BUICK RANDEZVOUS 2003 User Guide

Reclining Seatbacks
To adjust the seatback, pull up on the lever located on
the outboard sides of both the driver’s and front
passenger’s seats. Release the lever to lock the
seatback where you want it. Push and pull on the seat
to make sure it’s locked into position. Pull up on the
lever, and the seat will go to its original upright position.But don’t have a seatback reclined if your vehicle is
moving.
1-5
2003 - Rendezvous OM

{CAUTION:
Sitting in a reclined position when your vehicle
is in motion can be dangerous. Even if you
buckle up, your safety belts can’t do their job
when you’re reclined like this.
The shoulder belt can’t do its job because it
won’t be against your body. Instead, it will be
in front of you. In a crashyou could go into it,
receiving neck or other injuries.
The lap belt can’t do its job either. In a crash
the belt could go up over your abdomen. The
belt forces would be there, not at your pelvic
bones. This could cause serious internal
injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety belt
properly.
Head Restraints
Adjust your head restraint so that the top of the restraint
is closest to the top of your head. This position
reduces the chance of a neck injury in a crash.
The front seat head restraints are adjustable. Slide the
head restraint up or down to adjust it.
On some models, the head restraints tilt forward and
rearward also.
1-6
2003 - Rendezvous OM

The rear seat head restraints in your vehicle may be
adjustable. They work the same as the front seat head
restraints, except they do not tilt forward or rearward.
Rear Seats
Rear Seat Operation
The rear seats in your vehicle have seat operating
features to adjust, fold, remove and reinstall the seats.
By using the seat operating procedures, in the
correct order, you can easily remove the seats from
your vehicle.
When you put the seats back in the vehicle, be sure to
follow the label on the back of the seat for proper
location.
Split BenchSeats
If your vehicle has the split bench seat, the seatbacks
can be folded forward or reclined individually and
the sections can be flipped forward or removed
individually.
Folding or Reclining the Seatbacks
{CAUTION:
If the seatback isn’t locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
press rearward on the seatback to be sure it is
locked.
To recline the seatback on
base-level split bench
seats, lift up on the recliner
lever located on the
outboard side of the
seatback.
Base-Level
1-7
2003 - Rendezvous OM

To recline the seatback on
up-level split bench seats,
push forward on the
recliner lever located on
the outboard side of
the seatback.
Move the seatback to the desired position.
It is easier to raise or lower the seatback if you lean
forward and take the weight off the seatback.
The seatbacks on each section also fold forward to put
items behind the seats.
Lift up or push forward on the recliner lever and fold the
seatback forward. The seatback will lock into place
when you push it back to the upright position.
After raising a seatback to an upright position, push and
pull on the seatback to check that it is locked upright.Removing the Split Bench Seat
Each section of the split bench seat can beflipped
forward or removed individually.
1. Unlatch the shoulder belt from the lap-belt.
2. Make sure that the seatback is in the upright
position.
3. Lift up or push forward on the seatback recliner
lever to fold the seatback forward. Up-Level
1-8
2003 - Rendezvous OM

4. For base-level split bench seats, pull the lever at
the base of the seat on the outboard side to
release the rear latches from thefloor pins andflip
the seat forward.
For up-level split bench seats, continue pushing
forward on the recliner lever to release the
rear latches from thefloor pins andflip the seat
forward.
The seat can stay in this position or it can be
removed from the vehicle by following the next
steps.5. To release the front latches, squeeze the angled
latch release bar toward the straight crossbar.
6. Remove the seat by rocking it slightly toward the
rear of the vehicle and then pulling it out.
Repeat these steps for the other section of the split
bench seat. Base-Level
1-9
2003 - Rendezvous OM

Replacing the Split Bench Seat
{CAUTION:
If the seatback isn’t locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
press rearward on the seatback to be sure it is
locked.
{CAUTION:
A seat that isn’t locked into place properly can
move around in a collision or sudden stop.
People in the vehicle could be injured. Be sure
to lock the seat into place properly when
installing it.
{CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted won’t provide the
protection needed in a crash. The person
wearing the belt could be seriously injured.
After installing the seat, always check to be
sure that the safety belts are properly routed
and attached, and are not twisted.
Make sure that the seatback is in the folded forward
position and that the safety belts are on the correct
section of the seat.
Don’t put the sections of the bench seat in so that they
face rearward because they won’t latch that way.
The split bench seat sections have seat position labels,
located on the back of each section, showing where
the section must go.
1-10
2003 - Rendezvous OM

The seat must be placed in the proper location for the
legs to attach correctly.
1. Squeeze the angled latch release bar toward the
straight crossbar while placing the front hooks of
the bench seat onto the front twofloor pins.2. Make sure that the
bench seat is angled so
that the front hooks
clear thefloor pins.
If the front legs are
not attached correctly,
the rear legs will not
attach to the rear set of
floor pins.
3. Firmly push the rear hooks onto the rearfloor pins
by pushing down on the rear of the seat.
1-11
2003 - Rendezvous OM

4. Try to raise the seat to check that it is locked down.
5. Lift the seatback recliner lever and raise the
seatback until it locks upright.
6. Push and pull on the seatback to check that it is
locked upright.
7. Attach the lap belt.
Captain Chairs
If your vehicle has captain’s chairs, the chairs and
seatbacks can be adjusted forward or rearward.
Adjusting the Captain’s Chairs
(Second Row)
To adjust he second row captain’s chairs, use the
adjustment bar located below the front of each seat.
Lift up the lever to slide the seat forward or rearward.
Release the lever. Push and pull on the seat to
make sure it is locked into place.
Folding or Reclining the Seatbacks
{CAUTION:
If the seatback isn’t locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
press rearward on the seatback to be sure it is
locked.
1-12
2003 - Rendezvous OM

To recline the seatback, lift up on the recliner lever
located on the outboard side of the seatback. Use the
recliner lever to move the seatback to the desired
position.
It is easier to raise or lower the seatback if you lean
forward and take the weight off the seatback.
The seatbacks on the second row captain’s chairs fold
forward the same way.
After raising a seatback to an upright position, push and
pull on the seatback to check that it is locked upright.Removing the Captain’s Chairs
1. Make sure that the seatback is in the upright
position.
2. Lift the seatback recliner lever to fold the seatback
forward.
3. Pull up on the lever, located at the base on the
outboard side of the seat, to release the rear
latches from thefloor pins.
1-13
2003 - Rendezvous OM

4. The seat can then be lifted off the frontfloor pins.
5. Remove the seat by rocking it slightly toward
the rear of the vehicle and then pulling it out.
Repeat these steps for the other captain’s chair.
Replacing the Captain’s Chairs
{CAUTION:
If the seatback isn’t locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
press rearward on the seatback to be sure it is
locked.
{CAUTION:
A seat that isn’t locked into place properly can
move around in a collision or sudden stop.
People in the vehicle could be injured. Be sure
to lock the seat into place properly when
installing it.
1-14
2003 - Rendezvous OM
