BUICK RANDEZVOUS 2003 Service Manual

Lap-Shoulder Belt
The positions next to the windows have lap-shoulder
belts. Here’s how to wear one properly.
1. Pick up the latch plate and pull the belt across you.
Don’t let it get twisted.
The shoulder belt may lock if you pull the belt
across you very quickly. If this happens, let the belt
go back slightly to unlock it. Then pull the belt
across you more slowly.2. Push the latch plate into the buckle until it clicks.
If the belt stops before it reaches the buckle, tilt the
latch plate and keep pulling until you can buckle it.
Pull up on the latch plate to make sure it is secure.
If the belt is not long enough, seeSafety Belt
Extender on page 1-44.
Make sure the release button on the buckle is
positioned so you would be able to unbuckle the
safety belt quickly if you ever had to.
1-35
2003 - Rendezvous OM

3. To make the lap part tight, pull down on the buckle
end of the belt as you pull up on the shoulder part.The lap part of the belt should be worn low and
snug on the hips, just touching the thighs. In
a crash, this applies force to the pelvic bones. And
you’d be less likely to slide under the lap belt. If
you slid under it, the belt would apply force at your
abdomen. This could cause serious or even
fatal injuries. The shoulder belt should go over the
shoulder and across the chest. These parts of
the body are best able to take belt restraining
forces.
1-36
2003 - Rendezvous OM

The safety belt locks if there’s a sudden stop or a
crash, or if you pull the belt very quickly out of
the retractor.
Each position next to the windows in the second
row has a shoulder belt height adjuster. Move
the shoulder belt adjuster to the height that is right
for you.
To move it down, push down on the button and
move the height adjuster to the desired position.
You can move the height adjuster up just by pushing
up on the shoulder belt guide. After you move the
adjuster to where you want it, try to move it
down without pushing the button down to make
sure it has locked into position.
Adjust the height so that the shoulder portion of the
belt is centered on your shoulder. The belt should
be away from your face and neck, but not falling off
your shoulder.
{CAUTION:
You can be seriously hurt if your shoulder belt
is too loose. In a crash, you would move
forward too much, which could increase injury.
The shoulder belt should fit against your body.To unlatch the belt, just push the button on the
buckle.
1-37
2003 - Rendezvous OM

Center Rear Passenger Position
Lap-Shoulder Belt
If your vehicle has a bench seat, someone can sit in the
center position.
When you sit in the center seating position, you have a
lap safety belt, which has no retractor. You also
have a shoulder belt, which has a retractor. In order to
have the protection of the shoulder belt, you must
first connect it to the lap belt.1. Remove the shoulder belt from its stowage
location in the roof and pull it all the way down to
the lap belt.
1-38
2003 - Rendezvous OM

2. Insert the metal knob on the shoulder belt into the
keyhole on the lap belt buckle as shown. Be sure to
slide the shoulder belt part into the keyhole until
it locks into place.3. To make the lap belt longer, tilt the latch plate and
pull it along the belt.
1-39
2003 - Rendezvous OM

To make the belt shorter, pull its free end as shown
until the belt is snug
4. Buckle, position and release the lap-shoulder belt
the same way as the other lap-shoulder belts. If
the belt isn’t long enough, seeSafety Belt Extender
on page 1-44.
Make sure the release button on the buckle is positioned
so you would be able to unbuckle the safety belt
quickly if you ever had to.
Rear Safety Belt Comfort Guides for
Children and Small Adults
Your vehicle may have this feature already. If it doesn’t,
you can get it from any GM Dealer.
This feature will provide added safety belt comfort for
older children who have outgrown booster seats and for
small adults. When installed on a shoulder belt, the
comfort guide better positions the belt away from
the neck and head.
There is one guide available for each passenger
position in the second row rear seat. To provide added
safety belt comfort for children who have outgrown
child restraints and booster seats and for smaller adults,
the comfort guides may be installed on the shoulder
belts. Here’s how to install a comfort guide and use the
safety belt:
1-40
2003 - Rendezvous OM

For second row outside positions do the following:
1. Remove the guide from its storage clip located on
the sidewall next to the outer side of each outside
passenger position.2. Place the guide over the belt and insert the two
edges of the belt into the slots of the guide. Second Row Outside Positions
1-41
2003 - Rendezvous OM

3. Be sure that the belt is not twisted and it liesflat.
The guide must be on top of the belt.4. Buckle, position and release the safety belt as
described inRear Seat Passengers on page 1-34.
Make sure that the shoulder belt crosses the
shoulder.
To remove and store the comfort guides, squeeze the
belt edges together so that you can take them out of the
guides. Pull the guide upward to expose its storage
clip, and then slide the guide onto the clip. Turn
the guide and the clip inward, leaving only the loop of
elastic cord exposed.
1-42
2003 - Rendezvous OM

For second row center position do the following:
1. Remove the elastic cord from under the head
restraint of the second row driver’s side position.2. Attach the elastic cord to the comfort guide on the
center passenger shoulder belt. Second Row Center Position
1-43
2003 - Rendezvous OM

3. Be sure that the belt is not twisted and it liesflat.
The guide must be on top of the belt.
4. Buckle, position and release the safety belt as
described inCenter Rear Passenger Position
on page 1-38. Make sure that the shoulder belt
crosses the shoulder.
To remove and store the elastic cord, remove it from
the comfort guide. The elastic cord will go back
under the head restraint.
Safety Belt Extender
If the vehicle’s safety belt will fasten around you, you
should use it.
But if a safety belt isn’t long enough to fasten, your
dealer will order you an extender. It’s free. When you go
in to order it, take the heaviest coat you will wear, so
the extender will be long enough for you. The extender
will be just for you, and just for the seat in your
vehicle that you choose. Don’t let someone else use it,
and use it only for the seat it is made tofit. To wear
it, just attach it to the regular safety belt.
1-44
