CD player CADILLAC CTS V 2007 1.G Owners Manual

Anti-Lock Brake System Warning Light...... 206
Traction Control System (TCS)
Warning Light........................................ 206
Engine Coolant Temperature Warning
Light (CTS)............................................ 207
Engine Coolant Temperature Gage............ 208
Tire Pressure Light (CTS-V Only).............. 208
Malfunction Indicator Lamp........................ 209
Oil Pressure Light..................................... 212
Sport Mode Light (Automatic
Transmission/CTS)................................. 213
Security Light............................................ 213
Fog Lamp Light......................................... 213
Lights On Reminder.................................. 213
Cruise Control Light.................................. 214
Highbeam On Light................................... 214
Fuel Gage................................................. 214
Message Center.......................................... 215
Message Center (CTS-V).......................... 215
Transmission Fluid Hot Message............... 219
Hot Coolant Temperature Warning
Message................................................ 219
Check Engine Oil Pressure Message......... 220Oil Temperature Warning Message............ 220
Tire Pressure Warning Message................ 221
One-to-Four Shift Message
(CTS-V Only)......................................... 222
Driver Information Center (DIC).................. 222
System Controls........................................ 223
Status of Vehicle Systems......................... 223
DIC Main Menu......................................... 228
DIC Warnings and Messages.................... 232
DIC Vehicle Personalization....................... 242
Audio System(s)......................................... 258
Setting the Time........................................ 259
Radio with CD........................................... 260
XM Radio Messages................................. 277
Navigation/Radio System........................... 279
Theft-Deterrent Feature............................. 279
Audio Steering Wheel Controls (CTS)........ 279
Audio Steering Wheel Controls (CTS-V).... 280
Radio Reception........................................ 282
Care of Your CDs..................................... 283
Care of the CD Player.............................. 283
Diversity Antenna System.......................... 284
XM™ Satellite Radio Antenna System....... 284
Section 3 Instrument Panel
164

Notice:Before adding any sound equipment to
your vehicle, such as an audio system, CD
player, CB radio, mobile telephone, or two-way
radio, make sure that it can be added by
checking with your dealer/retailer. Also, check
federal rules covering mobile radio and
telephone units. If sound equipment can be
added, it is very important to do it properly.
Added sound equipment can interfere with the
operation of your vehicle’s engine, radio, or
other systems, and even damage them. Your
vehicle’s systems can interfere with the
operation of sound equipment that has
been added.
Your vehicle has a feature called Retained
Accessory Power (RAP). With RAP, the audio
system can be played even after the ignition
is turned off. SeeRetained Accessory Power
(RAP) on page 119for more information.Setting the Time
1. Press the TUNE/SEL (select) knob to enter
the main menu.
2. Turn the TUNE/SEL knob until SET CLOCK
appears on the display.
3. Press the TUNE/SEL knob to select
SET CLOCK.
4. Turn the TUNE/SEL knob to adjust the time.
5. Press the TUNE/SEL knob to update the
time. VEHICLE TIME UPDATED will appear
on the display.
If the CLOCK/RADIO DISP (display) is congured
into one of the congurable keys, pressing the key
will switch the display between the radio station
frequency and the time. See “Congurable Radio
Display Keys” underRadio with CD on page 260for
more information on conguring the keys.
259

