Doors and Locks
Door Locks
{CAUTION:
Unlocked doors can be dangerous.
Passengers — especially children — can
easily open the doors and fall out of a
moving vehicle. When a door is locked, the
handle will not open it. You increase the
chance of being thrown out of the vehicle
in a crash if the doors are not locked. So,
wear safety belts properly and lock the
doors whenever you drive.
Young children who get into unlocked
vehicles may be unable to get out. A child
can be overcome by extreme heat and can
suffer permanent injuries or even death
from heat stroke. Always lock your vehicle
whenever you leave it.
Outsiders can easily enter through an
unlocked door when you slow down or
stop your vehicle. Locking your doors can
help prevent this from happening.There are several ways to lock and unlock the vehicle.
From the outside, use the door key or remote keyless
entry transmitter. From the inside use the manual
or power door locks.
To manually lock or unlock the driver’s door from the
outside, insert the key and turn it clockwise or
counterclockwise.
To lock or unlock the doors from the inside, push the
manual lock lever forward or rearward.
2-9

Power Door Locks
The vehicle has front
power door lock switches.
Press the top portion of
a door lock switch to
unlock or the bottom
portion to lock all doors.
The rear doors do not have power door lock switches.
Programmable Automatic
Door Locks
Programmable power door locks are intended to provide
enhanced security and convenience by automatically
locking and unlocking doors under certain conditions.
The doors can be set to one of four operating modes.
Mode 1:Doors do not lock or unlock automatically when
the transaxle is shifted out of or into PARK (P).
Mode 2:All doors automatically lock when the transaxle
is shifted out of PARK (P), but do not unlock automatically
when the transaxle is shifted into PARK (P).
Mode 3:All doors automatically lock when the transaxle
is shifted out of PARK (P) and automatically unlock
when the transaxle is shifted into PARK (P).
Mode 4:All doors automatically lock when the transaxle
is shifted out of PARK (P) but only the driver’s door
automatically unlocks when the transaxle is shifted into
PARK (P).
2-10

The vehicle was originally programmed to Mode 3. The
mode may have been changed since then. To
determine the current mode, or to change the mode, do
the following:
1. Turn the ignition key to RUN.
2. Close all of the doors.
3. Apply the brakes.
4. Press and hold the power door lock switch in the
lock position.
5. Move the shift lever out of and back into PARK (P)
while holding the door lock switch in the LOCK
position.
6. Release the door lock switch to set the
desired mode.
After initially moving the shift lever out of and back into
PARK (P), each additional shift cycle will advance
the programming from the current mode to the next
operating mode. If cycled beyond Mode 4, the vehicle
will enter operating Mode 1.
Disconnecting the vehicle’s battery for up to a year will
not affect the programmed mode.Lockout Protection
This feature helps to prevent a driver from locking the
keys inside of the vehicle by disabling the power
door locks when the following occurs:
A door is opened.
The key is left in the ignition.
A power door lock is pressed.
The lockout protection feature can be overridden by
holding the power door lock switch in the lock position
for more than three seconds while the key is in the
ignition and any door is open.
This feature cannot guarantee that you will never be
locked out of the vehicle. If the manual door lock is used
or if the key is left in the vehicle, but not in the ignition,
you could still be locked out of the vehicle. Always
remember to take the keys with you.
Leaving Your Vehicle
Before leaving the vehicle, take the keys, open the
door, and set the locks from inside. Then get out and
close the door. See “Delayed Locking” in this section for
more information.
2-11

Trunk
{CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can not see or
smell CO. It can cause unconsciousness and
even death. If you must drive with the trunk lid
open or if electrical wiring or other cable
connections must pass through the seal
between the body and the trunk lid:
Make sure all other windows are shut.
Turn the fan on your heating or cooling
system to its highest speed and select the
control setting that will force outside air
into your vehicle. See Climate Control
System in the Index.
If you have air outlets on or under the
instrument panel, open them all the way.
SeeEngine Exhaust on page 2-29.
Trunk Lock
To unlock the trunk lid from the outside, insert the door
key into the trunk lock and turn it counterclockwise.
Or, with the vehicle in PARK (P), press the open trunk
symbol on the remote keyless entry transmitter.
Remote Trunk Release
Press the remote trunk
release button located
behind the glove box door
to release the trunk lid
from inside the vehicle.
The shift lever must be in PARK (P), but the key does
not have to be in the ignition for the remote trunk
lid release button to work.
2-12

Trunk Assist Handle
Notice:Using the trunk assist handle as a tie-down
or anchor point when securing items in the trunk
may damage it. Use the trunk assist handle only to
help you close the trunk lid.
The vehicle may have an
assist handle located on
the inside of the trunk
lid toward the driver’s side
of the vehicle.
Pull down on the handle to lower the trunk lid and close
the trunk. If the trunk is not properly closed, the
DOOR/TRUNK ajar warning light will appear in the
message center of the instrument panel cluster. See
Door/Trunk Ajar Warning Light on page 3-40for
more information.
Emergency Trunk Release Handle
Notice:Using the emergency trunk release handle
as a tie-down or anchor point when securing
items in the trunk may damage it. Use the
emergency trunk release handle only to help you
open the trunk lid.
The vehicle has a glow-in-the-dark emergency trunk
release handle located inside the trunk on the latch. This
handle will glow following exposure to light. Pull the
release handle to open the trunk from the inside.
2-13

Windows
{CAUTION:
Leaving children in a vehicle with the windows
closed is dangerous. A child can be overcome
by the extreme heat and can suffer permanent
injuries or even death from heat stroke. Never
leave a child alone in a vehicle, especially with
the windows closed in warm or hot weather.
2-14

