CADILLAC ELDORADO 2000 10.G Owners Manual

2-72
CHECK OIL LEVEL - 36: For correct operation of the
low oil sensing system, your vehicle should be on a level
surface. A false CHECK OIL LEVEL message may
appear if the vehicle is parked on grades. The oil level
sensing system does not check for actual oil level if the
engine has been off for a short period of time, and the oil
level is never sensed while the engine is running. If the
CHECK OIL LEVEL message appears and your vehicle
has been parked on level ground with the engine off for
at least 30 minutes, the oil level should be checked by
observing the oil dipstick. Prior to checking the oil level,
be sure the engine has been off for five minutes and your
vehicle is on a level surface. Then check the dipstick and
add oil if necessary. See ªEngine Oilº in the Index.
CHECK WASHER FLUID
- 25: This message will
appear for several seconds indicating that you need
windshield washer solvent.
CRUISE ENGAGED
- 43: This message will appear
for a few seconds when you select a speed at which
to cruise.
DOOR AJAR
- 141: A door other than the driver's
is open or ajar when this message appears. The vehicle's
engine must be running and the transaxle not in
PARK (P) for this message to display. A chime will
also sound when the vehicle's speed is greater than
5 mph (8 km/h).DRIVER DOOR AJAR
- 140: This message
will display when the vehicle is being shifted out of
PARK (P) with the engine running to signal that the
driver's door is open or ajar. A chime will also sound
when the vehicle's speed is greater than 5 mph (8 km/h).
ENGINE COOLANT HOT, IDLE ENGINE
- 44:
This message will appear when the engine coolant
temperature is over 248
F (126
C). To avoid added
strain on a hot engine, turn off the climate control
system. Stop and allow your vehicle to idle until it cools
down or the message is removed. If it does not cool
down, turn off the engine and have it serviced before
driving it again. Severe engine damage can result from
an overheated engine. See ªEngine Overheatingº in
the Index.
ENGINE HOT
- A/C OFF - 16: This message displays
when the engine coolant becomes hotter than the normal
operating temperature. To avoid added strain on a hot
engine, the air conditioning compressor is automatically
turned off so that air conditioned air is not delivered.
If the coolant temperature returns to normal, you must
select AC to return to a normal A/C compressor
operation. If this message continues to appear,
have the system repaired as soon as possible to avoid
compressor damage.

2-73
ENGINE MISFIRE -- EASE OFF GAS
PEDAL
- 114: An engine misfire has occurred.
You'll need to ease off the gas pedal.
ENGINE OVERHEATED, STOP ENGINE
- 42:
This message will appear when the engine has
overheated. Stop and turn the engine off immediately
to avoid severe engine damage. See ªEngine
Overheatingº in the Index. A multiple chime will also
sound when this message is displayed.
ENGINE POWER REDUCED
- 41: This message
informs you that your vehicle is reducing engine power
because the transaxle is being placed in gear under
conditions that may cause damage to the vehicle
powertrain or vehicle acceleration.
FUEL LEVEL LOW
- 11 : This message serves as a
warning that the fuel level in the tank is critically low.
Stop for fuel soon.
HEADLAMPS SUGGESTED
- 23: If it's dark
enough outside and the Twilight Sentinel control is off,
a HEADLAMPS SUGGESTED message will display on
the DIC. This message informs the driver that turning on
the exterior lamps is recommended even though the
Daytime Running Lamps (DRL) are still illuminated
(it's become dark enough outside to require the
headlamps and/or other exterior lamps).ICE POSSIBLE
- 13: This message appears when
the outside air temperature is cold enough to create icy
road conditions.
LOW REFRIG A/C OFF
- 12: This message means
that the air conditioning system detects a refrigerant
level that is low enough to cause damage to the air
conditioning compressor. Have the air conditioning
system serviced if this message appears.
MONITORED SYSTEMS OK
- 1: This message only
appears in the ªrecallº mode by pressing the INFO
RESET (NO) button. It lets you know that no other
messages are stored or currently active.
OIL PRESSURE LOW STOP ENGINE
- 35: If this
message appears while the engine is running, stop the
engine and do not operate it until the cause of low oil
pressure is corrected. Severe damage to the engine can
result. A multiple chime will also sound when this
message is displayed.
OPTIONS NOT SET
- 99: This message will display if
a fault has occurred in your vehicle's memory. Have
your vehicle serviced by your dealership.
PROGRAM PASS KEY
- 31: This warning message
displays when the PASS
-Key
II pellet information has
not been programmed into your vehicle. See your
dealership for service.

