2-17
4. Remove the RADIO fuse (Fuse 17). This fuse is in
the main fuse block, located on the left side of your
instrument panel. When the main fuse block is open,
the RADIO fuse (Fuse 17) is located in the lower
right corner side of the fuse panel. See ªFuses and
Circuit Breakersº in the Index.
5. Turn the ignition to ACCESSORY.
You can now program your choices. After programming
a feature, you can exit the programming mode
at anytime.
You should hear two chimes to verify that the system is
in programming mode. You will also be able to set
Lockout Prevention, Keyless Entry Verification, Arming
Method and Arming Verification.
Lockout Prevention
With this feature, the power door locks will not lock
when the key is in the ignition in OFF and a door
is open.Programmable Modes
Your vehicle can be programmed to one of the
following modes.
Mode 1: Lockout Prevention Disabled (Doors will
lock/unlock when you press the power door
lock switch).
Mode 2: Lockout Prevention Enabled
Your vehicle comes with this feature set in Mode 2.
To change the mode:
1. Press the power lock switch on the door.
2. Count the number of chimes you hear. The number
of chimes tells you which mode your vehicle is
set for.
3. Press the LOCK switch on the door until you hear
the number of chimes that correspond to the mode
selection you want.
The mode you select is now set. You can either exit the
programming mode by following the instructions later in
this section or program the next feature available on
your vehicle.

yellowblue
2-18 Keyless Entry Verification
This means that when you use the keyless entry
transmitter to lock/unlock your vehicle, your headlamps
and parking lamps will flash briefly when you press
LOCK once. Your horn will sound briefly and your
headlamps and parking lamps will flash briefly when
you press LOCK a second time. Your headlamps
and parking lamps will flash briefly when you
press UNLOCK.
Programming Modes
Your vehicle can be programmed to one of the
following modes.
Mode 1: All Off (The headlamps will not flash and the
horn will not sound to provide you feedback that a
lock/unlock command has been received by the keyless
entry transmitter.)
Mode 2: Horn and Lamps/Lamps (Your horn will sound
briefly and your headlamps and parking lamps will flash
when you press LOCK on the keyless entry transmitter.
Only your headlamps and parking lamps will flash when
you press UNLOCK.)
Mode 3: Horn and Lamps (Your horn will sound briefly
and your headlamps and parking lamps will flash every
time you push LOCK or UNLOCK.)Mode 4: Lamps (Your headlamps and parking lamps
will flash every time you press LOCK or UNLOCK.)
Mode 5: Lamps/Horn and Lamps/Lamps (Your
headlamps and parking lamps will flash upon the first
press on LOCK, your headlamps and parking lamps will
flash and your horn will sound upon the second press on
LOCK and your headlamps and parking lamps will flash
upon any press on UNLOCK.)
Your vehicle comes with this feature set in Mode 5.
To change the mode:
1. Press the UNLOCK button on the keyless
entry transmitter.
2. Count the number of chimes you hear. The number
of chimes tells you which mode your vehicle is
set for.
3. Press the UNLOCK button on the keyless entry
transmitter until you hear the number of chimes that
correspond to the mode selection you want.
The mode you select is now set. You can either exit the
programming mode by following the instructions later in
this section or program the next feature available on
your vehicle.

yellowblue
2-19 Theft-Deterrent Arming Method
This means that both your keyless entry transmitter and
the power door lock switch will actively arm the system.
Programmable Modes
Your vehicle can be programmed to one of the
following modes.
Mode 1: Alarm System Off (The system will not arm.)
Mode 2: Keyless Entry Transmitter Lock (When you
lock your doors using the keyless entry transmitter, the
system will arm.)
Mode 3: Keyless Entry Transmitter/Power Door Lock
Switch (If you use either the keyless entry transmitter or
the power door lock switch to lock the doors, the system
will arm.)
Mode 4: Passive arming and Keyless Entry
Transmitter/Power Door Lock Switch Arming (The
system will arm itself after all doors are closed, plus
arming per Mode 3.)
Your vehicle comes with this feature set in Mode 3.To change the mode:
1. Press the UNLOCK switch on the door.
2. Count the number of chimes you hear. The number
of chimes tells you which mode your vehicle is
set for.
3. Press the UNLOCK switch on the door until you
hear the number of chimes that correspond to the
mode selection you want.
The mode you select is now set. You can either exit the
programming mode by following the instructions later in
this section or program the next feature available on
your vehicle.
Theft-Deterrent Arming Verification
This programmable feature allows you to change horn
and exterior lamp verification when arming and
disarming the system.

