352 TECHNICAL DATA
Technical Data
Vehicle Identification
Vehicle IdentificationNumber (VIN) . . . . . . . . . . . . . . . . . . . 352
Service Parts Identification . . . . . . 352
Vehicle Data
Capacities and Specifications . . . . 353
Engine Drive Belt Routing . . . . . . . 355
Vehicle Identification
Vehicle Identification
Number (VIN)
This legal identifier is in the front
corner of the instrument panel, on the
driver side of the vehicle. It can be
seen through the windshield from
outside. The Vehicle Identification
Number (VIN) also appears on the
Vehicle Certification and Service Parts
labels and certificates of title and
registration.
Engine Identification
The eighth character in the VIN is the
engine code. This code identifies the
vehicle's engine, specifications, and
replacement parts. See “EngineSpecifications”
underCapacities and
Specifications 0353 for the vehicle's
engine code.
Service Parts Identification
There may be a large barcode on the
certification label on the center pillar
that you can scan for the following
information:
. Vehicle Identification
Number (VIN)
. Model designation
. Paint information
. Production options
If there is not a large barcode on this
label, then you will find this same
information on a label inside of the
glove box.

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566588) - 2020 - CRC - 4/24/19
TECHNICAL DATA 353
Vehicle Data
Capacities and Specifications
The following approximate capacities are given in metric and English conversions. SeeRecommended Fluids and Lubricants
0 349 for more information.
Application Capacities
Metric English
Air Conditioning Refrigerant For the air conditioning system refrigerant type and charge amount, see the refrigerant label under thehood. See your dealer for more information.
Engine Cooling System* 16.8 L 17.8 qt
Engine Oil with Filter 7.6 L 8.0 qt
Fuel Tank Short Wheelbase 98.4 L 26.0 gal
Long Wheelbase 119.2 L 31.5 gal
Transfer Case Fluid 1.5 L 1.6 qt
Wheel Nut Torque 190 Y140 lb ft
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this manual.
Recheck fluid level after filling.
*Engine cooling system capacity values are based on the entire cooling system and its components.

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566588) - 2020 - CRC - 4/24/19
354 TECHNICAL DATA
Engine Specifications
EngineVIN CodeSpark Plug Gap
6.2L V8 J0.95–1.10mm (0.037–
0.043 in)
Spark plug gaps are preset by the manufacturer. Re-gapping the spark plug is not recommended and can damage the
spark plug.

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566588) - 2020 - CRC - 4/24/19
TECHNICAL DATA 355
Engine Drive Belt Routing

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566588) - 2020 - CRC - 4/24/19
CUSTOMER INFORMATION 365
Insurance pays the bill for the repair,
but you must live with the repair.
Depending on your policy limits, your
insurance company may initially value
the repair using aftermarket parts.
Discuss this with the repair
professional, and insist on Genuine
GM parts. Remember, if the vehicle is
leased, you may be obligated to have
the vehicle repaired with Genuine GM
parts, even if your insurance coverage
does not pay the full cost.
If another party's insurance company
is paying for the repairs, you are not
obligated to accept a repair valuation
based on that insurance company's
collision policy repair limits, as you
have no contractual limits with that
company. In such cases, you can have
control of the repair and parts choices
as long as the cost stays within
reasonable limits.Publication Ordering
Information
Service Manuals
Service manuals have the diagnosis
and repair information on the engine,
transmission, axle, suspension, brakes,
electrical system, steering system,
body, etc.
Customer Literature
Owner’s manuals are written
specifically for owners and are
intended to provide basic operational
information about the vehicle. The
owner’s manual includes the
Maintenance Schedule for all models.
Customer literature publications
available for purchase include owner’s
manuals, warranty manuals,
infotainment manuals, and portfolios.
Portfolios include an owner’s manual,
warranty manual, infotainment
manual, if applicable, and zip lock bag
or pouch.
Current and Past Models
Service manuals and customer
literature are available for many
current and past model year GM
vehicles.
To order, call 1-800-551-4123
Monday–Friday, 8:00 a.m.–6:00 p.m.
eastern time
For credit card orders only (VISA,
MasterCard, or Discover), see Helm,
Inc. at: www.helminc.com.
To order by mail, write to:
Helm, Incorporated
Attention: Customer Service
47911 Halyard Drive
Plymouth, MI 48170
Make checks payable in U.S. funds.