2-74
PHONE NOT PRESENT - 126: This message will
appear when the steering wheel controls for the optional
phone system are activated but the phone is not plugged
into the vehicle. Make sure your phone is plugged in.
If your phone appears to be connected, see your
dealership for service.
REMOVE KEY
- 70: This message will appear
when the Personalized Automotive Security System
(PASS
-Key
II) is unable to read the pellet on the
ignition key or an improper key pellet has been inserted.
This message usually appears following the display of
STARTING DISABLED REMOVE KEY. The
instrument panel cluster will then run a timer and
change the messages to WAIT 3 MINUTES, WAIT 2
MINUTES, WAIT 1 MINUTE and then START CAR.
When the REMOVE KEY message is displayed, remove
the ignition key. Check the ignition key for damage. If it
is damaged, it may need to be replaced. If you see no
damage, clean the pellet contacts with a soft cloth or
napkin before inserting the key back into the ignition.
Have your vehicle serviced if the message still appears.
SERVICE A/C SYSTEM
- 14: This message
appears when the electronic sensors that control the air
conditioning and heating systems are no longer working.
Have the climate control system serviced if you notice a
drop in heating and air conditioning efficiency.SERVICE AIR BAG
- 83: There is a problem with the
Supplemental Inflatable Restraint (air bag) system when
this message appears. Let only a qualified technician work
on your vehicle. See your dealership for service at once.
SERVICE BRAKE FLUID SWITCH
- 37: A problem
in the brake fluid detection circuit causes this message
to display if the ignition is in RUN. Have the brake
system serviced by a technician as soon as possible. If
the brake warning light is on, refer to the directions
listed in that part.
SERVICE CHARGING SYSTEM
- 102: This
message will display when a problem with the charging
system has been detected. Have your vehicle serviced at
your dealership.
SERVICE ELECTRIC SYS
- 106: This message will
display if an electrical problem has occurred within the
Powertrain Control Module (PCM). Have your vehicle
serviced by your dealership.
SERVICE FUEL SYSTEM
- 101: The PCM has
detected a problem within the fuel system when this
message appears. See your dealership for service.
SERVICE IDLE CONTROL
- 107: A problem with
the idle control has occurred when this message displays.
Drive your vehicle to the dealership for service.

2-75
SERVICE RIDE SYS - 84: This message is displayed
to indicate that the suspension system is not operating
properly. To correct this problem, have your vehicle
serviced at your dealership.
SERVICE STEERING SYS
- 127: This message is
displayed when a problem has been detected in the
Magnasteer

variable effort steering system. Service is
required. A single chime will also sound when this
message is displayed.
SERVICE TRANSMISSION
- 100: If a problem is
detected with the transaxle, this message will appear.
Have your vehicle checked by your dealership.
SERVICE VEHICLE SOON
- 3: If a problem is
detected with the transaxle, this message will appear.
Have your vehicle checked by your dealership.
SERV STABILITY SYS
- 54: If you ever see the
SERV STABILITY SYS message, it means there may
be a problem with your stability enhancement system.
If you see this message, try to reset the system
(stop; turn off the engine; then start the engine again).
If the SERV STABILITY SYS message still comes on,
it means there is a problem. You should see your dealer
for service. Reduce your speed and drive accordingly.
A single chime will also sound when this message
is displayed.STABILITY ENGAGED
- 55: You may see the
STABILITY ENGAGED message on the Driver
Information Center. It means that an advanced,
computer
-controlled system has come on to help your
vehicle continue to go in the direction in which you're
steering. This stability enhancement system activates
when the computer senses that your vehicle is just
starting to spin, as it might if you hit a patch of ice or
other slippery spot on the road. When the system is on,
you may hear a noise or feel a vibration in the brake
pedal. This is normal.
When the STABILITY ENGAGED message is on, you
should continue to steer in the direction you want to go.
The system is designed to help you in bad weather or
other difficult driving situations by making the most of
whatever road conditions will permit. If the STABILITY
ENGAGED message comes on, you'll know that
something has caused your vehicle to start to spin,
so you should consider slowing down.