yellowblue
2-20
Programmable Modes
Your vehicle can be programmed to one of the
following modes.
Mode 1: All Off (No horn chirps or headlamps and
parking lamps will flash.)
Mode 2: Horn and Lamps (Your headlamps and parking
lamps will flash and your horn will chirp twice to verify the
system is armed using any arming method.) Headlamps and
parking lamps only will flash when disarming.
Mode 3: Horn and Lamps/Lamps (If you use the keyless
entry transmitter to arm the system, your headlamps and
parking lamps will flash and your horn will chirp twice
to verify that the system is armed. If you use either the
power door lock switch or passive arming, only your
headlamps and parking lamps will flash for
verification.) The headlamps and parking lamps will
flash only when disarming.
Mode 4: Lamps (When your vehicle arms, only your
headlamps and parking lamps will flash for
verification.) The headlamps and parking lamps will
flash only when disarming.
Your vehicle comes with this feature set in Mode 3.To change the mode:
1. Press the LOCK button on the keyless entry
transmitter.
2. Count the number of chimes you hear. The number
of chimes tells you which mode your vehicle is
set for.
3. Press the LOCK button on the keyless entry
transmitter until you hear the number of chimes that
corresponds to the mode selection you want.
The mode you select is now set. You can either exit the
programming mode by following the instructions later in
this section or program any of the previously mentioned
features on your vehicle.
Leaving Programming Mode
When programming is done, turn the ignition to OFF
and replace the RADIO fuse (Fuse 17).

yellowblue
2-21
Passlock
Your vehicle is equipped with the Passlock
theft
-deterrent system.
Passlock is a passive theft
-deterrent system. Passlock
enables fuel if the ignition lock cylinder is turned with a
valid key. If a correct key is not used or the ignition lock
cylinder is tampered with, fuel is disabled.
During normal operation, the SECURITY light will go
off approximately five seconds after the key is turned to
the RUN ignition position.
If the engine stalls and the SECURITY light flashes,
wait until the light stops flashing before trying to restart
the engine. Remember to release the key from START
as soon as the engine starts.
If the engine is running and the SECURITY light comes
on, you will be able to restart the engine if you turn the
engine off. However, your Passlock system is not
working properly and must be serviced by your dealer.
Your vehicle is not protected by Passlock at this time.
You may also want to check the fuse (see ªFuses and
Circuit Breakersº in the Index). See your dealer
for service.
In an emergency, call the Cadillac Roadside Assistance
Center at 1
-800-882-1112.
New Vehicle ªBreak-Inº
NOTICE:
Your vehicle doesn't need an elaborate
ªbreak
-in.º But it will perform better in the long
run if you follow these guidelines:

Keep your speed at 55 mph (88 km/h) or
less for the first 500 miles (805 km).

Don't drive at any one speed
-- fast or
slow
-- for the first 500 miles (805 km).
Don't make full
-throttle starts.

Avoid making hard stops for the first
200 miles (322 km) or so. During this time
your new brake linings aren't yet broken
in. Hard stops with new linings can mean
premature wear and earlier replacement.
Follow this breaking
-in guideline every
time you get new brake linings.

Don't tow a trailer during break
-in.
See ªTowing a Trailerº in the Index for
more information.

yellowblue
2-22
Ignition Positions
CAUTION:
Leaving children in a vehicle with the ignition
key is dangerous for many reasons. A child or
others could be badly injured or even killed.
They could operate power windows or other
controls or even make the vehicle move. Don't
leave the keys in the vehicle with children.
Use your key to start your vehicle. The key lets you turn
the ignition switch to five different positions.ACCESSORY (A): This position lets you use things
like the radio and the windshield wipers when the
engine is off. Push in the key and turn it toward you.
Your steering wheel will remain locked, just as it was
before you inserted the key.
LOCK (B): This position locks your ignition, steering
wheel and transmission. It's a theft
-deterrent feature.
You will only be able to remove your key when the
ignition is turned to LOCK.

yellowblue
2-23
OFF (C): This position lets you turn off the engine but
still turn the steering wheel. It doesn't lock the steering
wheel like LOCK. Use OFF if you must have your
vehicle in motion while the engine is off (for example, if
your vehicle is being pushed).
RUN (D): This is the position for driving.
START (E): This position starts your engine.
NOTICE:
If your key seems stuck in LOCK and you can't
turn it, be sure you are using the correct key; if
so, is it all the way in? If it is, then turn the
steering wheel left and right while you turn the
key hard. But turn the key only with your hand.
Using a tool to force it could break the key or the
ignition switch. If none of this works, then your
vehicle needs service.
Retained Accessory Power
Your vehicle is equipped with a Retained Accessory
Power (RAP) feature which will allow certain features
of your vehicle to continue to work up to 20 minutes
after the ignition key is turned to OFF.
Your audio system and power windows will work when
the ignition key is turned to RUN or ACCESSORY.
Once the key is turned from RUN to OFF, these features
will continue to work for up to 20 minutes or until a
door is opened.
Starting Your Engine
Move your shift lever to PARK (P) or NEUTRAL (N).
Your engine won't start in any other position
-- that's a
safety feature. To restart when you're already moving,
use NEUTRAL (N) only.
NOTICE:
Don't try to shift to PARK (P) if your vehicle is
moving. If you do, you could damage the
transmission. Shift to PARK (P) only when your
vehicle is stopped.

