DRIVING AND OPERATING 283
OPSymbol Fault/Condition/Event
OSolid GreennFlashing RedR m
Charge Cord Fault: The charge cord has detected a potential
problem with the charge cord. Reset the charge cord by
unplugging from the electrical outlet and re-plugging it. If the
fault remains, see an authorized dealer for service.
If no status indicators are lit, ensure
the electrical outlet is powered.
Charge Limit Selection
Charge level selection can be made
using the Charge Limit Preference
screen on the infotainment display.
See “Charge Limit Selection ”under
Programmable Charging (PLUG-IN Only)
0 152.
{Warning
Using a charge level that exceeds
the electrical circuit or electrical
outlet capacity may start a fire or
damage the electrical circuit. Use
the lowest charge level until a
(Continued)
Warning (Continued)
qualified electrician inspects the
electrical circuit capacity. Use the
lowest charge level if the electrical
circuit or electrical outlet capacity
is not known.
Grounding Instructions
This product must be grounded. If this
product should malfunction or break
down, grounding provides a path of
least resistance for electric current to
reduce the risk of electric shock. This
product is equipped with a cord that
has an equipment grounding
conductor and a grounding plug. The
plug must be plugged into an appropriate outlet that is properly
installed and grounded in accordance
with all local codes and ordinances.
{Warning
Improper connection of the charge
cord ground may cause electrical
shock. Check with a qualified
electrician if there is doubt as to
whether the charge circuit is
properly grounded. Do not modify
the plug provided with the product.
If it will not fit the electrical outlet,
have a proper electrical outlet
installed by a qualified electrician.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
DRIVING AND OPERATING 287
by the vehicle warranty. If heavy
knocking is heard when using gasoline
rated at 93 octane, the engine needs
service.
Prohibited Fuels
Caution
Do not use fuels with any of the
following conditions; doing so may
damage the vehicle and void its
warranty:. For vehicles which are not
FlexFuel, fuel labeled greater
than 15% ethanol by volume,
such as mid-level ethanol
blends (16 –50% ethanol),
E85, or FlexFuel.
. Fuel with any amount of
methanol, methylal, and
aniline. These fuels can
corrode metal fuel system
parts or damage plastic and
rubber parts.
. Fuel containing metals such
as methylcyclopentadienyl
manganese tricarbonyl
(Continued)
Caution (Continued)
(MMT), which can damage
the emissions control system
and spark plugs.
. Fuel with a posted octane
rating of less than the
recommended fuel. Using this
fuel will lower fuel economy
and performance, and may
decrease the life of the
emissions catalyst.
California Fuel
Requirements
If the vehicle is certified to meet
California Emissions Standards, it is
designed to operate on fuels that meet
California specifications. See the
underhood emission control label.
If this fuel is not available in states
adopting California Emissions
Standards, the vehicle will operate
satisfactorily on fuels meeting federal
specifications, but emission control
system performance may be affected.
The malfunction indicator lamp could
turn on and the vehicle may not pass a smog-check test. See
Malfunction
Indicator Lamp (Check Engine Light)
0 143. If this occurs, return to your
authorized dealer for diagnosis. If it is
determined that the condition is
caused by the type of fuel used,
repairs may not be covered by the
vehicle warranty.
Fuels in Foreign Countries
The U.S., Canada, and Mexico post
fuel octane ratings in anti-knock index
(AKI). For fuel not to use in a foreign
country, see “Prohibited Fuels” inFuel
0 286.
Fuel Additives
To keep fuel systems clean, TOP TIER
detergent gasoline is recommended.
See Fuel 0286.
If TOP TIER detergent gasoline is not
available, one bottle of GM Fuel
System Treatment Cleaner added to
the fuel tank at every engine oil
change, can help. GM Fuel System
Treatment Cleaner is the only gasoline
additive recommended by General
Motors. It is available at your dealer.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
DRIVING AND OPERATING 295
Because the vehicle has antilock
brakes, do not tap into the vehicle's
brake system. If this is done, both
brake systems will not work well or
at all.Conversions and
Add-Ons
Add-On Electrical
Equipment
{Warning
The Data Link Connector (DLC) is
used for vehicle service and
Emission Inspection/Maintenance
testing. SeeMalfunction Indicator
Lamp (Check Engine Light) 0143.
A device connected to the DLC —
such as an aftermarket fleet or
driver-behavior tracking device —
may interfere with vehicle systems.