2-76
STARTING DISABLED REMOVE KEY - 33:
This message will appear when the Personalized
Automotive Security System (PASS
-Key
II) senses
that an improper ignition key is being used to try to start
the vehicle. Check the ignition key for damage. If it is
damaged, it may need to be replaced. If you see no
damage, clean the pellet contacts with a soft cloth or
napkin. Remove the ignition key and wait for the DIC to
display WAIT 3 MINUTES. The instrument panel
cluster will then run a timer and change the messages to
WAIT 2 MINUTES, WAIT 1 MINUTE and then
START CAR. When the START CAR message is
displayed, try again to start the engine.
THEFT SYSTEM PROBLEM, CAR MAY NOT
RESTART
- 34: This message means there is a
problem in the Personalized Automotive Security System
(PASS
-Key
II). A fault has been detected in the system
which means that the PASS
-Key
II system is disabled
and is not protecting the vehicle. The vehicle usually
restarts, however, you may want to take your vehicle to a
proper service center before turning off the engine.
TOP SPEED FUEL OFF
- 111 : This message will
appear when the PCM senses that the maximum speed
for your vehicle has been reached. The speed of your
vehicle will decrease several mph as the fuel supply is
cut off. This allows your vehicle to stay in a stable
operating range.TRACTION ENGAGED
- 91 : When your traction
control system is limiting wheel spin, the TRACTION
ENGAGED message will be displayed. Slippery road
conditions may exist if this message is displayed, so
adjust your driving accordingly. This message will stay
on for a few seconds after the traction control system
stops limiting wheel spin.
TRACTION OFF
- 89: This message will be displayed
after the traction control has been turned off.
TRACTION READY
- 90: This message informs the
driver that the traction control system is available. This
occurs when the traction on/off button in the glove box
has been returned to an on position (pressing the button
once turns the traction control system off: pressing the
button again turns the system back on). This message
also self
-cancels after five seconds.
TRACTION SUSPENDED
- 56: This message
displays when the traction control system has been
temporarily shut off because your vehicle's brakes have
overheated. This message does not indicate a problem
with your vehicle's traction control system. After a
few minutes, the traction control system will be
available again and the TRACTION READY
message will appear.

2-77
TRANS FLUID RESET - 48: With the engine not running
and the ignition on, press and hold the OFF and rear defog
buttons until the TRANS FLUID RESET message appears
on the DIC (between five and 20 seconds).
TRANS HOT IDLE ENG
- 112: This message
indicates that the transaxle fluid in your vehicle is too
hot. Stop and allow your vehicle to idle until it cools
down or until this message is removed.
TRUNK OPEN
- 24: This message indicates that the
trunk is open when your vehicle's ignition is in RUN.
TURN SIGNAL ON
- 20: This message is a reminder,
after driving about 1 mile (1.6 km/h), that you have the
turn signal on. A multiple chime will also sound when
this message is displayed.
VEHICLE OVERSPEED
- 52:This message is
displayed when the vehicle speed exceeds a certain limit
as required by some export countries. A continuous
chime will also sound when this message is displayed.
VEHICLE SPEED LIMITED TO XXX MPH
(KM/H)
- 113: A failure in the suspension control
system has occurred when this message appears. The
Powertrain Control Module (PCM) determines the speed
your vehicle is limited to. Have your vehicle serviced if
this message appears. (The XXX indicates the speed
your vehicle is limited to.)
Memory and Personalization Features
(If Equipped)
Your vehicle may be equipped with the following
features that can be individually programmed,
memorized or personalized for up to two drivers.
For a brief description of each feature, see each feature
in the Index.
Memory Seat and Mirrors
To begin programming,
adjust the driver's seat
(including lumbar
adjustments) and both
outside mirrors to a
comfortable position and
then press the SET button.
Within five seconds,
press button ª1.º
A second mirror and seating position may be
programmed by repeating the above steps and pressing
button ª2º instead of button 1. Note that each time a
memory button is pressed, a single beep will sound
through the left front speaker.