Using Digital Signal Processing (DSP)
Available only with the premium Bose®audio
system, this feature is used to provide a choice of
ve different listening experiences: DSP normal,
talk, spacious, rear seat, and driver seat. DSP can
be used while listening to the radio or the CD
player. The radio keeps separate DSP settings for
each band, preset, and source. To select a
DSP choice, perform the following steps:
1. Press the TUNE/SEL knob to enter the
main menu.
2. Turn the TUNE/SEL knob until one of the
ve settings appears on the display.
3. Press the TUNE/SEL knob to select a
DSP setting.
4. Press the CLR button to exit the display. To
return to the original display, repeatedly press
the CLR button or wait for the display to
time out.DSP NORMAL:This setting provides the best
overall audio performance for all passengers.
DSP NORMAL does not appear on the display
when in this mode.
TALK:This setting should be used when listening
to non-musical material such as news, talk
shows, sports broadcasts, and books on tape.
Talk makes spoken words sound very clear.
SPACIOUS:This setting is used to make the
listening space seem larger.
REAR SEAT:This setting adjusts the audio to
give the rear seat passenger(s) the best possible
sound quality. Sound quality for the front seat
passengers may be different when this setting
is used.
DRIVER SEAT:This setting adjusts the audio to
give the driver the best possible sound quality.
Sound quality for the front and rear seat
passenger(s) may be different when this setting
is used.
267

Not all stations support CAT. The radio may not
go to all of the stations with that music type when
pressing the rm key.
AF (Alternate Frequency):Alternate frequency
allows the radio to switch to a stronger station with
the same category.
To turn AF on or off, perform the following steps:
1. Press the TUNE/SEL knob to enter the
main menu.
2. Turn the TUNE/SEL knob until ALTERNATE
FREQ. appears on the display.
3. Press the TUNE/SEL knob to select AF OFF,
AF ON, or AF REG. An X appears in the box
when AF is selected on.
4. Press the CLR button to exit the display. To
return to the original display, repeatedly press
the CLR button or wait for the display to
time out.
This function does not apply for XM™ Satellite
Radio Service.Radio Message
THEFTLOCK:This message is displayed when
the THEFTLOCK®system has been activated.
Take the vehicle to the dealer for service.
Radio Messages for XM™ Only
SeeXM Radio Messages on page 277later in this
section for further detail.
Using the Single CD Player
Insert a CD partway into the slot, label side up.
The player pulls it in. If the ignition and the
radio are on the CD begins playing. A CD may be
loaded with the radio off but it does not start
playing until the radio is on.
If the ignition or radio is turned off with a CD in
the player, it stays in the player. When the ignition
or radio is turned on, the CD starts to play
where it stopped, if it was the last selected
audio source.
When the CD is inserted, CD appears on the
display. As each new track starts to play, the track
number appears on the display.
270

The CD player can play the smaller 3 inch (8 cm)
single CDs with an adapter ring. Full-size CDs
and the smaller CDs are loaded in the same
manner.
If playing a CD-R, the sound quality may be
reduced due to CD-R quality, the method of
recording, the quality of the music that has been
recorded, and the way the CD-R has been
handled. There may be an increase in skipping,
difficulty in nding tracks, and/or difficulty in loading
and ejecting. If these problems occur, check the
bottom surface of the CD. If the surface of the CD
is damaged, such as cracked, broken, or
scratched, the CD will not play properly. If the
surface of the CD is soiled, seeCare of Your CDs
on page 283for more information.
If there is no apparent damage, try a known
good CD.
Do not add any label to a CD, it could get caught
in the CD player. If a CD is recorded on a
personal computer and a description label is
needed, try labeling the top of the recorded CD
with a marking pen.Notice:If a label is added to a CD, or more
than one CD is inserted into the slot at a time,
or an attempt is made to play scratched or
damaged CDs, the CD player could be
damaged. While using the CD player, use only
CDs in good condition without any label,
load one CD at a time, and keep the CD player
and the loading slot free of foreign materials,
liquids, and debris.
If an error appears on the display, see
“CD Messages” later in this section.
When a CD is inserted the CD functions appear
on the display above the rm keys, in place of the
preset stations (if programmed).
F1 PREV (Previous):Press this rm key to go to
the previous track. Press and hold this rm key
to reverse quickly within a track. Release the rm
key to play the passage. The elapsed time of
the track appears on the display.
F2 NEXT:Press this rm key to go to the next
track. Press and hold this rm key to advance
quickly within a track. Release the rm key to play
the passage. The elapsed time of the track
appears on the display.
271

