350 VEHICLE CARE
As an added safety feature, your
vehicle has been equipped with a tire
pressure monitoring system (TPMS)
that illuminates a low tire pressure
telltale when one or more of your tires
is significantly under-inflated.
Accordingly, when the low tire
pressure telltale illuminates, you
should stop and check your tires as
soon as possible, and inflate them to
the proper pressure. Driving on a
significantly under-inflated tire causes
the tire to overheat and can lead to
tire failure. Under-inflation also
reduces fuel efficiency and tire tread
life, and may affect the vehicle's
handling and stopping ability.
Please note that the TPMS is not a
substitute for proper tire maintenance,
and it is the driver's responsibility to
maintain correct tire pressure, even if
under-inflation has not reached the
level to trigger illumination of the
TPMS low tire pressure telltale.
Your vehicle has also been equipped
with a TPMS malfunction indicator to
indicate when the system is not
operating properly. The TPMS
malfunction indicator is combinedwith the low tire pressure telltale.
When the system detects a
malfunction, the telltale will flash for
approximately one minute and then
remain continuously illuminated. This
sequence will continue upon
subsequent vehicle start-ups as long
as the malfunction exists.
When the malfunction indicator is
illuminated, the system may not be
able to detect or signal low tire
pressure as intended. TPMS
malfunctions may occur for a variety
of reasons, including the installation
of replacement or alternate tires or
wheels on the vehicle that prevent the
TPMS from functioning properly.
Always check the TPMS malfunction
telltale after replacing one or more
tires or wheels on your vehicle to
ensure that the replacement or
alternate tires and wheels allow the
TPMS to continue to function
properly.
See
Tire Pressure Monitor Operation
0 350.
See Radio Frequency Statement 0417.Tire Pressure Monitor
Operation
This vehicle may have a Tire Pressure
Monitor System (TPMS). The TPMS is
designed to warn the driver when a
low tire pressure condition exists.
TPMS sensors are mounted onto each
tire and wheel assembly, excluding the
spare tire and wheel assembly. The
TPMS sensors monitor the air
pressure in the tires and transmit the
tire pressure readings to a receiver
located in the vehicle.
When a low tire pressure condition is
detected, the TPMS illuminates the
low tire pressure warning light on the
instrument cluster. If the warning
light comes on, stop as soon as
possible and inflate the tires to the
recommended pressure shown on the
Tire and Loading Information label.
See Vehicle Load Limits 0213.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/15/17
VEHICLE CARE 351
A message to check the pressure in a
specific tire displays in the Driver
Information Center (DIC). The low tire
pressure warning light and the DIC
warning message come on at each
ignition cycle until the tires are
inflated to the correct inflation
pressure. Using the DIC, tire pressure
levels can be viewed. For additional
information and details about the DIC
operation and displays seeDriver
Information Center (DIC) 0162.
The low tire pressure warning light
may come on in cool weather when
the vehicle is first started, and then
turn off as the vehicle is driven. This
could be an early indicator that the air
pressure is getting low and needs to
be inflated to the proper pressure.
A Tire and Loading Information label,
attached to your vehicle, shows the
size of the original equipment tires
and the correct inflation pressure for
the tires when they are cold. See
Vehicle Load Limits 0213, for an
example of the Tire and Loading
Information label and its location.
Also see Tire Pressure 0347. The TPMS can warn about a low tire
pressure condition but it does not
replace normal tire maintenance. See
Tire Inspection
0353, Tire Rotation
0 353 and Tires 0340.
Caution
Tire sealant materials are not all
the same. A non-approved tire
sealant could damage the TPMS
sensors. TPMS sensor damage
caused by using an incorrect tire
sealant is not covered by the
vehicle warranty. Always use only
the GM approved tire sealant
available through your dealer or
included in the vehicle.
Factory-installed Tire Inflator Kits use
a GM approved liquid tire sealant.
Using non-approved tire sealants
could damage the TPMS sensors. See
Tire Sealant and Compressor Kit 0362
for information regarding the inflator
kit materials and instructions.
TPMS Malfunction Light and
Message
The TPMS will not function properly if
one or more of the TPMS sensors are
missing or inoperable. When the
system detects a malfunction, the low
tire pressure warning light flashes for
about one minute and then stays on
for the remainder of the ignition cycle.