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566588) - 2020 - CRC - 4/24/19
CUSTOMER INFORMATION 367
Reporting Safety Defects
to the Canadian
Government
If you live in Canada, and you
believe that the vehicle has a
safety defect, notify Transport
Canada immediately, and notify
General Motors of Canada
Company. Call Transport Canada
at 1-800-333-0510; go to:
www.tc.gc.ca/recalls (English)
www.tc.gc.ca/rappels (French)
or write to:
Transport Canada
Motor Vehicle Safety Directorate
Defect Investigations and Recalls
Division
80 Noel Street
Gatineau
,QC J8Z 0A1
Reporting Safety Defects
to General Motors
In addition to notifying NHTSA (or
Transport Canada) in a situation like
this, notify General Motors.
In the U.S., call 1-800-458-8006,
or write:
Cadillac Customer Assistance Center
Cadillac Motor Car Division
P.O. Box 33169
Detroit, MI 48232-5169
In Canada, call 1-888-446-2000,
or write:
Canadian Cadillac Customer Care
Centre, Mail Code: CA1-163-005
General Motors of Canada Company
1908 Colonel Sam Drive
Oshawa, Ontario L1H 8P7
In Mexico, call 01-800-466-0805 or
01-800-212-234-5522.
In other Central America and
Caribbean Countries, call
52-722-236-0680.
Vehicle Data Recording
and Privacy
The vehicle has a number of
computers that record information
about the vehicle’s performance and
how it is driven or used. For example,
the vehicle uses computer modules to
monitor and control engine and
transmission performance, to monitor
the conditions for airbag deployment
and deploy them in a crash, and,
if equipped, to provide antilock
braking to help the driver control the
vehicle. These modules may store data
to help the dealer technician service
the vehicle or to help GM improve
safety or features. Some modules may
also store data about how the vehicle
is operated, such as rate of fuel
consumption or average speed. These
modules may retain personal
preferences, such as radio presets, seat
positions, and temperature settings.
Cybersecurity
GM collects information about the use
of your vehicle including operational
and safety related information. We

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566588) - 2020 - CRC - 4/24/19
ONSTAR 371
Or
.Give OnStar Turn-by-Turn
Navigation voice commands.
. Obtain and customize the Wi-Fi
hotspot name or SSID and
password, if equipped.
Press
Qto connect to an Advisor to:
. Verify account information or
update contact information.
. Get driving directions.
. Receive a Diagnostic check of the
vehicle's key operating systems.
. Receive Roadside Assistance.
. Manage Wi-Fi Settings,
if equipped.
Press
>to get a priority connection
to an OnStar Advisor available 24/7 to:
. Get help for an emergency.
. Be a Good Samaritan or respond
to an AMBER Alert.
. Get assistance in severe weather
or other crisis situations and find
evacuation routes.
OnStar Services
Emergency
Emergency Services require an active
safety and security plan. With
Automatic Crash Response, built-in
sensors can automatically alert a
specially trained OnStar Advisor who
is immediately connected in to the
vehicle to help.
Press
>for a priority connection to
an OnStar Advisor who can contact
emergency service providers, direct
them to your exact location, and relay
important information.
With OnStar Crisis Assist, specially
trained Advisors are available
24 hours a day, 7 days a week, to
provide a central point of contact,
assistance, and information during a
crisis.
With Roadside Assistance, Advisors
can locate a nearby service provider to
help with a flat tire, a battery jump,
or an empty gas tank.
Security
If equipped, OnStar provides these
services:
. With Stolen Vehicle Assistance,
OnStar Advisors can use GPS to
pinpoint the vehicle and help
authorities quickly recover it.
. With Remote Ignition Block,
if equipped, OnStar can block the
engine from being restarted.
. With Stolen Vehicle Slowdown,
if equipped, OnStar can work with
law enforcement to gradually slow
the vehicle down.
Theft Alarm Notification
If equipped, if the doors are locked
and the vehicle alarm sounds, a
notification by text, e-mail, or phone
call will be sent. If the vehicle is
stolen, an OnStar Advisor can work
with authorities to recover the vehicle.