yellowblue
2-24 How to Start the Engine
1. Without pushing the accelerator pedal, turn your
ignition key to START. When the engine starts, let
go of the key. The idle speed will go down as your
engine gets warm.
NOTICE:
Holding your key in START for longer than
15 seconds at a time will cause your battery to be
drained much sooner. And the excessive heat can
damage your starter motor. Wait about
15 seconds between each try to help avoid
draining your battery or damaging your starter.
2. If it doesn't start right away, hold your key in
START. If it doesn't start in 10 seconds, push the
accelerator pedal all the way down for five more
seconds, unless it starts sooner.3. If your engine still won't start (or starts but then
stops), wait 15 seconds and start over.
When the engine starts, let go of the key and the
accelerator pedal.
NOTICE:
Your engine is designed to work with the
electronics in your vehicle. If you add electrical
parts or accessories, you could change the way
the engine operates. Before adding electrical
equipment, check with your dealer. If you don't,
your engine might not perform properly.
If you ever have to have your vehicle towed, see
the part of this manual that tells how to do it
without damaging your vehicle. See ªTowing
Your Vehicleº in the Index.

yellowblue
2-25
Engine Coolant Heater (If Equipped)
In very cold weather, 0
F
(
-18
C) or colder, the
engine coolant heater
can help.
You'll get easier starting and better fuel economy during
engine warm
-up. Usually, the coolant heater should be
plugged in a minimum of four hours prior to starting
your vehicle.
To Use the Engine Coolant Heater
1. Turn off the engine.
2. Open the hood and unwrap the electrical cord.
The engine coolant heater electrical cord is located
on the driver's side of the engine compartment, near
the power steering reservoir.3. Plug it into a normal, grounded 110
-volt AC outlet.
CAUTION:
Plugging the cord into an ungrounded outlet
could cause an electrical shock. Also, the wrong
kind of extension cord could overheat and cause
a fire. You could be seriously injured. Plug the
cord into a properly grounded three
-prong
11 0
-volt AC outlet. If the cord won't reach, use a
heavy
-duty three-prong extension cord rated for
at least 15 amps.
4. Before starting the engine, be sure to unplug and store
the cord as it was before to keep it away from moving
engine parts. If you don't, it could be damaged.
How long should you keep the coolant heater plugged
in? The answer depends on the outside temperature, the
kind of oil you have, and some other things. Instead of
trying to list everything here, we ask that you contact
your dealer in the area where you'll be parking your
vehicle. The dealer can give you the best advice for that
particular area.

yellowblue
2-26
Automatic Transmission Operation
There are several different positions for your shift lever.
Your vehicle features an electronic shift position
indicator within the instrument cluster. This display
must be powered anytime the shift lever is capable of
being moved out of PARK (P). This means that if your
key is in OFF, rather than LOCK, there will be a small
current drain on your battery which could discharge
your battery over a period of time. If you need to leave
your key in OFF for an extended period for any reason,
it is recommended that you disconnect the battery cable
from the battery to prevent discharging your battery.PARK (P): This locks your rear wheels. It's the best
position to use when you start your engine because your
vehicle can't move easily.
CAUTION:
It is dangerous to get out of your vehicle if the
shift lever is not fully in PARK (P) with the
parking brake firmly set. Your vehicle can roll.
Don't leave your vehicle when the engine is
running unless you have to. If you have left the
engine running, the vehicle can move suddenly.
You or others could be injured. To be sure your
vehicle won't move, even when you're on fairly
level ground, always set your parking brake and
move the shift lever to PARK (P).
See ªShifting Into PARK (P)º in the Index. If you
have four
-wheel drive, your vehicle will be free to
roll
-- even if your shift lever is in PARK (P) -- if
your transfer case is in NEUTRAL. So, be sure
the transfer case is in a drive gear
-- not in
NEUTRAL. See ªFour
-Wheel Drive (Automatic
Transfer Case)º in the Index. If you're pulling a
trailer, see ªTowing a Trailerº in the Index.