A DIC warning message also displays.
The malfunction light and DIC
warning message come on at each
ignition cycle until the problem is
corrected. Some of the conditions that
can cause these to come on are:
. One of the road tires has been
replaced with the spare tire. The
spare tire does not have a TPMS
sensor. The malfunction light and
DIC message should go off after
the road tire is replaced and the
sensor matching process is
performed successfully. See “TPMS
Sensor Matching Process ”later in
this section.
. The TPMS sensor matching
process was not done or not
completed successfully after
rotating the tires. The malfunction

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/15/17
354 VEHICLE CARE
Use this rotation pattern if the
vehicle has different size tires on
the front and rear.
Different tire sizes should not be
rotated front to rear.Use this rotation pattern when
rotating tires of the same size
installed on all four wheel
positions.
If the vehicle has a compact spare
tire, do not include it in the tire
rotation.
Adjust the front and rear tires to
the recommended inflation
pressure on the Tire and Loading
Information label after the tires
have been rotated.
SeeTire Pressure 0347 and Vehicle
Load Limits 0213. Reset the Tire Pressure Monitor
System. See
Tire Pressure Monitor
Operation 0350.
Check that all wheel nuts are
properly tightened. See “Wheel
Nut Torque ”under Capacities and
Specifications 0404.
{Warning
Rust or dirt on a wheel, or on the
parts to which it is fastened, can
make wheel nuts become loose
after time. The wheel could come
off and cause an accident. When
changing a wheel, remove any rust
or dirt from places where the wheel
attaches to the vehicle. In an
emergency, a cloth or a paper towel
can be used; however, use a scraper
or wire brush later to remove all
rust or dirt.
Lightly coat the center of the
wheel hub with wheel bearing
grease after a wheel change or tire
rotation to prevent corrosion or
rust build-up. Do not get grease

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/15/17
VEHICLE CARE 357
range, speed rating, and
construction (radial) as the
original tires.
Vehicles that have a tire pressure
monitoring system could give an
inaccurate low-pressure warning if
non-TPC Spec rated tires are
installed. SeeTire Pressure Monitor
Operation 0350.
The Tire and Loading Information
label indicates the original
equipment tires on the vehicle.
See Vehicle Load Limits 0213.
Different Size Tires and
Wheels
If wheels or tires are installed that are
a different size than the original
equipment wheels and tires, vehicle
performance, including its braking,
ride and handling characteristics,
stability, and resistance to rollover
may be affected. If the vehicle has
electronic systems such as antilock
brakes, rollover airbags, traction control, electronic stability control,
or All-Wheel Drive, the performance
of these systems can also be affected.
{Warning
If different sized wheels are used,
there may not be an acceptable
level of performance and safety if
tires not recommended for those
wheels are selected. This increases
the chance of a crash and serious
injury. Only use GM specific wheel
and tire systems developed for the
vehicle, and have them properly
installed by a GM certified
technician.
See Buying New Tires 0355 and
Accessories and Modifications 0298.
Uniform Tire Quality
Grading
The following information relates
to the system developed by the
United States National Highway
Traffic Safety Administration
(NHTSA), which grades tires by treadwear, traction, and
temperature performance. This
applies only to vehicles sold in the
United States. The grades are
molded on the sidewalls of most
passenger car tires. The Uniform
Tire Quality Grading (UTQG)
system does not apply to deep
tread, winter tires, compact spare
tires, tires with nominal rim
diameters of 10 to 12 inches
(25 to 30 cm), or to some
limited-production tires.
While the tires available on
General Motors passenger cars
and light trucks may vary with
respect to these grades, they must
also conform to federal safety
requirements and additional
General Motors Tire Performance
Criteria (TPC) standards.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/15/17
VEHICLE CARE 359
Wheel Alignment and Tire
Balance
The tires and wheels were aligned and
balanced at the factory to provide the
longest tire life and best overall
performance. Adjustments to wheel
alignment and tire balancing are not
necessary on a regular basis. Consider
an alignment check if there is unusual
tire wear or the vehicle is significantly
pulling to one side or the other. Some
slight pull to the left or right,
depending on the crown of the road
and/or other road surface variations
such as troughs or ruts, is normal.
