Page 10 of 385
ix
For example,
these symbols
are used on an
original battery:
CAUTION
POSSIBLE
INJURY
PROTECT
EYES BY
SHIELDING
CAUSTIC
BATTERY
ACID COULD
CAUSE
BURNS
AVOID
SPARKS OR
FLAMES
SPARK OR
FLAME
COULD
EXPLODE
BATTERY
These symbols
are important
for you and
your passengers
whenever your
vehicle is
driven:
DOOR LOCK
UNLOCK
FASTEN
SEAT
BELTS
POWER
WINDOW
AIR BAG
These symbols
have to do with
your lamps:
MASTER
LIGHTING
SWITCH
TURN
SIGNALS
PARKING
LAMPS
HAZARD
WARNING
FLASHER
DAYTIME
RUNNING
LAMPS
FOG LAMPS
These symbols
are on some of
your controls:
WINDSHIELD
WIPER
WINDSHIELD
WASHER
WINDSHIELD
DEFROSTER
REAR
WINDOW
DEFOGGER
VENTILATING
FAN
These symbols
are used on
warning and
indicator lights:
ENGINE
COOLANT
TEMP
BATTERY
CHARGING
SYSTEM
BRAKE
COOLANT
ENGINE OIL
PRESSURE
ANTI-LOCK
BRAKES
Here are some
other symbols
you may see:
FUSE
LIGHTER
HORN
SPEAKER
FUEL
Vehicle Symbols
These are some of the symbols you may find on your vehicle.
Page 117 of 385
2-48
The DRL system will make the high-beam headlamps
come on at reduced intensity when:
it is still daylight and the ignition is on,
the headlamp switch is off and
the transaxle is not in PARK (P).
When DRL are on, only your high
-beam headlamps
(at reduced intensity) will be on. No other exterior
lamps such as the parking lamps, taillamps, etc. will be
on when the DRL are being used. Your instrument panel
won't be lit up either.
When the Twilight Sentinel control is on and it's dark
enough outside, the high
-beam headlamps (at reduced
intensity) will turn off and automatic high
-beam
headlamp operation will occur. When the Twilight
Sentinel switch is on and it's bright enough outside, the
automatic lamps will go off, and the high
-beam
headlamps at reduced intensity will take over.If it's dark enough outside and the Twilight Sentinel
control is off, a HEADLAMPS SUGGESTED message
will display on the Driver Information Center (DIC).
This message informs the driver that turning on the
exterior lamps is recommended even though the DRL
are still illuminated (it's become dark enough outside to
require the headlamps and/or other exterior lamps).
Turning on the Twilight Sentinel, the headlamp switch
or the fog lamp switch will remove the HEADLAMPS
SUGGESTED message.
To idle your vehicle at night with the DRL off, turn
off the Twilight Sentinel and shift the transaxle into
PARK (P). Placing your vehicle in PARK (P) disables
the DRL. The DRL will stay off until you shift out
of PARK (P).
To drive your vehicle at night with the DRL off, turn
off the Twilight Sentinel and manually turn on the
parking lamps.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
Page 118 of 385
2-49
Fog Lamps (If Equipped)
Use the fog lamps for better
vision in foggy or misty
conditions. When you press
the fog lamp button, a fog
lamp symbol located in the
instrument panel will come
on to indicate that the fog
lamps and the parking
lamps are on.
Press the button again to turn them off.
If you turn on the high
-beam headlamps, the fog lamps
will turn off. They'll turn back on again when you
switch to low
-beam headlamps.
When the Twilight Sentinel is on and the fog lamp
switch is activated, the fog lamps will remain on as well
as the headlamps and parking lamps.
Cornering Lamps
The cornering lamps come on when the headlamps
or parking lamps are on and you signal a turn with
the multifunction lever. They provide more light
for cornering.
Twilight Sentinel
This control is next to
the headlamp knob. It
automatically switches the
lamps on and off by sensing
how dark it is outside.
To operate the Twilight Sentinel, leave the lamp knob
off and move the TWILIGHT control to any position
but OFF.