Power Windows
The switches on the driver’s door armrest are used to
control each of the windows when the ignition is in
the ON position. Each passenger door has its
own window switch.
Express-Down Window
The driver’s window switch has an express-down
feature. This switch is labeled AUTO. Tap the switch
rearward and the driver’s window will open without
stopping.To stop the window while it is lowering, press forward
on the switch. To raise the window, press and hold
the switch forward.
Window Lock-Out
The driver’s window controls also include a lock-out
switch. Press LOCK on this control to prevent
passengers from using their window switches. The
driver can still control all the windows with the lock on.
Press the other side of the window lock-out switch
to allow passengers individual control of their windows.
Sun Visors
To block out glare, swing down the sun visors. They
can also be moved to the side windows. The sun visors
also have extenders that can be pulled out for added
coverage.
Visor Vanity Mirror
Open the cover on the sun visor to expose the vanity
mirror.
Lighted Visor Vanity Mirrors
If the vehicle has the lighted vanity mirrors, the lamps
come on when the cover is opened.
2-15

Theft-Deterrent Systems
Vehicle theft is big business, especially in some cities.
Although your vehicle has a number of theft-deterrent
features, we know that nothing we put on it can make it
impossible to steal. However, there are ways you
can help.
PASS-Key®II
The vehicle is equipped
with the PASS-Key®II
(Personalized Automotive
Security System)
theft-deterrent system.
PASS-Key
®II is a passive
theft-deterrent system.
It works when the ignition
key is inserted or
removed from the ignition.
PASS-Key
®II uses a resistor pellet in the ignition key
that matches a decoder in the vehicle.When the PASS-Key
®II system senses that the wrong
key has been inserted into the ignition, it shuts down
the vehicle’s starter and fuel systems. The starter will not
work and fuel will not go to the engine for about three
minutes. If someone tries to start the vehicle again with
the wrong key, or uses another incorrect key during
this time, the vehicle will not start. This discourages
someone from randomly trying keys with different
resistor pellets in an attempt to make a match.
The ignition key must be clean and dry before it is
inserted in the ignition or the engine may not start. If the
engine does not start and the SECURITY warning
light on the instrument panel is ashing, the key may be
dirty or wet. Turn the ignition off.
Clean and dry the key. Wait about three minutes and try
again. If the vehicle still does not start, the ignition
key may be faulty. Wait about three more minutes and
try a spare ignition key. At this time, you may also
want to check the fuse. SeeFuses and Circuit Breakers
on page 5-98for information on fuse location. If the
starter will not work with the spare key, the vehicle
needs service. See your dealer or a locksmith who can
service the PASS-Key
®II.
2-16

If a key is accidentally used that has a damaged or
missing resistor pellet, the starter will not work.
The SECURITY warning light on the instrument panel
will then come on. But you do not have to wait three
minutes before trying another ignition key.
See your dealer or a locksmith who can service the
PASS-Key
®II to have a new key made.
If the SECURITY warning light comes on the instrument
panel while the vehicle is being driven, the engine
will still be able to be started after it is turned off. The
PASS-Key
®II system, however, is not working properly
and must be serviced by your dealer. The vehicle is
not protected by the PASS-Key
®II system when
this happens.
If a PASS-Key
®II ignition key is lost or damaged, see
your dealer or a locksmith who can service
PASS-Key
®II to have a new key made. Also, see
Roadside Assistance Program on page 7-6for more
information.
Starting and Operating Your
Vehicle
New Vehicle Break-In
Notice:Your vehicle does not need an elaborate
“break-in.” But it will perform better in the long run
if you follow these guidelines:
Do not drive at any one speed — fast or
slow — for the rst 500 miles (805 km). Do not
make full-throttle starts.
Avoid making hard stops for the rst 200 miles
(322 km) or so. During this time your new
brake linings are not yet broken in. Hard stops
with new linings can mean premature wear
and earlier replacement. Follow this breaking-in
guideline every time you get new brake
linings.
Do not tow a trailer during break-in. SeeTowing
a Trailer on page 4-39for more information.
2-17

Ignition Positions
With the ignition key in the ignition, the key can be
turned to ve different positions:
A (ACCESSORY):This position lets the radio and
windshield wipers operate when the engine is off. To use
ACCESSORY, push in the key and turn it
counterclockwise. The steering wheel will stay locked.
B (LOCK):This is the only position in which the ignition
key can be inserted or removed. This position locks
the ignition, steering wheel and transaxle. It is a
theft-deterrent feature.Notice:If your key seems stuck in LOCK and you
can not turn it, be sure you are using the correct
key; if so, is it all the way in? If it is, then turn the
steering wheel left and right while you turn the
key hard. Turn the key only with your hand. Using a
tool to force it could break the key or the ignition
switch. If none of these works, then your vehicle
needs service.
C (OFF):In this position the engine is off but the
steering wheel is not locked and can still be turned. Use
the OFF position if the vehicle must be pushed or
towed.
D (RUN):This position is where the key returns to after
the vehicle is started. This position displays some of
the warning and indicator lights.
E. (START):This position starts the engine.
A warning chime will sound when the driver’s door is
opened if the ignition is in OFF, LOCK or ACCESSORY
and the key is in the ignition.
Retained Accessory Power (RAP)
Retained Accessory Power (RAP), lets the power
windows and audio system continue to operate for up to
10 minutes after the ignition key is turned to OFF and
before any of the doors are opened.
2-18