If the vehicle is vibrating when driving
on a smooth road, the tires and
wheels may need to be rebalanced.
See your dealer for proper diagnosis.
Wheel Replacement
Replace any wheel that is bent,
cracked, or badly rusted or corroded.
If wheel nuts keep coming loose, the
wheel, wheel bolts, and wheel nuts
should be replaced. If the wheel leaks
air, replace it. Some aluminum wheels
can be repaired. See your dealer if any
of these conditions exist.Your dealer will know the kind of
wheel that is needed.
Each new wheel should have the same
load-carrying capacity, diameter,
width, offset, and be mounted the
same way as the one it replaces.
Replace wheels, wheel bolts, wheel
nuts, or Tire Pressure Monitor System
(TPMS) sensors with new GM original
equipment parts.
{Warning
Using the wrong replacement
wheels, wheel bolts, or wheel nuts
can be dangerous. It could affect
the braking and handling of the
vehicle. Tires can lose air, and
cause loss of control, causing a
crash. Always use the correct wheel,
wheel bolts, and wheel nuts for
replacement.
Caution
The wrong wheel can also cause
problems with bearing life, brake
cooling, speedometer or odometer
calibration, headlamp aim, bumper
height, vehicle ground clearance,
and tire or tire chain clearance to
the body and chassis.
Used Replacement Wheels
{Warning
Replacing a wheel with a used one
is dangerous. How it has been used
or how far it has been driven may
be unknown. It could fail suddenly
and cause a crash. When replacing
wheels, use a new GM original
equipment wheel.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/15/17
VEHICLE CARE 375
The jump start negative terminal (3)
and positive terminal (4) are on the
battery of the vehicle providing the
jump start.
The positive jump start connection for
the discharged battery is under a red
cover. Remove the cover to expose the
terminal.1. Check the other vehicle. It must have a 12-volt battery with a
negative ground system.
Caution
If the other vehicle does not have a
12-volt system with a negative
ground, both vehicles can be
damaged. Only use a vehicle that
has a 12-volt system with a
negative ground for jump starting.
2. Position the two vehicles so that they are not touching.
3. Set the parking brake firmly and put the shift lever in P (Park). See
Shifting Into Park 0224.
Caution
If any accessories are left on or
plugged in during the jump starting
procedure, they could be damaged.
The repairs would not be covered
by the vehicle warranty. Whenever
possible, turn off or unplug all
accessories on either vehicle when
jump starting.
4. Turn the ignition off. Turn off all lights and accessories in both
vehicles, except the hazard
warning flashers if needed.
{Warning
An electric fan can start up even
when the engine is not running and
can injure you. Keep hands,
clothing, and tools away from any
underhood electric fan.
{Warning
Using a match near a battery can
cause battery gas to explode. People
have been hurt doing this, and
some have been blinded. Use a
flashlight if you need more light.
Battery fluid contains acid that can
burn you. Do not get it on you.
If you accidentally get it in your
eyes or on your skin, flush the place
with water and get medical help
immediately.
{Warning
Fans or other moving engine parts
can injure you badly. Keep your
hands away from moving parts
once the engine is running.
