CADILLAC ELDORADO 2002 10.G Owners Manual

2-34
Turn Signal/Multifunction Lever
The lever on the left side of your steering column
includes the following:

Turn Signal and Lane
-Change Signals

Headlamp High/Low
-Beam Changer

Flash
-to-Pass Feature

Windshield Wipers

Windshield Washer

Cruise Control
For more information on the exterior lamps,
see ªExterior Lampsº later in this section.
Turn and Lane-Change Signals
To signal a turn, move the lever all the way up or down.
The lever returns automatically when the turn is complete.
An arrow located on the
instrument panel cluster
will flash in the direction
of the turn or lane change.
Raise or lower the lever until the arrow starts to flash to
signal a lane change. Hold it there until the lane change
is complete. The lever returns when it's released.
If the turn signal is left on, a warning chime will
sound and the Driver Information Center (DIC) will
display TURN SIGNAL ON (after driving about
1 mile (1.6 km/h)) to remind you to turn it off.
Arrows that flash rapidly when signaling for a turn or
lane change may be caused by a burned
-out signal bulb.
Other drivers won't see the turn signal.
Replace burned
-out bulbs to help avoid possible
accidents. Check the fuse (see ªFuses and Circuit
Breakersº in the Index) and for burned
-out bulbs
if the arrow fails to work when signaling a turn.

2-35 Headlamp High/Low-Beam Changer
This light located on the
instrument panel cluster
will be on when the high
beam headlamps are in use.
Pull the turn signal lever all the way toward you and
then release it to change the headlamps from low beam
to high or from high beam to low.
Flash-To-Pass Feature
This lets you use the high-beam headlamps to
signal the driver in front of you that you want to pass.
Pull the turn signal lever toward you to use.
When you do:

If the headlamps are either off or in the Daytime
Running Lamps (DRL) mode, the high
-beam
headlamps will turn on. They'll stay on as long as
you hold the lever there. Release the lever to turn
them off.

If the headlamps are on low beam, they will shift
to high beam and stay there. Pull the lever toward
you to return to low beam.

If the headlamps are on high beam, they will switch
to low beam. To return to high beam, pull the lever
toward you.

2-36 Windshield Wipers
WIPER: Turn the band on the turn signal lever to
control the wipers.
MIST: Turn the band toward you and then release it for
a single wiping cycle. For more cycles, hold the band on
MIST longer.LO or HI: Turn the band away from you to either
LO (low speed) or to HI (high speed), depending on
the wiper speed you want.
DELAY: You can set the wiper speed for a long or
short delay between wipes with this setting. Turn the
band to the DELAY position. The closer you turn it
to LO, the shorter the delay.
OFF: Turn the band to OFF to turn off the wipers.
Be sure to clear ice and snow from the wiper blades
before using them. If they're frozen to the windshield,
carefully loosen or thaw them. If the blades do become
damaged, get new blades or blade inserts.
Heavy snow or ice can overload the wiper motor.
A circuit breaker will stop the motor until it cools.
Clear away snow or ice to prevent an overload.

2-37 Rainsense
Wipers (ETC Only)
The moisture sensor is mounted on the interior side
of the windshield behind the rearview mirror and is used
to automatically operate the wipers by monitoring the
amount of moisture build
-up on the windshield.
Wipes occur as needed to clear the windshield
depending on driving conditions and the sensitivity
setting. In light rain or snow, fewer wipes will occur. In heavy rain or snow, wipes will occur more frequently.
The Rainsense wipers operate in a delay mode as well as
a continuous low or high speed as needed. If the system
is left on for long periods of time, occasional wipes
may occur without any moisture on the windshield.
This is normal and indicates that the Rainsense system
is activated.
The Rainsense system can be activated by turning the
wiper stalk to one of the five sensitivity levels within the
AUTO DELAY area. The AUTO DELAY position
closest to OFF is the lowest sensitivity setting,
level one. This allows more rain or snow to collect on
the windshield between wipes. Turning the stalk away
from you to the higher levels of other AUTO DELAY
settings increases the sensitivity of the system and
frequency of wipes. The highest sensitivity setting,
level five is closest to LO. A single wipe will occur each
time you turn the wiper stalk to a higher sensitivity level
to indicate that the sensitivity level has been increased.
An initial wipe occurs when you turn the ignition on
as a reminder that Rainsense is active.

2-38
The windshield wipers also remain in a ªhigh parkº
position (when the wipers are stopped on the windshield
and are not in the normal park position), even when the
ignition is turned off.
NOTICE:
The wipers must be turned off when going
through a car wash to avoid damage.
The MIST and ªwashº cycles operate as normal and are
not affected by the Rainsense function. The Rainsense
system can be overridden at any time by turning the
wiper stalk to LO or HI speed.
NOTICE:
Do not place stickers or other items on the
exterior glass surface directly in front of the
moisture sensor. Doing this could cause the
moisture sensor to malfunction.
Windshield Washer
CAUTION:
In freezing weather, don't use your washer until
the windshield is warmed. Otherwise the washer
fluid can form ice on the windshield, blocking
your vision.
At the top of the turn signal/multifunction lever there
is a paddle with the word PUSH on it.
To spray washer fluid on the windshield, press and
release this paddle. The wipers will clear the windshield
and either stop or return to your preset speed. For more
washer cycles, press and hold the paddle.
LOW WASHER FLUID will be displayed on the
Driver Information Center (DIC) when the washer fluid
reaches a low level.

