Page 61 of 365
2-4
Keys
CAUTION:
Leaving children in a vehicle with the ignition
key is dangerous for many reasons. A child or
others could be badly injured or even killed.
They could operate the power windows or other
controls or even make the vehicle move. If they
turned the ignition to RUN and moved the shift
lever out of PARK (P), that would release the
parking brake. Don't leave the keys in a vehicle
with children.
Page 62 of 365
2-5
Ignition Key Door/Locks Key
The square key is for the ignition only. It has a
resistor pellet which is part of the vehicle's
PASS
-Key II system.
The oval key is for the doors and all other locks.
When a new vehicle is delivered, the dealer removes the
plug from the door key. The plug has a code on it that
tells the dealer or a qualified locksmith how to make
extra keys. The ignition key has a bar code tag attached
to it rather than a knock out plug. Your dealer or
qualified locksmith can make extra ignition keys by
reading the bar code tag.
NOTICE:
Your vehicle has a number of new features
that can help prevent theft. You can have a lot
of trouble getting into your vehicle if you ever
lock your keys inside and you may have to
damage your vehicle to get in. Be sure you have
extra keys.
There are 15 alternative ignition PASS-Key II blanks
to help discourage theft. Keep the bar code tag and the
door key plugs in a safe place. If you lose your keys,
you will be able to have new ones made using the plug
or bar code tag.
In an emergency, contact Cadillac Roadside Assistance.
See ªRoadside Assistanceº in the Index.
If your vehicle is equipped with the OnStar
system
with an active subscription and you lock your keys inside
the vehicle, OnStar may be able to send a command to
unlock your vehicle. See ªOnStarº in the Index for
more information.
Page 63 of 365
2-6
Door Locks
CAUTION:
Unlocked doors can be dangerous.
Passengers -- especially children -- can
easily open the doors and fall out of a
moving vehicle. When a door is locked,
the handle won't open it. You increase the
chance of being thrown out of the vehicle in
a crash if the doors aren't locked. So, wear
safety belts properly and lock the doors
whenever you drive.
Young children who get into unlocked
vehicles may be unable to get out. A child
can be overcome by extreme heat and can
suffer permanent injuries or even death
from heat stroke. Always lock your vehicle
whenever you leave it.
Outsiders can easily enter through an
unlocked door when you slow down or stop
your vehicle. Locking your doors can help
prevent this from happening.
There are several ways to lock and unlock your vehicle.
Because your vehicle has the theft
-deterrent system,
you must unlock the doors with the key or remote
keyless entry transmitter to avoid setting off the alarm.
From the outside, use either the key or the remote
keyless entry transmitter.
From the inside, use the manual lock levers located on
the door panels.
Slide the manual lock lever down to lock the door from
the inside. To unlock the door, slide the lock lever up.
Page 64 of 365
2-7 Central Door Unlocking System
Your vehicle will have this feature if it is equipped with
the theft
-deterrent system. When unlocking either door,
you can also unlock the other door by holding the key
in the turned position for a few seconds or by quickly
turning the door key twice in the lock cylinder.
Power Door Locks
Press the power door lock switch down to lock or
upward to unlock both doors at once.
Automatic Door Locks
Your vehicle is programmed to lock both doors when
the ignition is on and the shift lever is moved out of
PARK (P). The doors will unlock every time you stop
the vehicle and move the shift lever back into PARK (P).
If someone needs to get out while your vehicle is not in
PARK (P), have that person use the manual or power
door lock. When the door is closed again, it will not
lock automatically. Use the manual or power door lock
to lock the door again. If you need to lock the doors
before shifting out of PARK (P), use the manual or
power door lock.
Programmable Automatic Door Locks
(If Equipped)
With the ignition in RUN, the door locks can be
programmed through prompts displayed by the
Driver Information Center (DIC). These prompts
allow the driver to choose various lock settings.
For programming information, see ªMemory and
Personalization Featuresº in the Index.
Page 65 of 365
2-8 Anti-Lockout Feature
Leaving your key in any ignition position with either
door open will disable the use of the power door lock
switches as well as the lock button on the remote keyless
entry transmitter. If you close the doors, you can lock
them using the remote keyless entry transmitter. It is
always recommended that you remove your ignition key
when locking your vehicle.
The anti
-lockout feature can be overridden by
holding the driver's power door lock switch for
three seconds or longer.
Leaving Your Vehicle
If you are leaving the vehicle, open the door, set the
locks from the inside, get out and close the door.
Remote Keyless Entry System
With this feature, you can lock and unlock the doors,
unlock the trunk, open the fuel door and turn on your
vehicle's interior lamps from about 10 feet (3 m) away
using the remote keyless entry transmitter supplied with
your vehicle.
