phone CADILLAC ELDORADO 2000 10.G Owners Manual

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Keys
2
-4 Door Locks
2
-6 Remote Keyless Entry (RKE) System
2
-9 Trunk
2
-11 Theft
2
-12 Theft-Deterrent System
2
-14 PASS-Key
II
2
-15 New Vehicle ªBreak-Inº
2
-16 Ignition Positions
2
-17 Starting Your Engine
2
-18 Engine Coolant Heater (If Equipped)
2
-19 Automatic Transaxle Operation
2
-23 Parking Brake
2
-25 Shifting Into PARK (P)
2
-26 Shifting Out of PARK (P)
2
-27 Parking Over Things That Burn
2
-28 Engine Exhaust2
-28 Running Your Engine While You're Parked
2
-29 Windows
2
-30 Tilt Wheel
2
-30 Turn Signal/Multifunction Lever
2
-37 Exterior Lamps
2
-41 Interior Lamps
2
-42 Mirrors
2
-46 Storage Compartments
2
-49 Sun Visors
2
-49 Cellular Telephone (Option)
2
-50 Sunroof (Option)
2
-51 HomeLink
Transmitter (Option)
2
-54 The Instrument Panel -- Your
Information System
2
-58 Warning Lights, Gages and Indicators
2
-68 Driver Information Center (DIC)

2-47 Center Console Storage
The console includes a storage compartment for CDs or
tapes and an optional phone, an armrest and a cupholder.
The cupholder can be opened by pressing on the surface
panel located in front of the armrest. Close the lid
to secure.The console may have a lock. To lock the console, insert
the oval key into the lock cylinder and turn it clockwise.
Turn the key counterclockwise to unlock the door.
Rear Storage Armrest (If Equipped)
Your vehicle may be equipped with a rear seat armrest
which includes an open storage compartment and a dual
cupholder that unfolds for use. To open, lift the front
edge. (This feature is available on vehicles with leather
interiors only.)
Convenience Net
The convenience net is located inside the back wall of
the trunk. Put small loads, like grocery bags, behind the
net. It can help keep them from falling over during sharp
turns or quick starts and stops.
The net is not for larger, heavier loads. Store them in the
trunk as far forward as you can. When not using the net,
hook the net to the tabs securing it to the sill plate.

2-49
Sun Visors
Swing down the visor to block out glare. It can also be
detached from the center mount and moved to the side.
The driver's sun visor is also equipped with a storage
flap that can be used for maps or toll tickets.
Lighted Visor Vanity Mirror
Move the sun visor down and lift the cover to see the
mirror. Move the slide switch up or down to brighten or
dim the lamp.
Cellular Telephone (Option)
Your vehicle has been prewired for dealer installation of
a Cadillac dual
-mode (analog/digital) cellular telephone.
A fixed mobile or a portable hand
-held system is
available. Either system has steering wheel telephone
controls and information output through the Driver
Information Center (DIC). Voice activation and
hands
-free operation are standard features. For more
information, contact your dealer. A user's guide is
provided with the telephone.
OnStar
System (If Equipped)
OnStar is a vehicle communications service. The
following services are available through subscription
with OnStar and are available 24 hours a day:
Emergency Services

Automatic Notification of Air Bag Deployment

Theft Notification and Stolen Vehicle Tracking

Roadside Assistance with Location

Remote Diagnostics

OnStar MED
-NET

Accident Assist
Convenience Services

Remote Door Unlock

Route Support

Concierge Services

Ride Assist
A complete user's guide is provided with the OnStar
System. For more information contact OnStar
at 1
-888-ONSTAR7.

2-55
The main components of the instrument panel are:
A. Air Outlets
B. Turn Signal/Multifunction Lever
C. Instrument Panel Cluster
D. Radio (Audio System)
E. Driver Information Center Control Buttons
F. Lamp Controls
G. HVAC Steering Wheel Controls
(or Cellular Telephone Controls, If Equipped)H. Hood Release
I. Horn
J. Audio Steering Wheel Controls
K. Shift Lever
L. Climate Control System
M. Glove Box

