Page 135 of 490

Manually fold the mirrors inward to prevent damage when
going through an automatic car wash. To fold, push the
mirror toward the vehicle. Push the mirror outward, to
return to its original position.
Park Tilt Mirrors
If the vehicle has the memory package, the passenger
and/or driver’s outside mirror tilts to a preselected
position when the vehicle is in R (Reverse). This allows
the driver to view the curb when parallel parking.
When the vehicle is shifted out of R (Reverse) and after
a ve-second delay, the mirrors return to their original
position.
The park tilt can be turned on or off through the
Driver Information Center (DIC). SeeDIC Vehicle
Customization on page 3-72for more information.
Outside Convex Mirror
{CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you could
hit a vehicle on the right. Check the inside mirror or
glance over your shoulder before changing lanes.
The passenger side mirror is convex shaped. A convex
mirror’s surface is curved so more can be seen from
the driver’s seat.
Outside Heated Mirrors
=(Rear Window Defogger):Press to heat the mirrors.
See “Rear Window Defogger” underDual Climate Control
System on page 3-24for more information.
2-53
Page 138 of 490

When the System Does Not Seem to
Work Properly
If the URPA system will not activate due to a temporary
condition, the message PARK ASSIST OFF will be
displayed on the DIC and a red light will be shown on
the rear URPA display when the shift lever is moved into
R (Reverse). This occurs under the following conditions:
The driver disables the system.
The ultrasonic sensors are not clean. Keep the
vehicle’s rear bumper free of mud, dirt, snow,
ice and slush. For cleaning instructions, see
Washing Your Vehicle on page 5-110.
A trailer was attached to the vehicle, or a bicycle or
an object was hanging out of the trunk during the
last drive cycle, the red light may illuminate in
the rear display. Once the attached object is
removed, URPA will return to normal operation.
A tow bar is attached to the vehicle.
The vehicle’s bumper is damaged. Take the vehicle
to your dealer/retailer to repair the system.
Other conditions may affect system performance,
such as vibrations from a jackhammer or the
compression of air brakes on a very large truck.
If the system is still disabled after driving forward at least
15 mph (25 km/h), take the vehicle to your dealer/retailer.
OnStar®System
OnStar uses several innovative technologies and live
advisors to provide a wide range of safety, security,
information, and convenience services. If the airbags
deploy, the system is designed to make an automatic
call to OnStar Emergency advisors who can request
emergency services be sent to your location. If the keys
are locked in the vehicle, call OnStar at 1-888-4-ONSTAR
to have a signal sent to unlock the doors. OnStar
Hands-Free Calling, including 30 trial minutes good
for 60 days, is available on most vehicles. OnStar
Turn-by-Turn Navigation service, with one trial route, is
available on most vehicles. Press the OnStar button to
have an OnStar advisor contact Roadside Service.
OnStar service is provided subject to the OnStar Terms
and Conditions included in the OnStar Subscriber glove
box literature.
2-56
Page 155 of 490

Power Tilt Wheel and Telescopic
Steering Column
For vehicles with this feature, the power tilt wheel
control is located on the left side of the steering column.
To operate the power tilt feature, push the control up
or down to tilt the steering wheel up or down.
Push the control forward or rearward to move the
steering wheel toward the front or rear of the vehicle.
Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes the following:
G: Turn and Lane-Change Signals
P: Exterior Lamp Control
3: Headlamp High/Low-Beam Changer
#: Fog Lamps
Flash-To-Pass Feature.
Information for these features is on the pages following.
3-7
Page 157 of 490

Flash-to-Pass
This feature allows the high-beam headlamps to be
used to signal the driver in front of you that you want
to pass.
Pull and hold the turn signal/multifunction lever toward
you to use this feature. When this is done the following
will occur:
If the headlamps are off, in low-beam or in Daytime
Running Lamps (DRL) mode, the high-beam
headlamps will turn on. They will stay on as long as
the lever is held there. Release the lever to turn
them off.
For vehicles with High Intensity Discharge (HID)
headlamps, the low-beam headlamps must be
on to activate the high-beam headlamps. SeeHigh
Intensity Discharge (HID) Lighting on page 5-57.
If the headlamps are already in high-beam mode,
they will remain on high-beam.
Windshield Wipers
The lever on the right side of the steering column
operates the windshield wipers.
Move the lever to one of the following positions:
7(Mist):Pull the lever down and release it for a
single wiping cycle. The lever will return to its original
position. Hold the lever in this position for continuous
wiping cycles.
&(Delay):For a delayed wiping cycle. Turn the delay
adjustment band to set the length of the delay.
6(Delay Adjustment):Use this band to set the length
of the delay between wipes when using the delay
feature. The closer the band is moved towards
7,
the longer the delay. The windshield wiper lever must be
in delay for this feature to work.
3-9
Page 165 of 490

Headlamps
The exterior lamp control is located towards the end of
the turn signal/multifunction lever.
O(Exterior Lamp Control):Turn the band with this
symbol on it to operate the exterior lamps.
The exterior lamp control has four positions:
O(Off):Turns off all lamps, except the Daytime
Running Lamps (DRL).
AUTO (Automatic):Turns the headlamps on and off
automatically, depending upon how much light is
available outside of the vehicle.
;(Parking Lamps):Turns on the parking lamps
together with the following:
Sidemarker Lamps
Taillamps
License Plate Lamps
Instrument Panel Lights
5(Headlamps):Turns on the headlamps, together
with the previously listed lamps and lights.
Wiper Activated Headlamps
This feature activates the headlamps and parking
lamps after the windshield wipers have been in use
for about six seconds. For this feature to work,
the exterior lamp control must be in AUTO.
The wiper-activated headlamps immediately turn off,
when the ignition is turned to LOCK/OFF or the
windshield wiper control is turned off.
Headlamps on Reminder
A warning chime will sound if the exterior lamp control
is left on in either the headlamp or parking lamp position
and the driver’s door is opened with the ignition off.
SeeLights On Reminder on page 3-48for additional
information.
3-17
