CADILLAC ESCALADE 2002 2.G Owners Manual

2-92 Trip

Each press of the TRIP button will change the
display between personal trip computer, business trip
computer, timer, vehicle history, annual mileage and
a blank display.
Personal Trip Computer and Business
Trip Computer

Each press of the arrow button will change the
display between turn on/off, trip odometer, fuel used,
average fuel economy and average speed.

The ON/OFF button will turn the trip computer on
and off. The information on the trip computer only
gets updated when it is turned on. The personal and
business computers are independent, i.e. turning one
of them on does not turn the other off.

All information associated with the trip computer
will be reset when the RESET button is pressed.

If the RESET button is pressed and held for more
than two seconds, all of the trip computer settings
will reset starting from the last ignition cycle
(turning the ignition from OFF to RUN). This
feature is for someone who has forgotten to reset the
trip computer when pulling out of the driveway and
does not realize it until after driving for awhile.Timer

Each press of the ON/OFF button will turn the timer
on or off.

The RESET button will reset the timer to 00:00:00.

If turned on, the timer will accumulate whenever
the SIC is powered (the engine does not have to
be running).

The timer will rollover after 99:59:59.
Vehicle History Last 15 Days

The first press of the arrow button will display the
maximum speed and accumulated mileage for the
current day.

Every press of the arrow button after will display the
maximum speed and accumulated mileage for the
previous day.

This feature requires the date and time to be set
correctly. Refer to the setting of day/date/time under
the MENU button explained later in this section.

2-93
Annual Mileage

The annual mileage displayed is the mileage
accumulated since the annual mileage was reset.

Pressing the RESET button will reset the annual
mileage to 0.

Pressing the arrow button will display the ratio of
personal trip computer mileage to annual mileage
as a percent.

Pressing the arrow button again will display the ratio
of business trip computer mileage to annual mileage
as a percent.
Menu
Press the MENU button to choose a feature you would
like to personalize (the features are listed below). Each
press of the button will display a new item that can be
personalized. Use the arrow button to choose the
setting you would like to use within the chosen feature.
For example: Say you would like to personalize the
automatic door locks so that the automatic locking
feature is disabled. You would do the following:
1. First press the MENU button until you reach the
Automatic Door Lock screen.2. Next, press the arrow button until you find the
Disabled setting.
3. The setting is now actually set without having to
do anything else. You can do one of three things
at this point:

You can leave the personalization mode by
pressing FUEL or TRIP.

You can just let the SIC exit the personalization
mode on its own by waiting approximately
15 seconds without touching any buttons,

or you can press the MENU key to move on to
the next programmable feature.
The following is a list of the personal settings that can
be changed:
Automatic Door Lock

Enabled: Doors automatically lock when
transmission is shifted out of PARK (P).

Disabled: Doors do not lock automatically.

2-94
Automatic Door Unlock

Driver: Driver's door unlocks when transmission is
shifted into PARK (P).

All: All doors unlock when transmission is shifted
into PARK (P).

Disabled: Doors do not unlock automatically.
Remote Lock Feedback

Horn: Horn chirps on second press of the LOCK
button on the keyless entry transmitter.

Lamps: Parking lamps flash on each press of the
LOCK button on the keyless entry transmitter.

Horn and Lamps: Parking lamps flash on each
press, horn chirps on second press of LOCK on the
keyless entry transmitter.

None: No horn or lamp feedback to the LOCK
button on the keyless entry transmitter.
Remote Unlock Feedback

Horn: Horn chirps on second press of the UNLOCK
button on the keyless entry transmitter.

Lamps: Parking lamps flash on each press of the
UNLOCK button on the keyless entry transmitter.
Horn and Lamps: Parking lamps flash on each
press, horn chirps on the second press of the
UNLOCK button on the keyless entry transmitter.

None: No horn or lamp feedback will occur when
the UNLOCK button on the keyless entry transmitter
is pressed.
Headlamp Delay

None: Headlamps do not stay on after the ignition is
turned to OFF.

10/20/30/60/120/180 Seconds: Amount of time
headlamps stay on after the ignition is turned to
OFF when it is dark (switch must be in auto
headlamp position).
Perimeter Lamps

Enabled: Parking lamps, headlamps and puddle
lamps turn on for 40 seconds with the UNLOCK
button on the keyless entry transmitter. This feature
only operates when it is dark.

Disabled: Feature disabled, no perimeter lamps will
come on.

