When to Add Engine Oil
If the oil level is within the add cross-hatched area at
the tip of the dipstick, add at least one quart/liter of
the recommended oil. This section explains what kind
of oil to use. For engine oil crankcase capacity, see
Capacities and Specifications on page 5-129.Notice:Do not add too much oil. If the engine
has so much oil that the oil level gets above
the proper operating range and into the upper
cross-hatched area on the dipstick, the engine
could be damaged.
SeeEngine Compartment
Overview on page 5-14
for the location of the
engine oil ll cap.
Add enough oil to put the level somewhere in the proper
operating range. Push the dipstick all the way back in
when you are through.
5-17

What Kind of Engine Oil to Use
Look for three things:
GM4718M
Your vehicle’s engine requires a special oil
meeting GM Standard GM4718M. Oils meeting this
standard may be identied as synthetic. However,
not all synthetic oils will meet this GM standard.
Use only an oil that meets GM Standard GM4718M.Notice:If you use oils that do not have the
GM4718M Standard designation, you can cause
engine damage not covered by your warranty.
SAE 5W-30
SAE 5W-30 is best for the vehicle. These numbers
on an oil container show its viscosity, or thickness.
Do not use other viscosity oils such as SAE 20W-50.
American Petroleum Institute (API) starburst symbol
Oils meeting these
requirements should have
the starburst symbol on the
container. This symbol
indicates that the oil has
been certied by the
American Petroleum
Institute (API).
Your vehicle’s engine is lled at the factory with a
Mobil 1
®synthetic oil, which meets all requirements for
your vehicle.
Substitute Engine Oil: When adding oil to maintain
engine oil level, oil meeting GM Standard GM4718M
may not be available. You can add substitute oil
designated SAE 5W-30 with the starburst symbol at all
temperatures. Substitute oil not meeting GM Standard
GM4718M should not be used for an oil change.
5-18

Engine Oil Additives
Do not add anything to the oil. The recommended oils
with the starburst symbol that meet GM standards are all
you need for good performance and engine protection.
Engine Oil Life System
When to Change Engine Oil
Your vehicle has a computer system that lets you know
when to change the engine oil and lter. This is based
on engine revolutions and engine temperature, and not
on mileage. Based on driving conditions, the mileage
at which an oil change will be indicated can vary
considerably. For the oil life system to work properly,
you must reset the system every time the oil is changed.When the system has calculated that oil life has been
diminished, it will indicate that an oil change is necessary.
A Change Engine Oil Soon message will come on. See
DIC Warnings and Messages on page 3-56. Change
the oil as soon as possible within the next 600 miles
(1 000 km). It is possible that, if you are driving under the
best conditions, the oil life system might not indicate that
an oil change is necessary for over a year. However, the
engine oil and lter must be changed at least once a year
and at this time the system must be reset. Your dealer/
retailer has trained service people who will perform this
work using genuine parts and reset the system. It is also
important to check the oil regularly and keep it at the
proper level.
If the system is ever reset accidentally, you must
change the oil at 3,000 miles (5 000 km) since your
last oil change. Remember to reset the oil life system
whenever the oil is changed.
5-19

How to Reset the Engine Oil Life
System
The Engine Oil Life System calculates when to change
the engine oil and lter based on vehicle use. Whenever
the oil is changed, reset the system so it can calculate
when the next oil change is required. If a situation occurs
where you change the oil prior to a Change Engine Oil
Soon message being turned on, reset the system.
Always reset the engine oil life to 100% after every
oil change. It will not reset itself. To reset the Engine
Oil Life System:
1. Display the OIL LIFE REMAINING on the DIC.
2. Press and hold the SET/RESET button on the DIC
for more than ve seconds. The oil life will change
to 100%.
If the Change Engine Oil Soon message comes back
on when you start your vehicle, the Engine Oil Life
System has not reset. Repeat the procedure.
What to Do with Used Oil
Used engine oil contains certain elements that can be
unhealthy for your skin and could even cause cancer.
Do not let used oil stay on your skin for very long.
Clean your skin and nails with soap and water, or
a good hand cleaner. Wash or properly dispose of
clothing or rags containing used engine oil. See
the manufacturer’s warnings about the use and
disposal of oil products.
Used oil can be a threat to the environment. If you
change your own oil, be sure to drain all the oil from the
lter before disposal. Never dispose of oil by putting it
in the trash, pouring it on the ground, into sewers, or into
streams or bodies of water. Recycle it by taking it to a
place that collects used oil.
5-20

Engine Cover
Installing Engine Cover
1. Raise front edge of cover (B) while inserting rear
tabs (C).
2. Lower front edge of cover and slide cover rearward
so that rear tabs slide under retainers.3. Align cover over the oil ll tube.
4. Press cover down rmly on ball stud at the right
front corner.
5. Install oil ll cap (A).
6. Install the cross car brace.
Engine Air Cleaner/Filter
The engine air cleaner/lter is in the engine
compartment on the driver’s side of the vehicle,
near the front. SeeEngine Compartment Overview
on page 5-14for more information on location.
When to Inspect the Engine Air
Cleaner/Filter
Inspect the air cleaner/lter at the MaintenanceII
intervals and replace it at the rst oil change after each
50,000 mile (80 000 km) interval. SeeScheduled
Maintenance on page 6-4for more information. If you are
driving in dusty/dirty conditions, inspect the lter at each
engine oil change.
5-21