2-68 Fuel Data Display
Everything you need to know about the fuel economy
and how far you can travel with your vehicle's
remaining fuel is displayed. Fuel data can be obtained
by pressing the INFO (SKIP) button. See ªDIC Controls
and Displaysº later in this section.
Driver Information Center (DIC)
This display gives you the status of many of your
vehicle's systems. The DIC is also used to display driver
personalization features and warning/status messages.
DIC Controls and Displays
TRIP RESET (YES): By using this button, you can tell
how far you've gone since you last set the YES TRIP
RESET back to zero. To reset, press and hold this
button until zeros appear. If your vehicle is domestic,
the trip odometer will return to zero after 999.9 miles
(1 609 km). If your vehicle is Canadian, the
trip odometer will return to zero after
1 999.9 km (1,242 miles).
INFO RESET (NO): Pressing this button will reset the
MPG AVG, GAL FUEL USED, AVG MPH, TIMER,
OIL LIFE LEFT and ENGLISH/METRIC RESET.
Pressing NO INFO RESET when a non
-resettable
display appears will cause a ªrecallº mode to occur.
When this happens, all Driver Information Center (DIC)
warning messages that have been displayed since the
ignition key was turned to RUN will redisplay. If no
messages were displayed, a MONITORED SYSTEMS
OK message will appear.
INFO (SKIP): Pressing this button repeatedly will
display the RANGE, MPG AVG, MPG INST, GAL
FUEL USED, AVG MPH, TIMER, BATTERY VOLTS,
OIL LIFE LEFT, PHONE (if equipped) and
ENGLISH/METRIC RESET.

2-74
PHONE NOT PRESENT - 126: This message will
appear when the steering wheel controls for the optional
phone system are activated but the phone is not plugged
into the vehicle. Make sure your phone is plugged in.
If your phone appears to be connected, see your
dealership for service.
REMOVE KEY
- 70: This message will appear
when the Personalized Automotive Security System
(PASS
-Key
II) is unable to read the pellet on the
ignition key or an improper key pellet has been inserted.
This message usually appears following the display of
STARTING DISABLED REMOVE KEY. The
instrument panel cluster will then run a timer and
change the messages to WAIT 3 MINUTES, WAIT 2
MINUTES, WAIT 1 MINUTE and then START CAR.
When the REMOVE KEY message is displayed, remove
the ignition key. Check the ignition key for damage. If it
is damaged, it may need to be replaced. If you see no
damage, clean the pellet contacts with a soft cloth or
napkin before inserting the key back into the ignition.
Have your vehicle serviced if the message still appears.
SERVICE A/C SYSTEM
- 14: This message
appears when the electronic sensors that control the air
conditioning and heating systems are no longer working.
Have the climate control system serviced if you notice a
drop in heating and air conditioning efficiency.SERVICE AIR BAG
- 83: There is a problem with the
Supplemental Inflatable Restraint (air bag) system when
this message appears. Let only a qualified technician work
on your vehicle. See your dealership for service at once.
SERVICE BRAKE FLUID SWITCH
- 37: A problem
in the brake fluid detection circuit causes this message
to display if the ignition is in RUN. Have the brake
system serviced by a technician as soon as possible. If
the brake warning light is on, refer to the directions
listed in that part.
SERVICE CHARGING SYSTEM
- 102: This
message will display when a problem with the charging
system has been detected. Have your vehicle serviced at
your dealership.
SERVICE ELECTRIC SYS
- 106: This message will
display if an electrical problem has occurred within the
Powertrain Control Module (PCM). Have your vehicle
serviced by your dealership.
SERVICE FUEL SYSTEM
- 101: The PCM has
detected a problem within the fuel system when this
message appears. See your dealership for service.
SERVICE IDLE CONTROL
- 107: A problem with
the idle control has occurred when this message displays.
Drive your vehicle to the dealership for service.

3-30
NOTICE:
Before you add any sound equipment to your
vehicle
-- like a tape player, CB radio, mobile
telephone or two
-way radio -- be sure you can
add what you want. If you can, it's very
important to do it properly. Added sound
equipment may interfere with the operation of
your vehicle's engine, radio or other systems, and
even damage them. Your vehicle's systems may
also interfere with the operation of sound
equipment that has been added improperly.
So, before adding sound equipment, check with
your dealer and be sure to check Federal rules
covering mobile radio and telephone units.
Care of Your Cassette Tape Player
A tape player that is not cleaned regularly can cause
reduced sound quality, ruined cassettes or a damaged
mechanism. Cassette tapes should be stored in their
cases away from contaminants, direct sunlight and
extreme heat. If they aren't, they may not operate
properly or may cause failure of the tape player.
Your tape player should be cleaned regularly after every
50 hours of use. Your radio may display CLN or
CLEAN TAPE to indicate that you have used your tape
player for 50 hours without resetting the tape clean
timer. If this message appears on the display, your
cassette tape player needs to be cleaned. It will still play
tapes, but you should clean it as soon as possible to
prevent damage to your tapes and player. If you notice a
reduction in sound quality, try a known good cassette to
see if it is the tape or the tape player at fault. If this other
cassette has no improvement in sound quality, clean the
tape player.
The recommended cleaning method for your
cassette tape player is the use of a scrubbing action,
non
-abrasive cleaning cassette with pads which scrub
the tape head as the hubs of the cleaner cassette turn.
The recommended cleaning cassette is available through
your dealership (GM Part No. 12344789).

