CADILLAC DEVILLE 1993 7.G Owners Manual Downloaded from www.Manualslib.com manuals search engine EXECAUST SYSTEM
Type ............................... Single with Crossover Pipe
Exhaust Pipe
.................................. Stainless

Downloaded from www.Manualslib.com manuals search engine EXECAUST SYSTEM
Type ............................... Single with Crossover Pipe
Exhaust Pipe
.................................. Stainless Steel
Intermediate Pipe
............................. Stainless Steel
Tail Pipe
..................................... Stainless Steel
Muffler
.................................. One-Reverse Flow
Resonator ............................................ None
ELECTHCAL, SYSTEM
Voltage ................................................ 12
Generator
........................................ 140 AMP
Ground
........................................... Negative
AIR CONDITIONING SYSTEM
Refrigerant-12.(R-12) ......................... 2.87 lb.(1.30 kg)
Not all
air conditioning refrigerants are the same. If the air condi-
tioning system
in your vehicle needs refrigerant, be sure the proper
refrigerant is
used. If you’re not sure, ask your Cadillac dealer.
FLUID CAPACITIES
Automatic Transaxle (Overhaul) ................... 20 pts (9.5L)
With Filter Change .............................. 13 pts (6.2L)
Engine Oil
.................................. 5 quarts (4.7 L)
With Filter Change .......................... 5.5 quarts (5.2 L)
Engine Cooling System ...................... 12 quarts (1 1.4 L)
Fuel Tank ............................... 18.0 gallons (68.1 L)
Power Steering
.............................. 1.3 quarts (1.2 L)
Windshield Washer Reservoir .................. 3.7 quarts (3.5 L)
TIGHTEN TURQUE
Spark Plug ................................ 31N.m (23 lbs. ft.)
Oil Pan Drain Plug.
......................... 30N-m (22 lbs. ft.)
Wheel Lug Nut
........................... 140 N-m (100 lbs. ft.)
338

Page 352 of 406

CADILLAC DEVILLE 1993 7.G Owners Manual Downloaded from www.Manualslib.com manuals search engine VEJYICLE DIMENSIONS
Coupe
Shipping Weight ........................... -3424 lbs. (1553 kg)
Wheel Base
.............................. .11

Downloaded from www.Manualslib.com manuals search engine VEJYIC'LE DIMENSIONS
Coupe
Shipping Weight ........................... -3424 lbs. (1553 kg)
Wheel Base
.............................. .110.8 in. (2815 mm)
Length
.................................. .202.3 in. (5139 mm)
Height
..................................... 55 in. (1397 mm)
Width.. .................................. .72.5 in. (1842 mm)
Front Tread
............................... .60.3 in. (1532 mm)
Rear Tread
............................... .59.8 in. (1518mm).
Sedan
Shipping Weight (Touring Sedan) ............ .3556 lbs. (1613 kg)
Shipping Weight (DeVille)
.................. -3510 lbs. (1592 kg)
Wheel Base .............................. .113.8 in. (2890 mm)
Length
.................................. .205.3 in. (5214 mm)
Height
..................................... 55 in. (1397 mm)
Width..
.................................. .72.5 in. (1842 mm)
Front Tread
............................... .60.3 in. (1532 mm)
Rear Tread ............................... .59.8 in. (1518 mm)
339