Page 119 of 385
2-50
If you move the control all the way to the right, the
lamps will remain on for approximately three minutes
after the ignition has been turned to OFF. If you move
the control so it is just on, the lamps will go off quickly
when you turn the ignition switch out of OFF. You can
adjust the delay time from only a few seconds to about
three minutes.
If it's dark enough outside and the Twilight Sentinel
control is off, a HEADLAMPS SUGGESTED message
will display on the Driver Information Center (DIC).
This message informs the driver that turning on the
exterior lamps is recommended (it's become dark
enough outside to require the headlamps and/or other
exterior lamps). Turning on the Twilight Sentinel, the
headlamp switch or the fog lamp switch will remove the
HEADLAMPS SUGGESTED message.Light Sensor
The light sensor for the DRL and the Twilight Sentinel
is located in the center of the front defogger grille. If
you cover the sensor, it will read ªdarkº and the lamps
will come on.
Page 122 of 385
2-53
Battery Load Management
The battery load management feature is designed to
monitor the vehicle electrical load and determine when
the battery is in a heavy discharge condition. During
times of high electrical loading, the engine may idle at a
higher RPM setting than normal to make sure the battery
charges. High electrical loads may occur when several
of the following are on: headlamps, high beams, fog
lamps, rear window defogger, high blower fan, heated
seats and engine cooling fans.
Inadvertent Power Battery Saver
This feature is designed to protect your vehicle's battery
against drainage from the interior lamps, trunk lamp, glove
box lamp, cigarette lighters or the garage door opener.
When the ignition is turned off, the power to these features
will automatically turn off after 10 minutes (three minutes
if a new car has 15 miles (24 km) or less). Power will be
restored for an additional 10 minutes if any door is
opened, the trunk is opened or the courtesy lamp switch
is turned on.
Mirrors
Electrochromic Day/Night Rearview Mirror
with Compass (If Equipped)
Your vehicle may have an electrochromic inside
rearview mirror with a compass.
By pressing the MIRROR side of the button located at
the bottom of the mirror, the mirror automatically
darkens to reduce the glare from headlamps behind you.
The mirror also includes an eight
-point compass display
in the upper right corner of the mirror face. When on,
the compass automatically calibrates as the vehicle
is driven.
Page 153 of 385
2-84
CAUTION:
Don't keep driving if the oil pressure is low. If
you do, your engine can become so hot that it
catches fire. You or others could be burned.
Check your oil as soon as possible and have your
vehicle serviced.
NOTICE:
Damage to your engine from neglected oil
problems can be costly and is not covered by
your warranty.
Security Light
For information regarding
this light, see ªTheft
Deterrent
-Systemº in
the Index.
Fog Lamp Light (If Equipped)
This light will come on
when the fog lamp button
is pressed. For more
information about the fog
lamps, see ªFog Lampsº in
the Index.
Page 174 of 385
2-105
In dry, clear weather, the system can see pedestrians,
animals and the direction of the road ahead. In light rain,
light snow or light fog the image may not be as clear
and you may not be able to see the direction of the road
ahead. In more severe weather conditions, the image
may be unclear and not usable.
CAUTION:
Don't use the Night Vision System to replace
your normal view of the road ahead. It can't tell
you how far away things are. It senses only
warmer or colder objects, not all objects. Driving
by staring at the image might cause you not to see
important objects in the road ahead. If you don't
see something in time, you could have a crash in
which you and others could be injured. Use the
Night Vision System only as a driving aid.
It is also important to keep your windshield, the HUD
(Head-Up Display for the Night Vision System) lens and
the camera lens clean. If you do not keep everything
clean, system performance may be affected. The HUD
system is located on the driver's side of the instrument
panel, next to the windshield and the camera is located
behind the center of the front grille.
Use only household glass cleaner and a soft cloth. Wipe
gently and dry thoroughly.
NOTICE:
Be careful not to scratch the HUD or camera
lenses when cleaning. Use only household glass
cleaner and a soft cloth. Wipe gently and dry
thoroughly. Also, do not spray glass cleaner
directly on the HUD lens located inside your
vehicle, because the cleaner could leak inside the
unit and cause damage.