4-2
Defensive Driving
The best advice anyone can give about driving is:
Drive defensively.
Please start with a very important safety device in your
vehicle: Buckle up. (See ªSafety Beltsº in the Index.)Defensive driving really means ªbe ready for anything.º
On city streets, rural roads or freeways, it means
ªalways expect the unexpected.º
Assume that pedestrians or other drivers are going to
be careless and make mistakes. Anticipate what they
might do. Be ready for their mistakes.
Rear
-end collisions are about the most preventable
of accidents. Yet they are common. Allow enough
following distance. It's the best defensive driving
maneuver, in both city and rural driving. You never
know when the vehicle in front of you is going to brake
or turn suddenly.
Defensive driving requires that a driver concentrate on
the driving task. Anything that distracts from the driving
task
-- such as concentrating on a cellular telephone
call, reading, or reaching for something on the
floor
-- makes proper defensive driving more difficult
and can even cause a collision, with resulting injury.
Ask a passenger to help do things like this, or pull
off the road in a safe place to do them yourself.
These simple defensive driving techniques could save
your life.

4-18
Driving too fast through large water puddles or even
going through some car washes can cause problems, too.
The water may affect your brakes. Try to avoid puddles.
But if you can't, try to slow down before you hit them.
CAUTION:
Wet brakes can cause accidents. They won't work
as well in a quick stop and may cause pulling to
one side. You could lose control of the vehicle.
After driving through a large puddle of water or
a car wash, apply your brake pedal lightly until
your brakes work normally.
Hydroplaning
Hydroplaning is dangerous. So much water can build up
under your tires that they can actually ride on the water.
This can happen if the road is wet enough and you're
going fast enough. When your vehicle is hydroplaning,
it has little or no contact with the road.
Hydroplaning doesn't happen often. But it can if your
tires do not have much tread or if the pressure in one or
more is low. It can happen if a lot of water is standing on
the road. If you can see reflections from trees, telephone
poles or other vehicles, and raindrops ªdimpleº the
water's surface, there could be hydroplaning.
Hydroplaning usually happens at higher speeds. There
just isn't a hard and fast rule about hydroplaning. The
best advice is to slow down when it is raining.

6-66
Fuse Usage
RADIO/PHONE Radio Receiver, Radio Interface
Module (RIM) (Optional), Phone,
RAP Relay, Trunk Release Relay,
Fuel Door Release Relay,
High/Low
-Beam Relay
CLUSTER Steering Wheel Controls, Cluster
ACC PZM, Electrochromic Mirror,
Rain Sensor (Optional),
Accessory Relay
HTD MIR Right and Left Outside
Heated Mirror
HTD SEAT R Passenger Heated Seat
Relay (Optional)
HTD SEAT L Driver Heated Seat
Relay (Optional)
PULL DOWN Trunk Pull
-Down Motor
ANTENNA Power Mast Antenna
RSS Damper Relay (ETC Only)Fuse Usage
CONVENC Trunk Release Relay, Trunk
Release Solenoid, Fuel Door
Release Relay, Fuel Filler Door
Release Solenoid, Door Lock
Relay, Left and RIght Door
Motors, PZM, Door Unlock Relay
BATT Driver and Passenger Seat Lumbar
Switch (Optional), Driver and
Passenger Seat Belt Comfort
Solenoid, Memory Seat
Module (Optional)
RSS Road Sensing Suspension (RSS)
Module (ETC Only)
RT PARK Headlamp Switch, Right Front
Parking Lamp, Right Front and
Rear Sidemarker Lamps, Right
Turn/Stop/Tail Lamps
LT PARK Left Front and Rear Sidemarker
Lamps, Left Front Parking Lamp,
Left Turn/Stop/Tail Lamps, Right
and Left License Lamps,
Underhood Lamp
