2-17
Trunk
CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even death.
If you must drive with the trunk lid open or if
electrical wiring or other cable connections must
pass through the seal between the body and the
trunk lid:

Make sure all other windows are shut.

Turn the fan on your heating or cooling
system to its highest speed with the setting
on VENT. That will force outside air into
your vehicle. See ªComfort Controlsº in
the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.
Trunk Lock
To unlock the trunk from the outside, insert the door key
and turn it. You can also press the trunk symbol on your
remote keyless entry transmitter.
Remote Trunk Release
Press the button located
inside of the glove box door
to unlock the trunk from
inside the vehicle. The shift
lever must be in PARK (P)
for the remote trunk release
button to work.

2-18 Trunk Assist Handle (If Equipped)
Your vehicle may have an assist handle located on
the inside of the trunk lid toward the driver's side of
the vehicle.Pull down on the handle to lower the trunk lid.
Then close the trunk with your other hand. If the trunk
is not properly closed, the DOOR/TRUNK light will
appear in the message center of your instrument panel
cluster. See ªDOOR/TRUNK Lightº in the Index for
more information.
NOTICE:
The trunk assist handle was not designed to be
used to tie down the trunk lid or as an anchor
point when securing items in the trunk. Improper
use of the trunk assist handle could damage it.

2-19 Trunk Release Handle (If Equipped)
NOTICE:
The trunk release handle was not designed to be
used to tie down the trunk lid or as an anchor
point when securing items in the trunk. Improper
use of the trunk release handle could damage it.
There is a glow-in-the-dark trunk release handle located
inside the trunk on the latch. This handle will glow
following exposure to light. Pull the release handle up to
open the trunk from the inside.

2-20 Trunk Release Sensor TrapAlert
System
(If Equipped)
Your vehicle may have a sensor located on the underside
of the filler panel inside the trunk.The sensor is designed to open the trunk automatically.
If the sensor detects motion and a difference in
temperature in the trunk, the sensor will sound the horn
if the ignition is in OFF. There will be three short chirps
and a pause repeated for up to two minutes. After one
minute, the trunk latch will release. If the ignition is not
in OFF, the trunk latch will not release automatically
and the horn will not sound.
To cancel the horn alarm and automatically release
the trunk lid before two minutes are up, turn the
ignition to ON.
Do not cover the sensor with items you put into the
trunk or with add
-on accessory equipment. If the
sensor's field of view is blocked, it will not detect
motion and will not function properly.
Be sure to secure items in your trunk so that they
won't move around and cause the trunk to open.

2-21
Disabling the Trunk Release Sensor
A. Sensor Lens
B. Disable SwitchBecause the sensor detects motion, there are times when
you may want to turn off the trunk sensor so that the
motion of your vehicle or items in the trunk won't cause
the trunk to open, such as the following:

When your vehicle is transported on a car ferry,

when your vehicle is towed, or

when you will be loading items through the opening
in the split folding rear seat (if equipped).
Next to the sensor lens, there is a disable switch you can
use to turn off the trunk release sensor. To turn off the
sensor, turn the ignition to ON and press the switch next
to the lens for two seconds. The horn will chirp once
when the sensor is turned off. When the sensor is off,
the light in the switch will flash. The DOOR/TRUNK
light will flash for one minute each time the ignition is
turned on as a reminder that the sensor is turned off.
See ªDoor/Trunk Lightº in the Index.
To turn the sensor on again, press the switch again
or open the trunk. When the trunk is opened, the
sensor is automatically turned back on. If the sensor
is turned back on with the disable switch, the horn will
chirp twice.

2-22
Servicing the Trunk Release Sensor
The sensor lens should be inspected periodically. If the
lens is dirty, wipe it gently with a clean, soft cotton cloth.
If there is an electrical problem with the sensor, the
SERVICE VEHICLE SOON light will appear in the
instrument panel cluster. There are other possible
reasons for this light to appear. Be sure to see your
dealer as soon as possible. See ªService Vehicle Soon
Lightº in the Index for more information.
Theft
Vehicle theft is big business, especially in some cities.
Although your vehicle has a number of theft
-deterrent
features, we know that nothing we put on it can make it
impossible to steal. However, there are ways you can help.
Key in the Ignition
If you leave your vehicle with the keys inside, it's an
easy target for joy riders or professional thieves
-- so
don't do it.
When you park your vehicle and open the driver's door,
you'll hear a chime reminding you to remove your key
from the ignition and take it with you. Always do this.
Your steering wheel will be locked, and so will your
ignition and transaxle. And remember to lock the doors.
Parking at Night
Park in a lighted spot, close all windows and lock your
vehicle. Remember to keep your valuables out of sight.
Put them in a storage area, or take them with you.
Parking Lots
Even if you park in a lot where someone will be
watching your vehicle, it's still best to lock it up and
take your keys. But what if you have to leave your
ignition key?

If possible, park in a busy, well
-lit area.

Put your valuables in a storage area, like your trunk
or glove box.

Be sure to close and lock the storage area.

Close all windows.

Lock the glove box.

Lock all the doors except the driver's.

Then take the door key and remote keyless entry
transmitter with you.

