Page 491 of 616

CADILLAC ESCALADE 2010 3.G Owners Manual Notice:Ignoring these steps could result in costlydamage to the vehicle that would not be covered bythe warranty.
Trying to start the vehicle by pushing or pulling itwill not work, and it could damage

Page 492 of 616

CADILLAC ESCALADE 2010 3.G Owners Manual The remote negative (-) terminal is a stud locatedon the right front of the engine, where the negativebattery cable attaches.
SeeEngine Compartment Overviewon page 7!16for more information on the loca

Page 493 of 616

CADILLAC ESCALADE 2010 3.G Owners Manual {WARNING:
Fans or other moving engine parts can injure you
badly. Keep your hands away from moving parts
once the engine is running.
5. Check that the jumper cables do not have loose ormissing insulat

Page 494 of 616

CADILLAC ESCALADE 2010 3.G Owners Manual 9. Connect the other end of the negative (!) cable tothe remote negative (!) terminal, on the vehiclewith the dead battery.
10. Now start the vehicle with the good battery and runthe engine for a whil

Page 495 of 616

CADILLAC ESCALADE 2010 3.G Owners Manual 3. Disconnect the red positive (+) cable from thevehicle with the good battery.
4. Disconnect the red positive (+) cable from theother vehicle.
5. Return the remote positive (+) terminal cover,if the

Page 496 of 616

CADILLAC ESCALADE 2010 3.G Owners Manual What to Use
Refer to the Maintenance Schedule to determine whatkind of lubricant to use. SeeRecommended Fluids andLubricants on page 8!10.
Rear Axle
When to Check Lubricant
It is not necessary to regu

Page 497 of 616

CADILLAC ESCALADE 2010 3.G Owners Manual What to Use
Refer to the Maintenance Schedule to determine whatkind of lubricant to use. SeeRecommended Fluids andLubricants on page 8!10.
Front Axle
When to Check and Change Lubricant
It is not neces

Page 498 of 616

CADILLAC ESCALADE 2010 3.G Owners Manual Headlamp Aiming
The vehicle has a visual optical headlamp aimingsystem. The aim of the headlamps have been preset atthe factory and should need no further adjustment.
However, if the vehicle is damage

Page 499 of 616

CADILLAC ESCALADE 2010 3.G Owners Manual 4. At a wall, measure from the ground upward (A) tothe recorded distance from Step 3 and mark it.
5. Draw or tape a horizontal line (B) on the wall thewidth of the vehicle at the height of the mark in

Page 500 of 616

CADILLAC ESCALADE 2010 3.G Owners Manual 9. Make sure that the light from the headlamp ispositioned at the bottom edge of the horizontaltape line. The lamp on the left (A) shows thecorrect headlamp aim. The lamp on the right (B)shows the inc