5. Connect one end of the red positive (+) cable to the remote
positive (+) terminal on the
discharged battery.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
432 INDEX
IndexA
Accessories and Modifications . . . . . 298
Accessory Power . . . . . . . . . . . . . . . . . . . . 224
Adaptive Cruise Control . . . . . . . . . . . . 245
Add-On Electrical Equipment . . . . . . 295
Additional InformationOnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 426
Additional Maintenance and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . 396
Adjustments
Lumbar, Front Seats . . . . . . . . . . . . . . . . 67
Lumbar, Rear Seats . . . . . . . . . . . . . . . . . 76
Thigh Support . . . . . . . . . . . . . . . . . . . . . . 68
Air Cleaner/Filter, Engine . . . . . . . . . . 311
Air Conditioning . . . . . . . . . . . . . . .191, 197
Air Filter, Passenger
Compartment . . . . . . . . . . . . . . . . . . . . . 204
Air Vents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
Airbag System Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
How Does an Airbag Restrain? . . . . . 89
Passenger Sensing System . . . . . . . . . 91
What Makes an Airbag Inflate? . . . . 89
What Will You See after anAirbag Inflates? . . . . . . . . . . . . . . . . . . . 89
When Should an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Where Are the Airbags? . . . . . . . . . . . . 86 Airbags
Adding Equipment to the
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Passenger Status Indicator . . . . . . . 141
Readiness Light . . . . . . . . . . . . . . . . . . . 141
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
System Check . . . . . . . . . . . . . . . . . . . . . . . 85
Alarm Vehicle Security . . . . . . . . . . . . . . . . . . . . . 51
Alert
Lane Change . . . . . . . . . . . . . . . . . . . . . . 269
Side Blind Zone (SBZA) . . . . . . . . . . 268
All-Season Tires . . . . . . . . . . . . . . . . . . . . . 341
All-Wheel Drive . . . . . . . . . . . . . . . .234, 326
Antilock Brake System (ABS) . . . . . . 234 Warning Light . . . . . . . . . . . . . . . . . . . . 146
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 380
Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 384
Armrest Storage . . . . . . . . . . . . . . . . . . . . . 116
Ashtrays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Assistance Systems for Driving . . . . 260
Assistance Systems for Parking and Backing . . . . . . . . . . . . . . . . . . . . . . . 254
Auto Stop Mode . . . . . . . . . . . . . . . . . . . . 150
Automatic Climate Control System . . . . . 191, 197

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
INDEX 433
Automatic (cont'd)Dimming Mirrors . . . . . . . . . . . . . . . . . . . 55
Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Forward Braking . . . . . . . . . . . . . . . . . . 262
Headlamp System . . . . . . . . . . . . . . . . 185
Transmission . . . . . . . . . . . . . . . . . . . . . . 231
Transmission Fluid . . . . . . . . . . . . . . . 310
Vehicle Hold Light . . . . . . . . . . . . . . . . 147
Automatic Transmission
Manual Mode . . . . . . . . . . . . . . . . . . . . . 233
Shift Lock Control FunctionCheck . . . . . . . . . . . . . . . . . . . . . . . . . . . . 327
Automatic Vehicle Hold (AVH) . . . . 237
B
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135 Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
Power Protection . . . . . . . . . . . . . . . . . . 189
Battery - North America . . . . . .324, 374
Battery Gauge High Voltage . . . . . . . . . . . . . . . . . . . . . . 135
Blade Replacement, Wiper . . . . . . . . . 327
Boost Gauge . . . . . . . . . . . . . . . . . . . . . . . . . 136
Brake Parking, Electric . . . . . . . . . . . . . . . . . . 235
System Warning Light . . . . . . . . . . . . 145
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 322
Antilock . . . . . . . . . . . . . . . . . . . . . . . . . . . 234 Brakes (cont'd)
Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323
Regenerative Braking . . . . . . . . . . . . . 237
Braking . . . . . . . . . . . . . . . . . . . . . . . . .207, 208 Automatic Forward . . . . . . . . . . . . . . . 262
Braking System Front Pedestrian (FPB) . . . . . . . . . . . 264
Break-In, New Vehicle . . . . . . . . . . . . . . 216
Bulb Replacement . . . . . . . . . . . . . . . . . . 330
Headlamp Aiming . . . . . . . . . . . . . . . . 329
Headlamps . . . . . . . . . . . . . . . . . . . . . . . . 330
License Plate Lamps . . . . . . . . . . . . . . 330
Buying New Tires . . . . . . . . . . . . . . . . . . . 355C
Cadillac Premium Care