2-78
If your vehicle is in PARK (P), you can recall mirror and
seating positions by briefly pressing button 1 or 2.
This will adjust the seat and mirrors to where you have
previously programmed them. If you have accidentally
pressed one of the memory recall buttons and want to
stop seat or mirror movement, press one of the manual
seat or mirror control buttons. This cancels a
memory recall.
You can also recall a seat and mirror position if your
vehicle is not in PARK (P). Press and hold either the
1 or 2 button until seat and mirror movement is
complete. Releasing the buttons will stop adjustment.
The EXIT button can be programmed to allow easy exit
for up to two drivers. Adjust the seat to a comfortable
ªexitº position and then press the SET button followed
by the EXIT button. While your vehicle is in PARK (P),
briefly press the EXIT button to recall your programmed
exit position.
Programmable Automatic Door Locks
Your vehicle's ignition must be in RUN. To begin
programming, press and hold the SKIP INFO and NO
INFO RESET buttons at the same time to display the
following prompts.DOORS LOCK IN GEAR: All doors automatically
lock when shifted out of PARK (P). No automatic
door unlock.
DRIVR UNLOCK IN PARK: All doors automatically
lock when shifted out of PARK (P). Only the driver's
door automatically unlocks when shifted into PARK (P).
DRIVR UNLOCK KEY OFF: All doors automatically
lock when shifted out of PARK (P). Only the driver's
door automatically unlocks when the ignition key is
turned to OFF.
DOORS UNLOCK IN PARK: All doors automatically
lock when shifted out of PARK (P) and unlock when
shifting into PARK (P).
DOORS UNLOCK KEY OFF: All doors
automatically lock when shifted out of PARK (P).
All doors automatically unlock when the ignition key is
turned to OFF.
A ªyesº or ªnoº response must be made after each
prompt is displayed in order to continue on to the next
prompt or personalization feature. Press the YES TRIP
RESET button to choose yes, press the NO INFO
RESET button to choose no or press the SKIP INFO
button to ªskipº to the next personalization feature.

2-79
FEATURE ON appears when a yes response is made
and FEATURE OFF appears with a no response.
If a no response is made after the DOORS LOCK IN
GEAR prompt is displayed, FEATURE OFF will appear.
The automatic door locking system has been disabled
and no other door lock messages will be displayed.
LGHTS FLSH AT UNLOCK, which is the next
available personalization feature to display, will appear
next. See ªLock/Unlock Confirmationº in the Index
for more information.
If a yes response is made after the DOORS LOCK IN
GEAR prompt is displayed, FEATURE ON appears.
The automatic door locking system is enabled and
allows the DRIVR UNLOCK IN PARK prompt to
appear. Choosing this prompt advances you to LGHTS
FLSH AT UNLOCK whereas a no response will display
the DRIVR UNLOCK KEY OFF prompt.
If DRIVR UNLOCK KEY OFF is chosen, FEATURE
ON appears. You will advance to the LGHTS FLSH
AT UNLOCK prompt. If you don't choose this
prompt, FEATURE OFF appears as well as the next
prompt
-- DOORS UNLOCK IN PARK. If this prompt
is chosen, FEATURE ON appears. If a no response was
made, DOORS UNLOCK KEY OFF will appear. At this
point, a yes or no response automatically brings up the
LGHTS FLSH AT UNLOCK feature.Lock/Unlock Confirmation
This personalization feature allows the driver to
program the parking lamps to blink when the lock or
unlock buttons on the remote keyless entry transmitter
are pressed, to program the horn to sound when the lock
button is pressed and/or to program the exterior lamps to
turn on when the unlock button is pressed. Press the
YES TRIP RESET button to answer yes, press the NO
INFO RESET button to indicate no or press the SKIP
INFO button to skip to the next personalization feature.
To begin programming, your vehicle's ignition must be
in RUN. Press and hold the SKIP INFO and NO INFO
RESET buttons at the same time to display the
following prompts. LOCK/UNLOCK confirmation is
the second feature to appear. To skip past the first
personalization feature, press the SKIP INFO button.
LGHTS FLSH AT UNLOCK: Parking lamps blink
twice when the unlock button on the remote keyless
entry transmitter is pressed.
LIGHTS FLASH AT LOCK: Parking lamps blink
once when the lock button on the remote keyless entry
transmitter is pressed.
HORN SOUNDS AT LOCK: Horn sounds when the
lock button on the remote keyless entry transmitter
is pressed.

