BUICK PARK AVENUE 2002 Owner's Manual
Manufacturer: BUICK, Model Year: 2002, Model line: PARK AVENUE, Model: BUICK PARK AVENUE 2002Pages: 395, PDF Size: 2.67 MB
Page 1 of 395
Page 2 of 395
i
2002 Buick Park Avenue
Owner's Manual
Litho in U.S.A.Copyright General Motors Corporation 06/14/01
Part Number 25728656 A First Edition All Rights Reserved
Page 3 of 395
ii
GENERAL MOTORS, GM, the GM Emblem, BUICK,
the BUICK Emblem and the name PARK AVENUE are
registered trademarks of General Motors Corporation.
This manual includes the latest information at the time
it was printed. We reserve the right to make changes
after that time without further notice. For vehicles first
sold in Canada, substitute the name ªGeneral Motors of
Canada Limitedº for Buick Motor Division whenever it
appears in this manual.
Please keep this manual in your vehicle, so it will
be there if you ever need it when you're on the road.
If you sell the vehicle, please leave this manual in it
so the new owner can use it.
We support voluntary
technician certification.
For Canadian Owners Who Prefer a
French Language Manual:
Aux propri‡taires canadiens: Vous pouvez vous
procurer un exemplaire de ce guide en fran†ais chez
votre concessionaire ou au:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
Page 4 of 395
iii
CAUTION:
These mean there is something that could hurt
In the caution area, we tell you what the hazard is.
Y ou will also find a circle
Page 5 of 395
iv
Vehicle Damage Warnings
Also, in this book you will find these notices:
NOTICE:
These mean there is something that could damage
your vehicle.
In the notice area, we tell you about something that
can damage your vehicle. Many times, this damage
would not be covered by your warranty, and it could
be costly. But the notice will tell you what to do to help
avoid the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different
colors or in different words.
You'll also see warning labels on your vehicle.
They use the same words, CAUTION or NOTICE.
Vehicle Symbols
Your vehicle may be equipped with components and
labels that use symbols instead of text. Symbols,
used on your vehicle, are shown along with the text
describing the operation or information relating to a
specific component, control, message, gage or indicator.
If you need help figuring out a specific name of a
component, gage or indicator reference the following
topics in the Index:
ªEngine Compartment Overviewº
ªInstrument Panelº
ªComfort Controlsº
ªAudio Systemsº
Also see ªWarning Lights and Gagesº in the Index.
Page 6 of 395
v
These are some examples of vehicle symbols you may find on your vehicle:
Page 7 of 395
1-
1-1
Section 1 Seats and Restraint Systems
Here you'll find information about the seats in your vehicle and how to use your safety belts properly. You can also
learn about some things you should not do with air bags and safety belts.
1
-2 Seats and Seat Controls
1
-8 Safety Belts: They're for Everyone
1
-12 Here Are Questions Many People Ask About
Safety Belts
-- and the Answers
1
-14 How to Wear Safety Belts Properly
1
-14 Driver Position
1
-20 Safety Belt Use During Pregnancy
1
-21 Right Front Passenger Position
1
-21 Air Bag Systems
1
-30 Center Passenger Position1
-32 Rear Seat Passengers
1
-35 Rear Safety Belt Comfort Guides for Children
and Small Adults
1
-37 Children
1
-41 Restraint Systems for Children
1
-54 Older Children
1
-57 Safety Belt Extender
1
-57 Checking Your Restraint Systems
1
-57 Replacing Restraint System Parts
After a Crash
Page 8 of 395
1-2
Seats and Seat Controls
This part tells you about the seats -- how to adjust them,
and also about memory seats, reclining seatbacks and
head restraints.
Power Seats
The power seat controls are located on the outboard
sides of both the driver's and front passenger's seats.To adjust the power seats, do the following:
Raise or lower the front of the seat cushion by
holding the front part of the horizontal control up
or down.
Raise or lower the rear of the seat cushion by
holding the rear part of the horizontal control up
or down.
Raise or lower the entire seat cushion by holding the
whole horizontal control up or down.
Move the seat forward or backward by pushing the
horizontal control to the front or back.
Push the vertical control forward to bring the seat to
a more upright position. Push it rearward to recline
the seatback.
Raise or lower the shoulder belt by pushing the
vertical control up or down.
Page 9 of 395
1-3 Four-Way Power Lumbar Control (Option)
If your vehicle has this
option, the driver's and
passenger's seatback lumbar
support can be adjusted four
ways by moving the single
control located on the
outboard side of the seat.
To increase or decrease support, hold the control
forward or rearward. To move the lumbar up or down,
hold the control upward or downward.
If you have the independent front cushion moved down
as far as it will go, you may feel the lumbar support
higher in your back. Readjust the position of the cushion
until you are comfortable. You may also want to adjust
the seatback for maximum comfort.
Memory Seat and Mirrors (If Equipped)
If your vehicle has this
feature, the controls are
located on the driver's
door panel, and are used to
program and recall memory
settings for the driver's
seating, outside mirror
positions and comfort
controls. See ªComfort
Controlsº in the Index for
more information.
Page 10 of 395
1-4
To save your seat and mirror positions into memory, use
the following procedure:
1. First identify the DRIVER # on the Driver
Information Center (DIC) by pressing the
MEMORY button (1 or 2) or by pressing the
button with the unlock symbol on the remote
keyless entry transmitter. See ªDriver Information
Center (DIC)º in the Index.
2. Adjust the driver's seat and lumbar position to a safe
and comfortable driving position. Adjust both
outside mirrors to suit you. See ªOutside Mirrorsº
in the Index.
3. Press and hold the MEMORY button (1 or 2)
corresponding with your DRIVER # displayed on the
DIC for longer than three seconds. You will hear
two beeps confirming that the seat and mirror
positions have been entered into memory.
To set the seat and mirror positions for a second driver,
follow the previous steps, but use the MEMORY button
(1 or 2) which corresponds to the DRIVER # identified
by the second transmitter.To store the exit position for an easy exit, use the
following procedure:
1. First identify the DRIVER # by pressing the
MEMORY button (1 or 2) or by pressing the
button with the unlock symbol on the transmitter.
2. Adjust the driver's seat to the desired exit position.
3. Press and hold the EXIT button for longer than
three seconds. You will hear two beeps confirming
that the seat exit position has been entered
into memory.
To set the exit position for a second driver, follow the
previous steps, but use the MEMORY button (1 or 2)
which corresponds to the DRIVER # identified by the
other transmitter.
To recall your memory positions, your vehicle must be
in PARK (P). Push and release the MEMORY button
(1 or 2) corresponding to the desired driving position.
The seat and mirrors will move to the position
previously stored for the currently identified driver.
You will hear one beep.
