BUICK REGAL 2004 Owner's Manual

A. Windshield Washer Fluid Reservoir. SeeWindshield
Washer Fluid on page 5-42.
B. Battery. SeeBattery on page 5-46.
C. Remote Positive (+) Battery Terminal. SeeBattery
on page 5-46.
D. Underhood Fuse Block. SeeFuses and Circuit
Breakers on page 5-98.
E. Radiator Pressure Cap. SeeCooling System on
page 5-32.
F. Engine Coolant Recovery Tank. SeeCooling System
on page 5-32.G. Power Steering Fluid Reservoir (Below Generator).
SeePower Steering Fluid on page 5-40.
H. Electric Cooling Fan. SeeCooling System on
page 5-32.
I. Engine Oil Dipstick. SeeEngine Oil on page 5-16.
J. Engine Oil Fill Cap. SeeEngine Oil on page 5-16.
K. Automatic Transaxle Fluid Dipstick. SeeAutomatic
Transaxle Fluid on page 5-24.
L. Brake Fluid Reservoir. SeeBrakes on page 5-43.
M. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-22.
5-13

When you open the hood on the 3800 V6 Supercharged engine, you will see:
5-14

A. Windshield Washer Fluid Reservoir. SeeWindshield
Washer Fluid on page 5-42.
B. Battery. SeeBattery on page 5-46.
C. Remote Positive (+) Battery Terminal. SeeBattery
on page 5-46.
D. Underhood Electrical Center. SeeFuses and Circuit
Breakers on page 5-98.
E. Radiator Pressure Cap. SeeCooling System on
page 5-32.
F. Engine Coolant Recovery Tank. SeeCooling System
on page 5-32.G. Power Steering Fluid Reservoir (Below Generator).
SeePower Steering Fluid on page 5-40.
H. Electric Cooling Fan. SeeCooling System on
page 5-32.
I. Engine Oil Dipstick. SeeEngine Oil on page 5-16.
J. Engine Oil Fill Cap. SeeEngine Oil on page 5-16.
K. Automatic Transaxle Fluid Dipstick. SeeAutomatic
Transaxle Fluid on page 5-24.
L. Brake Fluid Reservoir. SeeAutomatic Transaxle
Fluid on page 5-24.
M. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-22.
5-15

Engine Oil
Checking Engine Oil
It is a good idea to check your engine oil every time you
get fuel. In order to get an accurate reading, the oil
must be warm and the vehicle must be on level ground.
The engine oil dipstick handle is a yellow loop. See
Engine Compartment Overview on page 5-12for
the location of the engine oil dipstick.
Turn off the engine and give the oil several minutes to
drain back into the oil pan. If you don’t, the oil
dipstick might not show the actual level.Pull out the dipstick and clean it with a paper towel or
cloth, then push it back in all the way. Remove it again,
keeping the tip down, and check the level.
5-16

When to Add Engine Oil
If the oil is at or below the cross-hatched area at the tip
of the dipstick, then you will need to add at least one
quart of oil. But you must use the right kind. This section
explains what kind of oil to use. For engine oil
crankcase capacity, seeCapacities and Specications
on page 5-103.
Notice:Do not add too much oil. If your engine has
so much oil that the oil level gets above the
cross-hatched area that shows the proper operating
range, your engine could be damaged.SeeEngine Compartment
Overview on page 5-12for
the location of the
engine oil dipstick.
Be sure to add enough oil to put the level somewhere in
the proper operating range in the crosshatched area.
Push the dipstick all the way back in when you are
through.
5-17

What Kind of Engine Oil to Use
Look for two things:
GM6094M
Your vehicle’s engine requires oil meeting GM
Standard GM6094M. You should look for and use
only an oil that meets GM Standard GM6094M.
5-18

SAE 5W-30
As shown in the viscosity chart, SAE 5W-30 is best
for your vehicle. However, if it is going to be 0°F
(–18°C) or above and SAE 5W-30 is not available,
you may use SAE 10W-30.
These numbers on an oil container show its
viscosity, or thickness. Do not use other viscosity
oils such as SAE 20W-50.
Oils meeting these
requirements should also
have the starburst
symbol on the container.
This symbol indicates
that the oil has been
certied by the American
Petroleum Institute (API).
You should look for this information on the oil container,
and useonlythose oils that are identied as meeting
GM Standard GM6094M and have the starburst symbol
on the front of the oil container.Notice:Use only engine oil identied as meeting
GM Standard GM6094M and showing the American
Petroleum Institute Certied For Gasoline Engines
starburst symbol. Failure to use the recommended
oil can result in engine damage not covered by
your warranty.
GM Goodwrench
®oil meets all the requirements for
your vehicle.
If you are in an area of extreme cold, where the
temperature falls below –20°F (–29°C), it is
recommended that you use either and SAE 5W-30
synthetic oil or an SAE 0W-30 oil. Both will provide
easier cold starting and better protection for your engine
at extremely low temperatures.
Engine Oil Additives
Do not add anything to your oil. The recommended oils
with the starburst symbol that meet GM Standard
GM6094M are all you will need for good performance
and engine protection.
5-19