2-95
Seat and Mirror Recall

Remote: When the remote keyless entry transmitters
are programmed for each driver (driver 1 or 2),
pressing the UNLOCK button on the transmitters
will move the seat and mirrors to the stored memory
position for the driver associated with that particular
transmitter (driver 1 or 2). For more information on
seat and mirror recall functions see ªMemory Seat
and Memory Mirrors in the Index.º

Key In: Inserting the key into the ignition will cause
the seat and mirrors to move to stored memory
position for driver 1 or 2.

Disabled: Position recall will not work with the
keyless entry transmitter or when key is placed in the
ignition. Driver must manually select memory button
1 or 2 to activate the memory seat recall when
disable is selected.
Exit Position of Seat

Enabled: Removing the key will cause the seat to
move to the stored driver 1 or 2 exit position.

Disabled: Seat will not move to exit position when
key is removed from ignition. Driver must manually
press EXIT button to activate the seat exit position
feature when disable is selected.Mirror Reverse Tilt

Passenger: Mirror on the passenger's side of vehicle
will tilt down to a stored memory position for driver
1 or 2 when the vehicle is placed in REVERSE (R).

Driver: Mirror on the driver's side of the vehicle
will tilt down to a stored memory position for driver
1 or 2 when the vehicle is placed in REVERSE (R).

All: Both the driver's and passenger's side mirrors
will tilt down to a stored memory position for driver
1 or 2 when the vehicle is placed in REVERSE (R).

Disabled: No mirrors will tilt when the vehicle is
placed in REVERSE (R).
Alarm Warning

Horn: Horn will sound when the alarm is active.

Lamps: Headlamps and park lamps will cycle on
and off when alarm is activated.

Horn and Lamps: Horn and lamps will alternate
when the alarm is activated.

None: No alarm warning will come on.

2-96
Language

English: All information displayed in English.

French: All information displayed in French.

Spanish: All information displayed in Spanish.

Arabic: All information displayed in Arabic.
Display Units

English: Units displayed in English units.

Metric: Units displayed in metric units.
Day/Date/Time

The RESET button will enable the operator to reset
the day/date/time. Each press of the RESET button
will scroll through the following: set year, set month,
set day, set hour, set minutes and set AM/PM.

Whichever is currently selected (i.e. year, month,
day, etc.) will flash. The arrow button is then used to
adjust the value. Each press of the arrow button will
change the value by one. If the arrow button is
pushed and held, the value will keep changing until
the button is released.

While in menu mode, the SIC will display the
day/date if no buttons have been pressed for more
than 15 seconds.Language and Personalization Reset

Press and hold the MENU button. After two seconds,
the display will begin cycling through the languages
at one second intervals. Release the MENU button
when the desired language is displayed.

The previous action will also reset the
personalization values to their factory default
settings which are as follows:
1.Automatic Door Lock: Enabled
2.Automatic Door Unlock: All
3.Remote Lock Feedback: Horn
4.Remote Unlock Feedback: Lamps
5.Headlamp Delay: 30 seconds
6.Perimeter Lamps: Enabled
7.Memory Position Recall: Key In
8.Exit Position of Seat: Enabled
9.Mirror Reverse Tilt: Passenger
10.Alarm Warning: Horn and Lamps
11.Display Units: English

2-97
Ultrasonic Rear Parking
Assist (URPA)
Ultrasonic Rear Parking Assist can help you to
determine how close an object is to your rear bumper
within a given area, making parking easier.
The URPA display is
located inside the vehicle,
on the passenger's side rear
upper trim panel. It has
three color
-coded lights that
can be seen through the
rearview mirror or by
turning around.
URPA can be disabled by
pressing the URPA on/off
button located near the
climate control system
and radio.
How the System Works
URPA comes on automatically when the shift lever is
moved into REVERSE (R) and the vehicle speed is less
than 3 mph (5 km/h). When the system comes on,
the three lights on the display will illuminate to let you
know that the system is working. URPA senses how
close your vehicle is to an object. The distance is
determined by the four ultrasonic sensors located on the
rear bumper. When shifting into REVERSE (R) and an
object is detected, one of the following will occur:

2-98
A chime will sound the first time an object is detected.
URPA can detect objects 3 inches (7.6 cm) and wider,
and at least 10 inches (25.4 cm) tall, but it cannot detect
objects that are above the center of the Cadillac crest
badge. In order for the rear sensors to recognize an
object, it must be within operating range.If the URPA system is not functioning properly, the
display will flash red, indicating that there is a problem.
The light will also flash red while driving if a trailer or
trailer hitch ball mount is attached to your vehicle or if a
bicycle or object is on the back of, or hanging out of
your vehicle. The light will continue to flash until the
trailer or the object is removed and your vehicle is
driven forward at least 15 mph (25 km/h).
It may also flash red if the ultrasonic sensors are not
kept clean. So be sure to keep your rear bumper free of
mud, dirt, snow, ice and slush or the system may not
work properly. If after cleaning the rear bumper and
driving forward at least 15 mph (25 km/h), the display
continues to flash red, see your dealer. It may also flash
red if your vehicle is moving in REVERSE (R) at a
speed greater than 3 mph (5 km/h).
Other conditions that may affect system performance
include things like the vibrations from a jackhammer
or the compression of air brakes on a very large truck.
As always, drivers should use care when backing
up a vehicle. Always look behind you, being sure to
check for other vehicles, obstructions and blind spots.
For cleaning instructions, see ªCleaning Your Vehicleº
in the Index.