How to Inspect the Engine Air
Cleaner/Filter
To inspect the air cleaner/lter, remove the lter from
the vehicle and lightly shake the lter to release loose
dust and dirt. If the lter remains caked with dirt, a new
lter is required.
To inspect or replace the engine air cleaner/lter, do the
following:
1. Turn the ignition off.
2. Remove side cover by pulling up on front of cover.3. Disconnect electrical connector from air box.
4. Loosen the screw on the clamp holding the air outlet
duct in place. Do not pry the clamp off. Position the
duct aside.
5. Remove the rubber hose from the air cleaner
housing mounting arm. Position the rubber hose
aside.
5-22

8. Remove the air cleaner element from the air
cleaner housing.
How to Reinstall Engine Air
Cleaner/Filter
1. Install the air cleaner element to the air cleaner
housing. Ensure that the air cleaner element
perimeter seal is installed correctly to the air
cleaner housing.
2. Align the air cleaner housing cover tabs to the air
cleaner housing.
3. Install the air cleaner housing cover.
4. Install the air cleaner housing cover screws.
5. Install the surge tank hose to the air cleaner housing
mounting arm. Ensure that the hose is routed
correctly.
6. Install the air cleaner outlet duct to the air cleaner
housing.
7. Tighten the air cleaner outlet duct screw clamp.
8. Attach electrical connector to airbox.
9. Reinstall side cover.
5-24

{CAUTION:
Operating the engine with the air cleaner/lter
off can cause you or others to be burned. The air
cleaner not only cleans the air; it helps to stop
ames if the engine backres. If it is not there
and the engine backres, you could be burned.
Do not drive with it off, and be careful working
on the engine with the air cleaner/lter off.
Notice:If the air cleaner/lter is off, a backre
can cause a damaging engine re. And, dirt can
easily get into your engine, which will damage it.
Always have the air cleaner/lter in place when
you are driving.
Automatic Transmission Fluid
How to Check Automatic Transmission
Fluid
It is not necessary to check the transmission uid level.
A transmission uid leak is the only reason for uid loss.
If a leak occurs, take the vehicle to the dealer/retailer
service department and have it repaired as soon as
possible.
There is a special procedure for checking and changing
the transmission uid. Because this procedure is difficult,
you should have this done at the dealer/retailer service
department. Contact your dealer/retailer for additional
information or the procedure can be found in the service
manual. To purchase a service manual, seeService
Publications Ordering Information on page 7-17.
Notice:Use of the incorrect automatic transmission
uid may damage your vehicle, and the damages
may not be covered by your warranty. Always
use the automatic transmission uid listed in
Recommended Fluids and Lubricants on page 6-14.
Change the uid and lter at the intervals listed in
Additional Required Services on page 6-6, and be
sure to use the uid listed inRecommended Fluids
and Lubricants on page 6-14.
5-25

Manual Transmission Fluid
When to Check Manual Transmission
Fluid
It is not necessary to check the manual transmission
uid level. A transmission uid leak is the only reason
for uid loss. If a leak occurs, take the vehicle to
your dealer/retailer service department and have it
repaired as soon as possible.
How to Check Manual Transmission
Fluid
Because this operation can be difficult, you may choose
to have this done at your dealer/retailer service
department.
If you do it yourself, be sure to follow all the instructions
here, or you could get a false reading.Notice:Too much or too little uid can damage
your transmission. Too much can mean that some
of the uid could come out and fall on hot engine
parts or exhaust system parts, starting a re.
Too little uid could cause the transmission to
overheat. Be sure to get an accurate reading if
you check your transmission uid.
Check the uid level only when your engine is off, the
vehicle is parked on a level place and the transmission
is cool enough for you to rest your ngers on the
transmission case.
To check the uid level, do the following:
1. Remove the ller plug.
2. Check that the lubricant level is up to the bottom of
the ller plug hole.
3. If the uid level is good, replace the gasket and
reinstall the ller plug.
With either vehicle, be sure the plug is fully seated.
If the uid level is low, add more uid as described
in the next steps.
5-26

How to Add Manual Transmission Fluid
Here is how to add uid. SeeRecommended Fluids
and Lubricants on page 6-14to determine which type of
uid to use.
1. Remove the ller plug.
2. Add uid at the ller plug hole. Add only enough
uid to bring the uid level up to the bottom of the
ller plug hole.
3. Replace the gasket and reinstall the ller plug.
Be sure the plug is fully seated.
Hydraulic Clutch
It is not necessary to regularly check clutch uid unless
you suspect there is a leak in the system. Adding
uid will not correct a leak. A uid loss in this system
could indicate a problem. Have the system inspected
and repaired.
When to Check and What to Use
The hydraulic clutch uid
reservoir cap has this
symbol on it. SeeEngine
Compartment Overview
on page 5-14for reservoir
location.
Refer to the Maintenance Schedule for the proper uid
to use. SeeRecommended Fluids and Lubricants on
page 6-14. The uid requires changing every two years.
SeeAdditional Required Services on page 6-6.
5-27
