Here are the most important things to know about the
airbag system:
{CAUTION:
You can be severely injured or killed in a crash
if you are not wearing your safety belt — even
if you have airbags. Wearing your safety belt
during a crash helps reduce your chance of
hitting things inside the vehicle or being
ejected from it. Airbags are “supplemental
restraints” to the safety belts. All airbags are
designed to work with safety belts but do not
replace them.
Frontal airbags for the driver and right front
passenger are designed to deploy in moderate
to severe frontal and near frontal crashes.
They are not designed to inate in rollover,
rear crashes, or in many side crashes. And, for
some unrestrained occupants, frontal airbags
may provide less protection in frontal crashes
than more forceful airbags have provided in
the past.
CAUTION: (Continued)
CAUTION: (Continued)
Seat-mounted side impact airbags and
roof-mounted side impact airbags are designed
to inate in moderate to severe crashes where
something hits the side of your vehicle. They
are not designed to inate in frontal, in rollover
or in rear crashes. Everyone in your vehicle
should wear a safety belt properly — whether
or not there is an airbag for that person.
1-55

{CAUTION:
Both frontal and side impact airbags inate
with great force, faster than the blink of an
eye. If you are too close to an inating airbag,
as you would be if you were leaning forward, it
could seriously injure you. Safety belts help
keep you in position for airbag ination before
and during a crash. Always wear your safety
belt even with frontal airbags. The driver
should sit as far back as possible while still
maintaining control of the vehicle. Occupants
should not lean on or sleep against the door.
{CAUTION:
Anyone who is up against, or very close to,
any airbag when it inates can be seriously
injured or killed. Airbags plus lap-shoulder
belts offer the best protection for adults, but
not for young children and infants. Neither the
vehicle’s safety belt system nor its airbag
system is designed for them. Young children
and infants need the protection that a child
restraint system can provide. Always secure
children properly in your vehicle. To read how,
seeOlder Children on page 1-30orInfants and
Young Children on page 1-33.
1-56

There is an airbag
readiness light on the
instrument panel, which
shows the airbag symbol.
The system checks the airbag electrical system for
malfunctions. The light tells you if there is an electrical
problem. SeeAirbag Readiness Light on page 3-58
for more information.Where Are the Airbags?
The driver’s frontal airbag is in the middle of the
steering wheel.
1-57

The right front passenger’s frontal airbag is in the
instrument panel on the passenger’s side.The seat-mounted side impact airbag for the driver is in
the side of the driver’s seatback closest to the door.
1-58

The seat-mounted side impact airbag for the right front
passenger is in the side of the passenger’s seatback
closest to the door.If your vehicle has one, the roof-mounted side impact
airbag for the driver and the person seated directly
behind the driver is in the ceiling above the side
windows.
1-59

If your vehicle has one, the roof-mounted side impact
airbag for the right front passenger and the person
seated directly behind that passenger is in the ceiling
above the side windows.
{CAUTION:
If something is between an occupant and an
airbag, the airbag might not inate properly or
it might force the object into that person
causing severe injury or even death. The path
of an inating airbag must be kept clear. Do
not put anything between an occupant and an
airbag, and do not attach or put anything on
the steering wheel hub or on or near any other
airbag covering. If your vehicle has
roof-mounted side impact airbags, never
secure anything to the roof of your vehicle by
routing the rope or tie-down through any door
or window opening. If you do, the path of an
inating airbag will be blocked. Do not let seat
covers block the ination path of a side impact
airbag. The path of an inating airbag must be
kept clear.
1-60

When Should an Airbag Inate?
The driver’s and right front passenger’s frontal airbags
are designed to inate in moderate to severe frontal
or near-frontal crashes. But they are designed to inate
only if the impact exceeds a predetermined deployment
threshold. Deployment thresholds take into account
a variety of desired deployment and non-deployment
events and are used to predict how severe a crash
is likely to be in time for the airbags to inate and help
restrain the occupants. Whether your frontal airbags
will or should deploy is not based on how fast your
vehicle is traveling. It depends largely on what you hit,
the direction of the impact and how quickly your
vehicle slows down.
Your vehicle has a “dual stage” driver airbag, which
adjusts the restraint according to crash severity using
electronic frontal sensor(s) which help the sensing
system distinguish between a moderate frontal impact
and a more severe frontal impact. The “dual stage”
driver airbag inates to a level less than full deployment
for moderate frontal impacts and to a full deployment
for more severe frontal impacts.Your vehicle is also equipped with a “dual depth”
passenger airbag that adjusts the restraint according to
crash severity, seat location, and safety belt status
using electronic frontal sensor(s) and other special
sensors which enable the sensing system to monitor the
status of the front passenger safety belt and the position
of the front passenger seat. The passenger airbag
inates to a reduced depth when the passenger seat is in
a forward position. For more rearward front seating
positions, the passenger airbag may inate to an
increased depth (a full deployment), based on safety belt
status and the crash severity measured early in the
event. (Always wear your safety belt, even with frontal
airbags.)
If the front of your vehicle goes straight into a wall that
does not move or deform, the threshold level for the
reduced deployment is about 12 to 16 mph
(19 to 26 km/h), and the threshold level for a full
deployment is about 17 to 23 mph (27 to 37 km/h) if the
other sensors do not over-ride this. The threshold
level can vary, however, with specic vehicle design, so
that it can be somewhat above or below this range.
1-61