Maintenance . . . . . . . . . . . . . . . . . . . . . . 390
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . 122
California
Fuel Requirements . . . . . . . . . . . . . . . . 287
Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . . . . . 297
California Proposition
65 Warning . . . . . . . . . . . . .297, 324, 374, Back Cover
Canadian Vehicle Owners . . . . . . . . . . . . . 2
Capacities and Specifications . . . . . . 404 Carbon Monoxide
Engine Exhaust . . . . . . . . . . . . . . . . . . . 230
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Winter Driving . . . . . . . . . . . . . . . . . . . . 211
Cargo Tie-Downs . . . . . . . . . . . . . . . . . . . . . . . . . 117
Caution, Danger, and Warning . . . . . . . . 2
Center Console Storage . . . . . . . . . . . . . 116
Chains, Tire . . . . . . . . . . . . . . . . . . . . . . . . . 360
Charge Cord . . . . . . . . . . . . . . . . . . . . . . . . . 279
Charging
Delay Override . . . . . . . . . . . . . . . . . . . . 275
Electrical Requirements . . . . . . . . . . 285
Plug-In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274
Programmable . . . . . . . . . . . . . . . . . . . . 152
Utility Interruption . . . . . . . . . . . . . . . 284
Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Charging Status Screens . . . . . . . . . . . . 275
Charging System Light . . . . . . . . . . . . . 142
Check Engine Light (Malfunction
Indicator) . . . . . . . . . . . . . . . . . . . . . . . . 143
Child Restraints Infants and Young Children . . . . . . . . 98
Lower Anchors and Tethersfor Children . . . . . . . . . . . . . . . . . . . . . . 103
Older Children . . . . . . . . . . . . . . . . . . . . . . 96
Securing . . . . . . . . . . . . . . . . . . . . . . 109, 111

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
434 INDEX
Child Restraints (cont'd)Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Cigarette Lighter . . . . . . . . . . . . . . . . . . . . 125
Circuit Breakers . . . . . . . . . . . . . . . . . . . . . 331
Cleaning Exterior Care . . . . . . . . . . . . . . . . . . . . . . 380
Interior Care . . . . . . . . . . . . . . . . . . . . . . 384
Climate Control Systems Automatic . . . . . . . . . . . . . . . . . . . . 191, 197
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Cluster, Instrument . . . . . . . . . . . .127, 130
Collision Damage Repair . . . . . . . . . . . 414
Compact Spare Tire . . . . . . . . . . . . . . . . . 373
Compartments Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Compass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Compressor Kit, Tire Sealant . . . . . . . 362
Connections OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 423
Control Traction and ElectronicStability . . . . . . . . . . . . . . . . . . . . . . . . . . 239
Control of a Vehicle . . . . . . . . . . . . . . . . 207
Convenience Net . . . . . . . . . . . . . . . . . . . . 117
Convex Mirrors . . . . . . . . . . . . . . . . . . . . . . 54 Coolant
Engine Temperature Gauge . . . . . . 139
Engine Temperature Warning
Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Cooling . . . . . . . . . . . . . . . . . . . . . . . . .191, 197
Cooling System . . . . . . . . . . . . . . . .312, 316
Courtesy Lamps . . . . . . . . . . . . . . . . . . . . . 187
Courtesy Transportation Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . 413
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . 242 Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Cruise Control, Adaptive . . . . . . . . . . . 245
Customer Assistance . . . . . . . . . . . . . . . 410 Offices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 410
Text Telephone (TTY) Users . . . . . 410
Customer Information
Service Publications OrderingInformation . . . . . . . . . . . . . . . . . . . . . . 416
Customer Satisfaction Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . 408
D
Damage Repair, Collision . . . . . . . . . . . 414
Danger, Warning, and Caution . . . . . . . . 2
Data CollectionInfotainment System . . . . . . . . . . . . . 420
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 420 Data Recorders, Event . . . . . . . . . . . . . . 419
Daytime Running Lamps (DRL) . . . 185
Defensive Driving . . . . . . . . . . . . . . . . . . . 207
Delayed Charging Override . . . . . . . . . 275
Delayed Locking . . . . . . . . . . . . . . . . . . . . . 45
Diagnostics
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 425
Distracted Driving . . . . . . . . . . . . . . . . . . 206
Dome Lamps . . . . . . . . . . . . . . . . . . . . . . . . 187
Door Ajar Light . . . . . . . . . . . . . . . . . . . . . . . . . 152