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566588) - 2020 - CRC - 4/24/19
380 INDEX
IndexA
Accessories and Modifications . . . . . 257
Accessory Power . . . . . . . . . . . . . . . . . . . . 188
Active Fuel Management . . . . . . . . . . . 190
Adaptive Cruise Control . . . . . . . . . . . . 210
Add-On Electrical Equipment . . . . . . 253
Additional InformationOnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 372
Additional Maintenance and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . 346
Adjustable Throttle and Brake Pedal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183
Adjustments Lumbar, Front Seats . . . . . . . . . . . . . . . . 43
Air Cleaner/Filter, Engine . . . . . . . . . . 265
Air Conditioning . . . . . . . . . . . . . . .157, 162
Air Filter, Passenger Compartment . . . . . . . . . . . . . . . . . . . . . 164
Air Vents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Airbag System
Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
How Does an Airbag Restrain? . . . . . 71
Passenger Sensing System . . . . . . . . . 73
What Makes an Airbag Inflate? . . . . 71
What Will You See after anAirbag Inflates? . . . . . . . . . . . . . . . . . . . 72
When Should an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 Airbag System (cont'd)
Where Are the Airbags? . . . . . . . . . . . . 69
Airbags Adding Equipment to the
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Passenger Status Indicator . . . . . . . 120
Readiness Light . . . . . . . . . . . . . . . . . . . 120
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
System Check . . . . . . . . . . . . . . . . . . . . . . . 67
Alarm Vehicle Security . . . . . . . . . . . . . . . . . . . . . 28
Alert Lane Change . . . . . . . . . . . . . . . . . . . . . . 230
Side Blind Zone (SBZA) . . . . . . . . . . 230
All-Season Tires . . . . . . . . . . . . . . . . . . . . . 292
All-Terrain Tires . . . . . . . . . . . . . . . . . . . . 293
Antilock Brake System (ABS) . . . . . . 200 Warning Light . . . . . . . . . . . . . . . . . . . . 124
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 329
Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 333
Armrest Storage . . . . . . . . . . . . . . . . . . . . . 101
Ashtrays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Assistance Systems for Driving . . . . 225
Assistance Systems for Parking
and Backing . . . . . . . . . . . . . . . . . . . . . . . 219