This could affect vehicle operation
and cause a crash. Such devices
may also access information stored
in the vehicle’s systems.
Caution
Some electrical equipment can
damage the vehicle or cause
components to not work and would
not be covered by the vehicle
warranty. Always check with your
dealer before adding electrical
equipment.
Add-on equipment can drain the
vehicle's 12-volt battery, even if the
vehicle is not operating.
The vehicle has an airbag system.
Before attempting to add anything
electrical to the vehicle, see Servicing
the Airbag-Equipped Vehicle 095 and
Adding Equipment to the
Airbag-Equipped Vehicle 095.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/15/17
VEHICLE CARE 321
Engine Overheating
The vehicle has several indicators to
warn of the engine overheating.
There is an engine coolant
temperature gauge and an engine
coolant temperature warning light on
the instrument cluster.
SeeEngine Coolant Temperature Gauge
0 139 and Engine Coolant Temperature
Warning Light 0149. The vehicle may
also display a message on the Driver
Information Center (DIC).
If the decision is made not to lift the
hood when this warning appears, get
service help right away. See Roadside
Service 0411.
If the decision is made to lift the
hood, make sure the vehicle is parked
on a level surface. Then check to see if
the engine cooling fan is running.
If the engine is overheating, the fan
should be running. If it is not, do not
continue to run the engine. Have the
vehicle serviced.Caution
Do not run the engine if there is a
leak in the engine cooling system.
This can cause a loss of all coolant
and can damage the system and
vehicle. Have any leaks fixed
right away.
If Steam Is Coming from the
Engine Compartment
{Warning
Steam and scalding liquids from a
hot cooling system are under
pressure. Turning the pressure cap,
even a little, can cause them to
come out at high speed and you
could be burned. Never turn the cap
when the cooling system, including
the pressure cap, is hot. Wait for
the cooling system and pressure
cap to cool.
If No Steam Is Coming from the
Engine Compartment
If an engine overheat warning is
displayed but no steam can be seen or
heard, the problem may not be too
serious. Sometimes the engine can get
a little too hot when the vehicle:
. Climbs a long hill on a hot day
. Stops after high-speed driving
. Idles for long periods in traffic
If the overheat warning is displayed
with no sign of steam: 1. Turn the air conditioning off.
2. Turn the heater on to the highest temperature and to the highest
fan speed. Open the windows as
necessary.
3. When it is safe to do so, pull off the road, shift to P (Park) or
N (Neutral), and let the
engine idle.
If the engine coolant temperature
gauge is no longer in the overheated
area or the engine coolant
temperature warning light no longer
displays, the vehicle can be driven.
Continue to drive the vehicle slowly

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
SERVICE AND MAINTENANCE 397
brake lamps need to be checked
periodically to ensure that they
light when braking.
. With a multi-point inspection,
your dealer can check the lamps
and note any concerns.
Shocks and Struts
Shocks and struts help aid in control
for a smoother ride.
. Signs of wear may include steering
wheel vibration, bounce/sway
while braking, longer stopping
distance, or uneven tire wear.
. As part of the multi-point
inspection, trained dealer
technicians can visually inspect
the shocks and struts for signs of
leaking, blown seals, or damage,
and can advise when service is
needed. Tires
Tires need to be properly inflated,
rotated, and balanced. Maintaining
the tires can save money and fuel, and
can reduce the risk of tire failure.
.
Signs that the tires need to be
replaced include three or more
visible treadwear indicators; cord
or fabric showing through the
rubber; cracks or cuts in the tread
or sidewall; or a bulge or split in
the tire.
. Trained dealer technicians can
inspect and recommend the right
tires. Your dealer can also provide
tire/wheel balancing services to
ensure smooth vehicle operation
at all speeds. Your dealer sells and
services name brand tires.
Vehicle Care
To help keep the vehicle looking like
new, vehicle care products are
available from your dealer. For
information on how to clean and
protect the vehicle’s interior and
exterior, see Interior Care 0384 and
Exterior Care 0380. Wheel Alignment
Wheel alignment is critical for
ensuring that the tires deliver optimal
wear and performance.
.
Signs that the alignment may need
to be adjusted include pulling,
improper vehicle handling,
or unusual tire wear.
. Your dealer has the required
equipment to ensure proper wheel
alignment.
Windshield
For safety, appearance, and the best
viewing, keep the windshield clean
and clear.
. Signs of damage include scratches,
cracks, and chips.
