Halogen Bulbs
{CAUTION:
Halogen bulbs have pressurized gas inside
and can burst if you drop or scratch the bulb.
You or others could be injured. Be sure to read
and follow the instructions on the bulb
package.
Headlamps
1. Open the hood.
2. Push in on the
headlamp panel and lift
up the headlamp
retaining clip partway,
but do not remove.
3. Undo the wing stud on the upper, outboard side of
the lamp assembly.
4. Unsnap the headlamp assembly by pulling it
forward, away from the vehicle.
5. Disconnect the electrical connector by pulling back
on the locking tab, located on the electrical
connector, to separate the two connectors.
5-43
2003 - Rendezvous OM

6. Turn the bulb socket
one-quarter of a turn
clockwise.
7. Pull the bulb assembly out from the lamp housing.8. Unhook the electrical connector by lifting up the
gray tabs and separate the connector from the
bulb base.
9. Install the new bulb into the electrical connector.
Push the bulbfirmly enough so that the gray tabs
hook over the tab on the bulb.
10. Put the bulb assembly back into the lamp housing
and turn the bulb socket one-quarter of a turn
counterclockwise.
11. Align the retaining clips on the back of the headlamp
with the rectangular holes in the mounting panel.
12. Pushfirmly on both ends of the headlamp to snap it
into position.
13. Push the retaining clip down to its original position.
14. Reinstall the wing stud.
Front Turn Signal, Sidemarker and
Parking Lamps
To replace the front turn signal, parking or sidemarker
lamp bulbs, follow the headlamp bulb replacement
procedure and replace the appropriate bulb.
5-44
2003 - Rendezvous OM

5. Pull the lamp applique directly rearward from the
vehicle.
A. Taillamp (outboard)
B. Taillamp (center)
C. Back-Up Lamp (inboard)
6. Turn the bulb socket one-quarter of a turn
counterclockwise.
7. Pull the bulb assembly out from the lamp housing.
8. Pull the bulb out of the base.
9. Install the new bulb into the electrical connector.
Push the bulbfirmly enough so that the tabs hook
over the tab on the bulb.10. Put the bulb assembly back into the lamp housing
and turn the bulb socket one-quarter of a turn
clockwise.
11. Replace the applique on the liftgate.
12. Gently lift the liftgate.
13. Reinstall the seven wing nuts and the four
outboard nuts.
14. Reinstall the panel inside the liftgate by connecting
the tabs.
15. Close the liftgate.
Replacement Bulbs
For any bulb not listed here contact your dealer.
Lamp Bulb Number
Front Turn Signal/Parking Lamps 3457K
Headlamps High-Beam 9005
Headlamps Low-Beam 9006
Liftgate-Mounted Back-Up Lamps 921
Liftgate-Mounted Taillamps 161
Rear Outboard Stop/Tail/Turn 3057K
Sidemarker Lamps 168
5-46