F3 RDM (Random):Press this rm key to listen
to the tracks in random, rather than sequential,
order. RANDOM appears on the display.
Press RDM again to turn off random play.
RANDOM disappears from the display.
F4 RPT (Repeat):Press this rm key to hear a
track over again. REPEAT appears on the display.
Press RPT again to turn off repeat play. REPEAT
disappears from the display.
F6 DISP (Display):Press this rm key to display
the time of the track. Press this rm key again
to remove the time of the track from the display.
QSEEKR:Press the up or the down arrow to go
to the next or to the previous track on the CD.
QSCANR:Press this button to listen to each
track for 10 seconds. The CD goes to a track,
plays for 10 seconds, then goes to the next track.
Press this button again to stop scanning.
X(Eject):Press this button to stop a CD when
it is playing or to eject a CD when it is not
playing. Eject may be activated with the ignition
and the radio off.
Using the Six-Disc CD Changer
The CD player can play the smaller 3 inch (8 cm)
single CDs with an adapter ring. Full-size CDs
and the smaller CDs are loaded in the same
manner.
If playing a CD-R, the sound quality may be
reduced due to CD-R quality, the method of
recording, the quality of the music that has been
recorded, and the way the CD-R has been
handled. There may be an increase in skipping,
difficulty in nding tracks, and/or difficulty in loading
and ejecting. If these problems occur, check the
bottom surface of the CD. If the surface of the CD
is damaged, such as cracked, broken, or
scratched, the CD will not play properly. If the
surface of the CD is soiled, seeCare of Your CDs
on page 283for more information.
If there is no apparent damage, try a known
good CD.
272

Do not add any label to a CD, it could get caught
in the CD player. If a CD is recorded on a
personal computer and a description label is
needed, try labeling the top of the recorded CD
with a marking pen.
Notice:If a label is added to a CD, or more
than one CD is inserted into the slot at a time,
or an attempt is made to play scratched or
damaged CDs, the CD player could be
damaged. While using the CD player, use only
CDs in good condition without any label,
load one CD at a time, and keep the CD player
and the loading slot free of foreign materials,
liquids, and debris.
If an error appears on the display, see “CD
Messages” later in this section.
When a CD is inserted the CD functions appear
on the display above the rm keys, in place of the
preset stations, if programmed.LOAD:Press the LOAD button to load CDs into
the CD player. This CD player holds up to six CDs.
To insert one CD, do the following:
1. The ignition and the radio can be on or off.
2. Press and release the LOAD button.
Please Wait appears on the display.
3. Load the CD, when INSERT appears on the
display, insert a CD partway into the slot,
label side up. The player pulls the CD in.
When a CD is inserted, CD appears on the
display, the number of the CD and the track
number appears on the display if the radio is on.
If the radio is on, the CD begins to play
automatically.
To insert multiple CDs, do the following:
1. The ignition and the radio can be on or off.
2. Press and hold the LOAD button for
two seconds. Please Wait appears on
the display and you will hear a beep.
273

3. Load the CD, when INSERT appears on the
display, insert a CD partway into the slot,
label side up. The player pulls the CD in.
Do not try to load two CDs at one time and
wait to load a CD until INSERT appears on the
display for each disc inserted. The CD
player takes up to six CDs. Do not try to load
more than six. If you want to load less
than six CDs, load the desired amount.
The CD player times out when it does not
receive any more CDs and the last CD loaded
begins to play.
If the radio is on, the last CD loaded begins to
play automatically.
F1 CD
n(Down):Press this rm key to go to the
previous CD.
F2 CD
m(Up):Press this rm key to go to the
next CD.
CD REV
{(Reverse):Press this rm key to go
to the previous track. Press and hold this rm
key to reverse quickly within the track. Release the
rm key to play the passage. The elapsed time
of the track appears on the display.CD FWD
|(Forward):Press this rm key to go
to the next track. Press and hold this rm key
to advance quickly within the track. Release the
rm key to play the passage. The elapsed time of
the track appears on the display.
F5 MODE:Press this rm key to select from
NORMAL, RPT TRCK (Repeat Track), RPT CD
(Repeat CD), RDM TRK (Random Track),
and RDM ALL (Random All CDs).
NORMAL:Sets the system for normal play of
the CD(s). NORMAL does not appear on the
display when in this mode.
RPT TRCK (Repeat Track):Repeats the
track over again. RPT TRCK appears on
the display. Press the MODE rm key again to
turn off repeat play. RPT TRCK disappears
from the display.
RPT CD (Repeat CD):Repeats the CD over
again. RPT DISC appears on the display.
Press the MODE rm key again to turn
off repeat play. RPT DISC disappears from
the display.
274