. Trained dealer technicians can
inspect the windshield and
recommend proper replacement if
needed.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
436 INDEX
Frequency StatementRadio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 417
Front Pedestrian Braking (FPB) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264
Front Seats Heated and Ventilated . . . . . . . . . . . . . 72
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 286
Additives . . . . . . . . . . . . . . . . . . . . . . . . . . 287
Economy Driving . . . . . . . . . . . . . . . . . . . 32
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . . . . . . 290
Filling the Tank . . . . . . . . . . . . . . . . . . . 288
Foreign Countries . . . . . . . . . . . . . . . . . 287
Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Low Fuel Warning Light . . . . . . . . . 150
Requirements, California . . . . . . . . . 287
Fuses Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 332
Fuses and Circuit Breakers . . . . . . . 331
Instrument Panel Fuse Block . . . . 335
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 337
G
Garage Door Opener . . . . . . . . . . . . . . . . 179Programming . . . . . . . . . . . . . . . . . . . . . . 179
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . . . . . . 328 Gauges
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Boost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Engine Coolant Temperature . . . . 139
Engine Oil Pressure . . . . . . . . . . . . . . . 137
Engine Oil Temperature . . . . . . . . . . 138
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Power Indicator . . . . . . . . . . . . . . . . . . . 136
Speedometer . . . . . . . . . . . . . . . . . . . . . . 134
Tachometer . . . . . . . . . . . . . . . . . . . . . . . 134
Trip Odometer . . . . . . . . . . . . . . . . . . . . 134
Voltmeter . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Warning Lights and
Indicators . . . . . . . . . . . . . . . . . . . . . . . . 126
General Information
Service and Maintenance . . . . . . . . 388
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
Vehicle Care . . . . . . . . . . . . . . . . . . . . . . . 297
Glove Box . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
H
Hazard Warning Flashers . . . . . . . . . . 186
Head Restraints . . . . . . . . . . . . . . . . . . . . . . 65
Head-up Display . . . . . . . . . . . . . . . . . . . . 165
Headlamps Aiming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 329
Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 185
Bulb Replacement . . . . . . . . . . . . . . . . 330 Headlamps (cont'd)
Daytime Running
Lamps (DRL) . . . . . . . . . . . . . . . . . . . . 185
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . 185
High-Beam On Light . . . . . . . . . . . . . . 151
High/Low Beam Changer . . . . . . . . . 185
Lamps On Reminder . . . . . . . . . . . . . . 151
Heated Steering Wheel . . . . . . . . . . . . . . . . . . . . 119
Heated and Ventilated Front Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Heated and Ventilated Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Heated Mirrors . . . . . . . . . . . . . . . . . . . . . . . 55
Heater
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223
Heating . . . . . . . . . . . . . . . . . . . . . . . . .191, 197
High Voltage Battery Gauge . . . . . . . 135
High-Beam On Light . . . . . . . . . . . . . . . . 151
High-Speed Operation . . . . . . . . . . . . . . 349
Hill and Mountain Roads . . . . . . . . . . 211
Hill Start Assist (HSA) . . . . . . . . . . . . . 237
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 299
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
How to Wear Seat Belts Properly . . . 79
HVAC . . . . . . . . . . . . . . . . . . . . . . . . . . .191, 197

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
438 INDEX
Lights (cont'd)Low Fuel Warning . . . . . . . . . . . . . . . . 150
Seat Belt Reminders . . . . . . . . . . . . . . 140
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Service Electric Parking Brake . . . 146
Service Vehicle Soon . . . . . . . . . . . . . 145
Sport Mode . . . . . . . . . . . . . . . . . . . . . . . . 146
StabiliTrak OFF . . . . . . . . . . . . . . . . . . . 148
Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 149
Traction Control System
(TCS)/StabiliTrak . . . . . . . . . . . . . . . . 148
Traction Off . . . . . . . . . . . . . . . . . . . . . . . 148
Vehicle Ready . . . . . . . . . . . . . . . . . . . . . 151
Winter Driving Mode . . . . . . . . . . . . . 146
Locks Automatic Door . . . . . . . . . . . . . . . . . . . . . 45
Delayed Locking . . . . . . . . . . . . . . . . . . . . 45
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Lockout Protection . . . . . . . . . . . . . . . . . 46