2-23
PASS-Key
II
Your vehicle is equipped
with the PASS
-Key II
(Personalized Automotive
Security System)
theft
-deterrent system.
PASS
-Key II is a passive
theft
-deterrent system.
It works when you insert
or remove the key from
the ignition.
PASS
-Key II uses a resistor pellet in the ignition key
that matches a decoder in your vehicle.
When the PASS
-Key II system senses that someone is
using the wrong key, it shuts down the vehicle's starter and
fuel systems. For about three minutes, the starter won't
work and fuel won't go to the engine. If someone tries to
start your vehicle again or uses another key during this
time, the vehicle will not start. This discourages someone
from randomly trying different keys with different resistor
pellets in an attempt to make a match.
The ignition key must be clean and dry before it's inserted
in the ignition or the engine may not start. If the engine
does not start and the SECURITY light is flashing, the key
may be dirty or wet. Turn the ignition off.Clean and dry the key. Wait about three minutes and try
again. If the starter still won't work, and the key appears
to be clean and dry, wait about three minutes and try
another ignition key. At this time, you may also want
to check the fuse (see ªFuses and Circuit Breakersº in
the Index). If the starter won't work with the other key,
your vehicle needs service. If your vehicle does start, the
first ignition key may be faulty. See your dealer or a
locksmith who can service the PASS
-Key II.
If you accidentally use a key that has a damaged or
missing resistor pellet, the starter won't work. The
SECURITY light will then come on. But you don't have
to wait three minutes before trying another ignition key.
See your dealer or a locksmith who can service the
PASS
-Key II to have a new key made.
If you're ever driving and the SECURITY light comes
on, you will be able to restart your engine if you turn it
off. Your PASS
-Key II system, however, is not working
properly and must be serviced by your dealer. Your
vehicle is not protected by the PASS
-Key II system.
If you lose or damage a PASS
-Key II ignition key, see
your dealer or a locksmith who can service PASS
-Key II
to have a new key made. Also, see ªRoadside
Assistanceº in the Index for more information.

2-24
New Vehicle ªBreak-Inº
NOTICE:
Your vehicle doesn't need an elaborate
ªbreak
-in.º But it will perform better in
the long run if you follow these guidelines:

Don't drive at any one speed -- fast or
slow
-- for the first 500 miles (805 km).
Don't make full
-throttle starts.

Avoid making hard stops for the first
200 miles (322 km) or so. During this time
your new brake linings aren't yet broken
in. Hard stops with new linings can mean
premature wear and earlier replacement.
Follow this breaking
-in guideline every
time you get new brake linings.

Don't tow a trailer during break
-in.
See ªTowing a Trailerº in the Index for
more information.
Ignition Positions
With the ignition key in the ignition, you can turn the
key to five different positions:
A (ACCESSORY): This position lets you use the
radio and windshield wipers when the engine is off.
To use ACCESSORY, push in the key and turn it
toward you. Your steering wheel will stay locked.

2-25
B (LOCK): This is the only position in which you can
insert or remove the key. This position locks the
ignition, steering wheel and transaxle. It's a
theft
-deterrent feature.
NOTICE:
If your key seems stuck in LOCK and you can't
turn it, be sure you are using the correct key;
if so, is it all the way in? If it is, then turn the
steering wheel left and right while you turn the
key hard. Turn the key only with your hand.
Using a tool to force it could break the key or
the ignition switch. If none of this works, then
your vehicle needs service.
C (OFF): This position lets you turn off the engine but
still turn the steering wheel. It doesn't lock the steering
wheel. Use OFF if you must have your vehicle pushed
or towed.D (RUN): This position is where the key returns to
after you start your vehicle. With the engine off, you
can use RUN to display some of your warning and
indicator lights.
E (START): This position starts your engine.
A warning chime will sound if you open the driver's
door when the ignition is in OFF, LOCK or
ACCESSORY and the key is in the ignition.
Retained Accessory Power (RAP)
With Retained Accessory Power (RAP), your power
windows, audio system and sunroof (if equipped) will
continue to work for up to 10 minutes after the ignition
key is turned to OFF and before any of the doors
are opened.

2-26
Starting Your Engine
Move your shift lever to PARK (P) or NEUTRAL (N).
Your engine won't start in any other position
-- that's a
safety feature. To restart when you're already moving,
use NEUTRAL (N) only.
NOTICE:
Don't try to shift to PARK (P) if your vehicle
is moving. If you do, you could damage the
transaxle. Shift to PARK (P) only when your
vehicle is stopped.
NOTICE:
If you cannot remove your key from the ignition
and the gear shift is in PARK (P) (with the shift
lever button fully released), see ªShift Lock
Releaseº in the Index.
1. With your foot off the accelerator pedal, turn your
ignition key to START. When the engine starts, let
go of the key. The idle speed will go down as your
engine gets warm.
NOTICE:
Holding your key in START for longer than
15 seconds at a time will cause your battery to
be drained much sooner. And the excessive heat
can damage your starter motor. Wait about
15 seconds between each try to help avoid
draining your battery or damaging your starter.
2. If it doesn't start within 10 seconds, hold your key
in START for about 10 seconds at a time until
your engine starts. Wait about 15 seconds between
each try.
