CADILLAC ESCALADE 2002 2.G Owner's Manual

1-9
3. Pull up on the strap loop
located at the rear of
the seat cushion and
pull the seat cushion up.
Then fold it forward.
4. Pull the seatback forward and fold it down until
it is flat.
If the seatback cannot fold flat because it interferes with
the cushion, try moving the front seat forward and/or
bringing the front seatback more upright.Returning the Seats to an Upright Position
To return the seat to the upright position,
do the following:
1. Lift the seatback up and push it rearward
all the way.
2. Lower the seat cushion until it latches
into position.
3. Pull forward on the seatback and up on the seat
cushion to make sure the seat is securely in place.
4. Return the headrest to the upright position by
pulling the top of the headrest upwards until
you hear a click.
5. Check to see that the safety belt buckles on
the driver's side seatback are accessible to the
outboard and center occupants and are not under
the seat cushions.

1-10
Rear Seat (Second Row) Armrest
The second row seat has a center fold down armrest
which contains a storage compartment. To release the
armrest, locate the loop attached to the armrest and
then pull it up and then down. Within the storage
compartment of the armrest you will find two sets of
earbud headphones which can be used for the rear seat
audio. The headphones plug into the rear seat audio
jacks provided in the back of the center console. See
ªRear Seat Audioº in the Index for more information.Entry/Exit to/from the Third Row Seat
To enter or exit the third row seat you must fold
the second row seat down following the instructions
given previously.
If you are exiting the third row seat with no assistance,
do the following:
1. Reach over the second
row seat and pull up on
the strap loop and then
pull the seat cushion up
and push it forward.
2. Next, push the seatback forward until it is flat with
the floor.
Be sure to return the seat to the passenger position when
you are finished. Pull forward and push rearward on the
seatback to make sure it is locked in place.

1-11
Folding the Third Row Seat
To fold the seatbacks, do the following:
1. Pull up on the release
lever, labeled 1, located
on the rear of the
seatback and push the
seatback forward.Returning the Seat(s) to an Upright Position
To return the seatback to an upright position,
do the following:1. Pull up on the release
lever labeled 1 and then
pull up on the seatback
or the assist strap
located on the outboard
side of the seat until the
seatback locks into the
upright position.
2. Push forward on the seatback to make sure it is
locked into position.

1-12
Tilting the Third Row Seat
1. Fold the seatbacks forward using the instructions
listed previously.
2. Unlatch the seat from
the floor by pulling up
on the lever labeled 2,
located on the rear of
the seat.
3. Lift the rear of the seat up off of the floor and push it
forward until it locks into place. You will not be able
to unlatch the seat from the floor unless the seatback
is folded down.
The seat will now remain locked in the upright position.
1. Pull the lever labeled 3 toward you.
2. While still holding lever 3 toward you, grasp the top
of the seat and pull it toward you slightly.

1-13
3. Let go of lever 3 and pull the seat completely down.
4. Push down on the seat firmly. Try pulling it up to be
sure it is locked into place.
5. Pull up on the release
lever labeled 1 and then
pull up on the seatback
or the assist strap
located on the outboard
side of the seat until the
seatback locks into the
upright position.Removing the Third Row Seats
Your vehicle's third row seats can be taken out for
more cargo space. To remove a rear split bench seat,
do the following:
1. Open the liftgate.
2. Pull up on the release
lever, labeled 1, located
on the rear of the
seatback and push the
seatback forward.

1-14
3. To unlatch the rear of
the seat from the floor,
pull up on the release
lever labeled 2, at the
rear of the seat, and lift
the rear of the seat up
off of the floor.
4. Squeeze the release handle while pulling the seat out.
5. While holding the rear of the seat up, roll the seat out
of the vehicle.

1-15
Replacing the Rear Seats
CAUTION:
A seat that isn't locked into place properly can
move around in a collision or sudden stop. People
in the vehicle could be injured. Be sure to lock
the seat into place properly when installing it.
To put a seat back in do the following:
1. While holding the rear of the seat up, slide the front
wheels into the slots on the floor. The front latches
should lock into place. If latches do not lock,
try tilting the rear of the seat upwards.
2. Once the latches are
engaged, let the seat
drop into place. Release
the lever labeled 1 and
pull the seatback up
using the assist strap on
the outboard side of the
seat to return it to its
upright position.
3. Push and pull on the seat to make sure it is locked
into place. The seatback cannot be raised to the
upright position unless the seat is secured to
the floor.

1-16 Heated Rear Seats (2nd Row)
The controls are located
on the back of the
center console.
The ignition must be in RUN for this feature to operate.
To activate the heated seats, press the button once for
the HI heat setting. Press the button again for the LO
heat setting. To turn off the heated seats, press the
button a third time. An indicator light on the button will
illuminate for each heat setting anytime the heated seats
are operating.
The heated seats will be canceled after the ignition is
turned to OFF. If you still want to use the heated seat
feature after you restart your vehicle, you will need to
press the heated seat button again.
Safety Belts: They're for Everyone
This part of the manual tells you how to use safety belts
properly. It also tells you some things you should not do
with safety belts.
And it explains the Supplemental Restraint System (SRS),
or air bag system.
CAUTION:
Don't let anyone ride where he or she can't wear
a safety belt properly. If you are in a crash and
you're not wearing a safety belt, your injuries
can be much worse. You can hit things inside the
vehicle or be ejected from it. You can be seriously
injured or killed. In the same crash, you might
not be if you are buckled up. Always fasten your
safety belt, and check that your passengers' belts
are fastened properly too.

1-17
CAUTION:
It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision,
people riding in these areas are more likely to be
seriously injured or killed. Do not allow people
to ride in any area of your vehicle that is not
equipped with seats and safety belts. Be sure
everyone in your vehicle is in a seat and using a
safety belt properly.
Your vehicle has a light
that comes on as a reminder
to buckle up. See ªSafety
Belt Reminder Lightº in
the Index.In most states and Canadian provinces, the law says to
wear safety belts. Here's why: They work.
You never know if you'll be in a crash. If you do have
a crash, you don't know if it will be a bad one.
A few crashes are mild, and some crashes can be so
serious that even buckled up a person wouldn't survive.
But most crashes are in between. In many of them,
people who buckle up can survive and sometimes walk
away. Without belts they could have been badly hurt
or killed.
After more than 30 years of safety belts in vehicles,
the facts are clear. In most crashes buckling up does
matter ... a lot!

1-18 Why Safety Belts Work
When you ride in or on anything, you go as fast as it goes.
Take the simplest vehicle. Suppose it's just a seat on wheels.
Put someone on it.