Power Door . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Loss of Control . . . . . . . . . . . . . . . . . . . . . . 209
Low Fuel Warning Light . . . . . . . . . . . 150
Low-Profile Tires . . . . . . . . . . . . . . . . . . . . 342
Lower Anchors and Tethers for Children (LATCH System) . . . . . . . . 103 Lumbar Adjustment . . . . . . . . . . . . . 67, 76
Front Seats . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
M
MaintenanceRecords . . . . . . . . . . . . . . . . . . . . . . . . . . . . 402
Maintenance and Care Additional . . . . . . . . . . . . . . . . . . . . . . . . . 396
Maintenance Modes . . . . . . . . . . . . . . . . 228
Maintenance Schedule . . . . . . . . . . . . . 390 Recommended Fluids and
Lubricants . . . . . . . . . . . . . . . . . . . . . . . 399
Malfunction Indicator Lamp . . . . . . . 143
Manual Mode . . . . . . . . . . . . . . . . . . . . . . . 233
Massage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Memory Features . . . . . . . . . . . . . . . . . . . . 13
Memory Seats . . . . . . . . . . . . . . . . . . . . . . . . 69
Messages Engine Power . . . . . . . . . . . . . . . . . . . . . 169
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Vehicle Speed . . . . . . . . . . . . . . . . . . . . . 169
Mirror Rear Camera . . . . . . . . . . . . . . . . . . . . . . . . 56
Mirrors Automatic Dimming . . . . . . . . . . . . . . . . 55
Automatic Dimming Rearview . . . . . 56 Mirrors (cont'd)
Convex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Folding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Heated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Tilt in Reverse . . . . . . . . . . . . . . . . . . . . . . 56
Mirrors, Interior Rearview . . . . . . . . . . . 56
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241 Driver Control . . . . . . . . . . . . . . . . . . . . . 241
Modes Driver Selected . . . . . . . . . . . . . . . . . . . . 226
Maintenance . . . . . . . . . . . . . . . . . . . . . . 228
Monitor System, Tire Pressure . . . . . 349
N
Navigation OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 423
Net, Convenience . . . . . . . . . . . . . . . . . . . 117
New Vehicle Break-In . . . . . . . . . . . . . . . 216
Night Vision System . . . . . . . . . . . . . . . . 266
O
Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134 Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . 209
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 307
Engine Oil Life System . . . . . . . . . . . 309

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
INDEX 439
Oil (cont'd)Engine Oil Pressure Gauge . . . . . . . 137
Pressure Light . . . . . . . . . . . . . . . . . . . . . 149
Older Children, Restraints . . . . . . . . . . . 96
Online Owner Center . . . . . . . . . . . . . . . 411
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 420
OnStar Additional Information . . . . 426
OnStar Connections . . . . . . . . . . . . . . . . 423
OnStar Diagnostics . . . . . . . . . . . . . . . . . 425
OnStar Emergency . . . . . . . . . . . . . . . . . . 422
OnStar Navigation . . . . . . . . . . . . . . . . . . 423
OnStar Overview . . . . . . . . . . . . . . . . . . . . 421
OnStar Security . . . . . . . . . . . . . . . . . . . . . 422
Ordering
Service Publications . . . . . . . . . . . . . . 416
Out of Fuel/Engine Unavailable . . . . 227
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Overheating, Engine . . . . . . . . . . . . . . . . 321
P
Park Shifting Into . . . . . . . . . . . . . . . . . . . . . . 224
Shifting Out of . . . . . . . . . . . . . . . . . . . . 225
Parking Brake and P (Park)Mechanism Check . . . . . . . . . . . . . . . 327
Extended . . . . . . . . . . . . . . . . . . . . . . . . . . 226 Parking (cont'd)
Over Things That Burn . . . . . . . . . . . 225
Parking Assist . . . . . . . . . . . . . . . . . . . . . . . 254
Parking or Backing Assistance Systems . . . . . . . . . . . . . . . 254
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Passenger Compartment Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204
Passenger Sensing System . . . . . . . . . . 91
Pedestrian Ahead Indicator . . . . . . . . 147
Perchlorate Materials Requirements, California . . . . . . . . . 297
Personalization
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Plug-In Charging . . . . . . . . . . . . . . . . . . . . 274
Power Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Flows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Indicator Gauge . . . . . . . . . . . . . . . . . . . 136
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Protection, Battery . . . . . . . . . . . . . . . . 189
Retained Accessory (RAP) . . . . . . . . 224
Seat Adjustment . . . . . . . . . . . . . . . . . . . . 67
