . . . . . . . . . 140
Fuel System . . . . . . . . . . . . . . . . . . 140
Key and Lock . . . . . . . . . . . . . . . . . 140
Object Detection System . . . . . 141
Ride Control System . . . . . . . . . . 143
Security . . . . . . . . . . . . . . . . . . . . . . 143
Steering System . . . . . . . . . . . . . . 143
Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Transmission . . . . . . . . . . . . . . . . . 144
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 136
Washer Fluid . . . . . . . . . . . . . . . . . 145
Window . . . . . . . . . . . . . . . . . . . . . . . 145
Messaging Text . . . . . . . . . . . . . . . . . . . . . . . . . . . 225
Mirrors Automatic Dimming . . . . . . . . . . . . . 44
Automatic Dimming
Rearview . . . . . . . . . . . . . . . . . . . . . . 44
Convex . . . . . . . . . . . . . . . . . . . . . . . . . 43

Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
8534310) - 2016 - crc - 2/29/16
Index 427
Mirrors (cont'd)Folding . . . . . . . . . . . . . . . . . . . . . . . . . 44
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 44
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Tilt in Reverse . . . . . . . . . . . . . . . . . . 44
Mirrors, Interior Rearview . . . . . . . . 44
Monitor System, Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 347
Multi-band Antenna . . . . . . . . . . . . . 175
N
Navigation
Destination . . . . . . . . . . . . . . . . . . . 196
OnStar
®. . . . . . . . . . . . . . . . . . . . . . .411
Using the System . . . . . . . . . . . . . 187
Navigation Symbols . . . . . . . . . . . . 195
Net, Convenience . . . . . . . . . . . . . . 100
New Vehicle Break-In . . . . . . . . . . . 259
O
Object Detection System Messages . . . . . . . . . . . . . . . . . . . . . 141
Odometer . . . . . . . . . . . . . . . . . . . . . . . 114 Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . 251
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . 314
Engine Oil Life System . . . . . . . 316 Oil (cont'd)
Messages . . . . . . . . . . . . . . . . . . . . 139
Pressure Light . . . . . . . . . . . . . . . . 125
Older Children, Restraints . . . . . . . 78
Online Owner Center . . . . . . . . . . . 399
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . 408
OnStar System . . . . . . . . . . . . . . . . . 186
OnStar
®Additional
Information . . . . . . . . . . . . . . . . . . . . 414
OnStar
®Connections . . . . . . . . . . . 412
OnStar®Diagnostics . . . . . . . . . . . . 414
OnStar®Emergency . . . . . . . . . . . . 411
OnStar®Navigation . . . . . . . . . . . . . 411
OnStar®Overview . . . . . . . . . . . . . . 410
OnStar®Security . . . . . . . . . . . . . . . 411
OnStar®System . . . . . . . . . . . . . . . . 209
Operation Fog Lamps . . . . . . . . . . . . . . . . . . . 160
Ordering Service Publications . . . . . . . . . . 405
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . 108
Overheating, Engine . . . . . . . . . . . . 323
Overview . . . . . . . . . . . . . . . . . . . . . . . 164
P
Pandora Internet Radio . . . . . . . . . 175
Park
Shifting Into . . . . . . . . . . . . . . . . . . . 264
Shifting Out of . . . . . . . . . . . . . . . . 265
Parking Brake and P (Park)Mechanism Check . . . . . . . . . . 328
Over Things That Burn . . . . . . . 265
Parking or Backing
Assistance Systems . . . . . . . . . . 285
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . 118
Passenger Compartment Air
Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Passenger Sensing System . . . . . 72
Perchlorate Materials Requirements, California . . . . . . 310
Personalization
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 146
Phone Bluetooth . . . . . . . . . . . 220, 221, 224
Port USB . . . . . . . . . . . . . . . . . . . . . . . . . . 182
Positioning Vehicle . . . . . . . . . . . . . . . . . . . . . . . .211
Power Door Locks . . . . . . . . . . . . . . . . . . . . . 34