Frontal airbags may inate at different crash speeds.
For example:
If the vehicle hits a stationary object, the airbags
could inate at a different crash speed than if the
vehicle hits a moving object.
If the vehicle hits an object that deforms, the
airbags could inate at a different crash speed than
if the vehicle hits an object that does not deform.
If the vehicle hits a narrow object (like a pole) the
airbags could inate at a different crash speed
than if the vehicle hits a wide object (like a wall).
If the vehicle goes into an object at an angle the
airbags could inate at a different crash speed
than if the vehicle goes straight into the object.
The frontal airbags (driver and right front passenger) are
not intended to inate during vehicle rollovers, rear
impacts, or in many side impacts.Your vehicle has special sensors which enable the
sensing system to monitor the position of the right front
passenger’s seat, whether the occupant is buckled
or unbuckled. The passenger seat position sensor and
passenger safety belt buckle switch provide information
which is used to determine if the airbags should
deploy at a reduced level or full deployment.
Side impact airbags are intended to inate in moderate
to severe side crashes. A side impact airbag will inate
if the crash severity is above the system’s designed
“threshold level.” The threshold level can vary with
specic vehicle design. Side impact airbags are not
intended to inate in frontal or near-frontal impacts,
rollovers or rear impacts. A side impact airbag is intended
to deploy on the side of the vehicle that is struck.
In any particular crash, no one can say whether an
airbag should have inated simply because of the
damage to a vehicle or because of what the repair costs
were. For frontal airbags, ination is determined by
what the vehicle hits, the angle of the impact, and how
quickly the vehicle slows down. For side impact
airbags, ination is determined by the location and
severity of the impact.
1-62

What Makes an Airbag Inate?
In an impact of sufficient severity, the airbag sensing
system detects that the vehicle is in a crash. The
sensing system triggers a release of gas from the
inator, which inates the airbag. The inator, airbag,
and related hardware are all part of the airbag modules
inside the steering wheel and in the instrument panel
in front of the right front passenger. For vehicles
with roof-mounted side impact airbags, there are also
airbag modules in the ceiling of the vehicle, near
the side windows.
How Does an Airbag Restrain?
In moderate to severe frontal or near frontal collisions,
even belted occupants can contact the steering wheel or
the instrument panel. In moderate to severe side
collisions, even belted occupants can contact the inside
of the vehicle. The airbag supplements the protection
provided by safety belts. Airbags distribute the force of
the impact more evenly over the occupant’s upper
body, stopping the occupant more gradually. But the
frontal airbags would not help you in many types
of collisions, including rollovers, rear impacts, and many
side impacts, primarily because an occupant’s motion
is not toward the airbag. Side impact airbags would not
help you in many types of collisions, including many
frontal or near frontal collisions, rollovers, and rear
impacts, primarily because an occupant’s motion is not
toward those airbags. Airbags should never be
regarded as anything more than a supplement to safety
belts, and then only in moderate to severe frontal or
near-frontal collisions for the driver’s and right front
passenger’s frontal airbags, and only in moderate to
severe side collisions for side impact airbags.
1-63

What Will You See After an Airbag
Inates?
After the frontal and seat-mounted side impact airbags
inate, they quickly deate, so quickly that some
people may not even realize the airbags inated.
Roof-mounted side impact airbags are designed to
deate more slowly and may still be partially inated
minutes after the vehicle comes to rest. Some
components of the airbag module — the steering wheel
hub for the driver’s airbag, the instrument panel for
the right front passenger’s bag, the side of the seatback
closest to the door for seat-mounted side impact
airbags, and the area along the ceiling of your vehicle
near the side windows for roof-mounted side impact
airbags — may be hot for a short time. The parts of the
bag that come into contact with you may be warm,
but not too hot to touch. There will be some smoke and
dust coming from the vents in the deated airbags.
Airbag ination does not prevent the driver from seeing
out of the windshield or being able to steer the
vehicle, nor does it stop people from leaving the vehicle.
{CAUTION:
When an airbag inates, there is dust in the
air. This dust could cause breathing problems
for people with a history of asthma or other
breathing trouble. To avoid this, everyone in
the vehicle should get out as soon as it is safe
to do so. If you have breathing problems but
cannot get out of the vehicle after an airbag
inates, then get fresh air by opening a
window or a door. If you experience breathing
problems following an airbag deployment, you
should seek medical attention.
Your vehicle has a feature that may automatically
unlock the doors and turn the interior lamps on when
the airbags inate. You can lock the doors again
and turn the interior lamps off by using the door lock
and interior lamp controls. The hazard warning ashers
will also come on when the airbags deploy. If you
want to turn them off, press the hazard warning asher
button twice.
1-64