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566588) - 2020 - CRC - 4/24/19
INDEX 381
AutomaticDoor Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Emergency Braking (AEB) . . . . . . . . 228
Headlamp System . . . . . . . . . . . . . . . . 151
Level Control . . . . . . . . . . . . . . . . . . . . . . 207
Transmission . . . . . . . . . . . . . . . . . . . . . . 191
Transmission Fluid . . . . . . . . . . . . . . . 264
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . . . . . 194
Shift Lock Control FunctionCheck . . . . . . . . . . . . . . . . . . . . . . . . . . . . 275
Axle, Front . . . . . . . . . . . . . . . . . . . . . . . . . . 275
Axle, Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . 275
B
Battery Exterior Lighting Battery
Saver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Load Management . . . . . . . . . . . . . . . . 155
Power Protection . . . . . . . . . . . . . . . . . . 155
Battery - North America . . . . . .273, 322
Blade Replacement, Wiper . . . . . . . . . 276
Brake
Parking, Electric . . . . . . . . . . . . . . . . . . 201
Pedal and Adjustable Throttle . . . 183
System Warning Light . . . . . . . . . . . . 123
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 271 Antilock . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 Brakes (cont'd)
Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
Parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
Braking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169 Automatic Emergency (AEB) . . . . . 228
Break-In, New Vehicle . . . . . . . . . . . . . . 183
Bulb Replacement Headlamp Aiming . . . . . . . . . . . . . . . . 279
Headlamps . . . . . . . . . . . . . . . . . . . . . . . . 279
License Plate Lamps . . . . . . . . . . . . . . 279
Buying New Tires . . . . . . . . . . . . . . . . . . . 306
C
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . 108
California Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . . . . . 257
California Proposition
65 Warning . . . . . . . . . . . . .256, 273, 322, Back Cover
Canadian Vehicle Owners . . . . . . . . . . . . . 2
Capacities and Specifications . . . . . . 353
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . . . . . 190
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Winter Driving . . . . . . . . . . . . . . . . . . . . 177 Cargo
Tie-Downs . . . . . . . . . . . . . . . . . . . . . . . . . 102
Caution, Danger, and Warning . . . . . . . . 2
Center Console Storage . . . . . . . . . . . . . 102
Chains, Tire . . . . . . . . . . . . . . . . . . . . . . . . . 310
Charging Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Charging System Light . . . . . . . . . . . . . 121
Check Engine Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . . . . . 121
Child Restraints Infants and Young Children . . . . . . . . 81
Lower Anchors and Tethers forChildren . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Older Children . . . . . . . . . . . . . . . . . . . . . . 79
Securing . . . . . . . . . . . . . . . . . . . . . . . . .94, 96
Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Child-View Mirror . . . . . . . . . . . . . . . . . . . . 36
Cigarette Lighter . . . . . . . . . . . . . . . . . . . . 113
Circuit Breakers . . . . . . . . . . . . . . . . . . . . . 280
Cleaning Exterior Care . . . . . . . . . . . . . . . . . . . . . . 329
Interior Care . . . . . . . . . . . . . . . . . . . . . . 333
Climate Control Systems
Dual Automatic . . . . . . . . . . . . . . . . . . . 157
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
13566588) - 2020 - CRC - 4/24/19
382 INDEX
Cluster, Instrument . . . . . . . . . . . . . . . . . 115
Collision Damage Repair . . . . . . . . . . . 363
CompartmentsStorage . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Compass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Connected Services Connections . . . . . . . . . . . . . . . . . . . . . . . 378
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . 379
Navigation . . . . . . . . . . . . . . . . . . . . . . . . . 377
Connections Connected Services . . . . . . . . . . . . . . . 378
Control Traction and ElectronicStability . . . . . . . . . . . . . . . . . . . . . . . . . . 203
Control of a Vehicle . . . . . . . . . . . . . . . . 168
Convenience Net . . . . . . . . . . . . . . . . . . . . 102
Convex Mirrors . . . . . . . . . . . . . . . . . . . . . . 32
Coolant Engine Temperature Gauge . . . . . . 118
Engine Temperature WarningLight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Cooling . . . . . . . . . . . . . . . . . . . . . . . . .157, 162
Cooling System . . . . . . . . . . . . . . . . . . . . . 266
Cornering Lamps . . . . . . . . . . . . . . . . . . . 153
Courtesy Transportation Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . 362
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . 207 Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129 Cruise Control, Adaptive . . . . . . . . . . . 210
Cupholders . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Customer Assistance . . . . . . . . . . . . . . . 358
Offices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 358
Text Telephone (TTY) Users . . . . . 358
Customer Information Publications Ordering
Information . . . . . . . . . . . . . . . . . . . . . . 365
Customer Satisfaction Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . 356
Cybersecurity . . . . . . . . . . . . . . . . . . . . . . . . 367
D
Damage Repair, Collision . . . . . . . . . . . 363
Danger, Warning, and Caution . . . . . . . . 2
Data Collection Infotainment System . . . . . . . . . . . . . 369
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 369
Data Recorders, Event . . . . . . . . . . . . . . 368
Daytime Running Lamps (DRL) . . . 150
Defensive Driving . . . . . . . . . . . . . . . . . . . 168
Delayed Locking . . . . . . . . . . . . . . . . . . . . . 19
Diagnostics Connected Services . . . . . . . . . . . . . . . 379
Distracted Driving . . . . . . . . . . . . . . . . . . 167
Dome Lamps . . . . . . . . . . . . . . . . . . . . . . . . 153
Door Ajar Light . . . . . . . . . . . . . . . . . . . . . . . . . 129 Door (cont'd)
Delayed Locking . . . . . . . . . . . . . . . . . . . . 19
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Power Locks . . . . . . . . . . . . . . . . . . . . . . . . . 19
Drive Belt Routing, Engine . . . . . . . . . 355
Driver Assistance Systems . . . . . . . . . 218
Driver Information Center (DIC) . . . . . . . . . . . . . . . . . . . . . . . 130
Driver Mode Control . . . . . . . . . . . . . . . . 205
Driving
Assistance Systems . . . . . . . . . . . . . . . 225
Better Fuel Economy . . . . . . . . . . . . . 167
Characteristics andTowing Tips . . . . . . . . . . . . . . . . . . . . . 237
Defensive . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Drunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Hill and Mountain Roads . . . . . . . . 176
If the Vehicle is Stuck . . . . . . . . . . . . 178
Loss of Control . . . . . . . . . . . . . . . . . . . . 170
Off-Road . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Off-Road Recovery . . . . . . . . . . . . . . . . 170
Vehicle Load Limits . . . . . . . . . . . . . . 178
Wet Roads . . . . . . . . . . . . . . . . . . . . . . . . . 175
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Winter Mode Light . . . . . . . . . . . . . . . 125
Dual Automatic Climate Control System . . . . . . . . . . . . . . . . . . . . 157