RDM TRK (Random Track):Plays the tracks
on the current CD in random, rather than
sequential, order. RDM TRK appears on the
display. Press the MODE rm key again to turn
off random play. RDM TRK disappears from
the display.
RDM ALL (Random All CDs):Plays all of the
CDs loaded in random, rather than sequential,
order. RDM ALL appears on the display.
Press the MODE rm key again to turn off
random play. RDM ALL disappears from
the display.
F6 DISP (Display):Press this rm key to display
the time of the track. Press this rm key again
to display CD PLAY and press this rm key once
more to clear the display.
QSEEKR:Press the up or the down arrow to go
to the next or to the previous track on the CD.
QSCANR:Press this button to listen to each
track for 10 seconds. The CD goes to a track,
plays for 10 seconds, then goes to the next track.
Press this button again to stop scanning.
X(Eject):Press this button to eject the CD that
is currently playing, or press and hold this button
to eject all of the CDs loaded. You will hear a
beep. Eject may be activated with the ignition or
radio off.
CD Messages
If the CD comes out, it could be for one of the
following reasons:
If it is very hot. When the temperature returns
to normal, the CD should play.
If you are driving on a very rough road.
When the road becomes smoother, the
CD should play.
The CD is dirty, scratched, wet, or
upside down.
The air is very humid. If so, wait about an
hour and try again.
There may have been a problem while
burning the CD.
The label may be caught in the CD player.
If the CD is not playing correctly, for any other
reason, try a known good CD.
275

SRCE (Source):Press this button to switch
between FM1, FM2, AM, or XM1 or XM2
(if equipped), radio, or CD.
g(OnStar®/Voice Recognition):If your vehicle
has the Radio with CD or Radio with Six-Disc
CD audio system, press this button to interact with
the OnStar system.
If your vehicle has the navigation system, press
this button to initiate voice recognition. See “Voice
Recognition” in the Navigation System manual
for more information. While in Voice Recognition,
say “OnStar” to interact with the OnStar
®
system. See theOnStar®System on page 142in
this manual for more information.
1-6 (Preset Stations):Press this button to play
stations that are programmed on the radio
preset pushbuttons. The radio will only seek preset
stations with a strong signal that are in the
selected band.
When a CD is playing, press this button to go to
the next track.
When a CD is playing in the six-disc CD changer,
press this button to go to the next available CD,
if multiple CDs are loaded.+
u— (Volume):Press this button to increase
or to decrease the volume.
+
tu— (Seek):Press either arrow to go to
the next or the previous radio station and stay
there. The radio will only seek stations with
a strong signal that are in the selected band.
When a CD is playing, press the minus sign to go
to the start of the current track, if more than
10 seconds have played. Press the plus sign to go
to the next track. If either the minus or the plus
button are pressed more than once, the player will
continue moving backward or forward through
the CD.
Press and hold the SEEK plus or minus button,
until you hear a beep. The CD will fast forward or
fast reverse through the CD. Press either button
again to play the passage.
If you have the navigation system, some of the
audio steering wheel controls work when a DVD is
playing in the navigation radio. See the Navigation
System manual for more information.
281