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Electronic Climate Control System
3
-7 Air Conditioning
3
-7 Heating
3
-8 Defogging and Defrosting
3
-8 Rear Window Defogger
3
-9 Ventilation System
3
-10 Audio Systems
3
-11 AM-FM Stereo with Cassette Tape
Player (Bose
)3
-15 Rear Seat Audio (RSA)
3
-17 Compact Disc Changer
3
-20 Theft-Deterrent Feature
3
-22 Audio Steering Wheel Control
3
-23 Understanding Radio Reception
3
-23 Tips About Your Audio System
3
-24 Care of Your Cassette Tape Player
3
-26 Care of Your Compact Discs
3
-26 Care of Your Compact Disc Changer
3
-26 Diversity Antenna

3-2
Comfort Controls
Electronic Climate Control System
Fan Knob
The knob on the left side of the electronic climate control
panel is used to regulate the fan speed. To manually
increase airflow, move the knob clockwise. To manually
decrease airflow, move it counterclockwise.
OFF: If the knob is in OFF, outside air will still enter
the vehicle, and will be directed based on the position of
the mode knob.
AUTO: If the knob is in AUTO, the fan speed will vary
as the system maintains the selected temperature.
When both the fan knob and mode knob are in the AUTO
position, the system will then automatically maintain the
desired cabin temperature as selected by the temperature
knob. Manual operation is also available.Temperature Knob
The middle knob on the control panel is used to select
the desired air temperature in your vehicle. This knob
will allow you to adjust the interior air temperature
independent of the mode knob setting. Move the knob
clockwise toward 82 for warmer air. Move the knob
counterclockwise toward 66 for cooler air. When the
system is set for automatic operation, sensors will
control the fan speed.
Full Hot: If you turn the temperature knob past 82, the
system will go into the ªfull hotº mode. The system will
remain at that maximum heating setting and the fan will
blow at the speed to which the fan knob is set. If the fan
is in AUTO, it will run at full speed.
Full Cold: If you turn the temperature knob past 66, the
system will go into the ªfull coldº mode. The system
will remain at that maximum cooling setting and the fan
will blow at the speed to which the fan knob is set. If the
fan is in AUTO, it will run at full speed.

3-3
Mode Knob - Automatic Operation
The right knob on the control panel allows you to
choose the direction of air delivery. When the system is
set in AUTO mode, sensors will control the air delivery
mode. Air will come primarily from the floor or
instrument panel outlets, with some air directed to the
windshield to prevent fogging.
When the system is in AUTO mode, the air conditioning
light will turn on, and the recirculation and outside air
lights turn off. With the system in full auto control
(both the fan and mode knobs in AUTO), you still
have the ability to override any function. However,
continually overriding the outside air or the A/C
compressor will limit the ability of the system to cool
the vehicle quickly.
If you push a button for a function which is not
available, the light next to that button will flash
three times to alert you that it's not available.
To find your comfort zone, start with the 74 setting
and allow about 20 minutes for the system to adjust
the temperature if necessary.With the automatic setting, the air conditioning
compressor automatically cycles when needed to cool
the air. In cold weather, when the system senses the need
for heat, the airflow will be directed out of the floor
outlets. As the interior temperature approaches a desired
setting, the fan speed will decrease. To maintain interior
comfort, the airflow will adjust between the instrument
panel air outlets and floor outlets. On bright sunny days
in cool weather, the airflow may come out of the air
conditioning and floor outlets (bi
-level mode) to
maintain comfort and prevent stuffiness.
To avoid blowing cold air in cold weather, the system
will delay turning on the fan until warm air is available.
The length of delay depends on the outside air
temperature, engine coolant temperature or the time
since the engine was last started. As the coolant
warms up, the fan speed will gradually increase and
air will flow from the floor outlets, with some airflow
to the windshield to prevent fogging under most
normal conditions.
Be careful not to put anything over the solar sensor
located near the center of the instrument panel.
This sensor is used by the automatic system to
regulate temperature.
