2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-11 Remote Keyless Entry System (If Equipped)
2
-16 Trunk
2
-19 Theft
2
-20 Content Theft-Deterrent System
2
-21 PASS-Key
III
2
-23 New Vehicle ªBreak-Inº
2
-24 Ignition Positions
2
-25 Starting Your Engine
2
-27 Engine Coolant Heater (If Equipped)
2
-28 Automatic Transaxle Operation
2
-31 Parking Brake
2
-32 Shifting Into PARK (P)
2
-35 Shifting Out of PARK (P)
2
-35 Parking Over Things That Burn
2
-36 Engine Exhaust
2
-36 Running Your Engine While You're Parked2
-37 Tilt Wheel
2
-38 Turn Signal/Multifunction Lever
2
-45 Exterior Lamps
2
-47 Interior Lamps
2
-50 Mirrors
2
-54 Storage Compartments
2
-62 OnStar
System (If Equipped)
2
-66 Sunroof (Option)
2
-67 HomeLink
Transmitter (If Equipped)
2
-70 The Instrument Panel -- Your
Information System
2
-72 Instrument Panel Clusters
2
-75 Warning Lights, Gages and Indicators
2
-87 Driver Information Center (DIC) (If
Equipped)
2
-97 Head-Up Display (HUD) (If Equipped)
2
-99 Ultrasonic Rear Parking Assist
(URPA) (Option)

2-12
Operation
The numbers on the back of the transmitters correspond
to DRIVER #1 and DRIVER #2 on the DIC
(if equipped). See ªDICº in the Index for
more information.
The driver's door will
unlock when the button
with the unlock symbol is
pressed. If pressed again
within five seconds, all the
doors will unlock.
Pressing any button will also illuminate the interior
lamps (see ªIlluminated Entryº in the Index).
All doors will lock when the button with the lock
symbol is pressed.
The trunk will unlock when the trunk button is pressed,
and the ignition is in LOCK or OFF. The trunk button
will also work when the ignition is on, but only while
the transaxle is in PARK (P).Instant Alarm
When the button with the horn symbol on the remote
keyless entry transmitter is pressed, the horn will sound
and the headlamps and taillamps will flash for up to
30 seconds. This can be turned off by pressing the
instant alarm button again or by turning the ignition on.
With the content theft-deterrent feature, you may also
turn off the instant alarm by unlocking the vehicle with
a key.
Personal Choice Features
Each remote keyless entry transmitter can be
programmed to the driver's preference for automatic
door locks, security feedback, delayed locking, memory
seat, perimeter lighting, parallel park assist mirror and
window lockout. See each feature in the Index. You can
also personalize your comfort control temperature, mode
and fan settings. See ªComfort Controls, Personal
Choiceº in the Index.
If your vehicle is equipped with the Driver
Information Center (DIC), you can also program
these features through the DIC. See ªDriver
Information Center (DIC)º in the Index.

2-47 Twilight Sentinel


Twilight Sentinel turns
your headlamps on and
off by sensing how dark
it is outside.
To operate this feature, slide the control to any position
to vary the lamp timeout.
You can set the delay time from only a few seconds to
three minutes. If you move the control all the way to
MAX, your lamps will remain on for three minutes after
you turn off your engine. If you move the control almost
all the way in the other direction, so it's just on, the lamps
will go off quickly when you turn off your engine. Sliding
the control to OFF, turns off the Twilight Sentinel feature.
Light Sensor
Your Twilight Sentinel and DRL work with the light
sensor on top of the instrument panel. Don't cover it up.
If you do, it will sense ªdarkº and the headlamps will
come on.
Interior Lamps
Instrument Panel Brightness Control
Instrument panel light brightness can be adjusted
by turning the exterior lamps control counterclockwise
and clockwise.
Courtesy Lamps
When any door is opened, several lamps go on.
They make it easy for you to enter and leave your
vehicle. You can also turn these lamps on by turning the
exterior lamps control clockwise all the way past the
normal stop.
Illuminated Entry System
When you open either front door or press the button
with the unlock symbol on the remote keyless entry
transmitter, the lamps inside your vehicle will turn on.
These lamps will turn off after about 40 seconds. These
lamps will also turn off if you start the engine or activate
the power door locks.

2-53
3. Once a zone number appears in the display, press the
COMPASS button (or the on/off button for mirrors
equipped with OnStar controls) quickly until the
correct zone number appears in the display. Stop
pressing the button and the mirror will return to
normal operation. If C appears in the compass
window, the compass may need calibration. See
ªCompass Calibrationº explained previously.
Power Remote Control Outside
Rearview Mirrors
Your vehicle has power mirror controls located on the
driver's door armrest.Press L or R on the selector switch located below the
control pad to choose the right or left mirror. If you
place the switch in the center position, no mirror
movement will occur. To adjust a mirror, use the arrows
located on the control pad to move the mirror in the
direction you want it to go.
Adjust each mirror so you can see some of the side of
your vehicle and the area behind your vehicle.
If your vehicle is equipped with the memory seat and
mirrors feature, these mirror positions, along with the
driver's seat position can be stored in memory. See
ªMemory Seat and Mirrorsº in the Index.
Parallel Park Assist Mirror (If Equipped)
If you have the DIC feature, the passenger's outside
rearview mirror also includes a tilt
-down feature that
operates when the shift lever is in REVERSE (R).
When the vehicle is shifted out of REVERSE (R), the
passenger mirror will return to its original position after
a five
-second delay. This delay prevents movement of
the mirror if multiple gear transitions (reverse to drive to
reverse) occur during a parallel parking maneuver. This
feature can be programmed on or off through the
personal choice selection menu. See ªDriver
Information Centerº or ªPersonal Choice Featuresº
in the Index for programming instructions.