2-80
EXT LIGHTS AT UNLOCK: Exterior lamps (parking
lamps, taillamps, sidemarker lamps, license plate lamps,
low
-beam headlamps, etc.) turn on when the unlock
button on the remote keyless entry transmitter is pressed
and it is dark outside. These lamps stay on for about
20 seconds or until the key is turned OFF.
The prompts listed here appear in the same order as
displayed on the DIC. FEATURE ON appears when a
yes response is made and FEATURE OFF appears with
a no response. To skip to the next personalization feature
(REMOTE RECALL MEMORY), press the SKIP
INFO button.
Remote Recall Memory (If Equipped with
Memory Personalization)
Memory settings that have been previously programmed
(climate control settings, radio preset settings, exterior
lighting choices, remote confirmation choices and
programmable automatic door lock choices) can be
recalled by using the remote keyless entry transmitter
or by placing the key in your vehicle's ignition.
Before you begin programming, make sure that your
vehicle's ignition is in RUN. To begin programming,
press the SKIP INFO and NO INFO RESET buttons
at the same time for about two seconds. As mentioned,
remote recall memory is the third feature to appear. To skip past the first two personalization features,
press the SKIP INFO button.
When REMOTE RECALL MEMORY appears, the
driver is able to recall memory settings when the unlock
button on the remote keyless entry transmitter is
pressed. Press the YES TRIP RESET button to select or
press the NO INFO RESET button to answer no and to
continue on to the next prompt. FEATURE ON displays
when a yes response is made.
If a no response was made, the KEY IN RECALL
MEMORY prompt will show next. This choice recalls
memory settings when the key is placed in your
vehicle's ignition. FEATURE ON displays for a yes
response, and FEATURE OFF for a no response.
A yes or no response is required.
Curb View Assist Mirror (If Equipped with Memory)
If your vehicle has this personalization feature, MIRROR
TILT IN REV will be the fourth personalization prompt
to display on the DIC.
To program your vehicle, press the SKIP INFO and NO
INFO RESET buttons at the same time for about two
seconds. When MIRROR TILT IN REV appears, a yes or no
response is needed. Press the YES TRIP RESET button to
answer yes or the NO INFO RESET button to answer no.

2-81
FEATURE ON displays when a yes response is made and
FEATURE OFF shows after a no response. If you do not
want this feature, press the SKIP INFO button to skip to the
next personalization feature which is STORAGE MODE.
Storage Mode Personalization
Before you begin programming, make sure that your
vehicle's ignition is in RUN. To begin programming,
press the SKIP INFO and NO INFO RESET buttons at
the same time for about two seconds. The first message
to appear is DOORS LOCK IN GEAR. Press the
SKIP INFO button after this prompt is displayed until
STORAGE MODE prompt appears on the DIC. Press
the YES TRIP RESET button to answer yes or press the
NO INFO RESET button to indicate a no response.
FEATURE ON appears when a yes response is made
and FEATURE OFF shows when a no response is made.
Since this is the last personalization feature available, a
yes or no response will end out of the Driver
Information Center (DIC) display.
Once the battery guard has been programmed, your
vehicle will enter the storage mode about 20 minutes
after the ignition key has been turned off.Your vehicle will stay in the storage mode until the
ignition key is turned out of LOCK. The system will
ªwake
-upº when the door key is inserted into the door,
however, your vehicle will remain in the storage mode.
The ignition must be out of LOCK before the battery
guard is disabled.
Comfort Controls and Radio System Personalization
These features allow both drivers to personalize their
own climate control settings as well as their radio
settings. For more information, see ªClimate Control
Personalizationº and ªRadio Personalizationº in
the Index.
Continuous Variable Road Sensing
Suspension (CVRSS) (ETC Only)
The CVRSS automatically adjusts the ride of your
vehicle. Automatic ride control is achieved through a
computer used to control and monitor the suspension
system. The controller receives input from various
sensors to determine the proper system response.
If the controller detects a problem within the system,
the Driver Information Center (DIC) will display a
SERVICE RIDE CONTROL message. If this message
appears, have your vehicle serviced at your dealership.