2-39 Cruise Control
The cruise control lever is located on the end of
the windshield wiper stalk on the left side of the
steering wheel.
With cruise control, you can maintain a speed of about
25 mph (40 km/h) or more without keeping your foot on
the accelerator. This can help on long trips. Cruise control
does not work at speeds below 25 mph (40 km/h).Cruise control shuts off when you apply your brakes.
CAUTION:

Cruise control can be dangerous where
you can't drive safely at a steady speed.
So, don't use your cruise control on
winding roads or in heavy traffic.

Cruise control can be dangerous on
slippery roads. On such roads, fast changes
in tire traction can cause needless wheel
spinning, and you could lose control.
Don't use cruise control on slippery roads.
If your vehicle is in cruise control when the traction
control system begins to limit wheel spin, the cruise
control will automatically disengage. See ªTraction
Control Systemº in the Index. When road conditions
allow you to safely use it again, you may turn the cruise
control back on.

2-40
Setting Cruise Control
CAUTION:
If you leave your cruise control switch on when
you're not using cruise, you might hit a button
and go into cruise when you don't want to.
You could be startled and even lose control.
Keep the cruise control switch off until you
want to use cruise control.
To use cruise control, do the following:
1. Move the cruise control switch to ON.
2. Accelerate to the speed you want.
3. Press the SET CRUISE button at the end of the lever
and release it. The CRUISE ENGAGED message
will display on the Driver Information Center (DIC).
4. Remove your foot from the accelerator pedal.Resuming a Set Speed
Setting the cruise control at a desired speed and then
applying the brake will end the cruise function.
Once you're going about 25 mph (40 km/h) or more,
you can move the cruise control switch from ON to R/A
(Resume/Accelerate) briefly to reset. This returns you
to your desired preset speed. The Driver Information
Center (DIC) will display the CRUISE ENGAGED
message again.
If you hold the switch at R/A longer, the vehicle will
accelerate until you release the switch or apply the
brake. So unless you want to go faster, don't hold
the switch at R/A.

2-41
Increasing Speed While Using Cruise Control
There are two ways to go to a higher speed:

Use the accelerator pedal to get to the higher speed.
Push the button at the end of the lever and then
release the button and the accelerator pedal.
You'll now cruise at the higher speed.

Move the cruise switch from ON to R/A. Hold it
there until you reach a desired speed and then
release the switch. (To increase your speed in very
small amounts, briefly move the switch to R/A.
Each time you do this, your vehicle will go about
1 mph (1.6 km/h) faster.)
The accelerate feature will only work after you
have set the cruise control speed by pushing the
SET CRUISE button.Reducing Speed While Using Cruise Control
There are two ways to reduce your speed while using
cruise control:

Push in the button at the end of the lever until
you reach a desired lower speed, then release it.
A CRUISE ENGAGED message will then
display in the Driver Information Center (DIC).

To slow down in very small amounts, push the
button briefly. Each time you do this, you'll go
about 1 mph (1.6 km/h) slower.
Passing Another Vehicle While Using Cruise Control
Use the accelerator pedal to increase your speed.
When you take your foot off the pedal, your vehicle will
slow down to the cruise control speed you set earlier.

2-42
Using Cruise Control on Hills
How well your cruise control will work on hills depends
upon your speed, load and the steepness of the hills.
When going up steep hills, you may have to step on the
accelerator pedal to maintain your speed. When going
downhill, you may have to brake or shift to a lower gear
to keep your speed down. Of course, applying the brakes
or downshifting into FIRST (1) takes you out of cruise
control. Many drivers find this to be too much trouble
and don't use cruise control on steep hills.
Ending Cruise Control
There are two ways to end cruise control:

Step lightly on the brake pedal.

Move the CRUISE switch to OFF.
Erasing Speed Memory
The cruise control set speed memory is erased when you
turn off the cruise control or the ignition.Exterior Lamps
The exterior lamp knob is
located to the left of the
steering wheel on the
instrument panel.
Pull the knob toward you to operate the lamps.
The exterior lamp knob has three positions:
Off: Pushing the knob all the way in turns off all lamps
except the Daytime Running Lamps (DRL).
Parking Lamps: Pulling the knob to the first position
turns on the parking lamps together with the following:

Sidemarker Lamps

Taillamps

License Plate Lamps

Instrument Panel Lights

2-43
Headlamps: Pulling the knob to the second position
turns on the headlamps, together with the previously
listed lamps and lights.
Wiper
-Activated Headlamps
This feature activates the headlamps and parking lamps
after the windshield wipers have been in use for
approximately 20 seconds.
In order to operate the wiper
-activated headlamps, the
Twilight Sentinel
must be turned on. This feature lights
the way in poor weather and it also makes your vehicle
more visible to other drivers. If the wiper
-activated
headlamps are on, and the ignition switch is turned off,
the wiper
-activated headlamps will immediately turn off.
The wiper
-activated headlamps will deactivate if you
turn off the Twilight Sentinel or if the windshield wipers
have been turned off for a period of one or two seconds.
Lamps On Reminder
If the exterior lamp knob is activated, you will hear a
warning chime if you open either door while leaving the
lamps on. An exception to this is when you're using
Twilight Sentinel.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier
for others to see the front of your vehicle during
the day. DRL can be helpful in many different
driving conditions, but they can be especially helpful
in the short periods after dawn and before sunset.
Fully functional daytime running lamps are required
on all vehicles first sold in Canada.
The DRL system will make the high
-beam headlamps
come on at reduced brightness when:

The ignition is on,

the exterior lamp knob is not in the
headlamp position

the transaxle is not in PARK (P).
When DRL are on, only your high
-beam headlamps
(at reduced brightness) will be on. No other exterior
lamps such as the parking lamps, taillamps, etc., will be
on when the DRL are being used. Your instrument panel
won't be lit up either.