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Pregnancy, Using Seat Belts . . . . . . . . . 83 Premium Care Maintenance
Cadillac . . . . . . . . . . . . . . . . . . . . . . . . . . . . 390
Privacy Vehicle Data Recording . . . . . . . . . . 419
Program Courtesy Transportation . . . . . . . . . 413
Programmable Charging . . . . . . . . . . . . 152
Proposition
65 Warning,
California . . . . . . . . . . . . . . .297, 324, 374, Back Cover
R
Radio Frequency Statement . . . . . . . . 417
Reading Lamps . . . . . . . . . . . . . . . . . . . . . 188
Ready Indicator . . . . . . . . . . . . . . . . . . . . . 151
Rear Camera Mirror . . . . . . . . . . . . . . . . . 56
Rear Seat Pass-Through Door . . . . . . . 77
Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Heated and Ventilated . . . . . . . . . . . . . 77
Rear Storage . . . . . . . . . . . . . . . . . . . . . . . . 116
Rear Vision Camera (RVC) . . . . . . . . . 254
Rear Window Sunshade . . . . . . . . . . . . . 60
Rearview Mirrors
Automatic Dimming . . . . . . . . . . . . . . . . 56
Reclining Seatbacks . . . . . . . . . . . . . . . . . 69
Recommended Fluids and
Lubricants . . . . . . . . . . . . . . . . . . . . . . . . . 399

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
442 INDEX
Tires (cont'd)Sealant and Compressor Kit,
Storing . . . . . . . . . . . . . . . . . . . . . . . . . . . 368
Sidewall Labeling . . . . . . . . . . . . . . . . . 342
Terminology and Definitions . . . . 345
Uniform Tire Quality Grading . . . . 357
Wheel Alignment and Tire
Balance . . . . . . . . . . . . . . . . . . . . . . . . . . 359
Wheel Replacement . . . . . . . . . . . . . . 359
When It Is Time for New
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 355
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 341
Towing Driving Characteristics . . . . . . . . . . . 290
Equipment . . . . . . . . . . . . . . . . . . . . . . . . 294
General Information . . . . . . . . . . . . . . 290
Recreational Vehicle . . . . . . . . . . . . . . 378
Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 376
Traction Control System (TCS)/StabiliTrak Light . . . . . . . . . . . . . . . . 148
Off Light . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Traction Control/Electronic Stability Control . . . . . . . . . . . . . . . . . . . 239
Trailer Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 293 Transmission
Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 231
Fluid, Automatic . . . . . . . . . . . . . . . . . . 310
Transportation Program, Courtesy . . . . . . . . . . . . . . . . . . . . . . . . . . . 413
Trip Odometer . . . . . . . . . . . . . . . . . . . . . . 134
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Turn and Lane-Change Signals . . . . 186
U
Uniform Tire Quality Grading . . . . . . 357
Universal Remote System . . . . . . . . . . 179 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 181
Programming . . . . . . . . . . . . . . . . . . . . . . 179
Using This Manual . . . . . . . . . . . . . . . . . . . . 2
Utility Interruption of Charging . . . 284
V
Vehicle Alarm System . . . . . . . . . . . . . . . . . . . . . . . 51
Automatic Hold Light . . . . . . . . . . . . 147
Canadian Owners . . . . . . . . . . . . . . . . . . . . 2
Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207
Identification Number (VIN) . . . . . 403
Load Limits . . . . . . . . . . . . . . . . . . . . . . . 213
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Personalization . . . . . . . . . . . . . . . . . . . 170
Remote Start . . . . . . . . . . . . . . . . . . . . . . . . 42
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Vehicle (cont'd)
Service Soon Light . . . . . . . . . . . . . . . . 145
Speed Messages . . . . . . . . . . . . . . . . . . . 169
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 376
Vehicle Ahead Indicator . . . . . . . . . . . . 147
Vehicle Care Storing the Tire Sealant andCompressor Kit . . . . . . . . . . . . . . . . . . 368
Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 347
Vehicle Data Recording and Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 419
Vehicle Hold Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 237
Vehicle Hold (AVH)
Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 237
Vehicle Ready Light . . . . . . . . . . . . . . . . 151
Ventilation, Air . . . . . . . . . . . . . . . . . . . . . 203
Video Recorder . . . . . . . . . . . . . . . . . . . . . . 272
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Voltmeter Gauge . . . . . . . . . . . . . . . . . . . . 140
W
Warning Brake System Light . . . . . . . . . . . . . . . 145
Caution and Danger . . . . . . . . . . . . . . . . . 2
Lane Departure (LDW) . . . . . . . . . . . 270
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 126