Delayed Locking . . . . . . . . . . . . . . . . . . . . 45
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Power Locks . . . . . . . . . . . . . . . . . . . . . . . . . 45
Rear Seat Pass-Through . . . . . . . . . . . . 77
Drive Belt Routing, Engine . . . . . . . . . 406
Drive Systems
All-Wheel Drive . . . . . . . . . . . . . . 234, 326
Driver Assistance Systems . . . . . . . . . 253
Driver Information Center (DIC) . . . . . . . . . . . . . . . . . . . . . . . 162
Driver Mode Control . . . . . . . . . . . . . . . . 241
Driver Selected Operating Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226
Driving
Assistance Systems . . . . . . . . . . . . . . . 260
Characteristics andTowing Tips . . . . . . . . . . . . . . . . . . . . . 290

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
INDEX 435
Driving (cont'd)Defensive . . . . . . . . . . . . . . . . . . . . . . . . . . 207
Drunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207
For Better Fuel Economy . . . . . . . . . . . 32
Hill and Mountain Roads . . . . . . . . 211
If the Vehicle is Stuck . . . . . . . . . . . . 212
Loss of Control . . . . . . . . . . . . . . . . . . . . 209
Off-Road Recovery . . . . . . . . . . . . . . . . 209
Vehicle Load Limits . . . . . . . . . . . . . . 213
Wet Roads . . . . . . . . . . . . . . . . . . . . . . . . . 210
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211
Winter Mode Light . . . . . . . . . . . . . . . 146
Driving for Better Energy Efficiency . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
E
Electric Parking Brake . . . . . . . . . . . . . . 235
Electric Parking Brake Light . . . . . . . 145
Electrical Equipment, Add-On . . . . . 295
Electrical Requirements for
Battery Charging . . . . . . . . . . . . . . . . . . 285
Electrical System Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 332
Fuses and Circuit Breakers . . . . . . . 331
Instrument Panel Fuse Block . . . . 335
Overload . . . . . . . . . . . . . . . . . . . . . . . . . . . 331
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 337 Emergency
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 422
Energy Efficiency Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Energy Information . . . . . . . . . . . . . . . . . 161
Engine Air Cleaner/Filter . . . . . . . . . . . . . . . . . 311
Check Light (Malfunction
Indicator) . . . . . . . . . . . . . . . . . . . . . . . . 143
Compartment Overview . . . . . . . . . . 300
Coolant Temperature Gauge . . . . . 139
Coolant Temperature Warning Light . . . . . . . . . . . . . . . . . . . 149
Cooling System . . . . . . . . . . . . . . 312, 316
Drive Belt Routing . . . . . . . . . . . . . . . . 406
Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230
Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223
Oil Life System . . . . . . . . . . . . . . . . . . . . 309
Oil Pressure Gauge . . . . . . . . . . . . . . . . 137
Oil Pressure Light . . . . . . . . . . . . . . . . . 149
Overheating . . . . . . . . . . . . . . . . . . . . . . . 321
Power Messages . . . . . . . . . . . . . . . . . . 169
Running While Parked . . . . . . . . . . . 230
Starting . . . . . . . . . . . . . . . . . . . . . . . 218, 221
Engine Oil
Temperature Gauge . . . . . . . . . . . . . . . 138
Engine Unavailable Out of Fuel . . . . . . . . . . . . . . . . . . . . . . . . 227 Entry Lighting . . . . . . . . . . . . . . . . . . . . . . 188
Equipment, Towing . . . . . . . . . . . . . . . . . 294
Event Data Recorders . . . . . . . . . . . . . . 419
Exit Lighting . . . . . . . . . . . . . . . . . . . . . . . . 189
Extended Parking . . . . . . . . . . . . . . . . . . . 226
Extender, Seat Belt . . . . . . . . . . . . . . . . . . 83
Exterior Lamp Controls . . . . . . . . . . . . 183
Exterior Lamps Off Reminder . . . . . . 185
Exterior Lighting Battery Saver . . . . 189
F
Features
Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Filter, Engine Air Cleaner . . . . . . . . . . . . . . . . 311
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . . . 185
Flashers, Hazard Warning . . . . . . . . . . 186
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 360 Changing . . . . . . . . . . . . . . . . . . . . . . . . . . 368
Floor Mats . . . . . . . . . . . . . . . . . . . . . . . . . . . 387
Fluid Automatic Transmission . . . . . . . . . 310
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323
Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 322
Folding Mirrors . . . . . . . . . . . . . . . . . . . . . . 55
Forward Automatic Braking . . . . . . . . 262
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260
