Circuit
BreakersUsage
TIRE RESET Tire In ation Monitor Reset Button
PWR/WNDW
PWR S/ROOFPower Windows, Power Sunroof
R/DEFOG Rear Window Defogger
PWR SEAT Power Seat
Blank Not Used
Fuses Usage
PRK/LCK Ignition Key Solenoid
Blank Not Used
Blank Not Used
PCM, BCM,
U/HIgnition Signal: Hot in Run and Start,
Powertrain Control Module, Body
Control Module, Underhood Relay
RADIO PREM.
SOUNDRemote Radio Premium Sound
PWR MIR Power Mirrors
Blank Not Used
INT/ILLUM Panel Dimming
Blank Not Used
IGN 0: CLSTR,
PCM & BCMIgnition Signal: Hot in Run, Unlock
and Start, Cluster, Powertrain
Control Module, Body Control
Module
Blank Not Used
Blank Not Used
Blank Not Used
ACCY PWR
BUSInterior Lamps
DR/ LCK Door Locks
Blank Not Used
R/LAMPS Taillamps, License Plate Lamps
Blank Not Used
5-99
Underhood Fuse Block
Some fuses and relays are located in the underhood
fuse block on the passenger’s side of the vehicle in the
engine compartment. SeeEngine Compartment
Overview on page 5-12for more information on location.
Fuses Usage
1 Anti-Lock Brake System
2 Starter Solenoid
3Power Seats, Rear Window
Defogger, Heated Seats
4High Blower, Hazard Flasher,
Stoplamps, Power Mirror, Door
Locks
5Ignition Switch, BTS Shifter Lock
Solenoid, Stoplamps, Anti-Lock
Brake System, Turn Signals,
Cluster, Air Bag, Daytime Running
Lamps Module
6 Cooling Fan
7Retained Accessory Power (RAP),
Remote Keyless Entry, Data Link,
Heating, Ventilation and Air
Conditioning Head, Cluster, Radio,
Cigarette Lighter
8Ignition Switch, Windshield Wipers,
Radio, Steering Wheel Controls,
Body Control Module, Power
Windows, Sunroof; Heating,
Ventilation and Air Conditioning
Controls; Daytime Running Lamps,
Rear Window Defogger Relay
5-101
Relays Usage
9 Cooling Fan 2
10 Cooling Fan 3
11 Starter Solenoid
12 Cooling Fan 1
13 Ignition Main
14 Air Pump (Optional)
15 Not Used
16 Horn
17 Fog Lamps
18 Not Used
19 Fuel Pump
Fuses Usage
20 Not Used
21 Generator
22 Engine Control Module
23 Air Conditioner Compressor Clutch
24 Cooling Fan
25 Electronic Ignition
Fuses Usage
26 Transaxle
27 Horn
28 Fuel Injector
29 Oxygen Sensor
30 Engine Emissions
31 Fog Lamps
32 Right Headlamp
33 Rear Compartment Release
34 Parking Lamps
35 Fuel Pump
36 Left Headlamp
37 Not Used
38 Not Used
39 Not Used
40 Not Used
41 Not Used
42 Not Used
43 Not Used
SYMBOLAir Conditioner Compressor Clutch