Your remote keyless entry system operates on a
radio frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation of
the device.
Page 66 of 365
2-9
Changes or modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.
The average range of this system is about 10 feet (3 m).
At times you may notice a decrease in range. This is
normal for any remote keyless entry transmitter.
If the transmitter does not work or if you have to
stand closer to your vehicle for the transmitter to work,
try the following:
Check the distance. You may be too far from your
vehicle. You may need to stand closer during rainy
or snowy weather.
Check the location. Other vehicles or objects may be
blocking the signal. Take a few steps to the left or
right, hold the transmitter higher, and try again.
Check to determine if battery replacement is
necessary. See the instructions that follow.
If you're still having trouble, see your dealer or a
qualified technician for service.Operation
(Lock): When you
press the button with the
lock symbol on it to lock
the doors, the parking
lamps will flash once.
You can program your
vehicle so the parking
lamps will not flash.
For more information, see ªLock/Unlock Confirmationº
in the Index. This also arms the theft
-deterrent system.
Page 67 of 365
2-10
(Unlock): When you press the button with
the unlock symbol on it to unlock the driver's door,
the parking lamps on your vehicle will flash twice.
You can program your vehicle so the parking lamps
will not flash. For more information, see ªLock/Unlock
Confirmationº in the Index.
Pressing the button with the unlock symbol on it again
within five seconds will unlock the other doors. Pressing
this button will also disarm the theft
-deterrent system
and turn on the interior lamps at night.
(Fuel Door): Press the button with the fuel door
symbol on it to open the fuel door. The VALET lockout
button must be off for this feature to work.
(Trunk): Press the button with the trunk symbol
on it to open the trunk. The VALET lockout button
must be off for this feature to work.
The remote keyless entry transmitter can also be
used to recall the memory seats for up to two drivers.
For more information, see ªMemory Seat and Mirrorsº
in the Index.
Matching Transmitter(s) to Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to bring any
remaining transmitters with you when you go to your
dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock your
vehicle. Each vehicle can have a maximum of four
transmitters matched to it.
Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about four years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have to
get close to your vehicle before the transmitter works,
it's probably time to change the battery.
Page 68 of 365
2-11
NOTICE:
When replacing the battery, use care not to touch any
of the circuitry. Static from your body transferred
to these surfaces may damage the transmitter.
1. Use a thin object like a coin to pry open the transmitter.
2. Once the transmitter is separated, use a pencil
(or similar object) to remove the old battery.
Do not use a metal object.
3. Remove and replace the battery. Insert the new
battery as the instructions under the cover indicate.
Do not use a metal object.
4. Snap the transmitter back together tightly to be sure
no moisture can enter.
5. Check the operation of the transmitter.
Page 69 of 365
2-12
Trunk
CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even death.
If you must drive with the trunk lid open or
if electrical wiring or other cable connections
must pass through the seal between the body
and the trunk lid:
Make sure all other windows are shut.
Turn the fan on your heating or cooling
system to its highest speed with the setting
on AUTO and the temperature between
65F (18C) and 85F (29C). That will
force outside air into your vehicle.
See ªComfort Controlsº in the Index.
If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.
Trunk Lock Release
The button for this feature
is located above the radio
on the Driver Information
Center (DIC).
Press the TRUNK button to open the trunk.
You can also press the button with the trunk symbol
on the remote keyless entry transmitter to access the
trunk compartment.
When the trunk opens, a light will come on inside the
trunk so that you can see what's inside the trunk.
To use this feature, your vehicle must be in PARK (P)
or NEUTRAL (N) and the VALET lockout button
must be off.
Page 70 of 365
2-13 Trunk Lid Automatic Pull-Down Feature
With the automatic pull-down feature, you never have to
slam the trunk lid in order to close the trunk. Instead,
gently lower the trunk lid until it is nearly shut
-- the
automatic pull
-down unit will take over and lock the
trunk firmly.
A. Trunk Lid
B. LeverIf for some reason the trunk lid (A) will not close, it may
be because the trunk pull
-down unit was accidentally
bumped. Even though the trunk lid remains open, the
motor from the pull
-down unit has already cycled down.
If this happens, press the lever (B) on the trunk lid.
The pull
-down unit motor will reset itself, allowing the
trunk lid to close when lowered.
CAUTION:
Your car may have an automatic pull-down
feature that helps close the trunk electronically.
Your fingers can be trapped under the trunk lid
as it goes down. Your fingers could be injured,
and you would need someone to help you free
them. Keep your fingers away from the trunk lid
as you close it and as it is going down.