2-91
When the STABILITY SYSTEM ACTIVE message
is on, you should continue to steer in the direction you
want to go. The system is designed to help you in bad
weather or other difficult driving situations by making
the most of whatever road conditions will permit. If the
STABILITY SYSTEM ACTIVE message comes on,
you'll know that something has caused your vehicle to
start to spin, so you should consider slowing down.
Tire Pressure Status
- 140: If you see the TIRE
PRESSURE LOW message, you should stop as soon as
you can and check all your tires for damage. (If a tire is
flat, see ªIf a Tire Goes Flatº in the Index.) Also check
the tire pressure in all four tires as soon as you can. See
ªInflation
- Tire Pressureº and ªCheck Tire Pressure
Systemº in the Index.
There are times when you will have to reset (calibrate)
the Check Tire Pressure System. See ªCheck Tire
Pressure Systemº in the Index.
DIC Personal Choice Programming
The DIC is used to program personal choices for up to
two drivers. The drivers are recognized as DRIVER #1
and DRIVER #2. The DIC will identify a person as
UNKNOWN DRIVER if they are neither DRIVER #1
nor DRIVER #2. You will let the DIC know which
driver you are by using your remote keyless entry
transmitter or by pressing one of the MEMORY buttons
located on the driver's door. Each remote keyless entry
transmitter was pre
-programmed to belong to
DRIVER #1 or DRIVER #2. Each transmitter
may be programmed differently for each driver.
After you press the button with the unlock symbol on
your transmitter with the ignition in RUN, the DIC will
automatically display the identified driver number. The
vehicle will recall the personal choice settings that were
last made to correspond to your transmitter, including
your radio and comfort control settings. See ªComfort
Controls, Personal Choiceº in the Index.

3-6
NOTICE:
Don't use a razor blade or something else sharp
on the inside of the rear window. If you do, you
could cut or damage the warming grid or the
integrated rear window antenna, and the repairs
wouldn't be covered by your warranty.
Passenger Climate Control
The front seat passenger can control the air temperature
in his or her seating area. This can be set up to 5
F
(3
C) cooler or warmer than the primary setting. You
can activate this feature by sliding the lever located on
the right side of the instrument panel toward WARM
or COOL.
If the passenger climate control has been turned on, it
can be turned off by pressing the OFF button on the
climate control system faceplate once. Pressing the OFF
button a second time will turn off the main system.
Personal Choice Comfort Controls
(If Equipped)
This feature enables up to two drivers to store and recall
comfort control settings for the temperature, fan speed
and the direction of the air flow.
The memory buttons (1 or 2) for this feature are located
on the driver's door panel and correspond to the
numbers (1 or 2) found on the back of each remote
keyless entry transmitter.
To recall comfort settings, press the unlock button on the
remote keyless entry transmitter and put the ignition in
ACCESSORY or RUN. The climate control setting last
chosen by the identified driver (1 or 2) will be recalled.

3-23 Personal Choice Radio Controls
(If Equipped)
This feature enables two drivers to store and recall personal
settings for AM and FM presets, last tuned station, volume,
tone and audio source (radio, cassette or CD).
The memory buttons (1 or 2) for this feature are located
on the driver's door panel and correspond to the
numbers (1 or 2) found on the back of the remote
keyless entry transmitter.
To recall audio sources, press the unlock button on the
remote keyless entry transmitter and put the ignition in
RUN. The source last listened to will be recalled for the
identified driver (1 or 2).
To program this feature, do the following:
1. Set all radio preferences. For more information see
ªSetting Preset Stationsº and ªSetting the Toneº
listed for your particular radio.
2. Locate the memory buttons on the driver's
door panel.
3. Press one of the memory buttons (1 or 2) until you
hear two beeps. The beeps confirm that your
selection has been saved and can now be recalled.
Follow these steps each time you want to change the
stored settings.
Theft-Deterrent Feature
THEFTLOCK
is designed to discourage theft of your
radio. It works by using a secret code to disable all radio
functions whenever battery power is removed.
If THEFTLOCK is active, the THEFTLOCK indicator
will flash when the ignition is off.
The THEFTLOCK feature for the radio may be used or
ignored. If ignored, the system plays normally and the
radio is not protected by the feature. If THEFTLOCK is
activated, your radio will not operate if stolen.
When THEFTLOCK is activated, the radio will display
LOC to indicate a locked condition anytime battery
power is removed. If your battery loses power for any
reason, you must unlock the radio with the secret code
before it will operate.
Activating the Theft
-Deterrent Feature
The instructions which follow explain how to enter your
secret code to activate the THEFTLOCK system. It is
recommended that you read through all nine steps
before starting the procedure.