The camera must also be aligned to work correctly. If
the camera needs adjustment, see your dealer. Do not
attempt to adjust the camera yourself.
Page 225 of 385
3-48 Care of Your Compact Discs
Handle discs carefully. Store them in their original cases
or other protective cases and away from direct sunlight
and dust. If the surface of a disc is soiled, dampen a
clean, soft cloth in a mild, neutral detergent solution and
clean it, wiping from the center to the edge.
Be sure never to touch the signal surface when handling
discs. Pick up discs by grasping the outer edges or the
edge of the hole and the outer edge.
Care of Your Compact Disc Player
The use of CD lens cleaner discs is not advised, due to
the risk of contaminating the lens of the CD optics with
lubricants internal to the CD mechanism.
Diversity Antenna System
Your AM-FM antennas are located in the front
windshield and rear window. Be sure that the inside
surfaces of the front windshield and rear window are
not scratched and that the lines on the glass are not
damaged. If the inside surfaces are damaged, they could
interfere with radio reception.
NOTICE:
Do not try to clear frost or other material from
the inside of the rear window with a razor blade
or anything else that is sharp. This may damage
the rear defogger grid and affect your radio's
ability to pick up stations clearly. The repairs
wouldn't be covered by your warranty.
If, when you turn on your rear window defogger, you
hear static on your radio station, it could mean that a
defogger grid line has been damaged. If this is true, the
grid line must be repaired.
If you choose to add an aftermarket cellular telephone to
your vehicle, and the antenna needs to be attached to the
glass, be sure that you do not damage the grid lines for
the AM
-FM antennas or place the cellular telephone
antenna over the grid lines.
Page 276 of 385
5-9
NOTICE:
Use the proper towing equipment to avoid
damage to the bumper, fascia or fog lamp areas
of the vehicle.
With current trends in automotive styles and design, it is
essential that the correct towing equipment is used to
tow a vehicle. Your vehicle can be towed with wheel lift
or car carrier equipment.
Consult your dealer or a professional towing service if
you need to have your vehicle towed. See ªRoadside
Assistanceº in the Index.
Engine Overheating
You will find an ENGINE COOLANT HOT, IDLE
ENGINE message or an ENGINE OVERHEATED,
STOP ENGINE message on the Driver Information
Center (DIC). You will also hear a chime. There is also
an engine temperature warning light and/or gage on the
instrument panel. See ªEngine Coolant Temperature
Warning Lightº or ªEngine Coolant Temperature Gageº
in the Index.
Overheated Engine Protection
Operating Mode
Should an overheated engine condition exist and the
message ENGINE OVERHEATED, STOP ENGINE is
displayed, an overheat protection mode which alternates
firing groups of cylinders helps prevent engine damage.
In this mode, you will notice a loss in power and engine
performance. This operating mode allows your vehicle
to be driven to a safe place in an emergency; you may
drive up to 50 miles (80 km). Towing a trailer in the
overheat protection mode should be avoided.
NOTICE:
After driving in the overheated engine protection
operating mode, to avoid engine damage, allow
the engine to cool before attempting any repair.
The engine oil will be severely degraded. Repair
the cause of coolant loss, change the oil and
reset the oil life indicator. See ªEngine Oilº in
the Index.
Page 364 of 385
6-65
Minifuses
Fuse Usage
1 Assembly Line Diagnostic Link
2 Accessory
3 Windshield Wipers
4 Not Used
5 Headlamp Low Beam LeftFuse Usage
6 Headlamp Low Beam Right
7 Instrument Panel
8 Powertrain Control Module Battery
9 Headlamp High Beam Right
10 Headlamp High Beam Left
11 Ignition 1
12 Fog
13 Transmission
14 Cruise Control
15 Coil Module
16 Injector Bank #2
17 Not Used
18 Not Used
19 Powertrain Control Module Ignition
20 Oxygen Sensor
21 Injector Bank #1
22 Cigar Lighter #2
23 Cigar Lighter #1
24 Daytime Running Lamps
25 Horn
26 Air Conditioner Clutch