When to Change Engine Oil
(GM Oil Life System™)
Your vehicle has a computer system that lets you know
when to change the engine oil and lter. This is
based on engine revolutions and engine temperature,
and not on mileage. Based on driving conditions,
the mileage at which an oil change will be indicated can
vary considerably. For the oil life system to work
properly, you must reset the system every time the oil is
changed.
When the system has calculated that oil life has been
diminished, it will indicate that an oil change is
necessary. A CHANGE OIL SOON light will come on.
Change your oil as soon as possible within the next two
times you stop for fuel. It is possible that, if you are
driving under the best conditions, the oil life system may
not indicate that an oil change is necessary for over a
year. However, your engine oil and lter must be
changed at least once a year and at this time the system
must be reset. Your dealer has GM-trained service
people who will perform this work using genuine GM
parts and reset the system. It is also important to check
your oil regularly and keep it at the proper level.
If the system is ever reset accidentally, you must change
your oil at 3,000 miles (5 000 km) since your last oil
change. Remember to reset the oil life system whenever
the oil is changed.
How to Reset the CHANGE OIL
SOON Light
The GM Oil Life System calculates when to change
your engine oil and lter based on vehicle use. Anytime
your oil is changed, reset the system so it can
calculate when the next oil change is required. If a
situation occurs where you change your oil prior to a
CHANGE OIL SOON light being turned on, reset
the system.
After changing the engine oil, reset the system by
performing the following steps:
1. With the engine off, turn the ignition key to RUN.
2. Fully press and release the accelerator pedal slowly
three times within ve seconds.
If the CHANGE OIL SOON light ashes, the system
is resetting.
3. Turn the key to OFF, then start the vehicle. The oil
life will change to 100 percent.
If the CHANGE OIL SOON light comes back on when
you start your vehicle, the oil life system has not
reset. Repeat the procedure.
If you have a Driver Information Center, the system may
be reset by pressing the DIC RESET button for ve
seconds while viewing the oil life display on the
DIC. SeeDriver Information Center (DIC) on page 3-42.
5-20

What to Do with Used Oil
Used engine oil contains certain elements that may be
unhealthy for your skin and could even cause cancer.
Do not let used oil stay on your skin for very long. Clean
your skin and nails with soap and water, or a good
hand cleaner. Wash or properly dispose of clothing or
rags containing used engine oil. See the manufacturer’s
warnings about the use and disposal of oil products.
Used oil can be a threat to the environment. If you
change your own oil, be sure to drain all the oil from the
lter before disposal. Never dispose of oil by putting it
in the trash, pouring it on the ground, into sewers, or into
streams or bodies of water. Instead, recycle it by
taking it to a place that collects used oil. If you have a
problem properly disposing of your used oil, ask
your dealer, a service station or a local recycling center
for help.
Supercharger Oil
Unless you are technically
qualied and have the
proper tools, you should let
your dealer or a qualied
service center perform
this maintenance.
When to Check
Check oil level every 30,000 miles (50 000 km) or every
36 months, whichever occurs rst.
What Kind of Oil to Use
Use only the recommended supercharger oil. See
Recommended Fluids and Lubricants on page 6-12.
5-21

How to Check and Add Oil
Park the vehicle on a level surface. Check oil only when
the engine is cold. Allow the engine to cool two to
three hours after running.
{CAUTION:
If you remove the supercharger oil ll plug
while the engine is hot, pressure may cause
hot oil to blow out of the oil ll hole. You may
be burned. Do not remove the plug until the
engine cools.
1. Clean the area around the oil ll plug before
removing it.
2. Remove the oil ll plug.
3. The oil level is correct when it just reaches the
bottom of the threads of the inspection hole.
4. Replace the oil plug with the O-ring in place.
Tighten to 88 lb-in (10Y).
Engine Air Cleaner/Filter
SeeEngine Compartment Overview on page 5-12for
location of engine air cleaner/lter.
When to Inspect the Engine Air
Cleaner/Filter
Inspect the air cleaner/lter at every oil change and
replace at the rst oil change after 25,000 miles
(40 000 km).
How to Inspect the Engine Air
Cleaner/Filter
To inspect the air cleaner/lter remove it from the
vehicle and lightly shake the lter to release loose dust
and dirt. If the lter remains “caked” with dirt, a new
lter is required.
5-22
